Acura RLX (2018 year). Instruction - part 22





345

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

To delete a voice tag

1. Press the SETTINGS button.
2. Rotate

 to select Phone Settings, then

press .

3. Move

or

to

select

the

Phone tab.

4. Rotate

 to select Edit Speed Dial, then

press .

5. Select an existing speed dial entry.

u

From the pop-up menu, rotate

 to

select Edit, then press

.

6. Rotate

 to select Voice Tag, then press

.

u

From the pop-up menu, rotate

 to

select Clear, then press

.

7. You will receive a confirmation message on

the screen. Rotate

 to select Yes, then

press .

To delete a speed dial

1. Press the SETTINGS button.
2. Rotate

 to select Phone Settings, then

press .

3. Move

or

to

select

the

Phone tab.

4. Rotate

 to select Edit Speed Dial, then

press .

5. Select an existing speed dial entry.

u

From the pop-up menu, rotate

 to

select Delete, then press

.

6. You will receive a confirmation message on

the screen. Rotate

 to select Yes, then

press .

18 ACURA RLX E-AWD-31TY36400.book  345 ページ  2017年7月20日 木曜日 午後6時8分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

346

Features

Add phonetic modifications or a new voice tag to the phone’s contact name so that
it is easier for HFL to recognize voice commands.

To add a new voice tag

1. Press the SETTINGS button.
2. Rotate

 to select System Settings, then

press .

3. Move

 or

 to select the Voice Reco

tab.

4. Rotate

 to select Phonebook Phonetic

Modification, then press

.

5. Rotate

 to select the phone you want to

add phonetic modification to, then press

.

Phonebook Phonetic Modification

1

Phonebook Phonetic Modification

You can store up to 20 phonetic modification items.

18 ACURA RLX E-AWD-31TY36400.book  346 ページ  2017年7月20日 木曜日 午後6時8分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

347

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

6. Rotate

 to select New Voice Tag, then

press .

7. Move

 or

 and rotate

 to select a

contact name, then press

.

u

The pop-up menu appears on the screen.

8. Rotate

 to select Modify, then press

.

9. Using the

 button, follow the prompts to

complete the voice tag.

10.You will receive a confirmation message

on the screen. Rotate

 to select OK, then

press .

18 ACURA RLX E-AWD-31TY36400.book  347 ページ  2017年7月20日 木曜日 午後6時8分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

348

Features

To modify a voice tag

1. Press the SETTINGS button.
2. Rotate

 to select System Settings, then

press .

3. Move

 or

 to select the Voice Reco

tab.

4. Rotate

 to select Phonebook Phonetic

Modification, then press

.

5. Rotate

 to select the phone you want to

add phonetic modification to, then press

.

6. Rotate

 to select a contact name you

want to modify, then press

.

u

The pop-up menu appears on the screen.

7. Rotate

 to select Modify, then press

.

8. Using the

 button, follow the prompts to

complete the voice tag.

9. You will receive a confirmation message on

the screen. Rotate

 to select OK, then

press .

1

Phonebook Phonetic Modification

You can only modify or delete contact names for the
currently connected phone.

18 ACURA RLX E-AWD-31TY36400.book  348 ページ  2017年7月20日 木曜日 午後6時8分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

349

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

To delete a modified voice tag

1. Press the SETTINGS button.
2. Rotate

 to select System Settings, then

press .

3. Move

or

to

select

the

Voice Reco

tab.

4. Rotate

 to select Phonebook Phonetic

Modification, then press

.

5. Rotate

 to select the phone you want to

delete phonetic modification, then press

.

6. Rotate

 to select a contact name you

want to delete, then press

.

u

The pop-up menu appears on the screen.

7. Rotate

 to select Delete, then press

.

8. Move   and rotate

 to select OK, then

press .

18 ACURA RLX E-AWD-31TY36400.book  349 ページ  2017年7月20日 木曜日 午後6時8分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

350

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

To delete all modified voice tags

1. Press the SETTINGS button.
2. Rotate

 to select System Settings, then

press .

3. Move

 or

 to select the Voice Reco

tab.

4. Rotate

 to select Phonebook Phonetic

Modification, then press

.

5. Rotate

 to select the phone you want to

delete phonetic modification, then press

.

u

The contact name list appears.

