3-15 CHAS PZ50VT “Europe”/PZ50MP Order Job name/Part name Q’ty Remarks Ski removal Remove the parts in the order listed below. 1 Cotter pin 1 2 Nut 1 3 Bolt 1 4 Collar 1 5 Collar 1 6 Washer 2 7 Collar 1 8 Ski stopper 1 9 Ski stopper plate 1 10 Ski 1 For installation, reverse the removal proce- |
