Scion FR-S. Instruction - part 2

22

1-2. Opening, closing and locking the doors and trunk

Wireless remote control

■

Operation signals

Doors:

A buzzer sounds and the emergency flashers flash to indicate that
the doors have been locked/unlocked. (Locked: once; Unlocked:
twice)

Trunk:

A buzzer sounds to indicate that the trunk has been unlocked.

■

Panic mode

The wireless remote control can be used to lock and unlock the vehi-

cle.

Locks both side doors

Check that the door is securely
locked.

Unlocks both side doors

Sounds the alarm
(press and hold)

Pressing the button unlocks
the driver’s door. Pressing the
button again within 3 seconds
unlocks the other doors.

Unlocks the trunk
(press and hold)

When

 is pressed for longer than

about one second, an alarm will sound
intermittently and the vehicle lights will
flash to deter any person from trying to
break into or damage your vehicle.

To stop the alarm, press any button on
the wireless remote control.

23

1-2. Opening, closing and locking the doors and trunk

1

Before driving

■

Vehicle finder function

■

Security feature

If a door is not opened within approximately 60 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.

■

Conditions affecting operation

The wireless remote control function may not operate normally in the follow-
ing situations:

●

When the wireless key battery is depleted

●

Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electri-
cal noise

●

When carrying a portable radio, cellular phone or other wireless commu-
nication devices

●

When the wireless key is in contact with, or is covered by a metallic
object

●

When other wireless key (that emit radio waves) is being used nearby

●

If window tint with a metallic content or metallic objects are attached to
the rear window

When the function is set, a buzzer
(sounds once) and the emergency flash-
ers (flash 3 times) are used to inform the
driver of the vehicle’s location.
Press

 3 times within 5 seconds

while within a circumference of approxi-
mately 30 ft. (10 m) from of the vehicle.
However, if the interval between the 3
presses is short, the system may not be
activated. This setting must be custom-
ized at your Scion dealer.

24

1-2. Opening, closing and locking the doors and trunk

■

Key battery depletion

If the wireless remote control function does not operate, the battery may be
depleted. Replace the battery when necessary. (

P. 273)

■

When the wireless remote control battery is fully depleted

P. 273

■

Customization that can be configured at your Scion dealer

Settings (e.g. wireless remote control system) can be changed.
(Customizable features

P. 373)

■

Certification for wireless remote control

For vehicles sold in the U.S.A.
FCC ID: HYQ23AAC

FCC ID: HYQ12BEL

NOTE:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.

FCC WARNING:
Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.

For vehicles sold in Canada
NOTE:
This device complies with Industry Canada licence-exempt RSS stan-
dard(s). Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any interfer-
ence, including interference that may cause undesired operation of the
device.

NOTE:
Le présent appareil est conforme aux CNR d’Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux
deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage,
et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en compromettre le fonctionne-
ment.

25

1

1-2. Opening, closing and locking the doors and trunk

Before driving

Doors

The vehicle can be locked and unlocked using the wireless remote

control, key or door lock switch.

■

Wireless remote control
P. 22

■

Key

Turning the key operates the doors as follows:

Locks driver’s side door

Unlocks driver’s side door

■

Door lock switch

Locks both side doors

Unlocks both side doors

26

1-2. Opening, closing and locking the doors and trunk

Locking the doors from the outside without a key

Move the inside lock button to the lock position.

Close the door.

■

Window open/close function linked to door operation

In order to make opening and closing the doors easier, completely closed
windows are linked to door operations. Therefore, when a door is opened, its
window opens slightly. When a door is closed, its window closes completely.

However, if the battery has discharged or is disconnected, this function will
not operate. (

P. 335)

■

Inside lock button

Locks the door

Unlocks the door

STEP

1

STEP

2

27

1-2. Opening, closing and locking the doors and trunk

1

Before driving

CAUTION

■

To prevent an accident

Observe the following precautions while driving the vehicle.
Failure to do so may result in a door opening and an occupant falling out,
resulting in death or serious injury.

●

Always use a seat belt.

●

Always lock both side doors.

