5-27 5 Testing Electrical Resistances (370 cc Models/440 cc Panther Model) NOTE: Resistance tests of the engine electrical components should be made using the Fluke Mul- IGNITION COIL (Primary) 1. Disconnect the two connectors from the CDI unit to the ignition coil. 2. Set the selector in the X1 position. connect the black meter lead to the black lead. AK051D 4. Ignition coil primary resistance must be between 0.25-0.34 ohm. IGNITION COIL (Secondary) 1. Remove the spark-plug caps from the high tension wires. 2. Set the selector in the X1K position. wire; then connect the black meter lead to the other high tension wire. AK050D 4. Ignition coil secondary resistance must be between 6800-10,200 ohms. STATOR COIL (Charge) 1. Disconnect the triple-wire plug from the CDI unit to the magneto. 2. Set the selector in the X100 position. the plug; then connect the black meter lead to the black/red wire in the plug. AK013 4. Charge coil resistance must be between 128-192 ohms. LIGHTING COIL 1. Disconnect the main wiring harness from the engine. 2. Set the selector in the X1 position. leads in the connector from the engine. AK015 4. Lighting coil resistance must be between 0.17- 0.26 ohm. SPARK-PLUG CAP 1. Remove the spark-plug caps from the high tension wires. 2. Set the selector in the X1K position. |
