Acura MDX (2018 year). Instruction - part 18





278

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Features

Editing a playlist

1. Select Audio Menu.
2. Select Edit/Delete HDD Music.
3. Select Playlists.
4. Select a playlist that you want to edit or

delete.

5. To edit a playlist name:

Select Edit Name, then select Playlist
Name
.

u

Enter the playlist name using the
keyboard, then select OK.

To delete a playlist:
Select Delete, then select Yes.

To edit track information or delete a track:
Select List Tracks.

Editing Track Information P. 280

6. Select Done.

18 ACURA MDX-31TZ56400.book  278 ページ  2017年8月23日 水曜日 午後4時1分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

279

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Continued

Features

Creating a new playlist

1. Select Audio Menu.
2. Select Edit/Delete HDD Music.
3. Select Playlists.

4. Select Create New Playlist.

5. Enter the playlist name using the keyboard,

then select OK.

6. Select an item, then select desired track.
7. Select Done.

18 ACURA MDX-31TZ56400.book  279 ページ  2017年8月23日 水曜日 午後4時1分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

280

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Features

Change the track title, artist name, genre and composer. You can also delete tracks.

1. Select Audio Menu.
2. Select Edit/Delete HDD Music.
3. Select Tracks.
4. Select a track you want to edit or delete.

5. To edit track information:

Select Edit Name, then select Track
Name
Track Artist, etc.

u

Enter the track name, track artist, etc.
using the keyboard, then select OK.

To delete a track:
Select Delete, then select Yes.

6. Select Done.

Editing Track Information

18 ACURA MDX-31TZ56400.book  280 ページ  2017年8月23日 水曜日 午後4時1分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

281

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Continued

Features

Music information (album name, artist name, genre) can be acquired by accessing
the Gracenote® Album Info.

1. Select Audio Menu.
2. Select Edit/Delete HDD Music.
3. Select an item you want to acquire music

information.

4. Select Edit Name.

5. Select Get Music Information.

u

The system starts to access the
Gracenote® Album Info.

Displaying Music Information

18 ACURA MDX-31TZ56400.book  281 ページ  2017年8月23日 水曜日 午後4時1分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

282

Features

Update the Gracenote® Album Info (Gracenote® Media Database) that is included
with the navigation system.

1. Select Audio Menu.
2. Select Audio Settings.
3. Select CD/HDD.
4. Insert the update disc into the disc slot or

connect the USB flash drive that includes
the update.

5. Select Update Gracenote Album

Information.

6. Select Update by CD or Update by USB.

u

The system starts updating and the
confirmation message appears on the
screen. Select OK to finish.

Updating Gracenote® Album Info

1

Updating Gracenote® Album Info

To acquire updated files:

Consult a dealer.

U.S.: Visit www.acura.com.

Canada: Visit www.acura.ca.

Once you perform an update, any information you
edited before will be overwritten or erased.

18 ACURA MDX-31TZ56400.book  282 ページ  2017年8月23日 水曜日 午後4時1分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

283

uu

Audio System Basic Operation

u

Playing Hard Disk Drive (HDD) Audio

Features

Delete all music data on the HDD.

1. Select Audio Menu.
2. Select Audio Settings.
3. Select CD/HDD.
4. Select Delete All HDD Data.

u

The confirmation message will appear.

5. Select Yes.

Deleting all HDD Data

18 ACURA MDX-31TZ56400.book  283 ページ  2017年8月23日 水曜日 午後4時1分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

284

uu

Audio System Basic Operation

u

Playing an iPod

Features

Playing an iPod

Connect the iPod using your USB connector to the USB port

 (2.5A), then select

the iPod mode.

USB Ports P. 233

Skip/Seek Icons
Select

 or

 to change songs.

Select and hold to move rapidly
within a song.

VOL/

 (Volume/Power) Knob

Press to turn the audio system on
and off.
Turn to adjust the volume.

Audio Menu
Select to display the menu items.

Source
Select to change an audio source.

 (Information) Icon

Select to displays the current song
details.
Select

 to displays the previous

screen.

Browse
Select to displays the music search
list screen.

On Demand Multi-Use Display

TM

Repeat Icon
Select to repeats the current song.

/

 (Play/Pause) Icon

Select to resume or play a song.

Shuffle Icon
Select to change a play mode in
album shuffle or shuffle all songs.

18 ACURA MDX-31TZ56400.book  284 ページ  2017年8月23日 水曜日 午後4時1分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

285

uu

Audio System Basic Operation

u

Playing an iPod

Features

1. Select Browse.
2. Select the items on that menu.

How to Select a Song from the Music Search List

1

How to Select a Song from the Music Search List

You can control an iPod using voice commands

*

.

Voice Control Operation P. 251
Song By Voice

TM

 (SBV) P. 287

Available operating functions vary on models and/or
versions. Some functions may not be available on the
vehicle’s audio system.

