Seat Exeo. Instruction - part 5





-------------------------------------------------------------------------------------------------------------------------------------------------------------

70
Cockpit
Glow plug system
Handbrake applied
The warning lamp also lights up when the handbrake is applied. In addi-
The indicator lamp lights up while the glow plugs are
tion to this, the handbrake warning ⇒ page 76 switches on after driving for 3
preheating.
seconds at a speed above 5 km/h.
The indicator lamp lights up while the glow plugs are preheating. When
the indicator lamp goes out the engine should be started straight away. When
WARNING
the engine is warm, or at outside temperatures above +8°C, the indicator
Before opening the bonnet and checking the brake fluid level, observe
lamp will only light up very briefly.
the warning information in page 213, “Work in the engine compart-
ment”.
Note
If the brake warning lamp does not go out, or if it lights up when
driving, the brake fluid level in the reservoir is too low and this may cause
If the glow plug indicator lamp should start flashing while the vehicle is
an increased accident risk. Stop the vehicle and do not drive on. Obtain
moving, this indicates a fault in the engine management system. The engine
technical assistance.
should be serviced without delay.
If the brake warning lamp lights up together with the ABS warning
If the indicator lamp fails to light up when the ignition is switched on, this
lamp, this can mean that the control function of the ABS is out of action. As
can mean that the glow plug system is defective. The engine should be
a result, the rear wheels can lock relatively easily when braking. Under
serviced.
certain circumstances, the rear of the vehicle could suddenly sway from
side to side, with the subsequent danger of skidding. Drive carefully to the
nearest specialist garage and have the fault rectified.
Brake system
The warning lamp flashes when the handbrake is applied, or
if the brake fluid level is too low or if there is a fault in the ABS
system.
If the warning lamp flashes (and the handbrake is not applied), stop the
vehicle and check the brake fluid level ⇒
⇒ page 222.
If a failure should occur in the ABS, the ABS warning lamp will light up
together with the brake warning lamp

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Cockpit
71
Driver information system
CD and radio display
⇒ page 72
Ambient temperature display
⇒ page 72
General notes
Distance to empty (the distance you can travel with the
⇒ page 73
remaining fuel)
The driver information system in the instrument panel shows
Door catch/tailgate warning
⇒ page 73
the status of various on-board systems at a glance.
Service interval display
⇒ page 74
auto-check control
⇒ page 75
Driving tips
⇒ page 75
Handbrake warning
⇒ page 76
Bulb monitor*
⇒ page 81
On-board computer*
⇒ page 84
Tyre pressure monitoring*
⇒ page 88
Navigation information*
Separate operat-
ing instructions
Fig. 47 Cockpit: Digital
display in the instrument
panel
Note
If a fault should occur, the display will show a red or yellow warning
The display for the driver information system is in the centre of the instrument
symbol. A red warning symbol indicates a serious malfunction ⇒ page 76. A
panel.
yellow warning symbol indicates a less serious malfunction ⇒ page 78.
The system runs a check on certain components and functions when the igni-
tion is switched on and while the vehicle is moving. The DIS system gives an
audible warning if a fault should occur or if servicing is required, and a red or
yellow warning symbol (in some cases with a corresponding driver message)
appears in the dashboard display.
The driver is informed on the audio system.
The driver information system includes the following functions:
Safety First
Operating instructions
Practical tips
Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

