FM 100-60
122-mm SP Howitzer Battalion,
MIBR and TBR ________________________________ ________________________
SP HOWITZER
BATTALION
(122-mm)
SUPPLY &
BATTALION
CONTROL
SP HOWITZER
SERVICE
HQ
PLATOON
BATTERY
PLATOON
(p 2-21)
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
122-mm SP Howitzer, 2S1
18
Trailer, Cargo, 2-Axle
16
122-mm Laser-Guided Projectile
Trailer, Generator
2
Set, Kitolov-2M*
4
Trailer, Kitchen
3
ACRV, 1V13/1V13M/1V22 (Btry FDC)
3
Trailer, POL (4,200-Liter)
2
ACRV, 1V14/1V14M/1V23 (Btry COP)
3
Trailer, Water (1,200-Liter)
1
ACRV, 1V15/1V15M/1V24 (Bn COP)
1
Rangefinder, Laser, 1D8/1D12
7
ACRV, 1V16/1V16M/1V25 (Bn FDC)
1
Rangefinder, Laser, Binocular, LPR-1
9
Mobile Recon Post, PRP-3/4**
1
Night-Vision Sight, (Aiming Circle)
6
7.62-mm GP MG, PKM
18
Periscopic Aiming Circle, PAB2A
6
SAM, Shoulder-Fired
18
GPS Receiver
32
ATGL, RPG-7V
6
Radios:
Truck, Light
4
VHF, Manpack, Low-Power
10
Truck, Medium
14
VHF, Vehicle Mount,
Truck, POL (5,000-Liter)
2
Medium-Power
27
Van, Maintenance
2
HF/VHF, Vehicle Mount,
Van, Signal
4
Medium-Power
4
Ambulance
1
Warning Receiver
2
____________________________________
* Not all SP howitzer battalions have laser-guided projectiles (LGPs) allocated to them. A battalion
receiving LGPs normally designates one firing platoon in one of its batteries as a special weapons
platoon to fire these, as well as smoke and illuminating rounds. In addition to the firing weapon
(2S1), each LGP set typically includes a dismountable laser target designator (1D15M/1D20/
1D22), a 1A35 synchronizer, and 50 LGPs. Although most of the 200 LGPs are in the special
weapons platoon, each firing platoon in the battalion would have some. Each battery COP and
the battalion's mobile reconnaissance post get a laser target designator. Each battery FDC gets a
synchronizer, and the fourth is in the special weapons platoon.
** This system includes the SMALL FRED or TALL MIKE battlefield surveillance radar.
2-20
FM 100-60
122-mm SP Howitzer Battery,
122-mm SP How Bn________________________________ ____________________
SP HOWITZER
BATTERY
(122-mm)
MOTOR
BATTERY
CONTROL
FIRING
TRANSPORT
HQ
PLATOON
PLATOON
SECTION
PLATOON
GUN
HQ
SECTION
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
122-mm SP Howitzer, 2S1
6
Rangefinder, Laser, Binocular, LPR-1
3
ACRV, 1V13/1V13M/1V22 (Btry FDC)
1
Night-Vision Sight (Aiming Circle)
2
ACRV, 1V14/1V14M/1V23 (Btry COP)
1
Periscopic Aiming Circle, PAB2A
2
7.62-mm GP MG, PKM
6
GPS Receiver
10
SAM, Shoulder-Fired
6
Radios:
ATGL, RPG-7V
2
VHF, Manpack, Low-Power
2
Truck, Medium
3
VHF, Vehicle Mount,
Van, Signal
1
Medium-Power
8
Trailer, Cargo, 2-Axle
3
HF/VHF, Vehicle Mount,
Rangefinder, Laser, 1D8/1D12
2
Medium-Power
1
2-21
FM 100-60
122-mm Howitzer Battalion, MIBR (APC) (Div)
or 122-mm How Bde ________________________________ ___________________
HOWITZER
BATTALION
(122-mm)
SUPPLY &
BATTALION
CONTROL
HOWITZER
SERVICE
HQ
PLATOON
BATTERY
PLATOON
(p 2-23)
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
122-mm Howitzer, D-30
18
Trailer, Cargo, 2-Axle
14
122-mm Laser-Guided Projectile
Trailer, Generator
2
Set, Kitolov-2M*
4
Trailer, Kitchen
4
ACRV, 1V18/1V152 (Btry COP)**
3
Trailer, POL (4,200-Liter)
2
ACRV, 1V19/1V152 (Bn COP)**
1
Trailer, Water (900-Liter)
1
ACRV, 1V110/1V153 (Btry FDC)**
3
Rangefinder, Laser, 1D8/1D12
7
ACRV, 1V111/1V153 (Bn FDC)**
1
Rangefinder, Laser, Binocular, LPR-1
9
Mobile Recon Post, PRP-3/4***
1
Night-Vision Sight (Aiming Circle)
6
7.62-mm GP MG, PKM
18
Periscopic Aiming Circle, PAB2A
6
SAM, Shoulder-Fired
18
GPS Receiver
32
ATGL, RPG-7V
6
Radios:
Truck, Utility
1
VHF, Manpack, Low-Power
14
Truck, Light
9
VHF, Portable, Low-Power
Truck, Medium
34
or Very Low-Power
23
Truck, POL (5,000-Liter)
2
VHF, Vehicle Mount,
Van, Maintenance
1
Medium-Power
9
Van, Signal
4
HF/VHF, Vehicle Mount,
Ambulance
1
Medium-Power
4
Warning Receiver
2
__________________________________________
* Not all howitzer battalions have laser-guided projectiles (LGPs) allocated to them. A battalion
receiving LGPs normally designates one firing platoon in one of its batteries as a special weapons
platoon to fire these, as well as smoke and illuminating rounds. In addition to the firing weapon
(D-30), each LGP set typically includes a dismountable laser target designator (1D15M/1D20/
1D22), a 1A35 synchronizer, and 50 LGPs. Although most of the 200 LGPs are in the special
weapons platoon, each firing platoon in the battalion would have some. Each battery COP and
the battalion's mobile reconnaissance post get a laser target designator. Each battery FDC gets a
synchronizer, and the fourth is in the special weapons platoon.
