Snowmobile Polaris 600 Switchback / 800 Switchback (2013 year). Instruction - part 9





36

FEATURES

Instrument Cluster

Rider Information Center

Standard/Metric Display

The odometer and temperature displays can be viewed in either standard
or metric units of measurement. Both displays change if units are
changed. The new settings will remain until changed by the operator.

Change Method 1

1. Press and release the MODE button or MODE switch until engine

temperature displays.

2. Press and hold the MODE button or MODE switch until the units

change.

Change Method 2

1. Press and release the SELECT button or SET switch until the

odometer displays.

2. Press and hold the SELECT button or SET switch until the units

change.

37

FEATURES

Instrument Cluster

Rider Information Center

Security System (Ignition Lock System)

This system is an optional feature and will not function until it has been
activated by your authorized POLARIS dealer. If you have this feature
activated, you can lock the ignition to prevent unauthorized use when
leaving the snowmobile unattended. A locked system will limit engine
speed to 3000 RPM, which prevents clutch engagement, and the snow-
mobile will not move when throttle is applied.

If you wish to use this feature, you must complete all four tasks on the
following pages to have your system activated and to change the secu-
rity code to one of your own choosing.

38

FEATURES

Instrument Cluster

Rider Information Center

Security System (Ignition Lock System)

First Time Use of Your Security System

Perform all tasks in the order shown if you wish to

activate and use the optional security system.

TASK 1: Activate the security system
See your authorized POLARIS dealer to have the optional security system
feature activated in the electronic control unit (ECU).

TASK 2: Lock the System the First Time
1. Start the engine and lock the parking brake.
2. Press and hold the MODE and SEL buttons for 3

seconds, then release. SECURE OFF should be
displayed. If not, repeat this step.

3. Wait until ENTER CODE displays, then press

and release SEL to advance the digit. When “0”
is displayed, press and release MODE to accept
the digit. TIP: If the ENTER CODE screen exits
due to inactivity, repeat step 2.

4. Press and release SEL to advance the second

digit. When “0” is displayed, press and release
MODE to accept the digit.

5. Press and release SEL to advance the third digit.

When “0” is displayed, press and release MODE
to accept the digit.

6. After accepting the third digit, view the display

screen. SECURE ON displays if the system locks.

NOTE:

The system is now locked.

7. You must now unlock the system. Proceed imme-

diately to TASK 3.

39

FEATURES

Instrument Cluster

Rider Information Center

Security System (Ignition Lock System)

First Time Use of Your Security System

TASK 3: Unlock the System

1. When the engine is running, the display will

alternate between SECURE ON and
ENTER CODE. Wait until ENTER CODE
displays, then press and release SEL to
advance the digit. When “0” is displayed,
press and release MODE to accept the
digit.

2. Press and release SEL to advance the second

digit. When “0” is displayed, press and release
MODE to accept the digit.

3. Press and release SEL to advance the third digit.

When “0” is displayed, press and release MODE
to accept the digit.

4. After accepting the third digit, view the display

screen. SECURE OFF displays if the system
unlocks.

NOTE:

The system is now unlocked.

5. You must now enter a new security code. Proceed immediately to TASK 4.

TASK 4: Enter Your New Security Code

1. Immediately after locking and unlocking the system, and while SECURE

OFF is displayed, press and release the MODE button to bring up the
ENTER CODE screen.

2. When ENTER CODE displays, use the SEL and MODE buttons to select

and accept each digit of a new personal security code.

3. After accepting the third digit, view the display

screen. The new code and CODE SET will dis-
play if the system accepted your new code. You
will not see this display again.

NOTE:

Your new code is now set. The system is

NOT locked.

4. Record your new security code in a safe place for future reference.

Record your new personal security code here: __________________

TIP: If you lose your personal security code, see your dealer to have the code

reset to “000”. Then perform TASK 2 through TASK 4 to change the code
to one of your own choosing.

888