72
Cockpit
CD and radio display
Ambient temperature display
Fig. 48 Display: addi-
Fig. 49 Display: Ambient
tional radio information
temperature display
If the radio is switched on and no Priority 2 faults are indicated by the auto-
The ambient temperature is shown in the display when the ignition is
check control, the “OK” symbol will go out and the display will show the name
switched on ⇒ fig. 49.
or frequency of the selected radio station and various other information,
At temperatures below +5°C a snowflake symbol appears next to the temper-
depending on the type of radio fitted.
ature display. This is to warn the driver to take extra care when there is a risk
When in CD mode*, the display will show the current track.
of ice on the road. When the vehicle is stationary or travelling at very low
speeds, the temperature displayed may be slightly higher than the actual
These displays appear in addition to the display on the radio itself.
ambient temperature as a result of heat coming from the engine.
If the vehicle has an air conditioning and the display is changed over to °F
(degrees Fahrenheit), the ambient temperature display automatically
changes over to °F ⇒ page 157.
WARNING
Do not rely on the ambient temperature display as an ice warning. Please
bear in mind that there may be ice on the roads even at ambient tempera-
tures of +5°C - beware of ice patches.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Cockpit
73
Door catch/ tailgate warning
Note
When the display shows route guidance instructions from the navigation
system, the ambient temperature appears in the second line of the radio
display.
Fuel range
The fuel range display can help you to plan your trip.
The estimated fuel range is displayed in km. It shows how far the vehicle can
be driven with the amount of fuel left in the tank, assuming the same style of
driving. The fuel range is displayed in increments of 10 km.
Fig. 50 Display: door
catch/tailgate warning
The fuel range is calculated on the basis of the fuel consumption over the last
30 kilometres. The fuel range will increase if you drive in a more economical
manner.
The door catch/tailgate warning symbol lights up if one or more of the doors,
or the bonnet or tailgate are not properly closed when the ignition is on. The
symbol also indicates which of these is not properly closed. The display in the
illustration ⇒ fig. 50 shows that the front left door is open.
The corresponding part of the pictogram will flash if either the bonnet or tail-
gate are open. The warning symbol goes out when the bonnet, tailgate and
all the doors are closed.
On vehicles with a driver information system and an on-board computer* the
door catches/tailgate warning symbol can be switched off by briefly pressing
one of the control switches for the on-board computer ⇒ page 85. However,
the warning symbol will appear again if any of the doors or the bonnet or tail-
gate is opened or closed.
Safety First
Operating instructions
Practical tips
Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

74
Cockpit
Service indicator
The display reverts back to the standard display after about 5 seconds. The
remaining distance to the next service is updated every time the ignition is
This display reminds the driver when the next routine service
switched on, until the service becomes due.
is due.
Service due
When a service is due, SERVICE! will appear in the display immediately after
you switch on the ignition. The display reverts back to the standard display
after about 5 seconds.
Resetting the display
The display is reset by the garage after the service has been carried out. If the
service indicator has not been reset by the specialist garage, please perform
the following steps:
Switch the ignition off.
Press the service button ⇒ fig. 51
1
and hold while switching on the
ignition. The display will show one of these messages: Service in ----- km or
Fig. 51 Detailed view of
Service!
the instrument panel:
Service indicator
Now press and hold the reset button until the display shows Service
2
in ----- km --- days or Service!
Displaying distance to next service
The display switches out of the reset mode if you do not press the reset button
When you press the service button briefly with the ignition switched on,1
within 5 seconds.
the display will show how far the vehicle can be driven before the next service
is due. The query can be made with the engine switched off or in gear up to
Note
speeds of 5 km/h. Every time the ignition is switched on, the remaining
distance is updated. However, the first time this will be after 500 km.
Do not reset the service indicator between services, otherwise the display
will be incorrect.
In new vehicles or following a service, the following display is given for the
The information in the service indicator remains intact if the battery is
first 500 km when the remaining distance until the next service is consulted:
disconnected.
Service reminder
The distance to the next service cannot be called up if the system has
The instrument panel controls the distance travelled every day. Calculate the
detected a Priority 1 fault (red symbol).
average of these distances travelled and enable the service reminder suffi-
ciently in advance.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Cockpit
75
Auto-check system
Driver messages
Additional messages to assist the driver are displayed
Introduction
together with the warning symbols in the instrument panel.
The auto-check system checks important components and vehicle systems.
These background checks are run constantly, as long as the ignition is
switched on.
A message is displayed in the instrument panel if a fault should occur or if any
maintenance or repairs are urgently required. This is accompanied by an
audible warning signal. Depending on the priority of the fault, a red or yellow
warning symbol lights up in the display.
The red symbols indicate a danger, whereas the yellow ones represent a
warning. Additional messages to assist the driver may be shown with the red
or yellow symbols.
Fig. 52 Instrument panel:
CHECK button
Driver messages and red symbols
If a red warning symbol appears in the display, you can press the
CHECK
button ⇒ fig. 52 to call up an additional driver message.
For example: in the event of an oil pressure malfunction, the oil pressure
symbol will appear in the display. If you now press the
button, the
CHECK
following message will appear in the display:
Switch off engine, check oil level
The message will disappear from the display after about 5 seconds. If
required, the message can be called up again by briefly pressing the
CHECK
button.
Safety First
Operating instructions
Practical tips
Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