** The 1V52 and 1V53 ACRVs are part of the Kapustnik-B automated fire control system.
*** This system includes the SMALL FRED or TALL MIKE battlefield surveillance radar.
2-22
FM 100-60
122-mm Howitzer Battery,
122-mm How Bn________________________________ _______________________
HOWITZER
BATTERY
(122-mm)
MOTOR
BATTERY
CONTROL
FIRING
TRANSPORT
HQ
PLATOON
PLATOON
SECTION
PLATOON
GUN
HQ
SECTION
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
122-mm Howitzer, D-30
6
Night-Vision Sight (Aiming Circle)
2
ACRV, 1V18/1V152 (Btry COP)**
1
Periscopic Aiming Circle, PAB2A
2
ACRV, 1V110/1V153 (Btry FDC)**
1
GPS Receiver
10
7.62-mm GP MG, PKM
6
Radios:
SAM, Shoulder-Fired
6
VHF, Manpack, Low-Power
2
ATGL, RPG-7V
2
VHF, Portable,
Truck, Medium
8
Very-Low-Power
7
Van, Signal
1
VHF, Vehicle Mount,
Trailer, Cargo, 2-Axle
2
Medium-Power
1
Rangefinder, Laser, 1D8/1D12
2
HF/VHF, Vehicle Mount,
Rangefinder, Laser, Binocular, LPR-1
3
Medium-Power
1
____________________________________
* The 1V152 and 1V153 ACRVs are part of the Kapustnik-B automated fire control system.
2-23
FM 100-60
Air Defense Battalion,
MIBR (Div) and TBR (Div) ________________________________ _______________
AIR
DEFENSE
BATTALION
SP AA
SAM
SAM
BATTALION
BATTERY
BATTERY
BATTERY
HQ
(2S6)
(SA-13)*
(Shoulder-Fired)
(p 2-25)
(p 2-26)
(p 2-27)
(p 2-28)
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
30-mm SP AA System, 2S6**
6
Trailer, Generator
2
SAM, SA-13/GOPHER TELAR***
6
Radios:
SAM, Shoulder-Fired
18
VHF, Portable, Low-Power
4
IFV, BMP-2/3****
6
VHF, Portable, Very Low-Power
8
ACV, PPRU*****
2
VHF, Vehicle Mount,
ACV, BTR-60 (PU-12)
2
Medium-Power
22
Truck, Light
3
HF, Vehicle Mount,
Truck, Medium
4
Medium-Power
1
Truck, POL (5,000-Liter)
2
Warning Receiver
4
____________________________________
* Some air defense battalions may not include the SA-13-equipped SAM battery.
** This system includes SA-19/GRISON SAM launchers and HOT SHOT target acquisition
and fire control radars.
*** This system includes a ranging radar.
**** In the mechanized infantry brigade (APC), this battalion may have six BTR-60/70/80
APCs in lieu of the BMP-2/3 in the shoulder-fired SAM battery.
***** This system includes the DOG EAR target acquisition radar.
2-24
FM 100-60
Battalion Headquarters,
Air Defense Bn ________________________________ ________________________
BATTALION
HEADQUARTERS
COMMAND
TRANSPORT
MAINT
SECTION
SECTION
SECTION
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
ACV, PPRU*
1
Radios:
Truck, Medium
4
VHF, Portable, Low-Power
1
Trailer, Generator
2
VHF, Vehicle Mount,
Medium-Power
1
HF, Vehicle Mount,
Medium-Power
1
Warning Receiver
1
____________________________________
* This system includes the DOG EAR target acquisition radar.
2-25
FM 100-60
SP AA Battery (2S6),
Air Defense Bn ________________________________ ________________________
SP AA
BATTERY
(2S6)
BATTERY
SP AA
TRANSPORT
HQ
PLATOON
SECTION
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
30-mm SP AA System, 2S6*
6
Radios:
ACV, BTR-60 (PU-12)
1
VHF, Portable, Low-Power
1
Truck, Light
1
VHF, Vehicle Mount,
Truck, Medium
4
Medium-Power
7
Trailer, Generator
2
Warning Receiver
1
____________________________________
* This system includes SA-19/GRISON SAM launchers and HOT SHOT target acquisition and
fire control radars.
2-26
FM 100-60
SAM Battery (SA-13),
Air Defense Bn ________________________________ ________________________
SAM
BATTERY
(SA-13)
BATTERY
SAM
TRANSPORT
HQ
PLATOON
SECTION
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
SAM, SA-13/GOPHER TELAR*
6
Radios:
ACV, PPRU**
1
VHF, Portable, Low-Power
1
Truck, Light
1
VHF, Vehicle Mount,
Medium-Power
7
Warning Receiver
1
____________________________________
* This system includes a ranging radar.
** This system includes the DOG EAR target acquisition radar.
2-27
FM 100-60
SAM Battery (Shoulder-Fired),
Air Defense Bn ________________________________ ________________________
SAM
BATTERY
(Shoulder-Fired)
BATTERY
SAM
TRANSPORT
HQ
PLATOON
SECTION
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
SAM, Shoulder-Fired
18
Radios:
IFV, BMP-2/3
6 **
VHF, Portable, Low-Power
1
ACV, BTR-60 (PU-12)
1
VHF, Portable, Very-Low-Power
8
Truck, Light
1
VHF, Vehicle Mount,
Medium-Power
7
Warning Receiver
1
____________________________________
* This SAM platoon differs from the one in an IFV-equipped mechanized infantry battalion (p
3-11) only by the fact that it tends to use IFVs mounting a 30-mm automatic cannon capable
of air defense missions in its own right.
** In the mechanized infantry brigade (APC), this battery may have BTR-60/70/80 APCs in lieu
of the IFVs. In that case the SAM platoons would be similar to the one in an APC-equipped
mechanized infantry battalion (p 3-25).
2-28
FM 100-60
Air Defense Battery,
MIBR (Div) and TBR (Div) ________________________________ _______________
AIR DEFENSE
BATTERY
SP AA
BATTERY
SAM
MAINT
GUN
HQ
PLATOON
SECTION
PLATOON
TRANSPORT
SECTION
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
SAM, SA-9/GASKIN TEL
Trailer, Generator
2
or SA-13/GOPHER TELAR*
4
Radios:
23-mm SP AA Gun, ZSU-23-4**
4
VHF, Manpack, Low-Power
2
ACV, BTR-60 (PU-12)***
3
VHF, Vehicle Mount,
Truck, Light
2
Medium-Power
11
Truck, Medium
2
Warning Receiver
3
Van, Maintenance
2
____________________________________
* The SA-13 system includes a ranging radar.
** This system includes the GUN DISH fire control radar. In lieu of the ZSU-23-4, some bat-
teries may have the 30-mm SP AA system 2S6, which includes SA-19/GRISON SAM
launchers and HOT SHOT target acquisition and fire control radars.
*** If the battery has tracked SA-13 and/or 2S6 systems, the ACV may be the tracked PPRU,
which includes a DOG EAR target acquisition radar.