●

Ensure that both side doors are properly closed.

●

Do not pull the inside handle of the doors while driving.
The doors may be opened and the passengers are thrown out of the vehi-
cle and it may result in serious injury or death.

28

1-2. Opening, closing and locking the doors and trunk

Trunk

The trunk can be opened using the key, trunk opener wireless

remote control.

■

Opening the trunk from inside the vehicle

Press and hold the opener
switch to release the trunk lid.

■

Opening the trunk from outside the vehicle

Key

Turn the master key clockwise
to release the trunk lid.

Wireless remote control



P. 22

29

1-2. Opening, closing and locking the doors and trunk

1

Before driving

Canceling the trunk opener feature

To protect luggage stored in the trunk against theft, do the following:

Turn the main switch in the trunk
off to disable the trunk opener.

On

Off

The trunk lid can only be opened
with the master key.

■

Trunk light

The trunk light turns on when the trunk is opened.

■

Internal trunk release lever

■

Which key to the vehicle is to leave with a parking attendant after dis-
abling the trunk opener main switch

P. 20

The trunk lid can be opened by pulling on
the glow-in-the-dark lever located on the
inside of the trunk lid.

The lever will continue to glow for some
time after the trunk lid is closed.

30

1-2. Opening, closing and locking the doors and trunk

CAUTION

■

Caution while driving

●

Keep the trunk lid closed while driving.
If the trunk lid is left open, it may hit near-by objects while driving or lug-
gage in the trunk may be unexpectedly thrown out, causing an accident.
In addition, exhaust gases may enter the vehicle, causing death or a seri-
ous health hazard. Make sure to close the trunk lid before driving.

●

Before driving the vehicle, make sure that the trunk lid is fully closed. If the
trunk lid is not fully closed, it may open unexpectedly while driving, caus-
ing an accident.

●

Never let anyone sit in the trunk. In the event of sudden braking or a colli-
sion, they are susceptible to death or serious injury.

■

When children are in the vehicle

Observe the following precautions.
Failure to do so may result in death or serious injury.

●

Do not allow children to play in the trunk.
If a child is accidentally locked in the trunk, they could suffer from heat
exhaustion, suffocation or other injuries.

●

Do not allow a child to open or close the trunk lid.
Doing so may cause the trunk lid to operate unexpectedly, or cause the
child’s hands, head, or neck to be caught by the closing trunk lid.

31

1-2. Opening, closing and locking the doors and trunk

1

Before driving

CAUTION

■

Using the trunk

Observe the following precautions.
Failure to do so may cause parts of the body to be caught, resulting in seri-
ous injury.

●

Remove any heavy loads, such as snow and ice, from the trunk lid before
opening it. Failure to do so may cause the trunk lid to suddenly shut again
after it is opened.

●

When opening or closing the trunk lid, thoroughly check to make sure the
surrounding area is safe.

●

If anyone is in the vicinity, make sure they are safe and let them know that
the trunk is about to open or close.

●

Use caution when opening or closing the trunk lid in windy weather as it
may move abruptly in strong wind.

●

Do not attach any accessories other than genuine Scion parts to the trunk
lid. Such additional weight on the trunk lid may cause the lid to suddenly
shut again after it is opened.

●

The trunk lid may suddenly shut if it is
not opened fully. It is more difficult to
open or close the trunk lid on an
incline than on a level surface, so
beware of the trunk lid unexpectedly
opening or closing by itself. Make
sure that the trunk lid is fully open
and secure before using the trunk.

●

When closing the trunk lid, take extra
care to prevent your fingers etc. from
being caught.

●

When closing the trunk lid, make sure
to press it lightly on its outer surface.

32

1-2. Opening, closing and locking the doors and trunk

NOTICE

■

Trunk damper stays

The trunk lid is equipped with damper stays that hold the trunk lid in place.
Observe the following precautions.
Failure to do so may cause damage to trunk damper stays, resulting in a
malfunction.

●

Do not attach any foreign objects such as stickers, plastic sheets and
adhesives to damper stay rods.

