Snowmobile Polaris 800 RMK / 800 Pro-RMK / 800 RMK (2010 year). Instruction - part 25





101

MAINTENANCE

Steering System

Ski Skags

WARNING! Worn skis and/or skags will adversely affect handling. Loss of
vehicle control may result, causing serious injury or death. See your dealer's
studding chart for recommended skags. If you install longer or more aggressive
carbide skags than the original equipment, it may also be necessary to add track
studs to maintain proper vehicle control while turning on hard-packed snow or
ice.

Check skags before each use of the snowmobile to ensure positive steer-
ing characteristics. Skags must be replaced when worn to half their orig-
inal diameter.

TIP: Carbide skags must be replaced if any abnormal wear or chipping is found.

Skag Replacement

1. Raise and support the front of the

snowmobile so the skis are
approximately 6I (15.2 cm) from
the ground.

2. Remove the attaching nuts and pry

the skag downward.

3. Remove the front end of the skag.

4. Remove the rear end of the skag.

5. Reverse the steps to install a skag.

Rail Slide Wear

For ease of inspection, all
POLARIS rail slides have
a wear limit indicator
groove to indicate the min-
imum permissible slide
thickness. Replace the rail
slides if they are worn to
the top of the groove at any
point along their length.
Failure to do so may result
in permanent damage to
the track or rails.

Skag

Replace when

worn to top of

groove

Minimum

Thickness

102

MAINTENANCE

Fall Tune-Up

For maximum performance, arrange for a fall service tune-up with your
POLARIS dealer. His experienced and trained service technician will
keep your snowmobile in peak operating condition.

Transporting the Snowmobile

Whenever the snowmobile is transported:

1. Be sure the fuel cap and oil cap are installed correctly.

2. Tie the snowmobile to the transporting unit securely using suitable

straps.

3. Remove the ignition key to prevent loss.

Extended Storage

Off-season or extended storage of your snowmobile requires preventive
measures to aid against deterioration and to prolong the useful life of
many components. See page 104 for the part numbers of POLARIS
products.

Cleaning and Preservation

Proper storage starts with cleaning, washing, and waxing the hood, side
panels, chassis, and plastic parts. Wipe down remaining surfaces with a
damp cloth. Clean and touch up with paint any rusted or previously
painted surfaces. Be sure that corrosive salt and acids are removed from
surfaces before beginning preservation with waxes and rust inhibitors
(grease, oil or paint).

The snowmobile should be stored in a dry garage or shed, out of direct
sunlight, and covered with a fabric snowmobile cover. Plastic tarp may
cause condensation to form and damage snowmobile components.

103

MAINTENANCE

Extended Storage

Controls and Linkage

Lubricate all bushings and cables as outlined in the Periodic Mainte-
nance Table beginning on page 70.

Clutch and Drive System

Remove the drive belt and store in a cool dry location. Do not lubricate
clutch components, except the driven clutch shaft bushing as outlined in
the Master Repair Manual. See your dealer.

Engine Protection

Proper preparation of the engine and fuel system is vital to the preven-
tion of rust and corrosion on precision engine parts during storage.
Whenever the snowmobile is stored for a period of more than 60 days,
the engine must be fogged with fogging oil. Follow the engine fogging
instructions provided on the container.

Always add Premium Carbon Clean or a fuel conditioner/stabilizer to
the fuel tank. Follow the instructions on the container, running the
engine for five minutes to get additives through the entire fuel system.
Top off with fresh fuel. Do not allow the snowmobile to run out of fuel.

Electrical Connections

Replace worn or frayed electrical wire and connectors. Be sure wiring
harness is properly secured away from sharp edges, steering linkage,
moving parts, and hot exhaust parts.

Track and Suspension

Moderate track tension should be maintained during summer storage.
The snowmobile should be supported off the ground to allow the track
to hang freely.

104

POLARIS PRODUCTS

Part No.

Description

Engine Lubricants

2870791

Fogging Oil (12 oz. Aerosol)

2875035

Premium 2-Cycle Semi-Synthetic Oil (qt./.95 l) (break-in only)

2875036

Premium 2-Cycle Semi-Synthetic Oil (gal./3.8 l) (break-in only)

2877882

VES Gold Plus 2-Cycle Oil (qt./.95 l)

2877953

VES Gold Plus 2-Cycle Engine Oil (2 qt./1.9 l)

2877883

VES Gold Plus 2-Cycle Engine Oil (gal./3.8 l)

2877884

VES Gold Plus 2-Cycle Engine Oil (2.5 gal./9.5 l)

2877887

VES Gold Plus 2-Cycle Engine Oil (ltr)

2877888

VES Gold Plus 2-Cycle Engine Oil (4 ltr)

Chaincase Lubricants

2873105

Synthetic Chaincase Lubricant (qt./.95 l)

2872951

Synthetic Chaincase Lubricant (12 oz./355 ml)

Grease/Specialized Lubricants

2871312

Grease Gun Kit, Premium All Season (3 oz./89 ml)

2871322

Premium All Season Grease (3 oz./89 ml cartridge)

2871423

Premium All Season Grease (14 oz./414 ml cartridge)

2871329

Dielectric Grease (Nyogel

t

)

Coolant

2871323

Anitfreeze, 60/40 Premix (gal.)

2871534

Anitfreeze, 60/40 Premix (qt.)

Additives/Miscellaneous

2871326

Carbon Clean Plus

2870652

Fuel Stabilizer

2872189

DOT4 Brake Fluid

2872893

Engine Degreaser

2870505

Isopropyl

2872889

Brake and Clutch Cleaner

2872890

Carb and Throttle Body Cleaner

2878018

Shock Thread Spray Lubricant
