Snowmobile Polaris 120 PRO R (2013 year). Instruction - part 11





45

ADULT SECTION

Operation

Starting the Engine

Never start the engine before performing the Pre-Ride Check. See pages
19 and 25.

1. Pull the engine stop switch up to the RUN position.

2. Do not use the choke when starting a warm engine. If the engine is

cold, pull the choke lever completely out to the FULL ON position.

CAUTION! Do not apply throttle while starting.

3. Grasp the starter handle and pull slowly until the recoil engages,

then pull abruptly to start the engine.

NOTICE: Extending the starter rope too far or allowing it to snap back into the

housing will cause damage to the recoil assembly. Do not extend the
starter rope to its maximum length, and do not drop the rope handle
during starting.

4. If the engine slows or stops, position the choke knob half way in.

5. Apply the brakes and vary the engine RPM slightly with the throttle

to aid in warm-up. When the engine idles smoothly, push the choke
knob all the way in.

NOTICE: To prevent excessive wear on the clutch components, don't engage

the clutch while performing the warm-up.

46

ADULT SECTION

Operation

Emergency Stopping Procedures

The following chart lists methods for stopping the snowmobile in the
event of an emergency. See pages 14 and 27 for more information about
the engine stop switch and throttle safety switch.

Daily Storage

At the end of each ride, park the snow-
mobile on a level surface. Support the
rear with an appropriate track stand.
The track should be suspended approxi-
mately 4” (10 cm) off the ground.

Cover the snowmobile with an appro-
priate snowmobile cover.

SYSTEM

WHAT IT DOES

THROTTLE

CONDITION

Engine Stop Switch

Interrupts ignition circuit

All

Throttle Safety Switch

Interrupts ignition circuit

All

Tether Switch

Interrupts ignition circuit

All

Brake

Slows driveshaft

All

Choke

Floods engine

Half throttle or less

47

ADULT SECTION

Operation

Pre-Ride Warm-Up

Always warm up the engine, drive train and track before operating the
snowmobile. Support the rear with an appropriate track stand. The track
should be suspended approximately 4” (10 cm) off the ground.

1. Start the engine. Allow it to idle for two to three minutes.

2. Engage the drive system abruptly and allow it to rotate the track

several revolutions.

TIP: In colder weather, the track will need a few more revolutions to fully warm it.

3. Stop the engine. Remove the rear support.

4. Grasp the skis by their front loops and move them from side to side

to loosen frozen snow.

WARNING

A loose track or flying debris could cause serious personal injury or death. Be
sure the rear support is stable. Stand clear of the front of the machine and the
moving track. Never hold the snowmobile up or stand behind it while perform-
ing this procedure. Do not use too much throttle during warm-up or when the
track is free-hanging.

48

ADULT SECTION

Emission Control Information

Any qualified repair shop or qualified person may maintain, replace, or
repair the emission control devices or systems on your snowmobile.

Emission Control Label

Your snowmobile is equipped at the time of sale with an emission con-
trol information (ECI) label and a factory-installed emissions informa-
tion hangtag. These items are required by U.S. Environmental
Protection Agency regulations. The ECI label is permanently affixed to
either the right side of the tunnel or the engine recoil cover. The ECI
label should not be removed, even after you purchase the snowmobile.
You may remove the factory-installed emissions information hangtag,
which is intended solely for your use in making a purchasing decision.

Emission Control Maintenance Requirements

Your snowmobile is certified to operate on gasoline with a minimum
octane level of 87 (R+M)/2. If your snowmobile is equipped with a
check engine light and it comes on, you must take your snowmobile to a
qualified dealer for diagnostic service. Specifications and adjustments
for engine tune-ups are located in the Service Manual, which is avail-
able to your qualified service technician. Reverse (if equipped) must not
be engaged during engine tune-ups.

Owner's Responsibilities

Please read the U.S.A EPA Emissions Limited Warranty beginning on
page 92, and read the maintenance section of your owner's manual. You
are responsible for ensuring that the specified maintenance is per-
formed. POLARIS recommends that you contact an authorized
POLARIS dealer to perform any service that may be necessary.

Non-Ionizing Radiation

This vehicle emits some electromagnetic energy. People with active or
non-active implantable medical devices (such as heart monitoring or
controlling devices) should review the limitations of their device and the
applicable electromagnetic standards and directives that apply to this
vehicle.