●

Do not touch damper stay rods with gloves or other fabric items.

●

Do not attach any accessories other than genuine Scion parts to the trunk
lid.

●

Do not apply lateral force to damper stays or place your hand on it.

33

1

Before driving

1-3. Adjustable components (seats, mirrors, steering wheel)

Front seats

Seat position adjustment
lever

Seatback angle adjustment
lever

Vertical height adjustment
lever (driver’s side only)

Seatback fold strap

34

1-3. Adjustable components (seats, mirrors, steering wheel)

Getting in and out of the rear seats

To get in and out of the rear seats, use the seatback angle adjust-
ment lever or seatback fold strap.

■

Before getting in or out of the rear seats

Release the seat belt from the seat belt guide. (

P. 41)

■

Getting in the rear seats

Lift the seatback angle adjust-
ment lever.

The seatback will fold forward.

Front passenger seat only: The
seat can be slid forward and
backward.

■

Getting out of the rear seats

Pull the seatback fold strap.

The seatback will fold forward.

Front passenger seat only: The
seat can be slid forward and
backward.

■

After getting in or out of the rear seats

Return the seatback to the upright position until the seat locks.

Front passenger seat only: The seat will lock in position at the point where
the seatback reaches the upright position.

■

Seat dust cover

Always remove the seat dust cover that may be attached at the time of pur-
chase before using the seat.

35

1-3. Adjustable components (seats, mirrors, steering wheel)

1

Before driving

CAUTION

■

Seat adjustment

●

To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.

●

After adjusting the seat, make sure that the seat is locked in position.

●

Take care not to hit passengers with the seat.
When sliding the seat rearward, make sure not to squash the legs of the
rear passengers.

●

When returning the seatback upright, perform seatback angle adjustment
while holding down the seatback.

●

Do not pull on or use the seat belt guide to adjust or fold the front seat.

●

Do not put your hands under the seat or near the moving parts to avoid
injury. Fingers or hands may become jammed in the seat mechanism.

■

When driving the vehicle

Never operate the seatback angle adjustment lever or seatback fold strap.
Doing so could cause an accident resulting in death or serious injury.

■

Getting in and out of the rear seats

●

When getting in or out of the rear seats, make sure not to get your hands,
legs, etc. squashed in the movable or connecting parts.

●

When getting in or out of the rear seats, make sure not to trip on the seat
rails.

●

After getting in or out of the rear seats, always make sure the front seat is
locked in position.

■

When operating the front seat from the rear seat

Make sure that no passenger is seated in the front seat.

36

1-3. Adjustable components (seats, mirrors, steering wheel)

Rear seats

■

Seat dust cover

Always remove the seat dust cover that may be attached at the time of pur-
chase before using the seat.

The seatbacks of the rear seats can be folded down.

Pull the seatback lock release
straps in the trunk for the seat-
back you wish to fold down.

To return the seatbacks to its
original position, lift it up until it
locks.

37

1-3. Adjustable components (seats, mirrors, steering wheel)

1

Before driving

CAUTION

■

When folding the rear seatbacks down

Observe the following precautions. Failure to do so may result in death or
serious injury.

●

Do not fold the seatbacks down while driving.

●

Stop the vehicle on level ground, set the parking brake and shift the shift
lever to P (automatic transmission) or N (instruction transmission).

●

Do not allow anyone to sit on a folded seatback or in the trunk while driv-
ing.

●

Do not allow children to enter the trunk.

■

After returning the rear seatback to the upright position

Observe the following precautions. Failure to do so may result in death or
serious injury.

●

Check that the seat belts are not twisted or caught in the seatback.

■

Before using the rear seat belts

●

Make sure that the seatback is securely
locked in position by lightly pushing it
back and forth.
If the seatback is not securely locked,
the red portion of the seatback lock
indicator will be visible. Make sure that
the red portion is not visible.

Always make sure that the seat belt is not
caught in the seatback or twisted in one
of the hooks that secure the seatback.
Failure to do so may cause the seat belt
to not be fastened correctly or to become
ineffective in a collision, resulting in death
or serious injury.
