Acura ILX (2018 year). Instruction - part 10





uu

Operating the Switches Around the Steering Wheel

u

Driving Position Memory System

*

148

Co
ntrols

1. Set the power mode to ON. Adjust the

driver’s seat to the desired position.

2. Press the SET button.

u

You will hear the beep, and the memory
button indicator light will blink.

3. Press memory button

(

1 or

(

2 within five

seconds of pressing the SET button.

u

Once the seat positions have been
memorized, the indicator light on the
button you pressed stays on.

1. Put the transmission into

(

P.

2. Apply the parking brake.
3. Press a memory button (

(

1 or

(

2).

u

You will hear the beep, and the indicator
light will blink.

The seat will automatically move to the
memorized positions. When it has finished
moving, you will hear the beep, and the
indicator light stays on.

Storing a Position in Memory

1

Storing a Position in Memory

After you press the SET button, the storing operation
will be canceled when:

You do not press the memory button within five
seconds.

You readjust the seat position before the double-
beep.

You set the power mode to any position except
ON.

SET Button

Memory Button 1

Memory Button 2

Recalling the Stored Position

1

Recalling the Stored Position

The seat will stop moving if you:

Press the SET button or memory button

(

1 or

(

2.

Adjust the seat position.

Put the transmission into a position other than

(

P.

Memory Buttons

18 ACURA ILX-31TX66500.book  148 ページ  2017年8月25日 金曜日 午前11時31分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

149

Co
ntrols

Adjusting the Mirrors

Interior Rearview Mirror

Adjust the angle of the rearview mirror when you are sitting in the correct driving
position.

Flip the tab to switch the position.
The night position will help to reduce the glare
from headlights behind you when driving
after dark.

When you are driving after dark, the
automatic dimming rearview mirror reduces
the glare from headlights behind you, based
on inputs from the mirror sensor. This feature
is always active.

Rearview Mirror with Day and Night Positions

*

1

Adjusting the Mirrors

Keep the inside and outside mirrors clean and
adjusted for best visibility.

Adjust the mirrors before you start driving.

Adjusting the Seat Positions P. 151

Tab

Daytime
Position

Night Position

Up

Down

Automatic Dimming Rearview Mirror

*

1

Automatic Dimming Rearview Mirror

*

The auto dimming function cancels when the
transmission is in

(

R.

Sensor

* Not available on all models

18 ACURA ILX-31TX66500.book  149 ページ  2017年8月25日 金曜日 午前11時31分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

150

uu

Adjusting the Mirrors

u

Power Door Mirrors

Co
ntrols

Power Door Mirrors

You can adjust the door mirrors when the
power mode is in ON.

Mirror position adjustment

L/R selector switch: Select the left or right
mirror. After adjusting the mirror, return the
switch to the center position.
Mirror position adjustment switch: Press
the switch left, right, up, or down to move the
mirror.

Selector Switch

Adjustment Switch

18 ACURA ILX-31TX66500.book  150 ページ  2017年8月25日 金曜日 午前11時31分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

151

Continued

Co
ntrols

Adjusting the Seats

Adjusting the Seat Positions

Adjust the driver's seat as far back as possible
while allowing you to maintain full control of
the vehicle. You should be able to sit upright,
well back in the seat and be able to
adequately press the pedals without leaning
forward, and grip the steering wheel
comfortably. The passenger's seat should be
adjusted in a similar manner, so that it is as far
back from the front airbag in the dashboard
as possible.

Adjusting the front power seat(s)

*

1

Adjusting the Seats

The National Highway Traffic Safety Administration
and Transport Canada recommend that drivers allow
at least 10 inches (25 cm) between the center of the
steering wheel and the chest.

Always make seat adjustments before driving.

3

WARNING

Sitting too close to a front airbag can result
in serious injury or death if the front
airbags inflate.

Always sit as far back from the front
airbags as possible while maintaining
control of the vehicle.

Move back.

Allow sufficient
space.

Horizontal
Position
Adjustment

Height
Adjustment
(Driver’s
seat only)

Seat-back Angle
Adjustment

* Not available on all models

18 ACURA ILX-31TX66500.book  151 ページ  2017年8月25日 金曜日 午前11時31分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

uu

Adjusting the Seats

u

Adjusting the Seat Positions

152

Co
ntrols

Adjusting the front instruction seat(s)

*

1

Adjusting the front instruction seat(s)

*

Once a seat is adjusted correctly, rock it back and
forth to make sure it is locked in position.

Horizontal Position
Adjustment
Pull up on the bar to move the
seat, then release the bar.

Height Adjustment
(Driver’s seat only)
Pull up or push down the lever
to raise or lower the seat.

Seat-back Angle
Adjustment
Pull up the lever to
change the angle.

* Not available on all models

18 ACURA ILX-31TX66500.book  152 ページ  2017年8月25日 金曜日 午前11時31分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

153

uu

Adjusting the Seats

u

Adjusting the Seat Positions

Co
ntrols

Adjust the driver's seat-back to a comfortable,
upright position, leaving ample space
between your chest and the airbag cover in
the center of the steering wheel.

