65

OPERATION

n

Emergency Stopping

The following chart lists methods for stopping the snowmobile in the
event of an emergency. See page 63 for more information about the
engine stop switch.

SYSTEM

WHAT IT DOES

THROTTLE

CONDITION

Ignition Switch

Interrupts ignition circuit

All

Brake

Slows jackshaft

All

Engine Stop Switch

Interrupts ignition circuit

All

Choke (if equipped)

Floods engine

Half throttle or less

Throttle Safety Switch

Interrupts ignition circuit

All

Tether Switch (if equipped)

Interrupts ignition circuit

All

66

OPERATION

Electronic Reverse (PERCt)

Electronic reverse will activate only if the engine RPM is below 4000.
The maximum engine RPM will be 6000 when in reverse.

WARNING

Improper reverse operation, even at low speeds, may cause loss of control,

resulting in serious injury or death. Damage will occur to the chaincase or

transmission if shifting is attempted when the engine is operating above idle

speed.
• Shift to or from reverse only when the snowmobile is stopped and when

engine speed is at idle.

• Look behind the snowmobile before and while backing.
• Avoid sharp turns.
• Apply throttle slowly.

CAUTION

Engaging the starter when the engine is running WILL result in serious

engine damage, especially if the transmission is in reverse. Never engage

the starter when the engine is running.

67

OPERATION

Electronic Reverse (PERCt)

Engaging Reverse

1. Stop the snowmobile and leave the

engine idling.

2. Make sure the area behind your snow-

mobile is clear.

3. Push the yellow reverse button on the

left-hand control for one second, then
release. The engine will automatically
reduce RPM and start a reverse rota-
tion.

NOTE:

A reverse light on the instrument panel will indicate that the transmis-

sion is in reverse.

4. Apply the throttle slowly to make sure the transmission is in

reverse.

NOTE:

If the engine stops running, the snowmobile will be in forward gear

when it's restarted.

Disengaging Reverse

1. Stop the snowmobile and leave the engine idling.

2. Push the yellow reverse button for one second and release. The

engine will slow and begin to rotate forward. The light on the
instrument panel will shut off.

3. Apply the throttle slowly to make sure the transmission is in for-

ward.

CAUTION

Engaging the starter when the engine is running WILL result in serious

engine damage, especially if the transmission is in reverse. Never engage

the starter when the engine is running.

Reverse Button

68

OPERATION

Daily Storage

At the end of each ride, park the snowmobile
on a level surface and support it at the rear
with an appropriate track stand. The track
should be suspended approximately 4" (10 cm)
off the ground.

Remove the key and cover the snowmobile.

Towing

Do not use the front bumper to pull or drag the snowmobile. The front
bumper is not designed for this type of use and may detach from the
vehicle if force is applied.

For your safety, do not attempt to use a tow hitch until you've read the
following warnings and understand the proper hitch functions.

If the snowmobile becomes inoperable and must be towed, and if it isn't
possible to use a rigid tow bar, attach the tow rope to the ski spindles
(not to the ski loops) to prevent damage to the steering components.
Remove the drive belt before towing, and have someone ride on the
towed snowmobile to operate the brake and steering when necessary.

WARNING

Objects towed with a rope have no braking power and can easily collide with

the rear of the snowmobile or other objects, resulting in serious injury or

death. DO NOT tow toboggans, sleds, saucers, or any type of vehicle with a

rope. Only a stiff metal pole connecting the towed object and the tow hitch on

the snowmobile should be used. If passengers are to be towed on a tobog-

gan or sled, make sure the pole is at least four feet (1.2 meters) long to pre-

vent any possibility of contact between the snowmobile's track and a person

riding in the towed object.
Braking distances increase when towing loads. Slow down to maintain con-

trol of the snowmobile.

CAUTION

Towing a disabled snowmobile with the drive belt in place can result in seri-

ous damage to the engine and drive system. Always remove the drive belt

from a disabled snowmobile before towing.