If there is a problem, you may see an error message
on the On Demand Multi-Use Display

TM

.

iPod/USB Flash Drive P. 310

* Not available on all models

18 ACURA MDX-31TZ56400.book  285 ページ  2017年8月23日 水曜日 午後4時1分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

uu

Audio System Basic Operation

u

Playing an iPod

286

Features

You can select repeat and shuffle modes when playing a song.

Shuffle/Repeat

Select shuffle or repeat icon repeatedly until a
desired mode.

To turn off a play mode

To turn off the shuffle or repeat, select shuffle or repeat icon repeatedly.

How to Select a Play Mode

1

How to Select a Play Mode

Play Mode Menu Items
Repeat

Shuffle

*1: Not available on all iPod.

(repeat off)

*1

: Repeat mode to off.

(repeat song): Repeats the current song.

(repeat all): Repeats the all songs.

(shuffle off): shuffle mode to off.

(shuffle all songs): Plays all available songs in
a selected list (playlists, artists, albums,
songs, genres, or composers) in random
order.
(shuffle albums): Plays all available albums in
a selected list (playlists, artists, albums,
songs, genres, or composers) in random
order.

Shuffle Icon

Repeat Icon

18 ACURA MDX-31TZ56400.book  286 ページ  2017年8月23日 水曜日 午後4時1分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

287

uu

Audio System Basic Operation

u

Song By Voice

TM

 (SBV)

Continued

Features

Song By Voice

TM

 (SBV)

Use SBV to search for and play music from your HDD or iPod using voice commands.

To enable SBV

1. Press the SETTINGS button.
2. Rotate

 to select System Settings, then

press .

3. Move

or

to

select

the

Voice Reco.

tab.

4. Rotate

 to select Song By Voice.

5. Press

to

select

On or Off.

Models with navigation system

1

Song By Voice

TM

 (SBV)

Setting options:

On (factory default): Song By Voice

TM

 commands

are available.

Off: Disable the feature.

18 ACURA MDX-31TZ56400.book  287 ページ  2017年8月23日 水曜日 午後4時1分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

uu

Audio System Basic Operation

u

Song By Voice

TM

 (SBV)

288

Features

Searching for music using SBV

1. Set the Song By Voice setting to On.
2. Press the

 (Talk) button and say “Audio”

to activate the SBV feature for the HDD and
iPod.

3. Press the

 button and say a command.

u

Example 1: Say “(List) ‘Artist A’” to view a
list of songs by that artist. Select the
desired song to start playing.

u

Example 2: Say “Play ‘Artist A’” to start
playing songs by that artist.

4. To cancel SBV, press the

 (hang-up/

back) button on the steering wheel. The
selected song continues playing.

Once you have canceled this mode, you need
to press the

 button and say “Audio” again

to re-activate this mode.

1

Searching for music using SBV

Song By Voice

TM

 Commands List

Voice Control Operation P. 251

NOTE:
Song By Voice

TM

 commands are available for tracks

stored on the HDD or iPod.

You can add phonetic modifications of difficult
words so that it is easier for SBV to recognize artists,
songs, albums, and composers in voice commands.

Phonetic Modification P. 289

SBV may not be able to recognize languages other
than English for the artist name, song title, album
title, and composers.

18 ACURA MDX-31TZ56400.book  288 ページ  2017年8月23日 水曜日 午後4時1分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

289

uu

Audio System Basic Operation

u

Song By Voice

TM

 (SBV)

Features

Add phonetic modifications of difficult or foreign words so that it is easier for SBV
to recognize artists, songs, albums, and composers in voice commands when
searching for music on the HDD or iPod.

1. Press the SETTINGS button.
2. Rotate

to

select

System Settings

then press

.

3. Move

 or

 to select the Voice Reco.

tab.

4. Rotate

to

select

Song By Voice

Phonetic Modification, then press

.

5. Rotate

to

select

New Modification

then press

.

6. Rotate

to

select

HDD or iPod, then

press .

Phonetic Modification

1

Phonetic Modification

Song By Voice Phonetic Modification is grayed
out when Song By Voice is set to Off.

You can store up to 2,000 phonetic modification
items.

18 ACURA MDX-31TZ56400.book  289 ページ  2017年8月23日 水曜日 午後4時1分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

290

uu

Audio System Basic Operation

u

Song By Voice

TM

 (SBV)

Features

7. Rotate

 to select the item to modify

(e.g., Artist), then press

.

u

The list of the selected item appears on
the screen.

8. Rotate

 to select an entry (e.g., No

Name), then press

.

u

The pop-up menu appears on the
screen.

9. Rotate

 to select Modify, then press

.

u

To listen to the current phonetic
modification, rotate

 to select Play

then press

.

u

To delete the current phonetic
modification, rotate

 to select

Delete, then press

.

10. Enter the phonetic spelling you wish to

use (e.g., “Artist A”) when prompted.