The front seat passenger should also adjust
their seat-back to a comfortable, upright
position.

Reclining a seat-back so that the shoulder part of the belt no longer rests against the
occupant's chest reduces the protective capability of the belt. It also increases the
chance of sliding under the belt in a crash and being seriously injured. The farther a
seat-back is reclined, the greater the risk of injury.

Adjusting the Seat-Backs

1

Adjusting the Seat-Backs

Do not put a cushion, or other object, between the
seat-back and your back. Doing so may interfere with
proper seat belt or airbag operation.

If you cannot get far enough away from the steering
wheel and still reach the controls, we recommend
that you investigate whether some type of adaptive
equipment may help.

3

WARNING

Reclining the seat-back too far can result in
serious injury or death in a crash.

Adjust the seat-back to an upright position,
and sit well back in the seat.

18 ACURA ILX-31TX66500.book  153 ページ  2017年8月25日 金曜日 午前11時31分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

154

uu

Adjusting the Seats

u

Head Restraints

Co
ntrols

Head Restraints

Your vehicle is equipped with head restraints in all seating positions.

Head restraints are most effective for
protection against whiplash and other rear-
impact crash injuries when the center of the
back of the occupant's head rests against the
center of the restraint. The tops of the
occupant's ears should be level with the
center height of the restraint.

To raise the head restraint: Pull it upward.
To lower the head restraint: Push it down
while pressing the release button.

Adjusting the Front and Rear Outer Head Restraint Positions

1

Head Restraints

In order for the head restraint system to work
properly:

Do not hang any items on the head restraints, or
from the restraint legs.

Do not place any objects between an occupant and
the seat-back.

Install each restraint in its proper location.

3

WARNING

Improperly positioning head restraints
reduces their effectiveness and increases
the likelihood of serious injury in a crash.

Make sure head restraints are in place and
positioned properly before driving.

Position head in the center
of the head restraint.

18 ACURA ILX-31TX66500.book  154 ページ  2017年8月25日 金曜日 午前11時31分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

155

uu

Adjusting the Seats

u

Head Restraints

Co
ntrols

A passenger sitting in the center back seating
position should adjust the height of their head
restraint to an appropriate position before the
vehicle begins moving.
To raise the head restraint:
Pull it upward.
To lower the head restraint:
Push it down while pressing the release
button.

Head restraints can be removed for cleaning or repair.

To remove a head restraint:
Pull the restraint up as far as it will go. Then push the release button, and pull the
restraint up and out.

To reinstall a head restraint:
Insert the legs back in place, then adjust the head restraint to an appropriate height
while pressing the release button. Pull up on the restraint to make sure it is locked
in position.

Changing the Rear Center Seat Head Restraint Positions

Removing and Reinstalling the Head Restraints

1

Removing and Reinstalling the Head Restraints

3

WARNING

Failure to reinstall, or correctly reinstall, the
head restraints can result in severe injury
during a crash.

Always replace the head restraints before
driving.

18 ACURA ILX-31TX66500.book  155 ページ  2017年8月25日 金曜日 午前11時31分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

156

uu

Adjusting the Seats

u

Maintain a Proper Sitting Position

Co
ntrols

Maintain a Proper Sitting Position

After all occupants have adjusted their seats and head restraints, and put on their
seat belts, it is very important that they continue to sit upright, well back in their
seats, with their feet on the floor, until the vehicle is safely parked and the engine is
off.

Sitting improperly can increase the chance of injury during a crash. For example, if
an occupant slouches, lies down, turns sideways, sits forward, leans forward or
sideways, or puts one or both feet up, the chance of injury during a crash is greatly
increased.

In addition, an occupant who is out of position in the front seat can be seriously or
fatally injured in a crash by striking interior parts of the vehicle or being struck by an
inflating front airbag.

1

Maintain a Proper Sitting Position

3

WARNING

Sitting improperly or out of position can
result in serious injury or death in a crash.

Always sit upright, well back in the seat,
with your feet on the floor.

18 ACURA ILX-31TX66500.book  156 ページ  2017年8月25日 金曜日 午前11時31分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

157

uu

Adjusting the Seats

u

Rear Seat

Co
ntrols

Rear Seat

1. Remove the center shoulder belt from the

guide.

2. Pull the release lever in the trunk to release

the lock.

3. Fold the seat-back down.

If the rear head restraints get caught on the
front seat-backs, remove the head restraints.

Removing and Reinstalling the Head

Restraints P. 155

Folding Down the Rear Seat

1

Folding Down the Rear Seat

The rear seat-backs can be folded down to
accommodate bulkier items in the trunk.

Never drive with the seat-back folded down and the
trunk lid open.

