Chrysler Pacifica Touring (2005 year). Instruction - part 2





be used to open the liftgate. The emergency liftgate
latch release can be accessed through a snap-in cover
located on the liftgate trim panel.

• If the liftgate is locked and is not equipped with a

powered liftgate, pressing the button on the remote
keyless entry transmitter will result in the liftgate
becoming unlocked for 30 seconds allowing you to
instructionly access the liftgate area. The liftgate will
re-lock automatically within 10 seconds once the lift-
gate is closed.

Power Liftgate — If Equipped
The power liftgate may be opened instructionly or by using
the button on the remote keyless entry transmitter. Press
the button on the remote keyless entry transmitter twice
within five seconds, to open the power liftgate. Once the
liftgate is fully open, pressing the button twice within
five seconds a second time will close the liftgate.

The power liftgate may also be opened by pressing the
switch located on the overhead console.

A beeping signal will sound two seconds before the
liftgate starts to open or close.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

27

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING!

During power operation, personal injury or cargo
damage may occur. Ensure the liftgate travel path is
clear. Make sure the liftgate is closed and latched
before driving away.

NOTE:

• If anything obstructs the power liftgate while it is

closing or opening, the liftgate will automatically
reverse to the closed or open position, provided it
meets sufficient resistance.

• There are also pinch sensors attached to the side of the

liftgate. Light pressure anywhere along these strips
will cause the liftgate to return to the open position.

• The power liftgate must be in the full open position for

any of the close buttons to operate. If the liftgate is not
fully open, press the open button to fully open the
liftgate and then press close.

• If the liftgate release switch is activated while the

power liftgate is closing, the liftgate will reverse to the
full open position.

• The power liftgate switches will not operate if the

vehicle is in gear or the vehicle speed is above 0 mph
(0 km/h).

• The power liftgate will not operate in temperatures

below

⫺22° F (⫺30° C) or temperatures above 150° F

(65° C). Be sure to remove any build-up of snow or ice
from the liftgate before pressing any of the power
liftgate switches.

28

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

-------------------------------------------------------------------------------------------------------------------------------------------------------------

• If the power liftgate encounters multiple obstructions

within the same cycle, the system will automatically
stop and must be opened or closed instructionly.

WARNING!

• Driving with the liftgate open can allow poisonous

exhaust gases into your vehicle. You and your pas-
sengers could be injured by these fumes. Keep the
liftgate closed when you are operating the vehicle.

• If you are required to drive with the liftgate open,

make sure that all windows are closed, and the
climate control blower switch is set at high speed.
DO NOT use the recirculation mode.

Gas props support the liftgate in the open position.
However, because the gas pressure drops with tempera-
ture, it may be necessary to assist the props when
opening the liftgate in cold weather.

WINDOWS

Power Windows
The window controls on the driver’s door control all the
door windows.

There are single window controls on each passenger door
trim panel which operate the passenger door windows.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

29

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The window controls will operate only when the ignition
switch is in the ON or ACCESSORY position.

The window lock switch on the driver’s door allows you
to disable the window controls on the passenger doors.
When the lock switch is pressed the window controls on
the passenger doors will not illuminate and the passen-
ger windows will be disabled.

Auto Down Feature
All the power window switches have an auto down
feature. Press the window switch to the second detent,
release, and the window will go down automatically.

To open the window part way, press the window switch
to the first detent and release it when you want the
window to stop.

The power window switches remain active for up to 45
seconds after the ignition switch has been turned off.
Opening either front door will cancel this feature.

Wind Buffeting
Wind buffeting can be described as the perception of
pressure on the ears or a helicopter type sound in the
ears. Your vehicle may exhibit wind buffeting with the
windows down, or the sunroof (if equipped) in certain
open or partially open positions. This is a normal occur-
rence and can be minimized. If the buffeting occurs with
the rear windows open, open the front and rear windows
together to minimize the buffeting. If the buffeting occurs
with the sunroof open, adjust the sunroof opening to
minimize the buffeting.

OCCUPANT RESTRAINTS
Some of the most important safety features in your vehicle
are the restraint systems. These include the front and rear
seat belts for the driver and all passengers, front airbags for
both the driver and front passenger, driver inflatable knee
blocker and if equipped, left and right side curtain airbags
for the driver and passengers seated next to a window. If
you will be carrying children too small for adult-size seat

30

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

-------------------------------------------------------------------------------------------------------------------------------------------------------------

belts, your seat belts or the LATCH feature (refer to the
Child Restraint section in this instruction), can be used to hold
infant and child restraint systems.

NOTE:

The front airbags have a multi stage inflator

design. This allows the airbag to have different rates of
inflation that are based on collision severity.

Please pay close attention to the information in this section.
It tells you how to use your restraint system properly to
keep you and your passengers as safe as possible.

WARNING!

In a collision, you and your passengers can suffer
much greater injuries if you are not properly buck-
led up. You can strike the interior of your vehicle or
other passengers, or you can be thrown out of the
vehicle. Always be sure you and others in your
vehicle are buckled up properly.

