MINI Paceman (2016 year). Instruction - part 6

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Interior equipment

CONTROLS

pending on how long the adjustment button is

▷

12 to 15 seconds: set the language.

pressed:

▷ Press briefly: switch the display on/off.

Setting compass zones

Set the compass zone corresponding to the ve-

▷

3 to 6 seconds: set the compass zone.

hicle's geographic location so that the compass

▷

6 to 9 seconds: calibrate the compass.

can function correctly; refer to the world map

▷

9 to 12 seconds: set left-hand/right hand

with compass zones.

steering.

Press the adjustment button for 3-4 seconds.

▷ The cardinal direction displayed does not

The number of the compass zone set is shown

change even if the direction of travel

in the display.

changes.

To change the zone setting, briefly press the

▷ Not all compass directions are shown.

adjustment button repeatedly until the display

shows the number of the compass zone corre-

Procedure

sponding to the current location.

1. Make sure that there are no large metal ob-

The compass is operational again after approx.

jects or overhead power lines in the vicinity

10 seconds.

of the vehicle and that there is enough

space to drive in a circle.

Calibrating the digital compass

2. Set the currently valid compass zone.

The digital compass must be calibrated in the

3. Press the adjustment button for 6-7 sec-

following situations:

onds to call up C. Then drive at least one full

▷ An incorrect compass direction is shown.

circle at a maximum speed of

4 mph/7 km/h. When the system is cali-

brated, the C is replaced by the compass di-

rections.

99

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS

Interior equipment

Right-hand/left-hand steering

The digital compass is set for right-hand or left-

hand steering at the factory.

Setting the language

Press the adjustment button for 12-13 seconds.

Briefly press the adjustment button again to

switch between English "E" and German "O".

The setting is automatically saved after approx.

Depending on the equipment, additional cu-

10 seconds.

pholders can be installed on the center rail.

WARNING

Cupholders and ashtray/

Unsuitable containers in the cup holder

and hot beverages can damage the cup holder

lighter

and increase the risk of injuries in the event of

an accident. There is risk of injuries or risk of

property damage. Use light-weight, unbreaka-

ble, and sealable containers. Do not transport

hot beverages. Do not force objects into the

cup holder.◀

Ashtray

The ashtray is located in one of the cupholders

in the center console at the front.

Cupholders

Emptying

Two cupholders are located in the center con-

Take out the entire ashtray, arrow.

sole in the front.

When installing, ensure that the ashtray is in-

MINI Countryman: two additional cupholders

serted in the cupholder with the adapter.

are located at the end of the center console in

the rear. Additional cupholders can be installed

Lighter

on the center rail.

With the engine running or the ignition

MINI Paceman: additional cupholders are lo-

switched on, press in the cigarette lighter.

cated in the console between the rear seats.

100

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Interior equipment

CONTROLS

The lighter can be removed as soon as it pops

Socket in the rear

back out.

MINI Countryman

WARNING

Contact with hot heating elements or the

hot socket of the cigarette lighter can cause

burns. Flammable materials can ignite if the

cigarette lighter falls down or is held against

the respective objects. There is risk of fire and

injuries. Hold the cigarette lighter on its handle.

Make sure that children do not use the ciga-

rette lighter and do not burn themselves, e.g.

by carrying the remote control along when ex-

Take out the cover.

iting the vehicle.◀

MINI Paceman

Connecting electrical de-

vices

The lighter socket can be used as a socket for

electrical equipment while the engine is run-

ning or when the ignition is switched on. The

total load of all sockets must not exceed

140 watts at 12 volt.

Avoid damaging the sockets by attempting to

insert plugs of unsuitable shape or size.

Take out the cover.

CAUTION

Battery chargers for the vehicle battery

Socket in the cargo area

can work with high voltages and currents,

which means that the 12V on-board network

MINI Countryman

can be overloaded or damaged. There is risk of

property damage. Only connect battery charg-

ers for the vehicle battery to the starting aid

terminals in the engine compartment.◀

CAUTION

If metal objects fall into the socket, they

can cause a short circuit. There is risk of prop-

erty damage. Replace the cigarette lighter or

socket cover again after using the socket.◀

Take out the cover.