76
Cockpit
Driver messages and yellow symbols
Red symbols
If a yellow warning symbol appears in the display, it will automatically be
accompanied by the corresponding driver message.
A red symbol warns of a danger.
For example, the symbol is displayed to indicate that the windscreen
washer fluid level is low. In addition, the following message will appear:
Top up washer fluid
The message will disappear after a few seconds. If required, the message can
be called up again by briefly pressing the
CHECK
button.
Note
The messages handbrake applied and When stationary apply footbrake
while selecting gear cannot be called up a second time. They will remain in
the display until the handbrake is released or until a gear is selected.
Fig. 53 Display: Coolant
level warning
Handbrake warning
- Stop the vehicle.
- Release the handbrake.
- Switch the engine off.
– Check the fault. Obtain professional assistance if necessary.
If you drive by mistake with the handbrake still applied, you will hear a
warning buzzer and the display will show the message:
Handbrake applied
Fault in brake system
⇒ page 77
The handbrake warning switches on after driving for 3 seconds at speeds
BRAKE
above 5 km/h.
Coolant level too low / coolant tem-
⇒ page 77
COOLANT
perature too high
Engine oil pressure too low
⇒ page 78
OIL
PRESSURE

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Cockpit
77
The red symbols are used to indicate a Priority 1 fault (serious malfunction).
WARNING (continued)
A red symbol is accompanied by three warning chimes. The symbols will keep
If the brake warning lamp lights up together with the ABS warning
flashing until the faults are corrected. If several Priority 1 faults are detected
lamp, this can mean that the control function of the ABS is out of action. As
at the same time, the symbols are displayed one after the other for about 2
a result, the rear wheels can lock relatively easily when braking. Under
seconds.
certain circumstances, the rear of the vehicle could suddenly sway from
side to side, with the subsequent danger of skidding. Drive carefully to the
nearest specialist garage and have the fault rectified.
Fault in the brake system
A fault in the brake system should be rectified as soon as
Fault in the cooling system
possible.
Faults in the cooling system must be rectified immediately.
If the symbol flashes in the display, there is a fault in the brake
system. One of the following messages will appear in the display
If the symbol flashes in the display, this means that either the
together with the symbol:
coolant temperature is too high or the coolant level is too low. The
following message will appear in the display together with the
Stop vehicle, check brake fluid and hydraulic fluid levels
symbol:
Warning! Fault in brake system (ABS) Please visit garage
Switch off engine and check coolant level
- Stop the vehicle.
- Stop the vehicle.
- Check the brake fluid level ⇒ page 222.
- Switch the engine off.
If the ABS fails, the ABS warning lamp will light up together with the brake
- Check the coolant level ⇒ page 218.
system fault symbol
- Add more coolant if necessary ⇒ page 218.
WARNING
- Wait for the symbol to go out before driving on.
Before opening the bonnet and checking the brake fluid level, observe
- Obtain professional assistance if necessary.
the warning information in page 213, “Work in the engine compart-
ment”.
If the coolant level is correct, the overheating may be caused by a malfunction
If the brake fluid level in the reservoir is too low, this could result in an
of the radiator fan.
accident. Do not drive on. Obtain technical assistance.
Safety First
Operating instructions
Practical tips
Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

