399 9-1. Specifications 9 Ve * : The capacity is a reference quantity. If replacement is necessary, contact your Scion dealer. * 1 : Minimum pedal clearance when depressed with a force of 66 lbf (300 N, 30 kgf) while the EV system is operating. * 2 : Parking brake lever travel when pulled up with a force of 44 lbf (200 N, 20 kgf). Electrical system 12-volt battery Open voltage * at 68 F (20C): 12.6
12.8 V Fully charged 12.2
12.4 V Half charged 11.8 12.0 V Discharged ( * : Voltage is checked 20 minutes after the EV system and all lights are turned off.) Charging rates 5 A max. Transmission Fluid capacity * 3.1 qt. (2.9 L, 2.6 Imp.qt.) Fluid type Toyota Genuine ATF WS NOTICE ■ Transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause Brakes Pedal clearance * 1 3.50 in. (89 mm) Min. Pedal free play 0.04 — 0.24 in. (1 — 6 mm) Brake pad wear limit 0.04 in. (1.0 mm) Brake lining wear limit 0.04 in. (1.0 mm) Parking brake lever travel * 2 5 — 8 clicks Fluid type FMVSS No. 116 DOT 3 or SAE J1703 |
