45

THE PERFECT FIT

Rear Suspension Adjustments

Shock Compression Valving

RMK Standard Rear Track Shock
The standard RMK rear track shock is an Arvin MPV Select shock that
allows for adjustments to the compression valving. Adjustments are
made by turning the adjustment screw located near the base of the
shock.

In half-turn increments, turn the screw clockwise to increase compres-
sion valving and stiffen the ride. Turn the screw counterclockwise to
reduce compression and soften the ride. There are approximately three
full turns of adjustment available.

If bottoming continues after the screw has been turned fully clockwise,
the torsion spring should be adjusted (see page 44). Return the screw to
its original starting position after the torsion spring has been adjusted.

Adjustment Screw

46

THE PERFECT FIT

Handlebar Adjustments

Handlebar position and handlebar angle can be adjusted to rider prefer-
ence. The optimum position for the proper vehicle balance is with the
riser block aligned with the steering post.

After making handlebar adjustments, check to make sure wires are not
pinched or kinked. Make sure the handlebars, brake lever and throttle
lever operate smoothly and do not hit the gas tank, windshield or any
other part of the vehicle when the handlebars are turned fully to the left
or right.

When adjustments are complete, torque the front adjuster block bolts
first, then torque the rear bolts. Torque the bolts to 11-13 ft. lbs. (15-18
Nm).

WARNING

Some aftermarket accessories (including windshields and cargo bags) may

interfere with the handlebar. Such accessories could limit your ability to steer

the vehicle and/or may contact the brake lever. This could lead to loss of con-

trol resulting in serious injury or death. Always be sure that accessories do

not contact the handlebar or brake lever at any handlebar position.

47

THE PERFECT FIT

Handlebar Adjustments

Handlebar Position

1. Loosen the four bolts on the

bottom of the adjuster block.

NOTE:

If necessary, pry the blocks

apart with a screwdriver.

2. Adjust the handlebar forward

or rearward to the desired
position.

3. Tighten the bolts.

Handlebar Angle

1. Loosen the four bolts on the

top of the adjuster block.

NOTE:

If necessary, pry the blocks

apart with a screwdriver.

2. Adjust the handlebar forward

or rearward to the desired
angle.

3. Tighten the bolts.

Loosen top bolts to adjust

handlebar angle

Loosen bottom bolts to

adjust handlebar position

48

THE PERFECT FIT

Accessories

Polaris offers a wide range of accessories for your snowmobile to help
make each ride more enjoyable.

Use only Polaris parts and accessories on your Polaris snowmobile. Use
of unapproved parts and accessories may result in:

• Non-compliance with government/industry requirements

• Voiding of warranty

• Injury to self or others

This applies, but is not limited to the following areas: brakes, clutches,
fuel systems, and exhaust systems.

NOTE:

Exhaust systems are critical safety areas that must use approved

Polaris parts. Please see your Polaris dealer for service.

Tether Switch
The accessory tether switch is available for all models. Order part num-
ber 2870668.