78
Cockpit
If the alternator warning lamp lights up as well ⇒ page 69, it is possible that
the drive belt has broken.
Note
The oil pressure warning lamp is not an indicator for the oil level. The oil
level should therefore be checked regularly, preferably every time you fill the
Caution
tank.
Do not drive on if the symbol has come on to indicate a fault in the cooling
system, otherwise there is a risk of engine damage.
Yellow symbols
Engine oil pressure too low
A yellow symbol indicates a warning.
If the engine oil pressure is too low the fault must be rectified
immediately.
If the symbol flashes in the display, the oil pressure is too low.
The following message will appear in the display together with the
symbol:
Switch off engine, check oil level
- Stop the vehicle.
- Switch the engine off.
Fig. 54
Display: Fuel level
– Check the engine oil level ⇒ page 215.
low
- Obtain professional assistance if necessary.
Fuel level low
⇒ page 79
Engine oil level too low
If the engine oil level is too low, add more oil ⇒ page 216.
Diesel particulate filter* obstructed
⇒ page 79
Engine oil level correct
Light sensor/ rain sensor faulty
⇒ page 79
If the symbol flashes and the engine oil level is correct, obtain profes-
sional assistance. Do not drive on. Do not continue to run the engine, even at
idle speed.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Cockpit
79
Fuel level low
Brake pad worn
⇒ page 80
When this symbol comes on for the first time, there are about 8 to 10 litres
Speed warning 1
⇒ page 80
of fuel left in the tank. You should fill up as soon as possible ⇒ page 208.
Dynamic headlight range control*
⇒ page 80
faulty
Self-directing headlights* faulty
⇒ page 80
Diesel particulate filter obstructed
Washer fluid level low*
⇒ page 80
If the symbol lights up, you may be able to contribute towards automatic
filter cleaning by driving in the right manner. You should drive at a speed of
at least 60 km/h for about 15 minutes in 4th or 5th gear, at an engine speed
Speed warning 2*
⇒ page 80
of around 2000 rpm. The increase in temperature will burn off any soot in the
filter. When cleaning is successful, the symbol switches off.
Battery voltage too high or too low*
⇒ page 80
If the light on symbol does not go off, take the vehicle to a specialist
Bulb monitor*
⇒ page 81
garage to repair the fault.
For further information on the diesel particulate filter, see ⇒ page 183.
Tyre pressure monitoring system*
⇒ page 88
Loss of pressure
WARNING
TPMS
Tyre pressure monitoring system*
⇒ page 66
System not available
It is essential that you adjust your speed to suit the weather, road, terrain
and traffic conditions. The recommended driving speed must never lead to
Yellow symbols are used to indicate a Priority 2 fault (warning).
the driver disregarding the traffic regulations.
Yellow symbols are accompanied by one warning chime. The function indi-
cated should be checked as soon as possible. If several Priority 2 faults are
detected at the same time, the symbols are displayed one after the other for
Light sensor/ rain sensor faulty
about 2 seconds at a time.
Automatic headlights / automatic wipers faulty
If the symbol appears, this means that the light sensor / rain sensor is not
working. For safety reasons, the dipped beam headlights will then be
switched on permanently when the light switch is set to the AUTO position.
However, you can still switch the lights on and off in the normal way with the
Safety First
Operating instructions
Practical tips
Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

80
Cockpit
light switch. If the rain sensor is faulty, the functions operated via the wind-
This symbol indicates that the self-directing headlight system is faulty.
screen wiper lever will still be available. You should have the light sensor /
Take the vehicle to a specialist garage to have the headlights or the self-
rain sensor checked by a specialist garage as soon as possible.
directing headlight control unit repaired.
Worn brake pads
Washer fluid level low
If the symbol lights up, have the front brake pads (and, for safety's sake,
If the symbol lights up, top up the fluid for the windscreen washer and
the rear pads as well) inspected by a specialist garage.
headlight washer system* ⇒ page 220.
Speed warning 1
Speed warning 2
If the symbol lights up, this means you are exceeding the speed that has
If the symbol lights up, this means you are exceeding the speed that has
been pre-set with the speed warning function. You should reduce your speed
been pre-set. You should reduce your speed accordingly ⇒ page 81.
accordingly ⇒ page 81.
Battery voltage too high or too low
Headlight range control faulty
If the symbol lights up, take the vehicle to a specialist garage and have
This symbol indicates a malfunction in the dynamic headlight range
the following items checked:
control. Take the vehicle to a specialist garage to have the dynamic headlight
Ribbed belt
range control function repaired.
Battery condition
It is also advisable to check whether the alternator warning lamp has come on
⇒ page 69.
Self-directing headlights* faulty
Self-directing headlights faulty