6. Move   and rotate

 to select Delete All

then press

.

7. You will receive a confirmation message on

the screen. Rotate

 to select Yes, then

press .

18 ACURA RLX E-AWD-31TY36400.book  350 ページ  2017年7月20日 木曜日 午後6時8分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

351

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

You can make calls by inputting any phone
number, or by using the imported
phonebook, call history, speed dial entries, or
redial.

Making a Call

1

Making a Call

Any voice-tagged speed dial entry, phonebook name,
or number can be dialed by voice from most screens.

Press the

 button and say “Call” and the voice tag

name, “Call by name” and the phonebook name, or
“Call” and the phone number.

The maximum range between your phone and
vehicles is 30 feet (10 meters).

Once a call is connected, you can hear the voice of
the person you are calling through the audio
speakers.

18 ACURA RLX E-AWD-31TY36400.book  351 ページ  2017年7月20日 木曜日 午後6時8分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

352

Features

To make a call using the imported
phonebook

1. Press the PHONE button.
2. Press the MENU button.
3. Rotate

 to select Phonebook, then

press .

4. The phonebook is stored alphabetically.

Move

to

Search.

u

You can use the keyboard on the touch
screen for an alphabetical search.

5. Rotate

 to select a number, then press

.

u

Dialing starts automatically.

1

To make a call using the imported phonebook

This function is disabled while the vehicle is moving.
However, you can call a stored voice-tagged speed
dial number, phonebook name, or number using
voice commands.

Limitations for Instruction Operation P. 327
Speed Dial P. 343

You can use the keyboard on the On Demand Multi-
Use Display

TM

 for an alphabetical search.

18 ACURA RLX E-AWD-31TY36400.book  352 ページ  2017年7月20日 木曜日 午後6時8分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

353

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

To make a call using a phone number

1. Press the PHONE button.
2. Press the MENU button.
3. Rotate

 to select Dial, then press

.

4. Rotate

 to select a number, then press

.

5. Rotate

 to select

, then press

.

u

Dialing starts automatically.

To make a call using redial

1. Press the PHONE button.
2. Press the MENU button.
3. Rotate

 to select Redial, then press

.

u

Dialing starts automatically.

1

To make a call using a phone number

You can use the keyboard on the On Demand Multi-
Use Display

TM

 to input numbers.

Select numbers, then

 to start dialing.

18 ACURA RLX E-AWD-31TY36400.book  353 ページ  2017年7月20日 木曜日 午後6時8分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

354

Features

To make a call using the call history

Call history is stored by AllDialed
Received, and Missed.
1. Press the PHONE button.
2. Press the MENU button.
3. Rotate

 to select Call History, then

press .

4. Move

or

to

select

AllDialed

Received, and Missed.

5. Rotate

 to select a number, then press

.

u

Dialing starts automatically.

1. Press the

 button.

2. Move the left selector wheel right to select

Call History.

3. Roll the left selector wheel to select a

number.

4. Push the left selector wheel or the



button.

u

Dialing starts automatically.

1

To make a call using the call history

The call history displays the last 20 dialed, received, or
missed calls.
(Appears only when a phone is connected to HFL.)

These icons next to the number indicate the
following:

: Dialed calls.
: Received calls.
: Missed calls.

The call history displays the last 12 dialed, received, or
missed calls.

Steering switches

111AAA####

Mr.AAA

Mr.BBB

Multi-information display

Head-up display

Steering switches

18 ACURA RLX E-AWD-31TY36400.book  354 ページ  2017年7月20日 木曜日 午後6時8分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

355

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

To make a call using a speed dial entry

1. Press the PHONE button.
2. Press the MENU button.
3. Rotate

to

select

Speed Dial, then press

.

4. Rotate

 to select a number, then press

.

u

Dialing starts automatically.

1. Press the

 button.

2. Move the left selector wheel left to select

Speed Dial.

3. Roll the left selector wheel to select a

number.

4. Push the left selector wheel or the



button.

u

Dialing starts automatically.

1

To make a call using a speed dial entry

Move   to select More Speed Dials to view another
paired phone’s speed dial list. You can make a call
from that list using the currently connected phone.

When a voice tag is stored, press the

 button to

call the number using the voice tag.