2-29
FM 100-60
Air Defense Battalion,
MIBR (Sep) and TBR (Sep) ________________________________ ______________
AIR DEFENSE
BATTALION
SP AA
SAM
SAM
BATTALION
BATTERY
BATTERY
BATTERY
HQ
(2S6)
(SA-15)*
(SA-13)
(p 2-25)
(p 2-26)
(p 2-27)
(p 1-26)
SAM
BATTERY
(Shoulder-Fired)
(p 2-28)
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
30-mm SP AA System, 2S6**
6
Trailer, Cargo, 2-Axle
5
SAM, SA-15/GAUNTLET TELAR***
8
Trailer, Generator
2
SAM, SA-13/GOPHER TELAR****
6
Trailer, Kitchen
3
SAM, Shoulder-Fired
24
Radios:
IFV, BMP-2/3
6
VHF, Manpack, Low-Power
2
ACV, PPRU*****
2
VHF, Portable, Very-Low-Power
8
ACV, BTR-60 (PU-12)
4
VHF, Portable, Low-Power
4
SA-15 Missile Transloader
VHF, Vehicle Mount,
(TELAR Chassis)
4
Medium-Power
32
Truck, Crane
1
HF, Vehicle Mount,
Truck, Light
7
Medium-Power
1
Truck, Medium
6
Warning Receiver
6
____________________________________
* In some separate mechanized infantry brigades, the air defense battalion may have SA-8-
equipped SAM batteries (see p 1-32) rather than the SA-15 batteries shown here.
** This system includes SA-19/GRISON SAM launchers and HOT SHOT target acquisition
and fire control radars.
*** This system includes the SCRUM HALF fire control/target acquisition radar.
**** This system includes a ranging radar.
***** This system includes the DOG EAR target acquisition and fire control radar.
2-30
FM 100-60
ATGM Battery, MIBR (Div)
or AT Bn, MIBR (Div) or MID ________________________________ _____________
ATGM
BATTERY
MOTOR
BATTERY
FIRING
TRANSPORT
HQ
PLATOON
SECTION
PLATOON
ATGM
HQ
SQUAD
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
ATGM, Vehicle, 9P148
Radar, Battlefield Surveillance, Man-
w/ AT-5/SPANDREL
9
Portable, PSNR-1 or TALL MIKE
1
ATGL, RPG-7V
9
Radios:
ACV, BRDM-2U
4
VHF, Manpack, Low-Power
4
Truck, Medium
3
VHF, Vehicle Mount,
Rangefinder, Laser, 1D8/1D12
1
Medium-Power
13
2-31
FM 100-60
Antitank Battalion,
MIBR (Div) ________________________________ ___________________________
ANTITANK
BATTALION
ANTITANK
SUPPLY &
BATTALION
ATGM
GUN
SERVICE
HQ
BATTERY
BATTERY
PLATOON
(p 1-43)
(p 1-44)
(pp 2-31/ 2-35)
(p 2-33)
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total *
Equipment
Total *
ATGM Vehicle, 9P148
Trailer, Generator
1
w/ AT-5/SPANDREL
9-12
Trailer, Kitchen
1
100/125-mm Antitank Gun,
Trailer, POL (1,200-/4,200-Liter)***
1
MT-12/2A45M
6
Trailer, Water (900-Liter)
1
ACV, BTR (R-145BM)/BRDM-2U
1
Rangefinder, Laser, 1D8/1D12
2
ACV, BRDM-2U
4
Radar, Battlefield Surveillance, Man-
ATGL, RPG-7V
9-12
Portable, PSNR-1 or TALL MIKE
2
Mobile Recon Post, PRP-3/4**
1
Radios:
Prime Mover, MT-LBT
7
VHF, Manpack, Low-Power
9
Truck, Utility
3
VHF, Vehicle Mount,
Truck, Light
4
Medium-Power
22-25
Truck, Medium
11
HF/VHF, Vehicle Mount,
Truck, POL (5,000-Liter)
3
Medium-Power
3
Van, Maintenance
2
HF, Vehicle Mount,
Van, Signal
2
Medium-Power
1
Ambulance
1
Radio Relay, VHF/UHF
1
Trailer, Cargo, 2-Axle
9
Warning Receiver
1
____________________________________
* Equipment totals can vary, depending on whether the battalion's ATGM battery has 9 or 12
ATGM vehicles.
** This system includes the SMALL FRED or TALL MIKE battlefield surveillance radar.
*** The size of this POL trailer depends on whether the battalion's ATGM battery has 9 or 12
ATGM vehicles.
2-32
FM 100-60
Supply and Service Platoon,
AT Bn, MIBR (Div) ________________________________ _____________________
SUPPLY &
SERVICE
PLATOON
MOTOR
PLATOON
MESS
MAINT
TRANSPORT
HQ
SECTION
SECTION
SECTION
MEDICAL
SECTION
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
Truck, Utility
1
Trailer, Generator
1
Truck, Light
4
Trailer, Kitchen
1
Truck, Medium
7
Trailer, POL (1,200-/4,200-Liter)*
1
Truck, POL (5,000-Liter)
3
Trailer, Water (900-Liter)
1
Van, Maintenance
2
Radios:
Van, Signal
2
VHF, Manpack, Low-Power
3
Ambulance
1
HF/VHF, Vehicle Mount,
Trailer, Cargo, 2-Axle
8
Medium-Power
1
____________________________________
* The size of the POL trailer depends on whether the battalion's ATGM battery has 9 or 12
ATGM vehicles.
2-33
FM 100-60
Antitank Battalion,
MIBR (Sep) ________________________________ ___________________________
ANTITANK
BATTALION
ANTITANK
SUPPLY &
BATTALION
ATGM
GUN
SERVICE
HQ
BATTERY
BATTERY
PLATOON
(p 1-43)
(p 2-35)
(p 2-36)
(p 1-44)
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total *
Equipment
Total *
ATGM Vehicle , 9P148
Trailer, Generator
1
w/ AT-5/SPANDREL
12
Trailer, Kitchen
1
100/125-mm Antitank Gun,
Trailer, POL (1,200-Liter)
1
MT-12/2A45M
6-12
Trailer, Water (900-Liter)
1
ATGL, RPG-7V
12
Rangefinder, Laser, 1D8/1D12
2-3
ACV, BTR (R-145BM)/BRDM-2U
5
Radar, Battlefield Surveillance, Man-
ACV, BRDM-2U
4
Portable, PSNR-1 or TALL MIKE
2-3
Mobile Recon Post, PRP-3/4**
1
Radios:
Prime Mover, MT-LBT
7-14
VHF Manpack, Low-Power
9-10
Truck, Utility
3
VHF, Vehicle Mount,
Truck, Light
4
Medium-Power
24-31
Truck, Medium
10-13
HF, Vehicle Mount,
Truck, POL (5,000-Liter)
3
Medium-Power
1
Van, Maintenance
2
HF/VHF, Vehicle Mount,
Van, Signal
2
Medium-Power
3
Ambulance
1
Radio Relay, VHF/UHF
1
Trailer, Cargo, 2-Axle
9-10
Warning Receiver
1
____________________________________
* Equipment totals can vary, depending on whether the battalion has one or two antitank gun
batteries.
