Acura RDX (2019 year). Instruction - part 6





85

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Vehicle Stability
Assist® (VSA®)
System
Indicator

Blinks when VSA®, or trailer stability
assist is active.

Comes on if there is a problem with
the brake assist system, VSA®
system or hill start assist system.

Stays on constantly - Have your vehicle
checked by a dealer.

Vehicle Stability Assist® (VSA®), aka

Electronic Stability Control (ESC),
System
 P. 434

Vehicle Stability
Assist® (VSA®)
OFF Indicator

Comes on when you partially
disable VSA®.

VSA® On and Off P. 435

19 ACURA RDX-31TJB6000.book  85 ページ  2018年4月26日 木曜日 午後4時51分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

86

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Low Tire
Pressure/TPMS
Indicator

Comes on if the tire pressure of any
of the tires becomes significantly
low.

Blinks for about one minute, and
then stays on if there is a problem
with the TPMS, or when a compact
spare tire

*

 is temporarily installed.

Comes on while driving - Stop in a safe
place, check tire pressures, and inflate the
tire(s) if necessary.

Blinks and remains on - Have your
vehicle checked by a dealer. If the vehicle
is fitted with a compact spare tire, get your
regular tire repaired or replaced and put
back on your vehicle as soon as you can.

* Not available on all models

19 ACURA RDX-31TJB6000.book  86 ページ  2018年4月26日 木曜日 午後4時51分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

87

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Turn Signal and
Hazard
Warning
Indicators

• Blinks when you operate the turn

signal lever.

• Blink along with all turn signals

when you press the hazard warning
button.

• Does not blink or blinks rapidly

Replacing Light Bulbs P. 545

High Beam
Indicator

• Comes on when the high beam

headlights are on.

Lights On
Indicator

• Comes on when the light switch in

a position other than OFF or when
the switch is set to AUTO and the
exterior lights come on.

• If you set the power mode to VEHICLE OFF

while the lights are on, a chime sounds
when the driver’s door is opened.

Fog Light
Indicator

*

• Comes on when the fog lights are

on.

Auto High-
Beam Indicator

• Comes on when all the operating

conditions of the auto high-beam
are met.

Auto High-Beam P. 191

* Not available on all models

19 ACURA RDX-31TJB6000.book  87 ページ  2018年4月26日 木曜日 午後4時51分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

88

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Canadian models only: Apply and hold the brake pedal before selecting the ON mode.

Indicator

Name

On/Blinking

Explanation

Message

*1

Immobilizer
System
Indicator

• Comes on briefly when you set the

power mode to ON, then goes off.

• Blinks if the immobilizer system

cannot recognize the key
information.

• Blinks - You cannot start the engine. Set

the power mode to VEHICLE OFF

*1

, then

select the ON mode again.

• Repeatedly blinks - The system may be

malfunctioning. Have your vehicle
checked by a dealer.

• Do not attempt to alter this system or add

other devices to it. Electrical problems can
occur.

Security System
Alarm Indicator

• Comes on briefly when you set the

power mode to ON, then goes off.

• Blinks when the security system

alarm has been set.

Security System Alarm P. 173

Indicator

Indicator

19 ACURA RDX-31TJB6000.book  88 ページ  2018年4月26日 木曜日 午後4時51分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

89

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

System
Message
Indicator

• Comes on along with a beep when

a problem is detected. A system
message on the multi-information
display appears at the same time.

• While the indicator is on, roll the right

selector wheel to see the message again.

Switching the Display P. 129

• Refer to the Indicators information in this

chapter when a system message appears
on the multi-information display. Take the
appropriate action for the message.

• The multi-information display does not

return to the normal screen unless the
warning is canceled, or the right selector
wheel is pressed.

19 ACURA RDX-31TJB6000.book  89 ページ  2018年4月26日 木曜日 午後4時51分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

90

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Super
Handling-All
Wheel Drive

TM



(SH-AWD®)
Indicator

*

Comes on if there is a problem with
the SH-AWD® system.

Blinks when the differential
temperature is too high.

Stays on constantly - The engine drives
the front wheels only in this state. Have
your vehicle checked by a dealer.

