2-69 2 FC018 6. On the 600 cc, remove the Allen-head cap screws securing the magneto case to the crankcase. Account for the alignment pins. NOTE: Note the different-sized cap screws for FC019 FC020 7. Remove the stator plate from the engine. FC021 FC065 NOTE: The stator plate screws had Loctite 8. On the 600 cc, remove the cap screws securing the APV assemblies to the cylinders; then remove the APV assemblies and set them aside. NOTE: Note that the APV exhaust valves and NOTE: The following photographs are for clarity FC023 |
