28

FEATURES

Backrest

The backrest is adjustable for either

operator or passenger use.

1. Loosen the upper adjustment

knobs to raise or lower the

backrest.

2. Loosen the lower adjustment

knobs to move the backrest

forward for operator use or

rearward for passenger use.

3. Always tighten the knobs

securely after adjusting.

Operator/Passenger

Raise/Lower

29

THE PERFECT FIT

Front Suspension Adjustments

Independent Front Suspension (IFS)

Break in the suspension for about 150 miles (240 km) before making

any fine-tuning adjustments.

Settings will vary from rider to rider, depending on rider weight, vehicle

speed, riding style, and trail conditions. We recommend starting with

factory settings and then customizing each adjustment individually to

suit rider preference. The machine should be methodically tested, one

change at a time, under the same conditions (trail and snow conditions,

vehicle speed, riding position, etc.) after each adjustment until the best

ride is achieved.

IFS Components
1. Skis
2. Front shocks and springs
3. Rod ends
4. Trailing arms

IFS Adjustment Options
• Front shock spring preload
• Optional springs
• Toe (ski alignment) (see

page 102)

• Camber (see your dealer)

2

3

4

1

30

THE PERFECT FIT

Front Suspension Adjustments

For the best ride, the suspension should be adjusted to use the full travel

of the shocks with occasional light bottoming. To determine if your

machine is using full travel, push the jounce bumper down on the shock

rod until it contacts the body and test ride the machine. The bumper will

move up on the rod in relation to the amount of travel that was used dur-

ing the ride. If the travel is full, the bumper will be seated at the top of

the rod.

Shock Components

The front springs can be

changed if spring preload

alone isn't sufficient and

further adjustment is

desired to control suspen-

sion stiffness. See your

Polaris dealer for more

information.

1. Retainer
2. Shock Rod
3. Jounce Bumper
4. Body
5. Threaded Spring Pre-

load Adjuster Nut

WARNING

Always verify ski alignment before making adjustments to the IFS. See page

102 to check alignment. If the skis are misaligned, see your dealer, as the

camber adjustment may also be affected.

2

3

4

5

1

31

THE PERFECT FIT

Front Suspension Adjustments

Spring Preload

Increasing spring preload will increase

ski-to-ground pressure. Decreasing

spring preload will decrease ski-to-

ground pressure. When adjusting, be

sure the springs on both the left and right

sides of the machine are at the same

adjustment.

To increase front shock spring preload,

grasp the spring and turn it to the right.

Turn it to the left to decrease preload.

Increasing the spring preload too much

may adversely affect the handling of the

snowmobile and the performance of the

suspension. Never exceed one inch of

preload beyond the factory settings, and

ensure that both sides are adjusted the

same. When decreasing preload, make sure at least two turns of preload

are holding the spring between the retainer on top of the shock and the

threaded spring preload adjuster nut on the shock body.

NOTE: Not all models have shocks with thread adjustable spring pre-

load. See your dealer for more information.

Front Springs

For models without externally adjustable or revalvable shocks, the front

springs can be changed if spring preload alone isn't sufficient and fur-

ther adjustment is desired to control suspension stiffness. See your

Polaris dealer for more information.

CAUTION

Always leave one thread showing above the adjuster nut. On models

equipped with a plastic adjuster nut, if the nut is unscrewed from the

threaded body, the nut will break.

Low

Preload

High

Preload
