4 157

Features of your vehicle

Declaration of Conformity

FCC

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a resi-
dential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions,may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or tel-
evision reception, which can be determined by turning the equipment off and on, the user is encouraged to try to cor-
rect the interference by one or more of the following measures :

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void
your authority to operate this equipment.

Features of your vehicle

158

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions :

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, includ-
ing interference that may cause undesired operation.

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

This equipment should be installed and operatedwith minmum 20cm between the and your body. This transmitter must
not be collocated or operating in conjunction with any other antenna or transmitter unless authorized to do so by the
FCC.

Driving your vehicle

Before driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

• Before entering vehicle . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
• Necessary inspections . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
• Before starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

Engine start/stop button . . . . . . . . . . . . . . . . . . . . . 5-6

• Illuminated Engine start/stop button . . . . . . . . . . . . . 5-6
• Engine start/stop button position. . . . . . . . . . . . . . . . . 5-6
• Starting the engine with a smart key . . . . . . . . . . . . . 5-8

Automatic transaxle . . . . . . . . . . . . . . . . . . . . . . . . 5-10

• Automatic transaxle operation. . . . . . . . . . . . . . . . . . 5-10
• Good driving practices . . . . . . . . . . . . . . . . . . . . . . . . 5-16

Brake system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-17

• Power brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-17
• Parking brake – Foot type . . . . . . . . . . . . . . . . . . . . . 5-19
• Electronic parking brake (EPB) . . . . . . . . . . . . . . . . 5-20
• AUTO HOLD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-26
• Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-28
• Anti-lock brake system (ABS) . . . . . . . . . . . . . . . . . . 5-29
• Electronic stability control (ESC) . . . . . . . . . . . . . . . 5-31
• Vehicle stability management (VSM) . . . . . . . . . . . . 5-34
• Hill-start assist control (HAC) . . . . . . . . . . . . . . . . . . 5-36
• Good braking practices. . . . . . . . . . . . . . . . . . . . . . . . 5-36

Autonomous emergency braking (AEB) /

Forward collision warning (FCW) . . . . . . . . . . . 5-38

• System setting and activation. . . . . . . . . . . . . . . . . . . 5-38

• AEB warning message and system control . . . . . . . . 5-41
• Brake operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-42
• Sensor to detect the distance from the vehicle in front

(front radar). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-43

• System malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-44
• Limitation of the system . . . . . . . . . . . . . . . . . . . . . . . 5-45
• Recognizing pedestrians . . . . . . . . . . . . . . . . . . . . . . . 5-48

Cruise control system. . . . . . . . . . . . . . . . . . . . . . . 5-49

• To set cruise control speed . . . . . . . . . . . . . . . . . . . . . 5-50
• To increase cruise control set speed. . . . . . . . . . . . . . 5-50
• To decrease the cruising speed . . . . . . . . . . . . . . . . . . 5-51
• To temporarily accelerate with the

cruise control on . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-51

• To cancel cruise control, do one of the following . . . 5-51
• To resume cruising speed at more than

approximately 20 mph (30 km/h) . . . . . . . . . . . . . . 5-52

• To turn cruise control off, do one of the following. . 5-52

Advanced smart cruise control system (ASCC). . 5-53

• Speed setting (ASCC) . . . . . . . . . . . . . . . . . . . . . . . . . 5-54
• Vehicle to vehicle distance setting (ASCC) . . . . . . . . 5-58
• To adjust the sensitivity of

Advanced Smart Cruise Control . . . . . . . . . . . . . . 5-62

• To convert to cruise control mode . . . . . . . . . . . . . . . 5-62
• Limitations of the system . . . . . . . . . . . . . . . . . . . . . . 5-62

Drive mode integrated control system . . . . . . . . . 5-68

• DRIVE MODE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-68
• ECO MODE Driving. . . . . . . . . . . . . . . . . . . . . . . . . . 5-69
• Conditions that limit Active ECO MODE: . . . . . . . . 5-69
• DRIVE MODE Indicator Screen. . . . . . . . . . . . . . . . 5-72

Blind spot detection system (BSD) . . . . . . . . . . . . 5-76

• BSD (Blind Spot Detection) /

LCA (Lane Change Assist). . . . . . . . . . . . . . . . . . . . 5-77

• RCTA (Rear Cross Traffic Alert). . . . . . . . . . . . . . . . 5-80
• Limitations condition . . . . . . . . . . . . . . . . . . . . . . . . . 5-82

