Snowmobile Polaris Trail RMK (2010 year). Instruction - part 19





77

MAINTENANCE

Carburetor

Water/Sediment Trap Service

Most Polaris snowmobiles contain patented carburetor bowl water/sedi-

ment traps located at the bottom of each carburetor. The trap, consisting

of a hose with a plug, should be drained about every 1000 miles (1600

km) and inspected for contamination.

WARNING! When draining the traps, fuel spillage will occur. Always work in a

well ventilated area away from anything that may cause the fuel to ignite, such

as open flames, sparks, heaters, trouble lights, cigarettes, etc. Review the

gasoline warnings found on page 53.

Plug Cleaning Procedure

1. Turn the fuel valve off.
2. Position a container or shop towels to

catch the contaminated gasoline.

3. Slide the clamp away from the drain

plug and remove the drain plug from the

sediment tube.

4. Wipe residue from the plug and reinstall

it. Reposition and tighten the clamps.

Continue until all the traps have been

emptied.

Clamp

Drain

Plug

78

MAINTENANCE

Carburetor

The number stamped in the end of the main jet indicates the jet size. The

jet installed at the time of manufacture is not necessarily correct for your

elevation. It’s your dealer’s responsibility to make sure the correct main

jet is installed.

NOTICE: Operating the snowmobile with incorrect jetting can result in serious

engine damage. Have your Polaris dealer perform all carburetor

adjustments to ensure all adjustments are done correctly.

Carburetor Adjustments

The frequency at which the carburetors are synchronized or balanced is

important. Properly adjusted carburetors can greatly improve engine

performance, fuel economy, engine life, and reliability.
If you notice any of the following conditions, the carburetor may need

adjustment:
• Hard starting
• Poor idle
• Overheated pistons and cylinder walls
• Plug fouling
• Poor engine response to various throttle valve openings

79

MAINTENANCE

Fuel Filter/Fuel Lines

The fuel filter is located inside the fuel tank. This component requires

no maintenance.
Inspect the fuel lines regularly for signs of deterioration or damage.

Always check fuel line condition after periods of storage. Normal dete-

rioration from weather and fuel compounds may occur. Replace worn or

damaged fuel lines promptly.

NOTICE: Kinking the fuel lines or using a pliers or similar tools to remove fuel

lines may cause damage to the lines. If a fuel line has been damaged

or kinked, replace it promptly.

Oil Filter

The oil filter on your model is assembled into the oil sending unit

located in the bottom of the oil tank. This component requires no main-

tenance.
If service is performed to the oil injection system, trapped air must be

bled from the system. See your dealer for instructions, or have your

dealer perform this service.

80

MAINTENANCE

Exhaust System

Check the exhaust system for wear or damage at approximately 1000

miles (1600 km). To inspect, allow the engine and exhaust system to

cool completely. Open the hood and inspect the muffler and pipes for

cracks or damage. Check for weak or missing retaining springs or

damper/support grommets.

CAUTION! Hot exhaust system parts can cause burns. Allow adequate time for

the exhaust system to cool. Never perform this procedure with the engine

running.

Drive Chain Tension

To obtain correct chain tension:
1. Rotate the driven clutch coun-

terclockwise to move all chain

slack to the tensioner side.

Lock the brake lever lock, or

have an assistant hold the

brake lever firmly.

2. Loosen the adjuster bolt jam

nut.

3. Finger tighten the adjuster

bolt until it can no longer be

adjusted by hand, then back

off 1/4 turn.

4. Tighten the jam nut while

holding the adjuster bolt.

5. The chain is now tensioned.

Release the brake lever lock.

Jam

Nut

Adjuster

Bolt
