Snowmobile Polaris 600 IQ Touring (2010 year). Instruction - part 19





77

OPERATION

n

Oil

Low Oil Indicator Light

The low oil indicator light will alert the operator if the oil level is low.

Visually check for oil in the bottle. Add oil before further operation of

the snowmobile. See page 73 for oil recommendations.

Low Oil Level

Maintaining the proper oil level will prevent system aeration and possi-

ble loss of pumping action, which could result in engine damage. This is

especially important when the machine is operated in mountainous ter-

rain.

NOTICE: Operating the snowmobile without adequate engine lubrication can

result in serious engine damage. Always check the oil level when

refueling. Add oil as needed.

Always maintain a visible level of oil in the tank. If oil is not visible,

continued operation may cause serious engine damage. See page 73 for

oil recommendations.
The Polaris oil cap on the oil bottle is vented to allow proper oil flow.

See your Polaris dealer for recommended replacement parts.

78

OPERATION

n

Engine Stop Switch

Push down on the engine stop

switch to ground out the ignition

and stop the engine quickly. Pull the

switch up to the RUN position to

allow restarting.

n

Throttle Safety Switch

The throttle safety switch is designed to stop the engine whenever all

pressure is removed from the throttle lever and the throttle cable or

valves do not return to the normal closed position.

WARNING! Operating the snowmobile with a faulty throttle safety switch can

result in serious injury or death in the event of an accident. If the throttle safety

switch does not shut off the engine during a carburetor/throttle system

malfunction, immediately push down the engine stop switch. Do not start the

engine again until the malfunction has been corrected by your dealer.

Stop Switch

79

OPERATION

n

Throttle Lever

WARNING! An improperly functioning throttle lever may cause erratic machine

behavior and loss of control, which could result in serious injury or death. If the

throttle lever does not work properly, DO NOT start the engine.

If the engine stops abruptly when the throttle lever is released:
1. Turn the ignition switch to OFF.
2. Visually inspect the throttle cable and throttle body to determine

what caused the safety switch to activate.

3. Test the throttle lever by compressing and releasing it several times.

The lever and cable must return to the idle position quickly and

completely.

4. If the throttle lever operates properly, turn the ignition switch on and

go through normal starting procedures.

5. If the engine doesn't start, take the snowmobile to an authorized

Polaris dealer for service.

Tip: Excessive freeplay in the throttle cable may cause the safety switch to acti-

vate, preventing the engine from starting. If this occurs, return the snowmo-

bile to an authorized Polaris dealer for service.

Tip: If an emergency exists and it's necessary to start the engine, the throttle

safety switch and engine stop switch may be disconnected from the wire

harness. When these switches are disconnected, the ignition key switch

must be used to shut off the engine. DO NOT continue to operate the

machine with the throttle safety switch disconnected. Return the machine to

an authorized Polaris dealer for service as soon as possible.

80

OPERATION

Electronic Reverse (PERCt)

Electronic reverse will activate only if the engine RPM is below 4000

.

WARNING! Improper reverse operation, even at low speeds, may cause loss of

control, resulting in serious injury or death. Damage will occur to the gearcase or

transmission if shifting is attempted when the engine is operating above idle

speed.
• Shift to or from reverse only when the snowmobile is stopped and when

engine speed is at idle.

• Look behind the snowmobile before and while backing.
• Avoid sharp turns.
• Apply throttle slowly.

NOTICE: Engaging the starter when the engine is running WILL result in serious

engine damage, especially if the transmission is in reverse. Never

engage the starter when the engine is running.

Engaging Reverse

1. Stop the snowmobile and

leave the engine idling.

2. Make sure the area behind

your snowmobile is clear.

3. Push the yellow reverse but-

ton on the left-hand control

for one second, then release.

Tip: A reverse light on the instrument panel will indicate that the transmission is

in reverse.

4. Apply the throttle slowly to make sure the transmission is in

reverse.

Tip: If the engine stops running, the transmission will be in forward gear when

it's restarted.

Reverse Button
