10-2

CAUTION:

Always keep the battery charged.
Storing a discharged battery can
cause permanent battery damage.

To charge a sealed-type (MF) battery,
a special (constant-voltage) battery
charger is required. Using a conven-
tional battery charger will damage
the battery. If you do not have
access to a sealed-type (MF) battery
charger, have a Yamaha dealer
charge your battery.

Do not charge the battery quickly.
Charge the battery for 10 hours at
1.8 amperes.

@

7. Drive track

Loosen the drive track, and block up the
chassis so that the track is suspended
above the ground.

8. V-belt

Remove the V-belt and store separately.

9. Storage

Store the snowmobile in a dry, well-venti-
lated place out of direct sunlight. Put a fab-
ric cover over the snowmobile, preferably
one that is designed for it. Do not use a
plastic or vinyl cover—condensation could
be trapped underneath which could
increase the chances of rusting.

Returning to service after storage

When returning your snowmobile to ser-
vice, reinstall the V-belt and adjust the
drive track, and install the battery.
Remove the spark plugs and clean or
replace them if necessary. Perform all
other pre-operation and seasonal mainte-
nance checks listed in the periodic mainte-
nance chart.

For peak performance, it is recommended
that you have your snowmobile checked
and tuned by a Yamaha dealer. They have
the experience and training to help you get
the maximum performance and use of your
Yamaha snowmobile.

11-1

ESU00228

11-

SPECIFICATIONS

ESU00229

Dimensions

CS-01E

ESU00230

Engine

CS-02E

RX10/RX10S/RX10M/RX10MS/

RX10R/RX10RS

Overall length

2,755 mm (108.5 in): RX10/RX10S/

RX10R/RX10RS

3,185 mm (125.4 in): RX10M/RX10MS

Overall width

1,210 mm ( 47.6 in): RX10/RX10S/

RX10R/RX10RS

1,115 mm ( 43.9 in): RX10M/RX10MS

Overall height

1,190 mm ( 46.9 in)

Dry weight

253 kg ( 558 lb): RX10/RX10S

267 kg ( 589 lb): RX10M/RX10MS
256 kg ( 564 lb): RX10R/RX10RS

Ski tread

1,068 mm ( 42.0 in): RX10/RX10S/

RX10R/RX10RS

980 mm ( 38.6 in): RX10M/RX10MS

RX10/RX10S/RX10M/RX10MS/

RX10R/RX10RS

Type

Liquid cooled 4-stroke, 20 valves

Cylinder arrangement

Parallel 4-cylinder

Displacement

998 cm

3

Bore

× Stroke

74.0

× 58.0 mm (2.91 × 2.28 in)

Idle speed

1,350 ± 100 r/min

Engine oil type

API SE, SF, SG or higher
SAE 5W-30

Carburetor type

MIKUNI, BSR37

× 4

Fuel

Unleaded gasoline

Pump octane

 ; 88 or higher

Starting system

Electric starter

R + M

2

11-2

ESU00231

Chassis

CS-03E

RX10/RX10S/RX10M/RX10MS/

RX10R/RX10RS

Drive track and suspension:

Track

Molded rubber, fiber glass rod reinforced

Width

381 mm (15.0 in)

Track deflection

25–30 mm (0.98–1.18 in)/
100 N (10 kg, 22 lb)

Length on ground

752 mm (29.6 in): RX10/RX10S/

RX10R/RX10RS

1,071 mm (42.2 in): RX10M/RX10MS

Suspension type

Slide Rail Suspension

Drive sprocket

Quadruple polyethylene, 9 teeth:

RX10/RX10S/RX10R/RX10RS

Quadruple polyethylene, 8 teeth:

RX10M/RX10MS

Transmission:

Type

Automatic centrifugal engagement, infinite-
ly variable 3.8:1–1:1

Sheave distance

Approx. 268.5 mm (10.57 in)

Sheave offset

Approx. 15 mm (0.59 in)

Engagement speed

∗1

Approx. 3,600 r/min:RX10/RX10S/

RX10R/RX10RS

Approx. 4,200 r/min:RX10M/RX10MS

Shift speed

∗1

Approx. 10,250 r/min

∗2

Drive chain

Silent chain enclosed in oil bath

Reduction ratio

38/24 (1.58): RX10/RX10S/

RX10R/RX10RS

40/21 (1.90): RX10M/RX10MS

∗1 Subject to change according to elevation settings.
∗2 Usually achieved after approximately 800 m (0.5 mi) traveled.

11-3

ESU00232

Electric

CS-04E

Fuel tank:

Tank capacity

38.0 L (8.4 lmp gal, 10.0 US gal)

Oil quantity:

With oil filter cartridge replacement

3.0 L (2.6 lmp qt, 3.2 US qt)

Without oil filter cartridge replacement

2.8 L (2.5 lmp qt, 3.0 US qt)

Total amount

3.8 L (3.3 lmp qt, 4.0 US qt)

Brake:

Type

Hydraulic disc type (ventilated disc)

Operation

Handle lever, left hand operated

Throttle:

Operation

Handle lever, right hand operated

RX10/RX10S/RX10M/RX10MS/

RX10R/RX10RS

Ignition system

DC-CDI

Spark plug

Type

· R · CR9E (NGK)

Gap

0.7–0.8 mm (0.028–0.031 in)

Battery

Capacity

YTX20L-BS 12 V 18 A·h

Maximum charge rate

1.8 Amperes/hr for 10 hrs

Headlight

 Bulb

× Quantity

12 V, 60/55 W

× 2

Tail/brake light

 Bulb

× Quantity

12 V, 5/21 W

× 2

Meter light

 Bulb

× Quantity

14 V, 50 mA

× 6

Indicator light

 Bulb

× Quantity

14 V, 80 mA

× 3

RX10/RX10S/RX10M/RX10MS/

RX10R/RX10RS