Smart blind spot detection system . . . . . . . . . . . . 5-84

• Limitations of the system . . . . . . . . . . . . . . . . . . . . . . 5-85

Lane departure warning system (LDWS) . . . . . . 5-88

• Warning indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-90
• Conditions that cause the LDWS not to operate . . . 5-90
• Conditions that cause missed warnings and

false warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-91

Economical operation . . . . . . . . . . . . . . . . . . . . . . 5-92
Special driving conditions . . . . . . . . . . . . . . . . . . . 5-94

• Hazardous driving conditions . . . . . . . . . . . . . . . . . . 5-94
• Rocking the vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-94
• Smooth cornering . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-95
• Driving at night . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-95
• Driving in the rain. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-96
• Driving in flooded areas . . . . . . . . . . . . . . . . . . . . . . . 5-97

• Driving off-road. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-97
• Highway driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-97

Winter driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-98

• Snowy or icy conditions . . . . . . . . . . . . . . . . . . . . . . . 5-98
• Use high quality ethylene glycol coolant . . . . . . . . . 5-100
• Check battery and cables . . . . . . . . . . . . . . . . . . . . . 5-100
• Change to "winter weight" oil if necessary . . . . . . 5-100
• Check spark plugs and ignition system. . . . . . . . . . 5-100
• To keep locks from freezing . . . . . . . . . . . . . . . . . . . 5-101
• Use approved window washer anti-freeze in

system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-101

• Don’t let your parking brake freeze . . . . . . . . . . . . 5-101
• Don't let ice and snow accumulate underneath . . . 5-101
• Carry emergency equipment . . . . . . . . . . . . . . . . . . 5-101

Trailer Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-101
Vehicle load limit . . . . . . . . . . . . . . . . . . . . . . . . . 5-102

• Tire and loading information label . . . . . . . . . . . . . 5-102
• Certification label . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-105

Vehicle weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-106

5 3

Driving your vehicle

Be sure the exhaust system does
not leak.
The exhaust system should be
checked whenever the vehicle is
raised to change the oil or for any
other purpose. If you hear a change in
the sound of the exhaust or if you drive
over something that strikes the under-
neath side of the vehicle, have the
exhaust system checked as soon as
possible by an authorized Kia dealer.

WARNING

- Engine

exhaust

Do not inhale exhaust fumes or
leave your engine running in a
enclosed area for a prolonged
time. Exhaust fumes contain
carbon monoxide, a colorless,
odorless gas that can cause
unconsciousness and death by
asphyxiation.

WARNING

- Open liftgate

Do not drive with the liftgate
open. Poisonous exhaust gases
can enter the passenger com-
partment. If you must drive with
the liftgate open proceed as fol-
lows:
1. Close all windows.
2. Open side vents.
3. Set the air intake control at

"Fresh", the air flow control at
"Floor" or "Face" and the fan
at the highest speed.

CALIFORNIA PROPO-

SITION 65 WARNING

Engine exhaust and a wide vari-
ety of automobile components
and parts, including compo-
nents found in the interior fur-
nishings in a vehicle, contain or
emit chemicals known to the
State of California to cause can-
cer and birth defects and repro-
ductive harm. In addition, cer-
tain fluids contained in vehicles
and certain products of compo-
nent wear contain or emit chem-
icals known to the State of
California to cause cancer and
birth defects or other reproduc-
tive harm.

Driving your vehicle

Before entering vehicle

• Be sure that all windows, outside

mirror(s), and outside lights are
clean.

• Check the condition of the tires.
• Check under the vehicle for any

sign of leaks.

• Be sure there are no obstacles

behind you if you intend to back up.

Necessary inspections

Fluid levels, such as engine oil,
engine coolant, brake fluid, and
washer fluid should be checked on a
regular basis, at the exact interval
depending on the fluid. Further
details are provided in chapter 7,
“Maintenance”.

Before starting

• Close and lock all doors.
• Position the seat so that all con-

trols are easily reached.

• Buckle your seat belt.
• Adjust the inside and outside

rearview mirrors.

• Be sure that all lights work.
• Check all gauges.
• Check the operation of warning

lights when the ignition switch is
turned to the ON position.

• Release the parking brake and

make sure the brake warning light
goes out.