Exhaust Gas Hazard P. 63

To lock the seat-back upright, push it backwards until
it locks.
When returning a seat-back to its original position,
push it firmly back. Also, make sure all rear shoulder
belts are positioned in front of the seat-back, and the
center shoulder belt is re-positioned in the guide.

Make sure that the folded seat-back does not press
against the front passenger seat, as this can cause the
weight sensors in the front passenger seat to work
improperly.

Passenger Front Airbag Off Indicator P. 48

Also make sure all items in the trunk or items
extending through the opening into the rear
seat is properly secured. Loose items can fly
forward if you have to brake hard.

The front seat(s) must be far enough forward so they
do not interfere with the rear seats as they fold
down.

Guide

Center
Shoulder Belt

Release Lever

18 ACURA ILX-31TX66500.book  157 ページ  2017年8月25日 金曜日 午前11時31分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

158

uu

Adjusting the Seats

u

Armrest

Co
ntrols

Armrest

Pull down the armrest in the center backrest.

Using the Rear Seat Armrest

18 ACURA ILX-31TX66500.book  158 ページ  2017年8月25日 金曜日 午前11時31分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

159

Co
ntrols

Interior Lights/Interior Convenience Items

Interior Lights

ON

The interior lights come on regardless of
whether the doors are open or closed.

Door activated

The interior lights come on in the following
situations:
• When any of the doors are opened.
• You unlock the driver's door.
• The lights also come on when the power

mode is set to VEHICLE OFF (LOCK).

OFF

The interior lights remain off regardless of
whether the doors are open or closed.

The map lights can be turned on and off by
pressing the

 (map light) button.

Interior Light Switches

1

Interior Light Switches

In the door activated position, the interior lights fade
out and go off about 30 seconds after the doors are
closed.
The lights go off after about 30 seconds in the
following situations:

When you unlock the driver's door but do not open
it.

When you set the power mode to VEHICLE OFF
(LOCK) but do not open a door.

You can change the interior lights dimming time.

Customized Features P. 99, 263

The interior lights go off immediately in the following
situations:

When you lock the driver's door.

When you set the power mode to ON.

To avoid draining the battery, do not leave the
interior light on for an extended length of time when
the engine is off.

If you leave any of the doors open, the interior lights
go off after about 15 minutes.

Door Activated Position

Off

Front

On

Off

Rear

On

Door Activated Position

Map Lights

1

Map Lights

When the front interior light switch is in the door
activated position and any door is open, the map
light will not go off when you press the

 button.

18 ACURA ILX-31TX66500.book  159 ページ  2017年8月25日 金曜日 午前11時31分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

160

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

Interior Convenience Items

Pull the handle to open the glove box. You
can lock the glove box with the built-in key.

Press the button to open the console
compartment.

Glove Box

1

Glove Box

3

WARNING

An open glove box can cause serious injury
to your passenger in a crash, even if the
passenger is wearing the seat belt.

Always keep the glove box closed while
driving.

Glove Box

To Lock

Console Compartment

Button

18 ACURA ILX-31TX66500.book  160 ページ  2017年8月25日 金曜日 午前11時31分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

161

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

Front seat beverage holders

Are located in the console between the front
seats.

Front door side beverage holders

Are located on the both of the front door side
pockets.

Rear seat beverage holders

Fold the armrest down to use the rear seat
beverage holders.

Beverage Holders

1

Beverage Holders

NOTICE

Spilled liquids damage the upholstery, carpeting, and
electrical components in the interior.

Be careful when you are using the beverage holders.
Hot liquid can scald you.

18 ACURA ILX-31TX66500.book  161 ページ  2017年8月25日 金曜日 午前11時31分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

162

Co
ntrols

The accessory power sockets can be used when the power mode is in ACCESSORY
or ON.

Accessory power socket (console
compartment)

Open the console lid and the cover to use it.

There is a coat hook on the rear left grab
handle. Pull it down to use it.

Accessory Power Socket

1

Accessory Power Socket

NOTICE

Do not insert an automotive type cigarette lighter
element. This can overheat the power socket.

The accessory power socket is designed to supply
power for 12-volt DC accessories that are rated 180
watts (15 amps) or less.

To prevent battery drain, only use the power socket
with the engine running.

Coat Hook

1

Coat Hook

The coat hook is not designed for large or heavy
items.

18 ACURA ILX-31TX66500.book  162 ページ  2017年8月25日 金曜日 午前11時31分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

163

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The power mode must be in ON to use the
seat heaters. The HI setting heats the seats
faster than the LO setting.

While in HI, the heater cycles on and off.

u

The appropriate indicator will be on
while the seat heater is on. Briefly press
the switch on the opposite side to turn
the heater off. The indicator will be off.
When a comfortable temperature is
reached, select LO to keep the seat
warm.

Seat Heaters

*

1

Seat Heaters

*

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

In the LO setting, the heater runs continuously and
does not automatically turn off.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

18 ACURA ILX-31TX66500.book  163 ページ  2017年8月25日 金曜日 午前11時31分

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     8      9      10      11     ..
