Snowmobile Polaris 550 Transport Trail Touring. Instruction - part 20





78

MAINTENANCE

Lubrication

n

Chaincase Oil

Check the chaincase oil level at the intervals outlined in the mainte-

nance charts beginning on page 72. Change the chaincase oil after the

first 500 miles (800 km), then every 1000 miles (1600 km) or season-

ally.

Maintain the oil level between the “safe” marks on the dipstick. Clean

the magnetic plug on the dipstick whenever checking or changing oil.

Polaris recommends the use of Polaris Synthetic Chaincase Lube. See

page 113 for the part numbers of Polaris products.

Oil Check
1. Position the vehicle on

a level surface.

2. Remove the dipstick (1)

and view the oil level

on the dipstick.

3. Add the recommended

oil as needed. Do not

overfill.

4. Clean the magnetic

plug (2).

5. Reinstall the dipstick.

1

2

79

MAINTENANCE

Spark Plugs

A new engine can cause temporary spark plug fouling due to the preser-

vative added during the assembly process. Avoid prolonged idle speeds,

which cause plug fouling and carbonization. Refer to your Owner's

Manual Supplement for the specific spark plug to be used in your

machine.

Spark plug condition is indicative of engine operation. The spark plug

firing end condition should be read after the engine has been warmed up

and the vehicle has been driven at higher speeds. Immediately check the

spark plug for correct color.

NOTE: Incorrect fuel mixture can often cause a spark plug to appear

too dark or too light in color. Before changing spark plug heat

ranges, be sure the correct main jet is installed in the carbure-

tor(s). Refer to the Owner's Manual Supplement or see your

dealer.

CAUTION

Using non-recommended spark plugs can result in serious engine damage. A

spark plug with a heat range too high will always cause engine damage if the

engine is operated in conditions more severe than intended for that plug.

Always use the spark plugs recommended for your snowmobile. See your

Owner’s Manual Supplement.
• Use recommended spark plugs with the proper gap.
• Torque spark plugs to 18-22 ft. lbs. (24-30 Nm).
• Always carry spare spark plugs.

WARNING

A hot exhaust system and engine can cause serious burns. Wear protective

gloves when removing a spark plug for inspection.

80

MAINTENANCE

Spark Plugs

Normal Plug
The normal insulator tip is gray, tan or light brown. There will be few

combustion deposits. The electrodes are not burned or eroded. This indi-

cates the proper type and heat range for the engine and the service.

NOTE: The tip should not be white. A white insulator tip indicates over-

heating, caused by use of an improper spark plug or incorrect

carburetor/throttle body adjustments.

Wet Fouled Plug
The wet fouled insulator tip is black. A damp oil film covers the firing

end. There may be a carbon layer over the entire nose. Generally, the

electrodes are not worn. General causes of fouling are excessive oil, use

of non-recommended injection oil, improper use of the choke, or incor-

rect carburetion adjustments.

Spark Plug Removal and Replacement

1. Remove the spark plug cap.
2. Using the special wrench provided in the tool pouch, rotate the

spark plug counterclockwise to remove it.

3. Reverse the procedure for spark plug installation.
4. Torque the spark plug to specification. See page 79.
5. Verify that gap is within specification. See your Owner’s Manual

Supplement.

6. Reinstall the spark plug cap.

81

MAINTENANCE

Intake Filters

The intake foam filter (+) limits snow ingestion into the intake system.

When operating in loose powder snow, check the top of the foam filter

periodically to remove any accumulation of snow.

NOTE: These illustrations are general representations. Your model

may differ.

CAUTION

Operating the snowmobile with the intake filters removed may cause carbu-

retor icing. The result will be poor fuel economy or carburetor malfunction.

Always reinstall the intake filters before operating the snowmobile.

+

+