Buckle up even though you are an excellent driver, even
on short trips. Someone on the road may be a poor driver
and cause a collision that includes you. This can happen
far away from home or on your own street.

Research has shown that seat belts save lives, and they
can reduce the seriousness of injuries in a collision. Some
of the worst injuries happen when people are thrown
from the vehicle. Seat belts reduce the possibility of
ejection and the risk of injury caused by striking the
inside of the vehicle. Everyone in a motor vehicle should
be belted at all times.

Lap/Shoulder Belts
All the seats in your vehicle are equipped with Lap/
Shoulder Belts.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

31

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The belt webbing retractor is designed to lock during
very sudden stops or collisions. This feature allows the
shoulder part of the belt to move freely with you under
normal conditions. But in a collision, the belt will lock
and reduce the risk of your striking the inside of the
vehicle or being thrown out.

WARNING!

• It is extremely dangerous to ride in a cargo area,

inside or outside of a vehicle. In a collision,
people riding in these areas are more likely to be
seriously injured or killed.

• Do not allow people to ride in any area of your

vehicle that is not equipped with seats and seat belts.

• Be sure everyone in your vehicle is in a seat and

using a seat belt properly.

WARNING!

• Wearing a seat belt incorrectly is dangerous. Seat

belts are designed to go around the large bones of
your body. These are the strongest parts of your
body and can take the forces of a collision the best.

• Wearing your belt in the wrong place could make

your injuries in a collision much worse. You
might suffer internal injuries, or you could even
slide out of part of the belt. Follow these instruc-
tions to wear your seat belt safely and to keep
your passengers safe, too.

• Two people should never be belted into a single

seat belt. People belted together can crash into one
another in a collision, hurting one another badly.
Never use a lap/shoulder belt or lap belt for more
than one person, no matter what their size.

32

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Lap/Shoulder Belt Operating Instructions

1. Enter the vehicle and close the door. Sit back and
adjust the seat.

2. The seat belt latch plate is near the seatback of the
front seats and next to your arm in the rear seats. Grasp
the latch plate and pull out the belt. Slide the latch plate
up the webbing as far as necessary to allow the belt to go
around your lap.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

33

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3. When the belt is long enough to fit, insert the latch
plate into the buckle until you hear a “click”.

WARNING!

• A belt that is buckled into the wrong buckle will not

protect you properly. The lap portion could ride too
high on your body, possibly causing internal injuries.
Always buckle your belt into the buckle nearest you.
• A belt that is too loose will not protect you as well.

In a sudden stop you could move too far forward,
increasing the possibility of injury. Wear your seat belt
snugly.
• A belt that is worn under your arm is very danger-

ous. Your body could strike the inside surfaces of the
vehicle in a collision, increasing head and neck injury.
A belt worn under the arm can cause internal injuries.
Ribs aren’t as strong as shoulder bones. Wear the belt
over your shoulder so that your strongest bones will
take the force in a collision.
• A shoulder belt placed behind you will not protect

you from injury during a collision. You are more likely
to hit your head in a collision if you do not wear your
shoulder belt. The lap and shoulder belt are meant to
be used together.

34

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

-------------------------------------------------------------------------------------------------------------------------------------------------------------

4. Position the lap belt across your thighs, below your
abdomen. To remove slack in the lap belt portion, pull up
on the shoulder belt. To loosen the lap belt if it is too tight,
tilt the latch plate and pull on the lap belt. A snug belt
reduces the risk of sliding under the belt in a collision.

WARNING!

• A lap belt worn too high can increase the risk of
internal injury in a collision. The belt forces won’t
be at the strong hip and pelvic bones, but across your
abdomen. Always wear the lap belt as low as pos-
sible and keep it snug.
• A twisted belt can’t do its job as well. In a collision
it could even cut into you. Be sure the belt is straight.
If you can’t straighten a belt in your vehicle, take it
to your dealer and have it fixed.

5. Position the shoulder belt on your chest so that it is
comfortable and not resting on your neck. The retractor
will withdraw any slack in the belt.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

35

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

6. To release the belt, push the red button on the buckle.
The belt will automatically retract to its stowed position.
If necessary, slide the latch plate down the webbing to
allow the belt to retract fully.

WARNING!

A frayed or torn belt could rip apart in a collision
and leave you with no protection. Inspect the belt
system periodically, checking for cuts, frays, or loose
parts. Damaged parts must be replaced immediately.
Do not disassemble or modify the system. Seat belt
assemblies must be replaced after a collision if they
have been damaged (bent retractor, torn webbing,
etc.).

Adjustable Upper Shoulder Belt Anchorage
In the front seats, the shoulder belt anchorage can be
adjusted upward or downward to help position the belt
away from your neck. Press the button to release the
anchorage, and then move it up or down to the position
that serves you best.

36

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

-------------------------------------------------------------------------------------------------------------------------------------------------------------

As a guide, if you are shorter than average, you will
prefer a lower position, and if you are taller than average,
you’ll prefer a higher position. When you release the
anchorage, try to move it up or down to make sure that
it is locked in position.