** This system includes the SMALL FRED or TALL MIKE battlefield surveillance radar.
2-34
FM 100-60
ATGM Battery, AT Bn,
MIBR or MID ________________________________ __________________________
ATGM
BATTERY
MOTOR
BATTERY
FIRING
TRANSPORT
HQ
PLATOON
SECTION
PLATOON
ATGM
HQ
SQUAD
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
ATGM, Vehicle, 9P148
Radar, Battlefield Surveillance, Man-
w/ AT-5/SPANDREL
12
Portable, PSNR-1 or TALL MIKE
1
ATGL, RPG-7V
12
Radios:
ACV, BRDM-2U
4
VHF, Manpack, Low-Power
4
Truck, Medium
4
VHF, Vehicle Mount,
Rangefinder, Laser, 1D8/1D12
1
Medium-Power
16
2-35
FM 100-60
Supply and Service Platoon,
AT Bn, MIBR (Sep) ________________________________ _____________________
SUPPLY &
SERVICE
PLATOON
MOTOR
PLATOON
MESS
MAINT
TRANSPORT
HQ
SECTION
SECTION
SECTION
MEDICAL
SECTION
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total *
Equipment
Total *
Truck, Utility
1
Trailer, Generator
1
Truck, Light
4
Trailer, Kitchen
1
Truck, Medium
5-7
Trailer, POL (1,200-Liter)
1-2
Truck, POL (5,000-Liter)
3
Trailer, Water (900-Liter)
1
Van, Maintenance
2
Radios:
Van, Signal
2
VHF, Manpack, Low-Power
3
Ambulance
1
HF/VHF, Vehicle Mount,
Trailer, Cargo, 2-Axle
8
Medium-Power
1
____________________________________
* Equipment totals can vary, depending on whether the battalion has one or two antitank gun
batteries.
2-36
FM 100-60
Reconnaissance Company,
MIBR (Div) and TBR (Div) ________________________________ _______________
RECON
COMPANY
RECON
RECON
COMPANY
MOTORCYCLE
PLATOON
PLATOON
HQ
SECTION*
(Tracked)
(Wheeled)
(p 2-39)
(p 2-39)
(p 2-38)
BRM-1K/3K
1
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total **
Equipment
Total **
ACV, BRM-1K/3K***/****
2-3
Night-Vision Sight (Small Arms)
8-11
IFV, BMP-1/2/3***
2-4
Radar, Battlefield Surveillance, Man-
ASC, BRDM-2
4
Portable, PSNR-1 or TALL MIKE
1
9-mm Pistol, PM
13-22
Radios:
5.45-mm Assault Rifle, AK-74
25-34
VHF, Manpack, Low-Power
4-7
5.45-mm LMG, RPK-74
4-7
VHF, Portable, Low-Power
4
40-mm Under-Barrel Grenade Launcher,
VHF, Vehicle Mount,
GP-25/30
10-15
Medium-Power
8-11
ATRL, RPG-22/26
8-11
HF, Vehicle Mount,
ATGL, RPG-7V
4-7
Medium-Power
1
Flamethrower, RPO
4-7
Warning Receiver
1
Night-Vision Goggles
8-11
____________________________________
* Although some reconnaissance companies have a motorcycle section, equipment totals on
this page do no include that section.
** Equipment totals can vary, depending on whether the company has one or two tracked
reconnaissance platoons.
*** The mix of IFVs and ACVs within a tracked reconnaissance platoon can vary.
**** This system includes the TALL MIKE battlefield surveillance radar.
2-37
FM 100-60
Reconnaissance Platoon (Tracked),
Recon Co or Recon and EC Co ________________________________ __________
RECON
PLATOON
(Tracked)
PLATOON
RECON
HQ
SQUAD
BRM-1K/3K
1
BMP-1/2/3
1
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
ACV, BRM-1K/3K*/**
1
40-mm Under-Barrel Grenade Launcher,
IFV, BMP-1/2/3*
2
GP-25/30
5
9-mm Pistol, PM
9
Night-Vision Goggles
3
5.45-mm Assault Rifle, AK-74
9
Night-Vision Sight (Small Arms)
3
5.45-mm LMG, RPK-74
3
Radios:
ATGL, RPG-7V***
3
VHF, Manpack, Low-Power
3
ATRL, RPG-22/26
3
VHF, Vehicle Mount,
Flamethrower, RPO
3
Medium-Power
3
____________________________________
* The mix of BRM-1K/3K and BMP vehicles can vary.
** This vehicle includes the TALL MIKE battlefield surveillance radar.
*** In units equipped with the BRM-3K, an ATGM manpack launcher (AT-4/SPIGOT or AT-
7/SAXHORN) may replace the one ATGL in that vehicle.
2-38
FM 100-60
Reconnaissance Platoon (Wheeled),
Recon Co, MIBR and TBR, or Recon and EC Co ____________________________
RECON
PLATOON
(Wheeled)
PLATOON
RECON
HQ
SQUAD
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
ASC, BRDM-2
4
Night-Vision Sight (Small Arms)
4
9-mm Pistol, PM
1
Radar, Battlefield Surveillance, Man-
5.45-mm Assault Rifle, AK-74
15
Portable, PSNR-1 or TALL MIKE
1
40-mm Under-Barrel Grenade Launcher,
Radios:
GP-25/30
4
VHF, Portable, Low-Power
4
ATRL, RPG-22/26
4
VHF, Vehicle Mount,
Night-Vision Goggles
4
Medium-Power
4
Motorcycle Section,
Recon Co or Recon and EC Co ________________________________ __________
MOTORCYCLE
SECTION
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
Motorcycle
3
Night-Vision Goggles
1
5.45-mm Assault Rifle, AK-74
6
Radio, VHF, Portable, Low-Power
1
40-mm Under-Barrel Grenade Launcher,
GP-25/30
1
2-39
FM 100-60
Reconnaissance and Electronic Combat Company,
MIBR (Sep) and TBR (Sep) ________________________________ ______________
RECON
& EC
COMPANY
RECON
RECON
COMPANY
JAMMING
PLATOON
PLATOON
HQ
PLATOON
(Tracked)
(Wheeled)
(p 2-39)
(p 2-41)
(p 2-38)
MOTORCYCLE
SECTI0N*
(p 2-39)
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total **
Equipment
Total **
ACV, BRM-1K/3K***/****
2-3
Communications Jammer, VHF,
IFV, BMP-1/2/3***
2-4
R-330P
3
ASC, BRDM-2
4
Communications Jammer, HF
1
9-mm Pistol, PM
13-22
Proximity Fuze Jammer, SPR
3
5.45-mm Assault Rifle
25-34
Radar, Battlefield Surveillance, Man-
5.45-mm LMG, RPK-74
4-7
Portable, PSNR-1 or TALL MIKE
1
40-mm Under-Barrel Grenade Launcher,
Radios:
GP-25/30
10-15
VHF, Manpack, Low-Power
4-7
ATGL, RPG-7V
4-7
VHF, Portable, Low-Power
4
ATRL, RPG-22/26
8-11
VHF, Vehicle Mount,
Flamethrower
4-7
Medium-Power
18-21
Night-Vision Goggles
8-11
HF, Vehicle Mount,
Night-Vision Sight (Small Arms)
8-11
Medium-Power
1
Radio Intercept/Direction Finder
3
Warning Receiver
1
____________________________________
* Although some reconnaissance and EC companies have a motorcycle section, equipment
totals on this page do not include that section.
