7-112 NOTE: Vigorously push the underside of the 4. After correct track tension is obtained, check track alignment (see Track Alignment in this sub-sec- tion). NOTE: Track tension and track alignment are Track Alignment NOTE: Proper track alignment is when the rear CHECKING/ADJUSTING 1. Using a shielded safety stand, raise the rear of the snowmobile off the floor making sure the track is free to rotate. 2. Start the engine and accelerate slightly. Use only enough throttle to rotate the track several revolu- tions. SHUT THE ENGINE OFF. NOTE: Allow the track to coast to a stop. Do not 3. When the track stops rotating, check the relation- ship of the rear idler wheels and the inner track drive lugs. If the distance from the idler wheels to the inner drive lugs is the same on both sides, no adjustment is necessary. 0739-637 4. On the side of the track which has the inner drive lugs closer to the rear idler wheel, loosen the adjusting bolt jam nut; then rotate the adjusting bolt clockwise 1-1 1/2 turns. NOTE: If the track tension must be loosened, it 5. Continue to check the track alignment and make the necessary adjustments until proper alignment is obtained. 6. After proper track alignment is obtained, lock the jam nut against the axle housing. NOTE: Make sure correct track tension is main- NOTE: Field test the track under actual condi- ! CAUTION After proper track tension and alignment have been ! WARNING The tips of the skis must be positioned against a ! CAUTION After proper track tension and alignment have been |
