3. Remove the lifting devise and the J 41427 . 4. Apply threadlock to the threads of the intake manifold lower bolts. 5. Install the intake manifold bolts. Refer to Sealers, Adhesives, and Lubricants for the correct part number. Tighten: 1. Tighten the bolts a first pass to 3 N.m (27 lb in). 2. Tighten the bolts a second pass to 12 N.m (106 lb in). 3. Tighten the bolts a final pass to 15 N.m (11 lb ft). 6. Install one transmission bolt until snug. 7. Remove the support jack from under the transmission. 8. Install the thermostat and water outlet. Refer to Engine Coolant Thermostat Replacement .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
|