** Equipment totals can vary depending on whether the company has one or two tracked re-
connaissance platoons. Totals for small arms and night-vision devices do not include the
jamming platoon, where such equipment varies.
*** The mix of IFVs and ACVs within a tracked reconnaissance platoon can vary. The com-
pany headquarters always has one ACV.
**** This system includes the TALL MIKE battlefield surveillance radar.
2-40
FM 100-60
Jamming Platoon,
Recon and EC Co ________________________________ _____________________
JAMMING
PLATOON
RADIO
RADIO
FUZE
PLATOON
INTERCEPT
JAMMING
JAMMING
HQ
SECTION
SECTION
SECTION
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
Radio Intercept/Direction Finder*
3
Proximity Fuze Jammer, SPR*
3
Communications Jammer, VHF,
Radio, VHF, Vehicle Mount
R-330P*
3
Medium-Power
10
Communications Jammer, HF*
1
____________________________________
* These systems are normally mounted on armored vehicles.
2-41
FM 100-60
Engineer Company,
MIBR (Div) and TBR (Div) ________________________________ _______________
ENGINEER
COMPANY
MINE
COMPANY
BRIDGE
CONSTRUCTION
WARFARE
HQ
PLATOON
PLATOON
PLATOON
TRANSPORT
PLATOON*
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total *
Equipment
Total *
ACV, BTR (R-145BM)
1
Armored Engineer Tractor, IMR
1
ATRL, RPG-22/26
5/7
Route-Clearing Vehicle, BAT
1
Flamethrower, LPO/RPO
4
Minelayer, GMZ**
3
Truck, Utility
4/6
Mine Roller-Plow
3/9
Truck, Medium
8/9
Mine Detector, DIM
1
Truck, Heavy, with Crane
3/9
Trailer, Cargo, 1-Axle
6
Truck, Crane
1
Trailer, Cargo, 2-Axle
2/3
Truck, Crane Shovel
1
Radios:
Truck, Dump
2
VHF, Vehicle Mount,
Truck, Water Purification
1
Medium-Power
13/21
Van, Maintenance
1
HF/VHF, Manpack,
Bridge, Tank-Launched
1/3
Low-Power
4/6
Bridge, Truck-Launched, TMM
4
HF, Vehicle Mount,
Ditching Machine, BTM/MDK
1
Medium-Power
1
Ditching Machine, PZM/TMK
3
____________________________________
* Totals listed with multiple numbers (such as 5/7) reflect the numbers of that particular piece
of equipment in the engineer company of a mechanized infantry brigade or tank brigade, re-
spectively. The divisional mechanized infantry brigade requires only one tank-launched
bridge and only one transport platoon to carry its mine roller-plows. The divisional tank bri-
gade requires three tank-launched bridges and three transport platoons.
** Some units may have PMR towed minelayers instead of GMZ armored, tracked minelayers.
Trucks normally tow PMR minelayers.
2-42
FM 100-60
Engineer Battalion,
MIBR (Sep) ________________________________ ___________________________
ENGINEER
BATTALION
MINE
ASSAULT
BATTALION
CONSTRUCTION
WARFARE
CROSSING
HQ
PLATOON
COMPANY
COMPANY
(p 1-56)
(p 1-57)
ENGINEER
SUPPLY &
SIGNAL
TRANSPORT
RECON
SERVICE
PLATOON
PLATOON
PLATOON
PLATOON
(p 2-45)
Principal Items of Equipment
ARMORED VEHICLES
APC, BTR-60/70/80
3
3
ACV, BTR (R-145BM)
1
1
ACV, BRDM-2U
1
1
WEAPONS
ATRL, RPG-22/26
3
1
4
SAM, Shoulder-Fired
3
3
ENGINEER EQUIPMENT
Bridge, Truck-Launched
4
4
Tracked Amphibian, K-61/PTS
12
12
Trailer, Amphibious, PKP
6
6
Tracked Ferry, GSP/PMM-2*
6
6
Assault Boat
10
10
Minelayer, GMZ
3
3
Mine Roller-Plow
5
5
Mineclearer, MTK/MTK-2
2
2
Mine Detector, DIM
2
1
3
Engineer Recon Vehicle, IRM
2
2
Armored Engineer Tractor, IMR
2
2
Ditching Machine, BTM/MDK
2
2
Route-Clearing Vehicle, BAT/PKT
2
2
Tractor
1
1
Truck, Water Purification
1
1
* With the PMM-2, there are a total of 8 ferries rather than 6
(continued)
2-43
FM 100-60
Engineer Battalion, MIBR (Sep) (continued) ________________________________
Principal Items of Equipment
TRUCKS
Truck, Utility
2
1
2
1
1
1
8
Truck, Medium
1
5
2
6
1
1
2
18
Truck, Heavy, with Crane
5
5
Truck, Crane
1
1
Truck, Crane Shovel
2
2
Truck, Dump
1
1
Truck, POL (5,000-Liter)
5
5
Van, Maintenance
4
4
Van, Signal
1
1
2
TRAILERS
Trailer, Cargo, 1-Axle
1
2
3
Trailer, Cargo, 2-Axle
1
1
1
3
Trailer, Compressor
1
1
Trailer, Generator
1
1
1
3
Trailer, Kitchen
1
1
2
Trailer, POL (4,200-Liter)
5
5
Trailer, Water (900-Liter)
1
1
2
RADIOS
VHF, Manpack, Low-Power
4
4
VHF, Vehicle Mount, Medium-Power
8
3
4
3
5
23
HF, Manpack, Low-Power
1
3
1
1
3
1
10
HF, Vehicle Mount, Medium-Power
1
1
HF/VHF, Vehicle Mount, Medium-Power
1
1
2
HF/VHF, Vehicle Mount, High-Power
1
1
2
Warning Receiver
1
1
2-44
FM 100-60
Transport Platoon, Engr Bn,
MIBR (Sep) or Transport Co ________________________________ _____________
TRANSPORT
PLATOON
COMPANY
TRANSPORT
HQ
SECTION*
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total *
Equipment
Total *
ATRL, RPG-22/26
1
Radios:
Truck, Utility
1
VHF, Vehicle Mount,
Truck, Heavy, with Crane
3-5
Medium-Power
3-5
Mine Roller-Plow
3-5
HF Manpack, Low-Power
1
____________________________________
* The number of transport sections per platoon corresponds to the number of tank companies in
each of the brigade's tank battalions. Equipment totals vary, depending on the number of sec-
tions in the platoon.
