63

MAINTENANCE

Lubrication

Lubrication points are indicated in the illustrations below.

Front Suspension

Lubricate the steering post U-
joint at the intervals outlined in
the maintenance charts
beginning on page 59.

Rear Suspension

Lubricate the suspension pivot shafts with POLARIS All Season Grease
at the intervals outlined in the Periodic Maintenance Table beginning on
page 59 and before seasonal storage. When operating in heavy, wet
snow conditions, lubricate every 500 miles (800 km).

Lack of lubrication will adversely affect your ride and the life of the
suspension. For more information about suspension lubrication and
adjustments, see your POLARIS dealer.

X

X

X

X

64

MAINTENANCE

Lubrication

Throttle Cable

Lubricate the throttle cable lightly
with grease or oil. With the engine
off, turn the handlebars to the left
and lubricate liberally as shown.

Choke and Choke Cable

Lubricate the choke slide and cables
lightly with oil or grease. Before
turning the engine off, operate the
choke intermittently to draw
moisture out of the choke plunger
area and reduce the possibility of the
choke becoming frozen.

X

X

65

MAINTENANCE

Lubrication

Chaincase Oil

Check the chaincase oil level at the intervals outlined in the
maintenance charts beginning on page 59. Change the chaincase oil
after the first 500 miles (800 km), then every 2000 miles (3200 km) or
seasonally.

Maintain the oil level between the “safe” marks on the dipstick. Clean
the magnetic plug on the dipstick whenever checking or changing oil.

POLARIS recommends the use of POLARIS Synthetic Chaincase Lube.
See page 100 for the part numbers of POLARIS products.

Oil Check

1. Position the vehicle on

a level surface.

2. Remove the dipstick (1)

and view the oil level
on the dipstick.

3. Add the recommended

oil as needed. Do not
overfill.

4. Clean the magnetic

plug (2).

5. Reinstall the dipstick.

1

2

66

MAINTENANCE

Spark Plugs

A new engine can cause temporary spark plug fouling due to the
preservative added during the assembly process. Avoid prolonged idle
speeds, which cause plug fouling and carbonization.

• Use recommended spark plugs with the proper gap.
• Torque spark plugs to 18-22 ft. lbs. (24-30 Nm).
• Always carry spare spark plugs.

NOTICE: Using non-recommended spark plugs can result in serious engine

damage. A spark plug with a heat range too high will always cause
engine damage if the engine is operated in conditions more severe
than intended for that plug. Always use the spark plugs recommended
for your snowmobile.

Spark Plug Condition

Spark plug condition is indicative of engine operation. The spark plug
firing end condition should be read after the engine has been warmed up
and the vehicle has been driven at higher speeds. Immediately check the
spark plug for correct color.

CAUTION! A hot exhaust system and engine can cause burns. Wear
protective gloves when removing a spark plug for inspection.

Incorrect fuel mixture can often cause a spark plug to appear too dark or
too light in color. Before changing spark plug heat ranges, be sure the
correct main jet is installed in the carburetor(s).
