Engine Suspension 1G-4
1.1.2 Engine3# Suspension Bracket Dismantling/ Mounting 1. Dismantle the engine mounts bolt 3 # 3 and nuts 1 and 2 (engine side); 2. Dismantle the engine mounts bolt 3 # 4, 5 and 6 (body side) ; 3. Whether to remove the engine mounts Check rubber damaged # 3 check 3 # suspended base oil leaks or damage. 4. Mount parts according to the sequence reverse to the dismantling process.
1.1.3 Engine4# Suspension Bracket Dismantling/Mounting 1. Dismantle 4 # 3 and 4-- suspension nut; 2. Dismantle 4 # suspension bolts 1 and 2 (body side); 3. Dismantle the four # mount bracket nut 6 and 7; 4. Dismantle the four # suspended inspection rubber is broken, hardening or damaged. 5. Mount parts according to the sequence reverse to the dismantling process.
Resonance block and insulation panels disassembly
1. Dismantle the heat shield bolts 1 and 2, remove the insulation panels; 2. Dismantle the resonator block bolt 3; 3. Dismantle the resonator block check rubber is broken, hardening or damaged. 4. Mount parts according to the sequence reverse to the dismantling process.
|
