Snowmobile Polaris 600 Switchback / 800 Switchback (2013 year). Instruction - part 28





112

MAINTENANCE

Steering System

Rail Slide Wear

Measure slide thickness at
several points along the rail.
Have your dealer replace the
slide when it's worn down to
the top of the wear limit
indicator groove (X). Do not
operate the snowmobile if
slide thickness measures less
than 7/16 inch (1.1 cm).

Rear Suspension

Lubricate the suspension pivot shaft with Polaris Premium All Season
Grease every 1000 miles (1600 km) and before seasonal storage.

Inspect the rear suspension bushings (X) at the intervals outlined in the
Periodic Maintenance Table beginning on page 81. Inspect more often if
the snowmobile is frequently operated in extreme conditions. Replace
bushings when they show evidence of wear.

7/16 inch

(1.1 cm)

X

X

X

X

Lubricate

113

MAINTENANCE

Fall Tune-Up

For maximum performance, arrange for a fall service tune-up with your
POLARIS dealer. His experienced and trained service technician will
keep your snowmobile in peak operating condition.

Matte Clear Coat Cleaning (if equipped)

Matte finish products are prone to trapping dirt, oils and other contami-
nants. POLARIS Industries recommends cleaning with warm water and
a mild dish detergent. Use a soft sponge to gently rub the surface and
rinse with clean warm water. For stubborn stains such as grease or oil
use a citrus based cleaner (3M Citrus Base Cleaner recommended).
Spray onto the area to be cleaned and rub with a soft sponge. Allow to
sit for a couple of minutes and wash away with clean warm water.
Repeat as necessary to clean the surface.

NOTICE: Never use a polishing/buffing wax or any sponge that has an abrasive

surface. These products will buff the matte surface of the finish result-
ing in a glossy finish. It is not recommended that you clean matte fin-
ishes with a pressure washer as this will further imbed contaminants
into the clear coat and possibly damage the labels.

114

MAINTENANCE

Extended Storage

Off-season or extended storage of your snowmobile requires preventive
measures to aid against deterioration and to prolong the useful life of
many components. See page 116 for the part numbers of POLARIS
products.

Cleaning and Preservation

Proper storage starts with cleaning, washing, and waxing the hood, side
panels, chassis, and plastic parts. Wipe down remaining surfaces with a
damp cloth. Clean and touch up with paint any rusted or previously
painted surfaces. Be sure that corrosive salt and acids are removed from
surfaces before beginning preservation with waxes and rust inhibitors
(grease, oil or paint).

The snowmobile should be stored in a dry garage or shed, out of direct
sunlight, and covered with a fabric snowmobile cover. Plastic tarp may
cause condensation to form and damage snowmobile components.

115

MAINTENANCE

Extended Storage

Clutch and Drive System

Remove the drive belt and store in a cool dry location. Do not lubricate
clutch components, except the driven clutch shaft bushing as outlined in
the Master Repair Manual. See your dealer.

Engine Protection

Proper preparation of the engine and fuel system is vital to the preven-
tion of rust and corrosion on precision engine parts during storage.
Whenever the snowmobile is stored for a period of more than 60 days,
the engine must be fogged with fogging oil. Follow the engine fogging
instructions provided on the container.

Always add Premium Carbon Clean or a fuel conditioner/stabilizer to
the fuel tank. Follow the instructions on the container, running the
engine for five minutes to get additives through the entire fuel system.
Top off with fresh fuel. Do not allow the snowmobile to run out of fuel.

Electrical Connections

Replace worn or frayed electrical wire and connectors. Be sure wiring
harness is properly secured away from sharp edges, steering linkage,
moving parts, and hot exhaust parts.

Track and Suspension

Moderate track tension should be maintained during summer storage.
The snowmobile should be supported off the ground to allow the track
to hang freely.

Transporting the Snowmobile

Whenever the snowmobile is transported:

1. Be sure the fuel cap and oil cap are installed correctly.

2. Tie the snowmobile to the transporting unit securely using suitable

straps.

3. Remove the ignition key to prevent loss.