Socket in the center console

Remove the cover or lighter, refer to page 100,

from the socket.

101

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS

Interior equipment

MINI Paceman

MINI Paceman:

Take out the cover.

Cargo area

Cargo cover

WARNING

Loose objects in the car's interior can be

thrown into the car's interior while driving, e.g.

MINI Countryman: rear seat backrests

in the event of an accident or during braking

and evasive maneuvers. There is risk of injuries.

Observe the instructions concerning the safety

Secure loose objects in the car's interior.◀

belt, refer to page 38. Otherwise, personal pro-

tection may be compromised.

When the tailgate is opened, the cargo cover is

WARNING

raised.

Danger of jamming with folding down the

When closing, ensure that the cargo cover is

backrests. There is risk of injuries or risk of

resting on the rubber buffers of the securing

property damage. Make sure that the area of

straps; otherwise, damage may occur when

movement of the rear backrest is clear prior to

closing the tailgate.

folding down.◀

To load bulky luggage, the cover can be re-

moved.

The rear seat backrest is divided at a ratio of

40-20-40.

1. Detach the securing straps from the tail-

When the outer rear seat backrests are folded

gate.

down, it is not permissible for a person to travel

2. Lift the cover slightly, arrow 1, and pull it

on the center seat.

back and out of the bracket, arrow 2.

Remove the third head restraint, refer to

MINI Countryman:

page 42, if necessary.

Open the center safety belt and insert it in the

belt holder on the headliner, refer to page 40.

Enlarge the cargo area by adjusting the rear

seat backrests to a more upright position.

102

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Interior equipment

CONTROLS

The backrests can be adjusted to 10 different

adjust the height of the head restraints or re-

positions between the comfort and transport

move them.◀

positions and they can be folded down.

When the backrests are folded back up, they

In the comfort position, the backrests are tilted

engage in the transport position.

back to the greatest possible angle and in the

To set the desired backrest inclination or com-

transport position they are nearly vertical.

fort position, hold the backrest, pull the loop

Before beginning with the mounting of a child

forward, and adjust the backrest.

restraint fixing system, note the instructions,

refer to page 45.

MINI Paceman: rear seat backrests

1. Hold the top of the backrest, for example

1. Fold the belt buckles down.

the head restraint, and pull on the loop, ar-

row.

2. Pull on the respective loop, arrow.

The backrest is unlocked.

2. Engage the backrest in the desired position

or fold it down.

Folding the backrests back up

WARNING

With an unlocked backrest, an unsecured

load can be thrown into the car's interior, e.g.

in case of an accident, braking or evasive ma-

neuver. There is risk of injuries. Make sure that

the backrest engages into the locking after

3. Fold the backrest forward.

folding it back.◀

Folding the backrests back up

WARNING

Hold the top of the backrest, for example the

The stability of the child restraint system

head restraint, and fold it back.

is limited or compromised with incorrect seat

adjustment or improper installation of the child

WARNING

seat. There is risk of injuries or danger to life.

With an unlocked backrest, an unsecured

Make sure that the child restraint system fits

load can be thrown into the car's interior, e.g.

securely against the backrest. If possible, adjust

in case of an accident, braking or evasive ma-

the backrest tilt for all affected backrests and

neuver. There is risk of injuries. Make sure that

correctly adjust the seats. Make sure that seats

the backrest engages into the locking after

and backrests are securely engaged. If possible,

folding it back.◀

103

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS

Interior equipment

Flat loading floor

MINI Countryman: partition net

The maximum load on the loading floor is:

330 lbs, 150 kg.

Before installing

1. Remove the pouch with the partition net

Access to storage area

from the storage compartment under the

loading floor in the cargo area.