2-45
FM 100-60
Signal Company,
MIBR and TBR ________________________________ ________________________
SIGNAL
COMPANY
WIRE/
COMPANY
RADIO
TELEPHONE
HQ
PLATOON
PLATOON
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total *
Equipment
Total
ACV, BMP-1KSh
5/0
Radios:***
ACV, BTR (R-145BM)
3/8
VHF, Manpack, Low-Power
7
Truck, Utility
5
VHF, Vehicle Mount,
Truck, Light
3
Medium-Power
8
Van, Signal
5
HF, Manpack, Low-Power
2
Motorcycle**
3
HF, Vehicle Mount,
Trailer, Generator
1
Medium-Power
8
HF, Vehicle Mount, High-Power
1
HF/VHF, Vehicle Mount,
Medium-Power
2
HF/VHF, Vehicle Mount,
High-Power
2
Radio Relay, VHF/UHF
2
Warning Receiver
3
____________________________________
* Totals listed with multiple numbers (such as 3/8) reflect the numbers of that particular piece
of equipment in the signal company of a mechanized infantry brigade (IFV) and tank brigade
or the signal company of a mechanized infantry brigade (APC), respectively.
** Motorcycles provide the brigade commander with messenger/courier service.
*** The radios listed normally support the brigade headquarters, but some may be attached to
subordinate headquarters.
2-46
FM 100-60
Chemical Defense Platoon, MIBR (Div)
and TBR (Div) or SP Arty Regt or SAM Regt or Engr Bde _____________________
CHEMICAL
DEFENSE
PLATOON
CHEMICAL
VEHICLE
PERSONNEL
PLATOON
RECON
DECON
DECON
HQ
SQUAD
SQUAD
SQUAD
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
Chemical Recon Vehicle,
Trailer, Water (1,200-Liter)
2
BRDM-2RKh or RKhM*
3
Radios:
Truck, Decon, ARS-12U/14
3
VHF, Vehicle Mount,
Truck, Decon, DDA-53/66
1
Medium-Power
3
Truck, Water (2,000-Liter)
2
HF, Manpack, Low-Power
1
____________________________________
* The tracked RKhM is more common in mechanized infantry (IFV-equipped), tank, and SP ar-
tillery units. In other units, the wheeled BRDM-2RKh is more common, and even the truck-
mounted UAZ-69RKh may appear.
2-47
FM 100-60
Chemical Defense Company,
MIBR (Sep) and TBR (Sep) ________________________________ ______________
CHEMICAL
DEFENSE
COMPANY
CHEMICAL
SUPPLY &
COMPANY
DECON
RECON
SERVICE
HQ
PLATOON
PLATOON
PLATOON
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
Chemical Recon Vehicle,
Truck, Water (2,000-Liter)
2
BRDM-2RKh/RKhM
4
Trailer, Water (1,200-Liter)
2
Truck, Decon, ARS-12U/14
8
Trailer, Water (900-Liter)
2
Truck, Decon, DDA-53/66
4
Radios:
Truck, Decon, TMS-65
2
VHF, Manpack, Low-Power
4
Truck, Utility
2
VHF, Vehicle Mount,
Truck, Light
3
Medium-Power
4
Truck, Medium
6
HF, Manpack, Low-Power
2
Truck, POL (4,000-Liter)
2
2-48
FM 100-60
Materiel Support Company,
MIBR (Div) and TBR (Div) ________________________________ _______________
MATERIEL
SUPPORT
COMPANY
AMMO & CARGO
POL
SUPPLY &
COMPANY
TRANSPORT
TRANSPORT
SERVICE
HQ
PLATOON
PLATOON
PLATOON
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
Truck, Utility
2
Trailer, Cargo, 2-Axle
30
Truck, Light
4
Trailer, Generator
1
Truck, Medium
45
Trailer, Kitchen
2
Truck, POL (5,000-Liter)
15
Trailer, POL (4,200-Liter)
15
Truck, Water (2,000-Liter)
4
Trailer, Water (1,200-Liter)
1
Van, Maintenance
1
Radio, VHF, Manpack, Low-Power
1
2-49
FM 100-60
Maintenance Company,
MIBR and TBR ________________________________ ________________________
MAINTENANCE
COMPANY
WHEELED
TRACKED
WPN/ORD
COMPANY
VEH REPAIR
VEH REPAIR
REPAIR
HQ
PLATOON
PLATOON
PLATOON
SPECIAL
MOBILE
RECOVERY
MAINT
REPAIR
PLATOON
PLATOON*
PLATOON**
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
MIBR TBR
Equipment
MIBR TBR
ATRL, RPG-22/26
4
4
Trailer, Cargo, 2-Axle
6
6
Truck, Utility
1
1
Trailer, Generator
3
3
Truck, Medium
2
2
Radios:
Van, Maintenance
12
12
VHF, Manpack,
Armored Maintenance
Low-Power
1
1
Vehicle, MTP
3
0
VHF, Vehicle Mount,
Armored Recovery Vehicle
3
5
Medium-Power
6
5
____________________________________
* The special maintenance platoon consists of an arc and gas welding section, a battery repair
and recharging section, and an electrical repair section.
** The mobile repair platoon normally is only present in IFV-equipped mechanized infantry bri-
gades. The platoon consists of three sections, each equipped with an MTP armored mainte-
nance vehicle. During field operations, one MTP supports each mechanized infantry battal-
ion.
2-50
FM 100-60
Medical Platoon, MIBR (Div) and TBR (Div) or SP Arty Regt
or 152-mm Arty Bde or MRL Bde or Engr Bde ______________________________
MEDICAL
PLATOON
ADMIN/
HQ
TREATMENT
COLLECTION
DISPOSITION
SECTION
SECTION
SECTION*
SECTION
SUPPLY &
SERVICE
SECTION
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
Truck, Light
1
Ambulance
4
Truck, Medium
2
Trailer, Kitchen
1
Truck, Decon, DDA-53/66
1
Trailer, Water (1,200-Liter)
1
Van, Hospital
1
Radio, VHF, Manpack, Low-Power
1
____________________________________
* Some medical platoons, particularly those in mechanized infantry and tanks units, have two
collection sections. In that case, there are four additional ambulances. Other general purpose
trucks may serve as ambulances.