For safe operation, be sure you are
familiar with your vehicle and its
equipment.

BEFORE DRIVING

WARNING

- Distracted

driving

Focus on the road while driving.
The driver's primary responsi-
bility is in the safe and legal
operation of the vehicle. Use of
any handled devices, other
equipment or vehicle systems
that distract the drive should
not be used during vehicle
operation.

5 5

Driving your vehicle

WARNING

- Check sur-

roundings

Always check the surrounding
areas near your vehicle for peo-
ple, especially children, before
putting a vehicle into D (Drive)
or R (Reverse).

WARNING

- Fire risk

When you intend to park or stop
the vehicle with the engine on,
be careful not to depress the
accelerator pedal for a long
period of time. It may overheat
the engine or exhaust system
and cause fire.

WARNING

- Loose

objects

Securely store items in your
vehicle. When you make a sud-
den stop or turn the steering
wheel rapidly, loose objects
may drop on the floor and it
could interfere with the opera-
tion of the foot pedals, possibly
causing an accident.

WARNING

- Driving while

intoxicated

Do not drive while intoxicated.
Drinking and driving is danger-
ous. Even a small amount of
alcohol will affect your reflexes,
perceptions and judgment.
Driving while under the influ-
ence of drugs is as dangerous
as or more dangerous than driv-
ing drunk.

Driving your vehicle

Illuminated ENGINE
START/STOP button

Whenever the front door is opened,
the ENGINE START/STOP button
will illuminate for your convenience.
The light will go off after about 30
seconds when the door is closed.
When all entrances are closed, if you
lock the vehicle by using the trans-
mitter or the smart key, the light will
go off immediately.

ENGINE START/STOP button
position

OFF

To turn off the engine (START/RUN
position) or vehicle power (ON posi-
tion), press the ENGINE
START/STOP button with the shift
lever in the P (Park) position. When
you press the ENGINE
START/STOP button without the shift
lever in the P (Park) position, the
ENGINE START/STOP button will
not change to the OFF position but to
the ACC position.

In an emergency situation while the
vehicle is in motion, you are able to
turn the engine off and to the ACC
position by pressing the ENGINE
START/STOP button for more than 2
seconds or 3 times successively
within 3 seconds. If the vehicle is still
moving, you can restart the engine
without depressing the brake pedal
by pressing the ENGINE
START/STOP button with the shift
lever in the N (Neutral) position.

ENGINE START/STOP BUTTON

OYG056003

Not illuminated

5 7

Driving your vehicle

ACC(Accessory)

Press the ENGINE START/STOP
button while it is in the OFF position
without depressing the brake pedal.
If the ENGINE START/STOP button
is in the ACC position for more than
1 hour, the button is turned off auto-
matically to prevent battery dis-
charge.

Press the ENGINE START/STOP
button while it is in the ACC position
without depressing the brake pedal.
The warning lights can be checked
before the engine is started. Do not
leave the ENGINE START/STOP
button in the ON position for a long
time. The battery may discharge,
because the engine is not running.

START/RUN

To start the engine, depress the
brake pedal and press the ENGINE
START/ STOP button with the shift
lever in the P (Park) or the N
(Neutral) position. For your safety,
start the engine with the shift lever in
the P (Park) position.
If you press the ENGINE
START/STOP button without depress-
ing the brake pedal for automatic
transaxle vehicles, the engine will not
start and the ENGINE START/STOP
button changes as follow:
OFF

➔

ACC

➔

OFF or ACC

Not illuminated

Amber

Super red

Driving your vehicle

✽

NOTICE

If you leave the ENGINE START/
STOP button in the ACC or ON
position for a long time, the battery
will discharge.

Starting the engine with a
smart key

1.Carry the smart key or place it

inside the vehicle.

2.Make sure the parking brake is

firmly applied

3.Place the transaxle shift lever in P

(Park). Depress the brake pedal
fully.
You can also start the engine when
the shift lever is in the N (Neutral)
position.

4.Press the ENGINE START/STOP

button while depressing the brake
pedal.
It should be started without
depressing the accelerator.

5.Do not wait for the engine to warm

up while the vehicle remains sta-
tionary.
Start driving at moderate engine
speeds. (Steep accelerating and
decelerating should be avoided.)

• Even if the smart key is in the vehi-

cle, if it is far away from you, the
engine may not start.