A storage area for items like the partition net is

found under the loading floor.

2. Take the partition net out of the pouch, un-

roll it, and unfold it.

1. Reach into the recess, arrow 1, on the rear

After use, fold and roll up the partition net

edge of the loading floor.

in the same manner and place it in the

2. Lift the loading floor at the rear, arrow 1,

pouch so that it can be stowed back under

and fold it forward, arrow 2.

the cargo floor panel. Ensure that hooks

MINI Countryman:

and tensioning buckles do not rest on the

rod elements.

3. Unfold the partition net to the point where

the rod elements engage.

Installation behind the front seats

MINI Paceman:

1. Take out the cargo cover if necessary.

2. Fold down the rear seat backrests, refer to

Enlarging the cargo area.

3. Insert the retaining pins of the partition net

all the way into the front holders in the

Before closing the tailgate, lower the loading

headliner, arrow 1, and push forward.

floor back onto the cargo area floor.

4. Attach the hooks, arrow 2, at the bottom of

the retaining straps on both sides to the

Removing

eyelets on the vehicle floor. Firmly attach

The loading floor can be removed if necessary.

the partition net.

1. Fold up the loading floor.

5. Lash the partition net tightly. To do this,

tighten the retaining straps using the ten-

2. Pull it back slightly and out of the holders.

sioning buckles.

3. Then remove it upward.

The folded loading floor can be stored in the

cargo area.

104

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Interior equipment

CONTROLS

Removing

To remove and stow the partition net, proceed

in reverse order.

To fold up, press the release button, arrow.

MINI Countryman: multi-function hook

Hooks designed for hanging shopping bags and

totes, for example, are located on the left and

right sides of the cargo cover support, arrow.

WARNING

Improper use of the multifunction hooks

can lead to a danger of objects flying about

during braking and evasive maneuvers. There is

risk of injuries and risk of property damage.

Only hang lightweight objects, e.g. shopping

bags, from the multifunction hooks. Only trans-

port heavy luggage in the cargo area if it has

been appropriately secured.◀

105

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS

Storage compartments

Storage compartments

▷ Cupholders, refer to page 100.

Vehicle features and op-

▷ Clothes hooks, refer to page 107.

tions

This chapter describes all standard, country-

Cargo area

specific and optional features offered with the

▷ Lashing eyes, refer to page 118.

series. It also describes features that are not

▷ Storage compartment under the flat load-

necessarily available in your car, e. g., due to

ing floor, refer to page 104.

the selected options or country versions. This

▷ Multi-function hook on the cargo cover

also applies to safety-related functions and sys-

support, refer to page 105.

tems.

When using the features and systems described

here, adhere to local regulations.

Glove compartment

Opening

Information

WARNING

Loose objects in the car's interior can be

thrown into the car's interior while driving, e.g.

in the event of an accident or during braking

and evasive maneuvers. There is risk of injuries.

Secure loose objects in the car's interior.◀

CAUTION

Anti-slip pads such as anti-slip mats can

Pull the handle to open the lid.

damage the dashboard. There is risk of prop-

The light in the glove compartment switches

erty damage. Do not use anti-slip pads.◀

on.

Closing

Storage compartments

Fold up the cover.

Interior

WARNING

▷ Glove compartment, refer to page 106.

Folded open, the glove compartment

▷ Center armrest, refer to page 107.

protrudes in the car's interior. Objects in the

▷ Center rail, refer to page 107.

glove compartment can be thrown into the

car's interior while driving, e.g. in the event of

▷ Compartments in the center console.

an accident or during braking and evasive ma-

▷ Compartments in the doors.

neuvers. There is risk of injuries. Always close

▷ Pockets on the back of the front seat back-

the glove compartment immediately after us-

rests.

ing it.◀

106

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Storage compartments

CONTROLS

Ventilation

Depending on the vehicle's equipment, the

glove compartment can be ventilated and, if

the cooling function is switched on, cooled.