Lap/Shoulder Belt Untwisting Procedure
Use the following procedure to untwist a twisted lap/
shoulder belt.

1. Position the latch plate as close as possible to the
anchor point.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

37

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2. At about 6 to 12 inches (15 to 30 cm) above the latch
plate, grasp and twist the belt webbing 180° to create a
fold that begins immediately above the latch plate.

3. Slide the latch plate upward over the folded webbing.
The folded webbing must enter the slot at the top of the
latch plate.

4. Continue to slide the latch plate up until it clears the
folded webbing.

38

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Seat Belt Pretensioners
The seat belts for both front seating positions are
equipped with pretensioning devices that are designed to
remove slack from the seat belt in the event of a collision.
These devices improve the performance of the seat belt
by assuring that the belt is tight about the occupant early
in a collision. Pretensioners are designed to work for all
size occupants.

NOTE:

These devices are not a substitute for proper seat

belt placement by the occupant. The seat belt still must be
worn snugly and positioned properly.

The pretensioners are triggered by the front airbag con-
trol module (see Airbag Section). Like the front airbags,
the pretensioners are single use items. After a collision
that is severe enough to deploy the airbags and preten-
sioners, both must be replaced.

Enhanced Driver Seat Belt Reminder System
(BeltAlert)
If the driver’s seat belt has not been buckled within 60
seconds of starting the vehicle and if the vehicle speed is
greater than 5 mph (8 km/h), the Enhanced Warning
System (BeltAlert) will alert the driver to buckle their seat
belt. The driver should also instruct all other occupants to
buckle their seat belts. Once the warning is triggered, the
Enhanced Warning System (BeltAlert) will continue to
chime and flash the Seat Belt Warning Light for 96
seconds or until the driver’s seat belt is buckled.

The Enhanced Warning System (BeltAlert) will be reacti-
vated if the driver’s seat belt is unbuckled for more than
10 seconds and the vehicle speed is greater than 5 mph (8
km/h).

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

39

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The Enhanced Warning System (BeltAlert) can be en-
abled or disabled by your authorized dealer or by
following these steps:

NOTE:

The following steps must occur within the first

60 seconds of the ignition switch being turned to the ON
or RUN position. DaimlerChrysler does not recommend
deactivating the Enhanced Warning System (BeltAlert).

1. Turn the ignition switch to the OFF position and
buckle the driver’s seat belt.

2. Turn the ignition key to the RUN position (engine
does not need to be running), and wait for the Seat Belt
Warning Light to turn off.

3. Within 60 seconds of starting the vehicle, unbuckle
and then re-buckle the driver’s seat belt at least three
times within 10 seconds, ending with the seat belt
buckled.

NOTE:

Watch for the Seat Belt Warning Light to turn on

while unbuckling and off while re-buckling the seat belt.
It may be necessary to retract the seat belt.

4. Turn off the engine. A single chime will sound to
signify that you have successfully completed the pro-
gramming.

The Enhanced Warning System (BeltAlert) can be reacti-
vated by repeating this procedure.

NOTE:

Although the Enhanced Warning System (BeltA-

lert) has been deactivated, the Seat Belt Warning Light
will continue to illuminate while the driver’s seat belt
remains unbuckled.

40

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Seat Belts and Pregnant Women
We recommend that pregnant women use the seat belts
throughout their pregnancies. Keeping the mother safe is
the best way to keep the baby safe.

Pregnant women should wear the lap part of the belt
across the thighs and as snug across the hips as possible.
Keep the belt low so that it does not come across the
abdomen. That way the strong bones of the hips will take
the force if there is a collision.

Seat Belt Extender
If a seat belt is too short, even when fully extended and
when the adjustable upper shoulder belt anchorage (if
equipped) is in its lowest position, your dealer can
provide you with a seat belt extender. This extender
should be used only if the existing belt is not long
enough. When it is not required, remove the extender
and stow it.

WARNING!

Using a seat belt extender when not needed can
increase the risk of injury in a collision. Only use
when the lap belt is not long enough when it is worn
low and snug, and in the recommended seating
positions. Remove and store the extender when not
needed.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

41

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driver and Front Passenger Supplemental
Restraint System - Airbag
This vehicle has airbags for both the driver and front
passenger as a supplement to the seat belt restraint systems.
The driver’s front airbag is mounted in the center of the
steering wheel. The passenger’s front airbag is mounted in
the instrument panel, above the glove compartment. The
words SRS AIRBAG are embossed on the airbag covers.

NOTE:

The front airbags are certified to the Federal

regulations that allow less forceful deployment in low
speed collisions.

The front airbags have a multi stage inflator design. This
allows the airbag to have different rates of inflation that
are based on collision severity.

This vehicle may also be equipped with a driver inflat-
able knee blocker located on the instrument panel below
the steering column.

This vehicle may also be equipped with left and right
side curtain airbags to protect the driver and passengers
sitting next to a window. If the vehicle is equipped with
side curtain airbags, they are located above the side
windows. Their covers are also labeled SRS AIRBAG.

42

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..      1      2      3      ..
