9-83 9 MS074 MS072A 4. Install the idler spacer collar onto the idler arm. MS064 5. Place the flared bushings with a thin flat washer through the notched side of the offset pivot idler arm assembly. NOTE: If the flared bushings in the offset pivot 6. Align the marks on the idler arm to the center- line of the offset pivot idler arm assembly. Secure the offset pivot idler arm to the idler arm with cap screws and lock nuts. Tighten to speci- fications. MS146A NOTE: When tightening the pivot idler arm lock MS019B Rear Axle and Idler Wheels NOTE: The skid frame must be removed for this DISASSEMBLING 1. Remove the cap screw and large flat washer securing the outer rear idler wheel. Remove the outer idler wheel from the shaft. ! CAUTION When driving the idler wheel onto the idler arm, use |
