Snowmobile Polaris 120. Instruction - part 8





28

ADULT SECTION

Pre-Ride Check

n

Inspect the track

Driving for extended periods of time with marginal lubrication could

severely damage the track. Driving on icy trails or driving when there is

little or no snow are two examples of situations that would provide mar-

ginal lubrication and are not recommended. Do not operate the snowmo-

bile with a damaged track.

NOTE:

Track damage or failure caused by operation under poor lubrication

conditions will void the track warranty.

WARNING

Operating the snowmobile with a damaged track will increase the possibility of

additional track damage and/or failure. This could cause loss of control, result-

ing in severe injury or death. Always inspect for damage before using the

snowmobile.

29

ADULT SECTION

Operation Warnings

n

Do not carry passengers

This snowmobile is designed for a single operator.

n

Do not operate with intake silencer removed

n

Stay clear of track

n

Do not operate with drive chain guard removed

CAUTION

If the engine is operated with the intake silencer removed, damage to the

engine may occur. Do not operate the engine with the intake silencer

removed.

WARNING

During warm-up and operation, stand clear of the rotating track. Entanglement

and serious injury or death may result. Use just enough throttle to rotate the

track and warm up the engine.

WARNING

The drive chain guard is designed to protect the operator from metal parts in

the event of a drive chain failure. Although the chance of failure is extremely

remote, do not defeat the purpose of the guard by removing it. It is provided

for the safety of the child.

30

ADULT SECTION

Operation Warnings

n

Do not touch the engine after it's been running

n

Disabled operators

WARNING

Hot components can cause serious burns to skin. Do not touch engine and

exhaust parts after the engine has been running.

WARNING

Safe operation of this rider-active vehicle requires good judgement and physi-

cal skills. Persons with cognitive or physical disabilities who operate this vehi-

cle have an increased risk of overturns and loss of control, which could result

in serious injury or death.

31

ADULT SECTION

Operation Warnings

n

Check brake lever travel

Depress the brake lever fully.

Measure the clearance between

the lever and brake block. Clear-

ance should be no more than 3/4"

(1.9 cm).
Excessive travel indicates a need

to adjust the brake cable. Refer to

the mechanical brake adjustment

information on page 56.

n

Secure the hood

The hood of the snowmobile protects the operator from moving and hot

parts as well as aiding in sound emission control and other functions.

Never operate a snowmobile with the hood open or removed.

n

Check lights

Start the engine and ensure that both the headlight and taillight operate.

3/4" (19 mm)