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Cockpit
81
Bulb monitor
Speed warning
The bulb monitor checks whether the lights on the vehicle are
working.
Introduction
If a defective bulb is detected, or if one of the lights has failed for any reason,
The speed warning function can help prevent you exceeding
the bulb monitor symbol will appear in the display together with an addi-
a particular pre-set maximum speed.
tional message (which goes out after 5 seconds). For instance, if the rear left
turn signal is not working, the display in the instrument panel will show the
following message:
Left rear turn signal
The message disappears after 5 seconds. Press the CHECK button briefly if
you wish to call up the message again.
If the display indicates that one of the lights is not working, this can have a
number of causes:
Bulb failure ⇒ page 249.
A “blown” fuse ⇒ page 247, “Changing fuses”.
Faulty electrical wiring.
Fig. 55 Display: Speed
warning function
Have the components replaced or the wiring repaired as necessary by a
specialist garage.
The speed warning function will warn the driver if a pre-set maximum speed
is exceeded. The system gives an audible warning signal if the set speed is
WARNING
exceeded by about 10 km/h. A warning symbol will also appear in the display
Bulbs are highly sensitive to pressure. The glass can break when you
⇒ fig. 55.
touch the bulb, causing injury.
The speed warning function has two different warning speeds, which operate
The high voltage element of gas discharge lamps* (xenon light) must
independently and serve slightly different purposes:
be handled correctly. Otherwise, there is a risk of death.
Speed limit warning 1
With speed limit warning 1, the maximum speed can be changed while
driving. The speed limit that has been set remains stored until the ignition is
switched off, or until it is changed or cleared.
Safety First
Operating instructions
Practical tips
Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

82
Cockpit
The speed limit warning symbol for speed warning 1 ⇒ page 81, fig. 55
Setting speed limit warning 1
will appear in the display if you exceed the pre-set speed. It goes out again if
the speed is reduced below the set speed limit.
Use the CHECK button to set speed limit warning 1.
The symbol also goes out if the speed is increased to more than about 40
km/h above the set speed for at least 10 seconds. However, this does not
cancel the speed limit that was originally set.
Setting speed limit warning 1 ⇒ page 82.
Speed limit warning 2
With speed limit warning 2, the speed limit can only be changed or cleared
when the ignition is switched off. You are recommended to store this speed
limit warning if you always wish to be reminded of a particular speed limit.
This could be when driving in countries with general speed limits, or if a
particular speed should not be exceeded when winter tyres are fitted etc.
Fig. 56 Detailed view of
The speed limit warning symbol for speed warning 2 will appear in the
the instrument panel:
display if you exceed the pre-set speed. Unlike speed limit warning 1, the
CHECK button
warning symbol only goes out once the road speed has dropped below the
set value again.
Setting the speed limit
Setting speed limit warning 2 ⇒ page 83.
- Drive at the desired maximum speed.
- Press the CHECK button and hold it down until the symbol
Note
⇒ page 81, fig. 55 appears.
Please bear in mind that, even with the speed warning function, it is still
important to keep a eye on the car's speed with the speedometer and to
Clearing the speed limit
observe the legal speed limits.
- Drive the vehicle at a minimum of 5 km/h.
- Press the CHECK button for at least two seconds.
The speed warning symbol lights up briefly in the display when the button
is released to confirm that the selected speed has been stored. The speed
limit that has been selected remains stored until another speed is selected