2-51
FM 100-60
Medical Company,
MIBR (Sep) and TBR (Sep) ________________________________ ______________
MEDICAL
COMPANY
INTERNAL
RECEIVING &
COMPANY
SURGICAL
MEDICINE
EVACUATION
HQ
PLATOON
PLATOON
PLATOON
RESUSCITATION
DENTAL
PHARMACY
MORGUE
SECTION
SECTION
SECTION
SUPPLY &
TRANSPORT
SERVICE
SECTION
SECTION
PRINCIPAL ITEMS OF EQUIPMENT
Equipment
Total
Equipment
Total
Truck, Utility
1
Trailer, Cargo, 2-Axle
7
Truck, Medium*
7
Trailer, Generator
2
Truck, Water (2,000-Liter)
2
Trailer, Kitchen
2
Van, Hospital
9
Trailer, Water (1,200-Liter)
1
Ambulance
4
Radio, VHF, Manpack, Low-Power
1
____________________________________
* In better-equipped units, additional hospital vans may replace these general-purpose cargo
trucks. Cargo trucks may also serve as ambulances.
2-52
FM 100-60
Tank Brigade (Div),
MID ________________________________ ________________________________ _
TANK
BRIGADE
(DIV)
SP HOWITZER
AIR DEFENSE
BRIGADE
TANK
BATTALION
BATTALION/
HQ
BATTALION
(122-mm)
BATTERY
(p 2-54)
(p 2-20)
(pp 2-24/2-29)
(pp 3-31/3-40)
CHEMICAL
RECON
ENGINEER
SIGNAL
DEFENSE
COMPANY
COMPANY
COMPANY
PLATOON
(p 2-37)
(p 2-42)
(p 2-46)
(p 2-47)
MATERIEL
MAINT
MEDICAL
SUPPORT
COMPANY
PLATOON
COMPANY
(p 2-49)
(p 2-50)
(p 2-51)
(continued)
2-53
FM 100-60
Tank Brigade (Div), MID (continued) ________________________________ ______
Principal Items of Equipment
ARMORED VEHICLES
Medium Tank, T-64K/72K/80K
1
3
4
Medium Tank, T-64/72/80
90
90
ACV, BMP-1K/2K/3K
3
3
6
IFV, BMP-1/2/3
6
4
10
ACV, BMP-1KSh
5
5
ACV, BRM-1K/3K*
3
3
APC, BTR-60/70/80
1
1
ACV, BTR (R-145BM)
3
1
3
7
APC, BTR-60PA (FAC)
1
1
ASC, BRDM-2
4
4
Chem Recon Vehicle, BRDM-2RKh/RKhM
3
3
Mobile Recon Post, PRP-3/4**
1
1
ACRV, 1V13/1V13M/1V22
3
3
ACRV, 1V14/1V14M/1V23
3
3
ACRV, 1V15/1V15M/1V24
1
1
ACRV, 1V16/1V16M/1V25
1
1
ACV, PPRU***
2
2
ACV, BTR-60 (PU-12)
2
2
Armored Recovery Vehicle
5
5
WEAPONS
122-mm SP Howitzer, 2S1
18
18
122-mm Laser-Guided Projectile Set
4
4
30-mm SP AA System, 2S6****
6
6
SAM, SA-13/GOPHER TELAR*****
6
6
SAM, Shoulder-Fired
3
18
18
39
ENGINEER EQUIPMENT
Bridge, Tank-Launched
3
3
Bridge, Truck-Launched
4
4
Minelayer, GMZ
3
3
Mineclearing Plow
27
27
Mine Roller-Plow
9
9
Mine Detector, DIM
1
1
Armored Engineer Tractor, IMR
1
1
Ditching Machine, BTM/MDK
1
1
Ditching Machine, PZM/TMK
3
3
Route-Clearing Vehicle, BAT
1
1
Truck, Water Purification
1
1
* This system includes the TALL MIKE battlefield surveillance radar.
** This system includes the SMALL FRED or TALL MIKE battlefield surveillance radar.
*** This system includes the DOG EAR target acquisition radar.
**** This system includes SA-19/GRISON SAM launchers and HOT SHOT target acquisition and fire control radars.
***** This system includes a ranging radar.
(continued)
2-54
FM 100-60
Tank Brigade (Div), MID (continued) ________________________________ ______
Principal Items of Equipment
TRUCKS
Truck, Utility
3
6
5
2
1
17
Truck, Light
4
3
3
4
1
15
Truck, Medium
1
21
14
4
9
45
2
2
98
Truck, Heavy, with Crane
9
9
Truck, Crane
1
1
Truck, Crane Shovel
1
1
Truck, Decon, ARS-12U/14
3
3
Truck, Decon, DDA-53/66
1
1
2
Truck, Dump
2
2
Truck, POL (5,000-L)
15
2
2
15
34
Truck, Water (2,000-L)
2
4
6
Van, Command
3
3
Van, Hospital
1
1
Van, Kitchen
3
3
Van, Maintenance
3
2
1
1
12
19
Van, Signal
4
5
9
Ambulance
3
1
4
8
TRAILERS
Trailer, Cargo, 1-Axle
3
6
9
Trailer, Cargo, 2-Axle
18
16
3
30
6
73
Trailer, Generator
3
2
2
1
1
3
12
Trailer, Kitchen
3
2
1
6
Trailer, POL (4,200-L)
12
2
15
29
Trailer, Water (900/1,200-L)
3
1
2
1
1
8
RADAR
Radar, Battlefield Surveillance, Man-
1
1
Portable, PSNR-1 or TALL MIKE
RADIOS
VHF, Manpack, Low-Power
3
3
10
7
7
1
1
1
33
VHF, Portable, Low-Power
4
4
8
VHF, Portable, Very-Low-Power
8
8
VHF, Vehicle Mount, Medium-Power
3
99
27
22
11
21
8
3
5
199
HF, Manpack, Low-Power
6
6
2
1
15
HF, Vehicle Mount, Medium-Power
1
18
1
1
1
8
30
HF/VHF, Vehicle Mount, Medium-Power
4
2
6
HF/VHF, Vehicle Mount, High-Power
2
2
HF, Vehicle Mount, High-Power
1
1
Radio Relay, VHF/UHF
2
2
Warning Receiver
3
2
4
1
3
13
MISCELLANEOUS
Rangefinder, Laser
7
7
Rangefinder, Laser, Binocular
30
30
GPS Receiver
32
32
Motorcycle
3
3
2-55
FM 100-60
Tank Brigade (Div),
TD ________________________________ ________________________________ __
TANK
BRIGADE
(DIV)
MECHANIZED
SP HOWITZER
BRIGADE
TANK
INFANTRY
BATTALION
HQ
BATTALION
BN (IFV)
(122-mm)
(p 2-57)
(p 3-3)
(p 2-20)
(pp 3-31/3-40)
AIR DEFENSE
RECON
ENGINEER
SIGNAL
BATTALION/
COMPANY
COMPANY
COMPANY
BATTERY
(pp 2-24/2-29)
(p 2-37)
(p 2-42)
(p 2-46)
CHEMICAL
MATERIEL
MAINT
MEDICAL
DEFENSE
SUPPORT
COMPANY
PLATOON
PLATOON
COMPANY
(p 2-47)
(p 2-49)
(p 2-50)
(p 2-51)
(continued)
2-56
FM 100-60
