9.23
REAR SUSPENSION
9
Rear Suspension Rear Track Shock (RTS)
Stock Valving
SHOCK VALVE PART NUMBERS
Shock valves are used in a stack on the top and on the bottom of
the shock piston. These stacks can be adjusted so that it can
control the amount of fluid that is forced by as the piston travels
through its motion. Below is a chart that has the part numbers of
these valves, proceeding the part number is the size of the
washer (out side diameter x thickness). A thick washer (.700 x
.010) will try to keep the fluid from passing through the piston
as it travels.
Refer to the appropriate parts manual for a complete listing of
shock parts.
SHOCK PN
7043177
7043246
7043266
7043205
7043216
7043235
CO
MP
RE
SSIO
N
1.125x.093
.900x.010
1.000x.010
1.100x.012
1.100x.010
1.100.008
1.000x.006
1.300x.008
1.300x.008
1.125x.093
.700x.015
.700x.015
.700x.015
1.000x.010
1.100x.012
1.250x.012
.800x.008
1.250x.008
1.300x.008
.700x.015
.700x.015
.700x.015
.900x.010
1.000x.008
1.100x.008
1.250x.010
.900x.010
1.250x.008
1.300x.006
.875x.090
.625x.065
.700x.008
.800x.008
.900x.010
1.000x.010
1.100x.008
.900x.008
1.100x.008
.700x.010
1.250x.010
1.300x.010
1.125x.093
.900x.008
1.300x.008
1.300x.008
1.300x.010
.800x.010
1.300x.006
1.300x.008
.625x.065
.700x.010
.800x.010
.900x.010
1.000x.010
1.100x.010
1.250x.012
Piston Orifice
.093
.070
.076
.082
.055
.040
REBOUND
1.250x.010
1.250x.010
1.100x.012
1.000x.012
.900x.012
.800x.012
.620x.093
1.250x.008
.700x.006
1.100x.015
1.100x.015
.900x.008
.950x.050
.950x.050
1.250x.008
.700x.008
1.100x.012
1.000x.010
.900x.008
.800x.008
.950x.050
.950x.050
1.250x.012
.800x.008
1.100x.010
1.000x.010
.900x.010
.800x.010
.700x.010
.625x.065
1.250x.012
1.100x.010
1.125x.093
.620x.093
1.300x.010
1.250x.010
1.100x.008
1.100x.008
1.000x.010
.900x.010
.800x.008
.700x.010
.875x.090
ADJUSTER
Piston Assy
1.100x.025
1.000x.015
1.100x.015
.700x.010
.875x.090