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Cockpit
83
with a brief push of the button, or until the memory is cleared with a long
- To change the speed limit, press the top or bottom of the function
push of the button.
selector switch on the windscreen wiper lever
A
⇒ fig. 57. The
speed limit displayed will then increase or decrease by 10 km/h
at a time.
Setting speed limit warning 2
Clearing the speed limit
Speed limit warning 2 is set using the switches on the wind-
- Switch the ignition off.
screen wiper lever.
- Briefly press the CHECK button in the instrument cluster
⇒ page 82, fig. 56. The distance display and the digital clock
will light up.
- Press the CHECK button for at least two seconds. The display will
show the speed limit which is currently set.
- Now press and hold the Reset button on the windscreen wiper
lever
B
⇒ fig. 57 until the crossed out warning symbol for
speed limit 2 appears on the display.
The display lighting for the mileage recorder and digital clock goes off again
Fig. 57 Windscreen wiper
a few seconds after the button is released.
lever: Function selector
switch
Setting the speed limit
- Switch the ignition off.
- Briefly press the CHECK button in the instrument cluster
⇒ page 82, fig. 56. The distance display and the digital clock
will light up.
- Press the CHECK button for at least two seconds. The display will
show the speed limit which is currently set or, if no speed limit
has been set, the crossed out warning symbol for speed limit 2.
Safety First
Operating instructions
Practical tips
Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

84
Cockpit
Single-journey memory (on-board computer 1)
On-board computer
The single-journey memory processes the information on a journey from the
time the ignition is switched on until it is switched off. If the journey is
Introduction
resumed within two hours after the ignition is switched off, the new figures
are automatically included in the calculation. If the journey is interrupted for
The on-board computer provides you with useful information
more than two hours the stored information is automatically erased when you
during a journey, including average and current fuel
resume your journey.
consumption, average speed, fuel range, driving time and
Total-journey memory (on-board computer 2)
distance covered.
Unlike the single-journey memory, the total-journey memory is not erased
automatically. Hence, you can determine the period for which you wish the
on-board computer to supply figures.
Fuel range
The estimated fuel range is displayed in km. The fuel range is displayed in
increments of 10 km.
Average fuel consumption
This mode shows the average fuel consumption since the memory was last
cancelled in litres/100 km.
Instantaneous fuel consumption
The display shows the instantaneous fuel consumption in litres/100 km.
Fig. 58 On-board
computer: memory 1
When the vehicle is stationary, the computer will display the last value in the
memory.
Press RESET button
B
⇒ page 85, fig. 59 to switch back and forward
Average speed
between the functions of on-board computers 1 and 2.
This mode shows the average speed driven since the memory was last
cancelled (in km/h).
The numbers in the display ⇒ fig. 58 indicates which of the two memories is
currently in use. The figure 1 means that the display is showing the informa-
Driving time
tion in the single journey memory (on-board computer 1). The figure 2 means
This display shows the period of time which has elapsed since the memory
that the display is showing the information in the total journey memory (on-
was last cancelled. The longest possible period it can cover is 999 hours and
board computer 2).
59 minutes.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Cockpit
85
Driving time warning
Operating
After 2 hours of continuous driving, the display automatically switches over
to the driving time display of 2:00. At the same time the driving time display
The on-board computer is controlled by means of two
starts flashing. This is to remind the driver to take a break.
switches on the windscreen wiper lever.
The driving time warning can be switched off by briefly pressing the function
selector switch or the
Reset
button ⇒ fig. 59.
If you continue driving or take a break for less than 10 minutes, the driving
time warning will switch on once again when the total driving time is 4:00
hours, 6:00 hours, etc. However, if you take a break for more than 10 minutes,
the driving time warning clock will be erased.
Distance covered
This display shows the distance you have covered since the memory was last
cancelled. The longest possible distance which can be recorded is
9999.9 km.
Fig. 59 Windscreen wiper
lever: On-board computer
Note
controls
The displays for fuel consumption (average and instantaneous), fuel
range and speed are shown in metric units.
Enabling the on-board computer
The information in the memory is lost if the battery is disconnected.
- Press the reset button
B
repeatedly until the on-board
computer (memory 1 or 2) ⇒ page 84, fig. 58 is displayed.
Selecting the function
- Press the top or bottom of the function selector switch
A
⇒ fig. 59. This displays the functions of the on-board computer
in sequence.
Resetting to zero
- Press and hold the Reset button
B
for at least two seconds.
The following values can be reset to zero using the Reset button:
Safety First
Operating instructions
Practical tips
Technical Data















Content      ..     3      4      5      6     ..