Opening

Center rail

Rail segment

The rail segment can be used to secure various

objects that are placed into the rail against slip-

Turn the switch in the direction of the arrow.

ping, such as a ball point pen or smartphone.

In addition, the connection cable of the smart-

Closing

phone can be secured using the rail segment.

Move the switch to the vertical position by

1. Twist the rail segment, arrow 1, to remove

turning it in the opposite direction of the arrow.

it.

Depending on the temperature setting of the

2. Insert the connection cable centrally into

air conditioning or automatic climate control,

the recess, arrow 2.

high temperatures may occur in the glove com-

partment.

Center armrest

The center armrest between the front seats

contains a storage compartment or a cover for

the snap-in adapter, refer to page 145, de-

pending on the equipment.

Do not position tall accessory parts directly on

3. Fix the rail segment in the rail.

the center rail of the center armrest; otherwise,

they may be damaged when the center arm-

rest is opened or closed.

Clothes hooks

Center armrest front

Clothes hooks are located on the grab handles

in the rear.

Opening

WARNING

Press the button, arrow, and pull up the lid.

Clothing articles on the clothes hooks can

obstruct the view while driving. There is risk of

an accident. When suspending clothing articles

107

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS

Storage compartments

from the hooks, ensure that they will not ob-

struct the driver's view.◀

WARNING

Improper use of the clothes hooks can

lead to a danger of objects flying about during

braking and evasive maneuvers. There is risk of

injuries and risk of property damage. Only hang

lightweight objects, e.g. clothing articles, from

the clothes hooks.◀

Connection for an exter-

nal audio device

This can be used to connect an external audio

device, such as a CD or MP3 player.

Radio MINI Boost CD, refer to page 132.

108

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Things to remember when driving

DRIVING TIPS

Closing the tailgate

If you have problems of this nature, we recom-

mend that you consult your dealer’s service

WARNING

center or another qualified service center or re-

An open tailgate protrudes from the vehi-

pair shop.◀

cle and can endanger occupants and other traf-

fic participants or damage the vehicle in the

Hydroplaning

event of an accident, braking or evasive ma-

neuvers. In addition, exhaust fumes may enter

On wet or slushy roads, a wedge of water can

the vehicle interior. There is risk of injuries or

form between the tires and road surface.

risk of property damage. Do not drive with the

This phenomenon is referred to as hydroplan-

tailgate open.◀

ing. It is characterized by a partial or complete

loss of contact between the tires and the road

If, despite this, the vehicle must be driven with

surface, ultimately undermining your ability to

the tailgate open:

steer and brake the vehicle.

▷ Drive moderately.

The risk of hydroplaning increases as the tire

▷ Close all windows and the glass sunroof.

tread depth decreases. Minimum tread depth,

▷ Switch off recirculated air mode and greatly

refer to page 160.

increase the blower speed.

Driving through water

Hot exhaust system

Drive though calm water only if it is not deeper

WARNING

than 12 inches/30 cm and at this height, no

faster than walking speed, up to

During driving operation, high tempera-

6 mph/10 km/h.

tures can occur underneath the body, e.g.

caused by the exhaust gas system. If combusti-

Using the parking brake on inclines

ble materials, such as leaves or grass, come in

contact with hot parts of the exhaust gas sys-

On inclines, do not hold the vehicle stationary

tem, these materials can ignite. There is risk of

with a slipping clutch for extended period; use

injuries or risk of property damage.

the parking brake instead. Otherwise, the

clutch will be subject to increased wear.

Do not remove the heat shields installed and

never apply undercoating to them. Make sure

Support from the hill drive-off assistant, refer to

that no combustible materials can come in con-

page 86.

tact with hot vehicle parts in driving operation,

idle or during parking. Do not touch the hot ex-

Braking safely

haust system.◀

The vehicle is equipped with ABS as a standard

feature.

Mobile communication devices in the

Applying the brakes fully is the most effective

vehicle

way of braking in situations when this is neces-

sary.