11. Select OK to exit.

u

The artist “No Name” is phonetically
modified to “Artist A.” When in the SBV
mode, you can press the

 (Talk)

button and use the voice command
“Play ‘Artist A’” to play songs by the
artist “No Name.”

On Demand Multi-Use Display

TM

18 ACURA MDX-31TZ56400.book  290 ページ  2017年8月23日 水曜日 午後4時1分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

291

uu

Audio System Basic Operation

u

Playing Pandora®

*1

Continued

Features

Playing Pandora®

*1

Your audio system allows you to listen to music from the Pandora® app on a
compatible smartphone.
This function is available when the phone is paired and connected to the vehicle’s
Bluetooth® HandsFreeLink® (HFL) system, or with an iPhone, you can connect using
your USB cable to the USB port

 (2.5A).

Phone Setup P. 401
USB Ports P. 233

*1:Available only on U.S. models.

1

Playing Pandora®

*1

Pandora®, the Pandora logo, and the Pandora trade
dress are trademarks or registered trademarks of
Pandora Media, Inc., used with permission. Pandora
is currently available exclusively in the United States.

To find out if your phone is compatible with this
feature, visit www.handsfreelink.com/Acura, or call
1-888-528-7876.

VOL/

 (Volume/Power) Knob

Press to turn the audio system on
and off.
Turn to adjust the volume.

Audio Menu
Select to display the menu items.

Source
Select to change an audio source.

 (Information) Icon

Select to displays the current track
details.
Select

 to displays the previous

screen.

Stations
Select to displays the station list
screen.

On Demand Multi-Use Display

TM

Like/Dislike Icons
Select to evaluate a track.

Skip Icon
Select to skip a track.

Play/Pause Icon
Select to resume or play a track.

Station Up/Down Icons
Select to change a station.

Bookmark Track Icon
Bookmarks the current track.
Bookmark Artist Icon
Bookmarks the current artist.

18 ACURA MDX-31TZ56400.book  291 ページ  2017年8月23日 水曜日 午後4時1分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

uu

Audio System Basic Operation

u

Playing Pandora®

*1

292

Features

1. Select Stations.
2. Select a item to select a track.

Create Station

You can create a station by GenreCurrent
Track
 or Current Artist.
1. Select Stations.
2. Select Create Station.
3. Select the item you want to create a station.

You can also create a station by the following
procedure.
1. Select track name or artist name.
2. Select Yes.

Select the connecting method

If the two devices that install Pandora app are connected via the USB and Bluetooth®
connection separately, you can select the USB or Bluetooth® connection to use the
Pandora®.

1. Select the PANDORA on the source list screen.
2. Select USB or Bluetooth.

How to Select a Track from the Stations List

1

Playing Pandora®

*1

Pandora® is a personalized Internet radio service that
selects music based on an artist, track, or genre a user
enters, and streams what is likely to be of interest.

To use this service in your vehicle, the Pandora® app
must first be installed on your phone. Visit
www.pandora.com. for more information.

If you cannot operate Pandora® through the audio
system, it may be streaming through Bluetooth®
Audio. Make sure Pandora® mode on your audio
system is selected.

Available operating functions vary on software
versions. Some functions may not be available on the
vehicle’s audio system.

If there is a problem, you may see an error message
on the On Demand Multi-Use Display

TM

.

Pandora® P. 312

There are restrictions on the number of tracks you
can skip or dislike in a given hour.

If your phone is connected to Android Auto,
Pandora® is only available through the Android Auto
interface.
Visit the Android Auto website to check
compatibility.

Select track or artist name.

18 ACURA MDX-31TZ56400.book  292 ページ  2017年8月23日 水曜日 午後4時1分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

293

uu

Audio System Basic Operation

u

Playing a USB Flash Drive

Continued

Features

Playing a USB Flash Drive

Your audio system reads and plays sound files on a USB flash drive in either MP3,
WMA, or AAC

*1

 format.

Connect your USB flash drive to the USB port

 (2.5A), then select the USB mode.

USB Ports P. 233

*1:Only AAC format files recorded with iTunes are playable on this unit.

VOL/

 (Volume/Power) Knob

Press to turn the audio system on
and off.
Turn to adjust the volume.

Skip/Seek Icons
Select

 or

 to change files.

Select and hold to move rapidly
within a file.

Audio Menu
Select to display the menu items.

Source
Select to change an audio source.

 (Information) Icon

Select to displays the current file
details.
Select

 to displays the previous

screen.

Search
Select to displays the music search
list screen.

Folder Up/Down Icons
Select

 to

 skip to the next

folder, and to skip to the beginning
of the previous folder.

On Demand Multi-Use Display

TM

Repeat Icon
Select to repeats the current file.

SCAN Icon
Select to provides 10-second sampling of each files.

Random Icon
Select to plays all files in random
order.

18 ACURA MDX-31TZ56400.book  293 ページ  2017年8月23日 水曜日 午後4時1分

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     16      17      18      19     ..