Blinks while driving - Stop in a safe
place, put the transmission into

(

P, and

idle the engine until the indicator goes off.
If the indicator does not stop blinking,
take your vehicle to a dealer.

Super Handling-All Wheel Drive

TM



(SH-AWD®)

*

 P. 437

Maintenance
Minder
Indicator

Comes on when the scheduled
maintenance is due soon.

Consequently, Maintenance Due
Now
 and Maintenance Past Due
follow.

Maintenance Minder

TM

 P. 525

* Not available on all models

19 ACURA RDX-31TJB6000.book  90 ページ  2018年4月26日 木曜日 午後4時51分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

91

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Adaptive
Cruise Control
(ACC) with Low
Speed Follow
(LSF) Indicator
(Amber)

Comes on if there is a problem with
ACC with LSF.

Stays on constantly - Have your vehicle
checked by a dealer.

Indicator may come on temporarily
when the Maximum Load Limit is
exceeded.

ACC with LSF has been
automatically canceled.

Make sure the total load is within the
Maximum Load Limit.

Maximum Load Limit P. 401

Stays on constantly - Have your vehicle
checked by a dealer.

Adaptive
Cruise Control
(ACC) with Low
Speed Follow
(LSF) Indicator
(Green)

Comes on when you press the
MAIN button.

Adaptive Cruise Control (ACC) with

Low Speed Follow (LSF) P. 455

Lane Keeping
Assist System
(LKAS
Indicator
(Amber)

Comes on if there is a problem with
the LKAS.

Stays on constantly - Have your vehicle
checked by a dealer.

Lane Keeping
Assist System
(LKAS
Indicator
(Green)

Comes on when you press the
MAIN button.

Lane Keeping Assist System (LKAS)

P. 471

19 ACURA RDX-31TJB6000.book  91 ページ  2018年4月26日 木曜日 午後4時51分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

92

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Road
Departure
Mitigation
(RDM) Indicator

Comes on if there is a problem with
RDM.

Stays on constantly - Have your vehicle
checked by a dealer.

Indicator may come on temporarily
when the Maximum Load Limit is
exceeded.

Make sure the total load is within the
Maximum Load Limit.

Maximum Load Limit P. 401

Stays on constantly - Have your vehicle
checked by a dealer.

Comes on when RDM shuts itself
off.

Indicator may come on temporarily when
passing through an enclosed space, such
as tunnel.

The area around the radar sensor is
blocked by dirt, mud, etc. Stop your
vehicle in a safe place and wipe the debris
off with a soft cloth.

Have your vehicle checked by a dealer if
the indicator does not go off even after
you have cleaned the radar sensor.

Radar Sensor P. 485

Stays on - The temperature inside the
camera is too high.
Use the climate control system to cool
down the camera.
The system activates when the
temperature inside the camera cools
down.

Front Sensor Camera P. 483

19 ACURA RDX-31TJB6000.book  92 ページ  2018年4月26日 木曜日 午後4時51分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

93

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Road
Departure
Mitigation
(RDM) Indicator

Comes on when RDM shuts itself
off.

Stays on - The area around the camera is
blocked by dirt, mud, etc. Stop your
vehicle in a safe place and wipe the debris
off with a soft cloth.

Have your vehicle checked by a dealer if
the indicator and message are still
displayed even after you have cleaned the
area around the camera.

Front Sensor Camera P. 483

Collision
Mitigation
Braking
System

TM



(CMBS

TM

Indicator

Comes on when you deactivate the
CMBS

TM

. A multi-information

display message appears for five
seconds.

Comes on if there is a problem with
CMBS

TM

.

Stays on constantly without the
CMBS

TM

 OFF - Have your vehicle checked

by a dealer.

Indicator may come on temporarily
when the Maximum Load Limit is
exceeded.

Make sure the total load is within the
Maximum Load Limit.

Maximum Load Limit P. 401

Stays on constantly - Have your vehicle
checked by a dealer.

19 ACURA RDX-31TJB6000.book  93 ページ  2018年4月26日 木曜日 午後4時51分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

94

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Collision
Mitigation
Braking
System

TM



(CMBS

TM

Indicator

Comes on when CMBS

TM

 shuts itself

off.