WARNING

The vehicle maintains steering responsiveness.

The vehicle's performance may be af-

You can still avoid any obstacles with a mini-

fected by interference from high frequency

mum of steering effort.

radio signals. These signals are emitted by a

series of transmission systems, such as from air

Pulsation of the brake pedal and sounds from

traffic beacons or relay stations for mobile tele-

the hydraulic circuits indicate that ABS is in its

communications.

active mode.

113

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DRIVING TIPS

Things to remember when driving

Objects in the area around the pedals

an accident. Avoid placing excessive load on

the brake system.◀

WARNING

Objects in the driver's floor area can limit

WARNING

the pedal distance or block a depressed pedal.

In idle or with the engine switched off,

There is risk of an accident. Stow objects in the

safety-relevant functions are restricted or not

vehicle such that they are secured and cannot

available anymore, e.g. braking effect of the

enter into the driver's floor area. Use floor mats

engine or braking force and steering support.

that are suitable for the vehicle and can be

There is risk of an accident. Do not drive in idle

safely attached to the floor. Do not use loose

or with the engine switched off.◀

floor mats and do not layer several floor mats.

Make sure that there is sufficient clearance for

Brake disc corrosion

the pedals. Ensure that the floor mats are se-

curely fastened again after they were removed,

Corrosion on the brake discs and contamina-

e.g. for cleaning.◀

tion on the brake pads are furthered by:

▷ Low mileage.

Driving in wet conditions

▷ Extended periods when the vehicle is not

When roads are wet or there is heavy rain,

used at all.

briefly exert gentle pressure on the brake pedal

▷ Infrequent use of the brakes.

every few miles.

Corrosion occurs when the minimum pressure

Ensure that this action does not endanger other

that must be exerted by the pads during brake

road users.

applications to clean the discs is not reached.

The heat generated in this process helps dry

Should corrosion form on the brake discs, the

the brake discs and pads.

brakes will tend to respond with a pulsating ef-

In this way braking efficiency will be available

fect that generally cannot be corrected.

when you need it.

When the vehicle is parked

Hills

When using the automatic climate control, con-

Drive long or steep downhill gradients in the

densation water develops that exits under-

gear in which the least braking is required. Oth-

neath the vehicle.

erwise, the brake system may overheat, result-

Therefore, traces of condensed water under the

ing in a reduction in the brake system effi-

vehicle are normal.

ciency.

After the engine is switched off, the coolant

You can increase the engine's braking effect by

pump may continue running for some time in

shifting down, going all the way to first gear, if

the MINI Cooper S. This causes noises in the en-

necessary.

gine compartment.

Downshifting in instruction mode of the Steptronic

transmission, refer to page 58.

Driving on poor roads

Your MINI with ALL4 all-wheel drive feels com-

WARNING

fortable on all streets and roads. It combines an

Light but consistent brake pressure can

all-wheel drive system with the advantages of a

lead to high temperatures, brakes wearing out

normal passenger car.

and possibly even brake failure. There is risk of

114

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DRIVING TIPS

Loading

Loading

Vehicle features and op-

Determining the load

tions

limit

This chapter describes all standard, country-

specific and optional features offered with the

series. It also describes features that are not

necessarily available in your car, e. g., due to

the selected options or country versions. This

also applies to safety-related functions and sys-

tems.

When using the features and systems described

here, adhere to local regulations.

1.

Locate the following statement on your ve-

hicle's placard:

General information

▷ The combined weight of occupants and

cargo should never exceed XXX kg or

WARNING

YYY lbs. Otherwise, damage to the ve-

High gross weight can overheat the tires,

hicle and unstable driving situations

damage them internally, and cause a sudden

may result.

drop in tire inflation pressure. There is risk of an

2.

Determine the combined weight of the

accident. Pay attention to the permitted load

driver and passengers that will be riding in

capacity of the tires and never exceed the per-

your vehicle.

mitted gross weight.◀

3.