Tank Brigade (Div), TD (continued) ________________________________ _______
Principal Items of Equipment
ARMORED VEHICLES
Medium Tank, T-64K/72K/80K*
1
3
4
Medium Tank, T-64/72/80
90
90
ACV, BMP-1K/2K/3K**
3
2
3
8
IFV, BMP-1/2/3
41
6
4
51
ACV, BMP-1KSh
5
5
ACV, BRM-1K/3K***
1
3
4
APC, BTR-60/70/80
1
1
ACV, BTR (R-145BM)****
3
2
1
3
9
APC, BTR-60PA (FAC)
1
1
ASC, BRDM-2
4
4
Chem Recon Vehicle, BRDM-2RKh/RKhM
3
3
Mobile Recon Post, PRP-3/4*****
1
1
ACRV, 1V13/1V13M/1V22
3
3
ACRV, 1V14/1V14M/1V23
3
3
ACRV, 1V15/1V15M/1V24
1
1
ACRV, 1V16/1V16M/1V25
1
1
ACV, PPRU******
2
2
ACV, BTR-60 (PU-12)
2
2
Armored Recovery Vehicle
5
5
WEAPONS
30-mm Auto Grenade Launcher, AGS-17
6
6
120-mm or 82-mm Mortar
6
6
122-mm SP Howitzer, 2S1
18
18
122-mm Laser-Guided Projectile Set
4
4
ATGM Manpack, AT-7/SAXHORN
9
9
30-mm SP AA System, 2S6*******
6
6
SAM, SA-13/GOPHER TELAR********
6
6
SAM, Shoulder-Fired
3
9
18
18
48
ENGINEER EQUIPMENT
Bridge, Tank-Launched
3
3
Bridge, Truck-Launched
4
4
Minelayer, GMZ
3
3
Mineclearing Plow
27
27
Mine Roller-Plow
9
9
Mine Detector, DIM
1
1
Armored Engineer Tractor, IMR
1
1
Ditching Machine, BTM/MDK
1
1
Ditching Machine, PZM/TMK
3
3
Route-Clearing Vehicle, BAT
1
1
Truck, Water Purification
1
1
* One of the three tank brigades in a tank division has a second command tank, probably for the tank division
commander.
** In lieu of these BMP command variants, some mechanized infantry battalions may have an
ACV, BTR (R-145BM), or an ACV, BMP-1KSh.
*** This system includes the TALL MIKE battlefield surveillance radar.
**** Some IFV-equipped mechanized infantry battalions may have the ACV, BMP-1KSh, instead of the
ACV, BTR (R-145BM).
***** This system includes the SMALL FRED or TALL MIKE battlefield surveillance radar.
****** This system includes the DOG EAR target acquisition radar.
******* This system includes SA-19/GRISON SAM launchers and HOT SHOT target acquisition and fire control radars.
******** This system includes a ranging radar.
(continued)
2-57
FM 100-60
Tank Brigade (Div), TD (continued) ________________________________ _______
Principal Items of Equipment
TRUCKS
Truck, Utility
3
4
6
5
2
1
21
Truck, Light
13
4
3
3
4
1
28
Truck, Medium
1
21
4
14
4
9
45
2
2
102
Truck, Heavy, with Crane
9
9
Truck, Crane
1
1
Truck, Crane Shovel
1
1
Truck, Decon, ARS-12U/14
3
3
Truck, Decon, DDA-53/66
1
1
2
Truck, Dump
2
2
Truck, POL (5,000-L)
15
3
2
2
15
37
Truck, Water (2,000-L)
2
4
6
Van, Command
3
3
Van, Hospital
1
1
Van, Kitchen
3
1
4
Van, Maintenance
3
1
2
1
1
12
20
Van, Signal
4
5
9
Ambulance
3
1
1
4
9
TRAILERS
Trailer, Cargo, 1-Axle
3
2
6
11
Trailer, Cargo, 2-Axle
18
16
3
30
6
73
Trailer, Generator
3
1
2
2
1
1
3
13
Trailer, Kitchen
3
3
2
1
9
Trailer, POL (4,200-L)
12
3
2
15
32
Trailer, POL (1,200-L)
1
1
Trailer, Water (900/1,200-L)
3
1
1
2
1
1
9
RADAR
Radar, Battlefield Surveillance, Man-
1
1
Portable, PSNR-1 or TALL MIKE
RADIOS
VHF, Manpack, Low-Power
3
3
19
10
7
7
1
1
1
52
VHF, Portable, Low-Power
21
4
4
29
VHF, Portable, Very-Low-Power
4
8
12
VHF, Vehicle Mount, Medium-Power
3
99
47
27
22
11
21
8
3
5
246
HF, Manpack, Low-Power
6
6
2
1
15
HF, Vehicle Mount, Medium-Power
1
18
4
1
1
1
8
34
HF/VHF, Vehicle Mount, Medium-Power
4
2
6
HF/VHF, Vehicle Mount, High-Power
2
2
HF, Vehicle Mount, High-Power
1
1
Radio Relay, VHF/UHF
2
2
Warning Receiver
3
1
2
4
1
3
14
MISCELLANEOUS
Rangefinder, Laser
1
7
8
Rangefinder, Laser, Binocular
30
30
GPS Receiver
1
32
33
Periscopic Aiming Circle
1
1
Collimator
6
6
Motorcycle
3
3
2-58
FM 100-60
Tank Brigade (Sep) ________________________________ ____________________
TANK
BRIGADE
(SEP)*
MECHANIZED
SP HOWITZER
BRIGADE
TANK
INFANTRY
BATTALION
HQ
BATTALION
BN (IFV)
(152/122-mm)**
(p 2-60)
(p 3-3)
(pp 1-12/2-20)
(pp 3-38/3-40)
SIGNAL
AIR DEFENSE
RECON & EC
ENGINEER
BATTALION/
BATTALION
COMPANY
BATTALION
COMPANY
(p 2-30)
(p 2-40)
(p 2-63)
(pp 1-61/2-46)
CHEMICAL
MATERIEL
MAINT
MEDICAL
DEFENSE
SUPPORT
BATTALION/
BATTALION/
COMPANY
BATTALION
COMPANY
COMPANY
(p 2-48)
(p 1-69)
(pp 1-73/2-50)
(pp 1-79/2-52)
____________________________________
* A separate tank brigade most likely has four tank battalions of 31 to 51 tanks each and one
mechanized infantry battalion. However, the mix might be three tank battalions and two
mechanized infantry battalions. The mechanized infantry battalions are most likely IFV-
equipped (see p 3-3), although there may be
some APC-equipped battalions (see p 3-19).
** When there is a single SP howitzer battalion, it may be either 122-mm or 152-mm, with 152-
mm most likely. When there are two battalions, there may be one 122-mm and one 152-mm
or, more likely, both 152-mm.
(continued)
2-59
|
|