• When the ENGINE START/STOP

button is in the ACC position or
above, if any door is opened, the
system checks for the smart key. If
the smart key is not in the vehicle,
a message "key is not in the vehi-
cle" will appear on the LCD display.
And if all doors are closed, the
chime will sound for 5 seconds.
The indicator or warning will turn
off while the vehicle is moving.
Always have the smart key with
you.

WARNING

- Starting

vehicle

Never press the ENGINE
START/STOP button while the
vehicle is in motion except in an
emergency. This would result in
loss of directional control and
braking function, which could
cause an accident.

5 9

Driving your vehicle

• If the battery is weak or the smart

key does not work correctly, you
can start the engine by pressing
the engine start/stop button with
the smart key.
The side with the lock button
should contact the engine
start/stop button directly.
When you press the engine
start/stop button directly with the
smart key, the smart key should
contact the button at a right angle.

• When the stop lamp fuse is blown,

you can't start the engine normally.
Replace the fuse with a new one. If
it is not possible, you can start the
engine by pressing the ENGINE
START/STOP button for 10 sec-
onds while it is in the ACC posi-
tion. The engine can start without
depressing the brake pedal. But for
your safety always depress the
brake pedal before starting the
engine.

Do not press the ENGINE START/
STOP button for more than 10 sec-
onds except when the stop lamp fuse
is blown.

WARNING

- Unintended

vehicle movement

Never leave the smart key in the
vehicle with children or vehicle
occupants who are unfamiliar
with the vehicle operation.
Pushing the ENGINE
START/STOP button while the
smart key is in the vehicle may
result in unintended engine
activation and/or unintended
vehicle movement.

OYG056008

Driving your vehicle

Automatic transaxle operation

The automatic transaxle has 8 for-
ward speeds and one reverse speed.
The individual speeds are selected
automatically, depending on the
position of the shift lever.

✽

NOTICE

The first few shifts on a new vehicle,
if the battery has been disconnected,
may be somewhat abrupt. This is a
normal condition, and the shifting
sequence will adjust after shifts are
cycled a few times by the TCM
(Transaxle Control Module) or
PCM (Powertrain Control Module).

For smooth operation, depress the
brake pedal and the lock release but-
ton when shifting from N (Neutral) to
a forward or reverse gear.

AUTOMATIC TRANSAXLE

OYG056011

((

))

((

))

The shift lever can be shifted freely.

Press the lock release button when shifting.

Depress the brake pedal and the lock release button when shifting.

5 11

Driving your vehicle

When stopped on an incline, do not
hold the vehicle with the engine
power. Use the service brake or the
parking brake.

Transaxle ranges

The indicator in the instrument clus-
ter displays the shift lever position
when the ignition switch is in the ON
position.

P (Park)

Always come to a complete stop
before shifting into P (Park). This
position locks the transaxle and pre-
vents the drive wheels from rotating.
Shifting into P (Park) while the vehi-
cle is in motion will cause the drive
wheels to lock which will cause you
to lose control of the vehicle.

R (Reverse)

Use this position to drive the vehicle
backward.

N (Neutral)

The wheels and transaxle are not
engaged. The vehicle will roll freely
even on the slightest incline unless
the parking brake or service brakes
are applied.

WARNING

- Leaving

Vehicle

Before leaving the driver’s seat,
always make sure the shift lever
is in the P (Park) position; then
set the parking brake fully and
shut the engine off. Do not use
the P position in place of the
parking brake. Always make
sure the shift lever is locked in
the P position and set the park-
ing brake fully. Unexpected and
sudden vehicle movement can
occur if these precautions are
not followed.

CAUTION

- Transaxle

To avoid damage to your
transaxle, do not accelerate the
engine in R (Reverse) or any for-
ward gear position with the
brakes on. The transaxle may be
damaged if you shift into P
(Park) while the vehicle is in
motion.

CAUTION

- Shifting

Always come to a complete stop
before shifting into or out of R
(Reverse); you may damage the
transaxle if you shift into R
(Reverse) while the vehicle is in
motion, except when “Rocking
the vehicle” explained in this
chapter.

Driving your vehicle

- Parking in N (Neutral) gear
Follow below steps when parking
and you want the vehicle to move
when pushed.
1.After stopping your vehicle, depress

the brake pedal and move the
transaxle shift lever to [P] with the
ignition button in [ON] or while the
engine is running.