Subtract the combined weight of the driver

CAUTION

and passengers from XXX kilograms or YYY

pounds.

Fluids in the cargo area can cause dam-

age. There is risk of property damage. Make

4.

The resulting figure equals the available

sure that no fluids leak in the cargo area.◀

amount of cargo and luggage load ca-

pacity.

WARNING

For example, if the YYY amount equals

Loose objects in the car's interior can be

1,000 lbs and there will be four 150 lbs pas-

thrown into the car's interior while driving, e.g.

sengers in your vehicle, the amount of

in the event of an accident or during braking

available cargo and luggage load capacity

and evasive maneuvers. There is risk of injuries.

is 400 lbs: 1,000 lbs minus 600 lbs =

Secure loose objects in the car's interior.◀

400 lbs.

5.

Determine the combined weight of luggage

and cargo being loaded on the vehicle.

That weight may not safely exceed the

116

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Loading

DRIVING TIPS

available cargo and luggage load capacity

▷ Heavy cargo: stow as far forward and as

calculated in Step 4.

low as possible, ideally directly behind the

backrests.

6. If your vehicle will be towing a trailer, load

from your trailer will be transfered to your

▷ Cover sharp edges and corners.

vehicle. Consult the manual for transporting

▷ Do not stack cargo above the top edge of

a trailer to determine how this may reduce

the backrests.

the available cargo and luggage load ca-

▷ If necessary, fold down the rear backrests

pacity of your vehicle.

to stow cargo.

▷ Use the partition net, refer to page 104, to

protect passengers. Make sure that objects

Load

cannot penetrate the partition net.

4-seater:

▷ Place protective material around any sharp-

edged or pointed objects that could bump

against the rear window while the vehicle is

in motion.

MINI Countryman

5-seater:

MINI Paceman

The maximum load is the sum of the weight of

the occupants and the cargo.

The greater the weight of the occupants, the

less cargo that can be transported.

Stowing cargo

▷ Very heavy cargo: when the rear seat is not

occupied, secure each of the outer safety

belts in the opposite buckle.

117

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DRIVING TIPS

Loading

sive maneuvers. Vehicle occupants can be hit

Securing cargo

and injured. There is risk of injuries. Stow and

secure objects and cargo properly.

Lashing eyes in the cargo area

Do not secure cargo using the upper LATCH

MINI Countryman

mounting points, refer to page 48; otherwise,

these may become damaged.◀

Roof-mounted luggage

rack

Information

A special rack system is available as an optional

accessory.

MINI Paceman

Securing

Follow the installation instructions of the roof

rack.

Ensure that adequate clearance is available for

the movement of the glass sunroof.

Loading

Because roof racks raise the vehicle's center of

gravity when loaded, they have a major effect

on vehicle handling and steering response.

Securing cargo

Therefore, note the following when loading and

▷ Secure smaller and lighter pieces with tight-

driving:

ening belts or straps.

▷ Do not exceed the approved roof/axle

▷ Secure larger and heavier pieces with cargo

loads and the approved gross vehicle

straps.

weight.

Adhere to the information included with

▷ Distribute the roof load uniformly.

the cargo straps.

▷ The roof load should not extend past the

▷ Eight mounting eyes are available for fas-

loading area.

tening the cargo straps.

▷ Always load the heaviest pieces on the bot-

Two of them are located on the side wall of

tom.

the cargo area, arrows 1, and two are lo-

▷ Secure the roof luggage firmly, e.g., tie with

cated on the rear wall of the cargo area, ar-

ratchet straps.

rows 2.

▷ Do not let objects project into the opening

WARNING

path of the tailgate.

Improperly stowed objects can shift and

▷ Drive smoothly. Avoid sudden acceleration

be thrown into the car's interior, e.g. in the

and braking maneuvers. Take corners gen-

event of an accident or during braking and eva-

tly.

118

Content      ..     4      5      6      7     ..
