Snowmobile Polaris RMK & Switchback (2004 year). Instruction - part 6

SAFETY

Safety Decals and Locations

Track/Seat Warning

The track/seat warning decal is on the rear of

the tunnel:

Stay clear of track. Do not sit on seat

back. Entanglement with the track or a

fall from seat back may result in

severe injury or death.

Reverse Warning

Some Polaris snowmobiles are equipped with electric reverse and will

have this decal on the console:

Reverse operation, even at low

speeds, may cause loss of

control resulting in serious injury

or death. To avoid loss of control,

always:

Look behind before and while

backing.

Avoid sharp turns.

Shift to or from reverse only

when stopped.

Apply throttle slowly.

NOTE: For more information, see your Owner’s Manual.
If electric reverse:

Machine stopped and engine at idle, push yellow button on LH

control to reverse. Flashing light on dash indicates reverse opera-

tion.

Push button again to return to forward.

Elevation setting (above 6000 feet): push and hold for longer than

5 seconds to set. Let go of button at desired setting-fast flash for

high elevation, slower flash for low. Setting will remain until

changed.

SAFETY

Safety Decals and Locations

Operation Warning

An operation warning decal is present on the console of all Polaris

snowmobiles:

To avoid serious injury or death, read

and understand all warnings and the

Owner’s Manual before operation. If

manual is missing, contact a Polaris

dealer for a replacement.

This vehicle is capable of high

speeds. Buried objects or uneven

terrain can cause loss of control.

Reduce speed and use extreme

caution when operating in unfamiliar

terrain.

Excessive speed, especially at night or with limited visibility, can result

in insufficient time for you to react to terrain changes, to avoid unex-

pected obstacles, or to stop safely.

Never consume alcohol or drugs before or while operating this vehicle.

In an emergency, push down the Auxiliary Shut-Off Switch, located on

the top of the throttle control assembly, to stop the engine. Then pull the

brake lever to stop.

Always wear an approved helmet, eye protection, and adequate cloth-

ing while operating this vehicle.

This vehicle is designed for adult use only. Check local laws for age re-

quirements.

When operating with a passenger (on approved models only), reduce

speed and allow extra space for steering and stopping. A passenger

reduces your ability to control the vehicle.

When operating on hard-packed snow, ice, or when crossing roads,

steering and braking ability are greatly reduced. Reduce speed and al-

low extra space to turn or stop.

To maintain vehicle control on ice or hard-packed surfaces, you should

have a proper balance of ski carbides to track studs. See Owner’s

Manual for proper use of traction products.

Repeated stops from high speed may cause fading or sudden loss of

braking ability.

Parking brake may relax when used for long periods. Do not leave brake

engaged for more than five minutes.

Before starting the engine, check throttle, brake, and steering for proper

operation. Make sure hood is latched. Be seated and in position to con-

trol the vehicle.

Oil injection system: Use unmixed fuel only. Check oil level when refueling.

FEATURES AND CONTROLS

Controls

1. Fuel Filler Cap (may include a fuel gauge)

2. Ignition Switch

3. Brake Lever

4. Speedometer (may include indicator/warning lights)

5. Tachometer (may include indicator/warning lights)

6. Engine Stop Switch (see page 59)

7. Throttle Control

8. Recoil Starter Handle

9. Choke

FEATURES AND CONTROLS

Controls

Some Polaris snowmobiles are equipped with special features.

Controls for these features are illustrated on this page. Not all models

come with these features. Refer to your Owner’s Manual Supplement

for a list of features on your machine.
Accessories are available from your Polaris dealer.
1. Headlight Dimmer

Switch (2 Position)

2. Park Brake

3. Handlebar Grip

Warmer Switch

4. Thumbwarmer

Switch

5. Electronic Reverse

Button
