7-152 4. Remove the button-head screw from the nitrogen valve in the shock body. FS040 5. Insert the needle squarely into center of the nitro- gen valve to release the pressure. FS016 6. When the shock is fully discharged, pull the needle away from the reservoir in a straight, smooth motion. 7. Loosen (but do not remove) the bearing bleed screw. FS013 8. Loosen and unscrew the bearing assembly from the shock body. FS006 9. Remove the shaft assembly from the body tube and place it on a clean, lint-free paper towel. 10. Remove the shock from the vise and pour shock oil from body tube into a proper disposal con- tainer. DO NOT REUSE OLD SHOCK OIL. 11. Clamp the body cap of the shock securely in vise with the open end of the body tube pointing up. 12. Loosen and remove the nitrogen valve from the body. FS014 13. Remove the shock body from the vise; then invert the shock body and place it on a folded shop towel open end down. 14. Using compressed air (NEVER USE HIGH PRESSURE NITROGEN), insert the air gun noz- zle into the nitrogen valve port and blow the IFP out of the shock body and onto the folded shop towel. FS012 ! WARNING Point the nitrogen valve away from face and body to |
