68

OPERATION

Hauling Cargo

Overloading the vehicle or carrying or towing cargo improperly can alter vehicle

handling and may cause loss of control or brake instability. Always follow these

precautions when hauling cargo:
Never exceed the stated load capacity for this vehicle.
REDUCE SPEED AND ALLOW GREATER DISTANCES FOR BRAKING

WHEN HAULING CARGO.
NEVER EXCEED THE MAXIMUM WEIGHT CAPACITY of the vehicle. When

determining the weight you are adding to the vehicle, include the weight of the

operator, accessories, loads in the rack or box and the load on the trailer tongue.

The combined weight of these items must not exceed the maximum weight

capacity.
Always load the cargo box with the load as far forward and as low as possible.
When operating over rough or hilly terrain, reduce speed and cargo to maintain

stable driving conditions.
Always operate the vehicle with extreme care when hauling or towing loads.

Slow down and drive in the lowest gear available.
SECURE ALL LOADS BEFORE OPERATING. Unsecured loads can create

unstable operating conditions, which could result in loss of control of the vehicle.
OPERATE ONLY WITH STABLE AND SAFELY ARRANGED LOADS. When

handling off-centered loads that cannot be centered, securely fasten the load

and operate with extra caution. Always attach the tow load to the hitch point

designated for your vehicle.
HEAVY LOADS CAN CAUSE BRAKING AND CONTROL PROBLEMS. Use

extreme caution when applying brakes with a loaded vehicle. Avoid terrain or

situations that may require backing downhill.
USE EXTREME CAUTION when operating with loads that extend over the rack

sides. Stability and maneuverability may be adversely affected, causing vehicle

rollover.
DO NOT TRAVEL FASTER THAN THE RECOMMENDED SPEEDS. Vehicle

should never exceed 10 MPH (16 km/h) while towing a load on a level grass

surface. Vehicle speed should never exceed 5 MPH (8 km/h) when towing loads

in rough terrain, while cornering, or while ascending or descending a hill.
Carrying a passenger in the cargo box could

result in a fall from the vehicle or contact with

moving components. Never allow a passenger

to ride in the cargo box.

WARNING

69

OPERATION

Hauling Cargo

Your POLARIS vehicle has been designed to carry or tow specific

capacities. Reduce speed and allow a greater distance for braking when

carrying cargo.
Loads should be centered and carried as low as possible in the box. For

stability on rough or hilly terrain, reduce both speed and cargo. Exercise

caution if the cargo load extends over the side of the box.
Always read and understand the load distribution warnings listed on

warning labels and in this manual. Never exceed the maximum

capacities specified for your vehicle. See page 132.

Belt Life
To extend belt life, use low gear when hauling or towing heavy cargo.

70

OPERATION

Towing Loads

Towing is approved OFF-ROAD ONLY. See your POLARIS dealer about

configuring the vehicle to be certified to tow a trailer on-road.
Towing improperly can alter vehicle handling and may cause loss of control or

brake instability.

Always follow these precautions when towing:
1. Never load more than 150 lbs. (68 kg) tongue weight on the towing

bracket.

2. When towing a disabled vehicle, place the disabled vehicle’s

transmission in neutral. Do not operate the vehicle faster than 10

MPH (16 km/h) when towing.

3. Towing a trailer increases braking distance. Do not operate the

vehicle faster than 10 MPH (16 km/h) when towing.

4. Do not tow more than the recommended weight for the vehicle.
5. Attach a trailer to the trailer hitch bracket only. Do not attach a

trailer to any other location, which could result in loss of control of

the vehicle.

6. The total load (operator, accessories, cargo and weight on hitch)

must not exceed the maximum weight capacity of the vehicle.

Total Towed

Load Weight

(Level Ground)

Total Towed

Load Weight

(15° grade)

Total Hitch

Vertical

Weight

Maximum

 Towing

Speed

 1500 lbs. (680 kg)

850 lbs. (386 kg)

150 lbs. (68 kg)

10 MPH (16 km/h)

WARNING

71

OPERATION

All Wheel Drive (AWD) System

Engaging AWD

Press the top of the rocker switch to engage All Wheel Drive (AWD).

Once enabled, the AWD remains enabled until the switch is turned off.
The AWD switch may be turned on or off while the vehicle is moving.

When the AWD switch is on, the front gearcase will automatically

engage any time the rear wheels lose traction. When the rear wheels

regain traction, the front gearcase will automatically disengage.

Tip: AWD will not engage initially until speed is less than 5 MPH (8 km/h).

Engage the AWD before getting

into conditions where front wheel

drive may be needed. If the rear

wheels are spinning, release the

accelerator before switching to

AWD.

NOTICE: Switching to AWD while

the rear wheels are

spinning may cause

severe drive train

damage. Always switch to

AWD while the rear

wheels have traction or

are at rest.

Locking the Differential

NOTICE: Damage to the differential

can occur if it is engaged

while the vehicle is

traveling at high speeds or

while the rear wheels are

spinning. Slow the vehicle

to nearly stopped before

engaging the differential.

Locking the differential in slippery or low traction conditions helps

improve traction. Move the rocker switch to the center position (2WD)

to lock the differential and operate in rear wheel drive.
Press the bottom of the switch to unlock the differential and allow the

rear drive wheels to operate independently. This mode of operation is

well suited to turf driving or whenever aggressive traction is not

required.

AWD

2WD

1WD/TURF
