Indicators
u
Continued
In
strum
e
nt Pa
nel
Indicator
Name
On/Blinking
Explanation
Message
Anti-lock Brake
System (ABS)
Indicator
●
Comes on for a few seconds
when you set the power mode to
ON, then goes off.
●
If it comes on at any other time,
there is a problem with the ABS.
●
Stays on constantly - Have your vehicle
checked by a dealer. With this indicator on,
your vehicle still has normal braking ability but
no anti-lock function.
2 Anti-lock Brake System (ABS) P. 305
Supplemental
Restraint System
Indicator
●
Comes on for a few seconds
when you set the power mode to
ON, then goes off.
●
Comes on if a problem with any
of the following is detected:
- Supplemental restraint system
- Side airbag system
- Side curtain airbag system
- Seat belt tensioner
●
Stays on constantly or does not come on
at all - Have your vehicle checked by a dealer.
Auto High-Beam
Indicator
●
Comes on when all the operating
conditions of the Auto high-
beam are met.
2 Auto High-Beam P. 172
—