Indicator may come on temporarily when
passing through an enclosed space, such
as tunnel.

The area around the radar sensor is
blocked by dirt, mud, etc. Stop your
vehicle in a safe place and wipe the debris
off with a soft cloth.

Have your vehicle checked by a dealer if
the indicator does not go off even after
you have cleaned the radar sensor.

Radar Sensor P. 485

Stays on - The temperature inside the
camera is too high.
Use the climate control system to cool
down the camera.
The system activates when the
temperature inside the camera cools
down.

Front Sensor Camera P. 483

19 ACURA RDX-31TJB6000.book  94 ページ  2018年4月26日 木曜日 午後4時51分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

95

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Collision
Mitigation
Braking
System

TM



(CMBS

TM

Indicator

Comes on when CMBS

TM

 shuts itself

off.

Stays on - The area around the camera is
blocked by dirt, mud, etc. Stop your
vehicle in a safe place and wipe the debris
off with a soft cloth.

Have your vehicle checked by a dealer if
the indicator and message are still
displayed even after you have cleaned the
area around the camera.

Front Sensor Camera P. 483

Blind spot
information
System
Indicator

*

Stays on while BSI is turned off.

Customized Features P. 332

* Not available on all models

19 ACURA RDX-31TJB6000.book  95 ページ  2018年4月26日 木曜日 午後4時51分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

96

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Blind spot
information
System
Indicator

*

Comes on when mud, snow, or ice
accumulates in the vicinity of
sensor.

Comes on while driving - Remove the
obstacle in the vicinity of sensor.

Blind spot information System

*



P. 438

Comes on if there is a problem with
the system.

Comes on while driving - Have your
vehicle checked by a dealer.

U.S.

Canada

U.S.

Canada

* Not available on all models

19 ACURA RDX-31TJB6000.book  96 ページ  2018年4月26日 木曜日 午後4時51分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

97

uu

Indicators

u

Multi-Information Display Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Multi-Information Display Warning and Information Messages

The following messages appear only on the multi-information display. Roll the right selector wheel to see the message again with the
system message indicator on.

2 Switching the Display P. 129

Message

Condition

Explanation

Appears when the vehicle is no longer able to run
due to a malfunction.

Immediately stop in a safe place.

Appears when there is a risk that the vehicle will
move unexpectedly after you have stopped due to a
malfunction with the vehicle.

While the vehicle is stopped, apply the parking brake.

Have your vehicle checked by a dealer.

Appears when you set the power mode to ON again
and the vehicle is able to run.

Starting the Engine P. 411

Appears when the engine stops without the
transmission in

(

P, and does not restart

automatically.

Appears if you open the bonnet while Auto Idle Stop
activates.

If you want to set the power mode to ON, put the
transmission into

(

P.

If you want to start the engine, follow the normal
procedure.

Starting the Engine P. 411

19 ACURA RDX-31TJB6000.book  97 ページ  2018年4月26日 木曜日 午後4時51分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

98

uu

Indicators

u

Multi-Information Display Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears when the washer fluid is low.

Refill the washer fluid.

Refilling Window Washer Fluid P. 544

• Appears if there is a problem with the cooling

system.

• Drive slowly to prevent overheating and have your

vehicle checked by a dealer as soon as possible.

Canadian models

19 ACURA RDX-31TJB6000.book  98 ページ  2018年4月26日 木曜日 午後4時51分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

99

uu

Indicators

u

Multi-Information Display Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears when the starter system has a problem.

As a temporary measure, press and hold the ENGINE
START/STOP
 button for up to 15 seconds while
pressing the brake pedal, manually start the engine.
Have your vehicle checked by a dealer.

U.S.

Canada

19 ACURA RDX-31TJB6000.book  99 ページ  2018年4月26日 木曜日 午後4時51分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

100

uu

Indicators

u

Multi-Information Display Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears when the engine oil pressure is low.

• Appears while driving - Immediately stop in a safe

place.

If the Low Oil Pressure Warning Appears P. 608

Appears when the engine coolant temperature gets
abnormally high.

Overheating P. 606

19 ACURA RDX-31TJB6000.book  100 ページ  2018年4月26日 木曜日 午後4時51分

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     4      5      6      7     ..