Speed Dial P. 343

Any voice-tagged speed dial entry, phonebook name
or number can be dialed by voice from any screen.
Press the

 button and follow the prompts.

The speed dial displays the 20 speed dial entries.

Steering switches

111AAA####

Mr.AAA

Mr.BBB

Multi-information display

Head-up display

Steering switches

18 ACURA RLX E-AWD-31TY36400.book  355 ページ  2017年7月20日 木曜日 午後6時8分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

356

Features

When there is an incoming call, an audible
notification sounds (if activated) and the
Incoming call screen appears.

Press the

 button to answer the call.

Press the

 button to decline or end the

call.

Receiving a Call

1

Receiving a Call

Call Waiting

Press the

 button to put the current call on hold to

answer the incoming call.

Press the

 button again to return to the current

call.
Ignore the incoming call if you do not want to answer
it.
Press the

 button if you want to hang up the

current call.

You can select the icons on the On Demand Multi-
Use Display

TM

 instead of the

 and

 buttons.

18 ACURA RLX E-AWD-31TY36400.book  356 ページ  2017年7月20日 木曜日 午後6時8分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

357

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

The following options are available during a call.
Mute: Mute your voice.
Transfer: Transfer a call from HFL to your phone.
Touch Tones: Send numbers during a call. This is useful when you call a menu-
driven phone system.

The available options are shown on the Phone
screen.
Rotate

 to select the option, then press

.

u

The mute icon appears when Mute is
selected. Select Mute again to turn it off.

Options During a Call

1

Options During a Call

Touch Tones: Available on some phones.

You can select the icons on the On Demand Multi-
Use Display

TM

.

0123456789####

01’23

John

10

Mute Icon

18 ACURA RLX E-AWD-31TY36400.book  357 ページ  2017年7月20日 木曜日 午後6時8分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

358

Features

HFL can display newly received text/e-mail messages as well as 20 of the most
recently received messages on a linked cell phone. Each received message can be
read aloud and replied to using a fixed common phrase.

1. A pop-up appears and notifies you of a new

text/e-mail message.

2. Rotate

 to select Read to check the

message, then press

.

u

The text/e-mail message is displayed.

Receiving a Text/E-mail Message

1

Receiving a Text/E-mail Message

The system does not display any received messages
while you are driving. You can only hear them read
aloud.

With some phones, you may be able to display up to
20 most recent text/e-mail messages.

State or local laws may limit your use of the HFL text/
e-mail message feature. Only use the text/e-mail
message feature when conditions allow you to do so
safely.

When you receive a text/e-mail message for the first
time since the phone is paired to HFL, you are asked
to turn the New Text/Email Alert setting to On.

To turn on or off the text/e-mail message

notice P. 337

18 ACURA RLX E-AWD-31TY36400.book  358 ページ  2017年7月20日 木曜日 午後6時8分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

359

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

If a paired phone has text message or mail accounts, you can select one of them to
be active and receive notifications.

1. Press the SETTINGS button.
2. Rotate

 to select Phone Settings, then

press .

3. Move

or

to

select

the

Text/Email

tab.

4. Rotate

 to select Select Account, then

press .

5. Rotate

 to select Text Messages or an

e-mail account you want, then press

.

Selecting a Mail Account

1

Selecting a Mail Account

You can also select a mail account from the folder list
screen or the message list screen.
Move   to select Select Account, then press

.

You can only receive notifications from one text
message or mail account at a time.

18 ACURA RLX E-AWD-31TY36400.book  359 ページ  2017年7月20日 木曜日 午後6時8分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

360

Features

Displaying text messages

1. Press the PHONE button.
2. Press the MENU button.
3. Rotate

 to select Text/Email, then press

.

u

Select account if necessary.

4. Rotate

 to select a message, then press

.

u

The text message is displayed.

Displaying Messages

1

Displaying Messages

The

 icon appears next to an unread message.

If you delete a message on the phone, the message is
also deleted in the system. If you send a message
from the system, the message goes to your phone’s
outbox.

To see the previous or next message, move

 or



on the text message screen.

Message List

Text Message

18 ACURA RLX E-AWD-31TY36400.book  360 ページ  2017年7月20日 木曜日 午後6時8分

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     20      21      22      23     ..
