Snowmobile Polaris Rush (2010 year). Instruction - part 19





77

MAINTENANCE

Hood/Side Panel

The hood and side panels of the

snowmobile protect the operator

from moving parts. Never oper-

ate a snowmobile with the hood

or side panels open or removed.

Always ensure that the hood

and side panels are securely in

place before starting the engine.
To open a side panel, rotate the

two 1/4-turn fasteners at the

upper edges of the side panel.

Release the side panel strap at

the lower edge of the panel.
To remove an open side panel,

pull the panel outward to release

the tabs at the lower edge of the

panel.
Removing the hood is not recommended. Any service requiring the

removal of the hood should be performed by an authorized Polaris

dealer.

Strap

1/4-Turn Fasteners

78

MAINTENANCE

Lubrication

n

Chaincase Oil

Check and change the chaincase oil at the intervals outlined in the main-

tenance charts beginning on page 73. Maintain the oil level at the top of

the fill plug hole. Polaris recommends the use of Polaris Synthetic

Chaincase Lube. See page 110 for the part numbers of Polaris products.

Oil Level
1. Position the vehicle on a level

surface.

2. Remove the fill plug.
3. Using a funnel, slowly add the

recommended oil until the fluid

begins to overflow.

4. Wipe the fill area with a clean

cloth.

5. Reinstall the fill plug. Torque to

6-10 ft. lbs. (8-13 Nm).

Fill Plug

79

MAINTENANCE

Lubrication

n

Chaincase Oil

Oil Change
1. Position the vehicle on a level surface.
2. Place a drain pan under the drain plug. Remove the drain plug.

Allow the oil to drain completely.

3. Clean off all metal shavings from the plug. Install a new sealing

washer on the drain plug.

TIP: The sealing surfaces on the drain plug and the oil tank should be clean and

free of burrs, nicks or scratches.

4. Reinstall the drain plug. Torque to 6-10 ft. lbs. (8-13 Nm).
5. Remove the fill plug. Clean off all metal shavings from the plug.
6. Using a funnel, slowly add the recommended oil until the fluid

begins to overflow. Fluid capacity is 9 oz. (266 ml).

7. Wipe the fill area with a clean cloth.
8. Reinstall the fill plug. Torque to 6-10 ft. lbs. (8-13 Nm).

80

MAINTENANCE

Lubrication

Rear Shock Body Threads

Lubricate rear shock body threads

seasonally. We recommend the use

of Polaris Shock Thread Lubricant, a

silicone spray lubricant. This lubri-

cant is specifically designed for cold

temperatures and high loads. Other

silicone lubricants will not perform

as well. See page 110 for the part

numbers of Polaris products.

Driveshaft Bearing

Inject grease into the fitting on the

speedometer sensor housing until

grease purges from the seal on the

inside of the tunnel. This should

take approximately two pumps. Do

not use more than four pumps.

Throttle Cable

Lubricate the throttle cable lightly

with grease or oil. With the engine

off, turn the handlebars to the left

and lubricate liberally as shown.

+

+

+