2.If the parking brake is applied,

release the parking brake.
-

For EPB (Electronic Parking
Brake) equipped vehicles,
depress the brake pedal with the
ignition button in [ON] or while the
engine is running to disengage
the parking brake. If [AUTO
HOLD] function is used while
driving (If [AUTO HOLD] indicator
is on in the cluster), press [AUTO
HOLD] switch and [AUTO HOLD]
function should be turn off.

3.While depressing the brake pedal,

turn the ignition button [OFF].
- For smart key equipped vehicles,

the ignition switch can be moved
to [OFF] only when the shift lever
is in [P].

4.Change the gear shift lever to [N]

(Neutral) while depressing the
brake pedal and inserting, press-
ing down a tool (e.g. flathead
screw-driver) into the [SHIFT
LOCK RELEASE] access hole at
the same time. Then, the vehicle
will move when external force is
applied.

✽

NOTICE

• After the ignition switch has been

turned off, the EPB (Electronic
Parking Brake) cannot be released.

• For EPB (Electronic Parking

Brake) equipped vehicles with
[AUTO HOLD] function used
while driving, if the ignition but-
ton has been turned [OFF], the
EPB (Electronic Parking Brake)
will be engaged automatically.
Therefore, [AUTO HOLD] func-
tion should be turned off before
the ignition button is turned off.

WARNING

- Parking In

Neutral

• With the exception of parking

in neutral gear, always park the
vehicle in [P] (Park) for safety
and apply the parking brake.

• Before parking in [N] (Neutral)

gear, make sure the parking
ground is level and flat. Do not
park in [N] gear on any slopes
or gradients. If parked and left
in [N], the vehicle may move
and cause serious damage or
injury.

5 13

Driving your vehicle

D (Drive)

This is the normal forward driving
position. The transaxle will automati-
cally shift through a 8-gear
sequence, providing the best fuel
economy and power.

For extra power when passing anoth-
er vehicle or climbing grades,
depress the accelerator fully, at
which time the transaxle will auto-
matically downshift to the next lower
gear.

Manual mode

Whether the vehicle is stationary or
in motion, manual mode is selected
by pushing the shift lever from the D
(Drive) position into the manual gate.
To return to D (Drive) range opera-
tion, push the shift lever back into the
main gate.

In manual mode, moving the shift
lever backwards and forwards will
allow you to make gearshifts rapidly.
In contrast to a manual transaxle, the
manual mode allows gearshifts with
the accelerator pedal depressed.
Up (+) : Push the lever forward once

to shift up one gear.

Down (-) : Pull the lever backwards

once to shift down one
gear.

• In manual mode, the driver must

execute upshifts in accordance
with road conditions, taking care to
keep the engine speed below the
red zone.

• In manual mode, only the 8 forward

gears can be selected. To reverse
or park the vehicle, move the shift
lever to the R (Reverse) or P (Park)
position as required.

OYG056013

Driving your vehicle

• In manual mode, downshifts are

made automatically when the vehi-
cle slows down. When the vehicle
stops, 1st gear is automatically
selected.

• In manual mode, when the engine

rpm approaches the red zone shift
points are varied to upshift auto-
matically.

• To maintain the required levels of

vehicle performance and safety,
the system may not execute cer-
tain gearshifts when the shift lever
is operated.

• When driving on a slippery road,

push the shift lever forward into the
+(up) position. This causes the
transaxle to shift into the 2nd gear
which is better for smooth driving
on a slippery road. Push the shift
lever to the -(down) side to shift
back to the 1st gear.

Paddle shifter (if equipped)

The paddle shifter is available when
the shift lever is in the D position or
the manual mode.

With the shift lever in the D position

The paddle shifter will operate when
the vehicle speed is more than
6.2mph(10km/h).
Pull the [+] or [-] paddle shifter once
to shift up or down one gear and the
system changes from automatic
mode to manual mode.
When the vehicle speed is lower than
6.2mph(10km/h), if you depress the
accelerator pedal for more than 5
seconds or if you shift the shift lever
from D (Drive) to manual mode and
shift it from manual mode to D (Drive)
again, the system changes from
manual mode to automatic mode.

With the shift lever in the manual mode

Pull the [+] or [-] paddle shifter once
to shift up or down one gear.

✽

NOTICE

If you pull the [+] and [-] paddle
shifters at the same time, you cannot
shift the gear.

OYG056145L

Content .. 13 14 15 16 ..
