MPE 750 NA Snow. Instruction - part 3





10056_abMJ07_ETK_Rev1.3_090128

MPE 750 NA Snow

1

2

4

3

5

6

7

4

7

10

11

12

14

6

13

8

9

Spare Parts Catalogue

Page 7

See Chapter Engine Management System

030 Cylinder

Head

03 Cylinder Head

Pos.

Part No

Description

QTY

1

100514

Bolt

M6x40 10.9

4

2

*

Spark Plug

RC7YC

2

3

100228

Sleeve

8

4

100094

Welch Plug

2

5

104249

Cylinder Head incl. Pos. 1, 4, 6, 7, 8, 13

1

6

100587

Seal

8x12x1 Al

2

7

102992

Plug

2

8

400920

Fitting (total lenght 33mm) M8x1x12

1

9

101445

Cylinder Head Gasket

1

10

102453

Stud

M8x38 8.8

8

Pos.

Part No

Description

QTY

11

101446

Exhaust Gasket

2

12

100737

Nut

M8

8

Depending on delivery status Pos. 13 or Pos. 14

13

401990

Fitting (total lenght 38mm) M8x1x17

1

14

100572

Banjo Bolt

M8x1

1

Quod vide chapter 910 Repair Kits

10056_abMJ07_ETK_Rev1.3_090128

MPE 750 NA Snow

1

2

3

4

5

6

7

8

Spare Parts Catalogue

Page 8

030 Cylinder

Head

04 Valves

See Table Valve Adjustment Shim

Intake Side

Exhaust Side

Pos.

Part No

Description

QTY

1

*

Shim

8

2

100129

Collet Valve

16

3

102316

Spring Cup

8

4

100081

Valve Spring

8

5

100658

Valve Stem Seal

8

6

100262

Spring Pad

8

7

102542

Intake Valve

4

8

100091

Exhaust Valve

4

Valve Adjustment Shim (8 parts per bag)

Part No

Description

QTY

102043

Shim

10x2.50

1

102044

Shim

10x2.55

1

102045

Shim

10x2.60

1

102046

Shim

10x2.65

1

102047

Shim

10x2.70

1

102048

Shim

10x2.75

1

102049

Shim

10x2.80

1

102050

Shim

10x2.85

1

102051

Shim

10x2.90

1

102029

Shim

10x2.95

1

102030

Shim

10x3.00

1

102052

Shim

10x3.05

1

102031

Shim

10x3.10

1

102032

Shim

10x3.15

1

102033

Shim

10x3.20

1

102034

Shim

10x3.25

1

102053

Shim

10x3.30

1

102035

Shim

10x3.35

1

102036

Shim

10x3.40

1

102037

Shim

10x3.45

1

102038

Shim

10x3.50

1

102039

Shim

10x3.55

1

102040

Shim

10x3.60

1

102041

Shim

10x3.65

1

102042

Shim

10x3.70

1

10056_abMJ07_ETK_Rev1.3_090128

MPE 750 NA Snow

2

4

5

7

8

9

10

11

6

3

1

Spare Parts Catalogue

Page 9

040 Valve

Train

Pos.

Part No

Description

QTY

1

101921

Camshaft

1

2

100116

Timing Chain incl. Link

1

3

100557

Chain Link, Single

1

4

100078

Camshaft Axle

1

5

100502

Bolt

M6x25 8.8

1

6

100069

Chain Rail

1

7

102456

Chain Guide

1

8

100079

Chain Tensioner

1

9

100436

Seal

24x32x2 Al

1

10

100337

Plug

1

Pos.

Part No

Description

QTY

11

100832

Bolt

M8x25 10.9

1

10056_abMJ07_ETK_Rev1.3_090128

MPE 750 NA Snow

1

2

3

6

4

7

5

8

9

Spare Parts Catalogue

Page 10

050 Cooling

System

01 Water Manifold

See Chapter Engine Management System

Pos.

Part No

Description

QTY

1

100517

O-Ring

2

2

100501

Bolt

M6x20 8.8

2

3

*

Sensor Coolant Temperature

1

4

101076

Water Manifold

1

5

402430

Thermostat

1

6

401279

Distance Washer

1

7

100516

O-Ring

1

8

101253

Fitting

1

9

100294

Circleclip

1
