Snowmobile Yamaha FX10X, FX10RTX, FX10RTRX, FX10RTRAX, FX10MTX, FX10MTRX, FX10MTRAX. Instruction - part 58





5-52

ENG

CRANKCASE

Order

Job name/Part name

Q’ty

Remarks

8

Primary sheave drive shaft assembly bolt

4

9

Lower crankcase

1

10

Dowel pin

1

For installation, reverse the removal proce-
dure.

LS

E

E

E

E

LT

LT

LT

3

6

5

4

1

1

10

9

7

8

(4)

É

Ë

Ë

È

È

È

É

É

Ê

Ê

É

É

É

Ì

2

25 Nm (2.5 m

 kg, 18 ft

 lb)

24 Nm (2.4 m

 kg, 17 ft

 lb)

Ê:
Ë:

12 Nm (1.2 m

 kg, 8.7 ft

 lb)

10 Nm (1.0 m

 kg, 7.2 ft

 lb)

È:
É:

: Yamaha bond No.1215
  (Three Bond No.1215

®

)

Ì

:

Specified angle 65 ~ 70˚

Final

15 Nm (1.5 m

 kg, 11 ft

 lb)

15 Nm (1.5 m

 kg, 11 ft

 lb)

1st

2nd

5-53

ENG

CRANKCASE

REMOVAL

1. Remove:

• Crankcase bolts

NOTE:

• Place the engine upside down.
• Loosen the bolts in decreasing numerical order of

the embossed numbers on the crankcase.

• Loosen each bolt 1/4 of a turn at a time. After all

of the bolts are fully loosened, remove them.

L

2

H F

5

6

7

C

9

1

0

D

4

E

I

G

3

8

J

K

N

M

A

B

2. Remove:

• Lower crankcase

CAUTION:

Tap on one side of the crankcase with a soft-
face hammer. Tap only on reinforced portions
of the crankcase, not on the crankcase mating
surfaces. Work slowly and carefully and make
sure that the crankcase halves separate evenly.

INSPECTION

1. Inspect:

• Crankcase:

Cracks/damage

→ Replace.

NOTE:

• Thoroughly wash the crankcase halves in a mild

solvent.

• Thoroughly clean all the gasket surfaces and

crankcase mating surfaces.

• Oil delivery passages

Obstruction

→ Blow out with compressed air.

2. Inspect:

• Timing chain
• Oil pump drive chain

Damage/stiffness

→ Replace the chain and

sprocket as a set.

3. Inspect:

• Timing chain guide (intake side)
• Timing chain guide (exhaust side)

Damage/wear

→ Replace the timing chain

guide(-s).

5-54

ENG

CRANKCASE

INSTALLATION

1. Lubricate:

• Crankshaft journal bearings

(with the recommended lubricant)

Recommended lubricant:

Engine oil

2. Apply:

• Sealant

(onto the crankcase mating surfaces)

NOTE:

Do not allow any sealant to come into contact with
the oil gallery or crankshaft journal bearings. Do not
apply sealant to within 2 ~ 3 mm (0.08 ~ 0.12 in) of
the crankshaft journal bearings.

3. Install:

• Lower crankcase

(onto the upper crankcase)

Yamaha bond No. 1215:

90890-85505
(Three Bond No.1215

®

)

4. Install:

• Crankcase bolts

NOTE:

• Lubricate the bolts 1  ~  8 thread and washers

with engine oil.

• Lubricate the bolts 9  ~  E,  I  ~  N thread part

and mating surface with engine oil.

• Apply Yamaha bond No. 1215 to the threads of

the bolts F ~ H.

• Finger tighten the crankcase bolts.

M9

× 105 mm bolts: 1 ~

M8

× 70 mm bolts: 9, 0, B

M8

× 55 mm bolt: A

M6

× 80 mm bolts: E, I, J

M6

× 80 mm bolts (black): F ~

M6

× 55 mm bolts: C, D, K, L, N

M6

× 52 mm bolt: M

L

2

H F

5

6

7

C

9

1

0

D

4

E

I

G

3

8

J

K

N

M

A

B

5-55

ENG

CRANKCASE

5. Tighten:

• Crankcase bolts (M9

× 105 mm) 1 ~

NOTE:

Tighten the bolts in the order of the embossed
numbers on the crankcase.

• Tighten the crankcase bolts.

• Loosen and retighten the crankcase bolts.

• Tighten the crankcase bolts further to reach

the specified angle 65 ~ 70°.

WARNING

If the bolt is tightened more than the specified
angle, do not loosen the bolt and then retighten
it. Instead, replace the bolt with a new one and
perform the procedure again.

CAUTION:

• Do not use a torque wrench to tighten the bolt

to the specified angle.

• Tighten the bolt until it is at the specified

angle.

NOTE:

On a hexagonal bolt, note that the angle from one
corner to another is 60°.

T



R

.

.

Crankcase bolt 1 ~ 8:

1st:

15 Nm (1.5 m · kg, 11 ft · lb)

T



R

.

.

Crankcase bolt 1 ~ 8:

2nd:

15 Nm (1.5 m · kg, 11 ft · lb)

T



R

.

.

Crankcase bolt 1 ~ 8:

Final:

Specified angle 65 ~ 70°

2

5

6

7

1

4

3

8
