Vehicle care

11. Set the rocker switch on the

compressor to I. The tyre is filled

with sealant.

12. The compressor pressure gauge

briefly indicates up to

600 kPa (6 bar) whilst the sealant

cartridge is emptying (approx.

30 s). Then the pressure starts to

drop.

13. All of the sealant is pumped into

the tyre. Then the tyre is being

inflated.

14. The prescribed tyre pressure

should be obtained within ten

minutes.
Tyre pressure

355.

When the correct pressure is

obtained, switch off the

compressor.
If the prescribed tyre pressure is

not obtained within ten minutes,

remove the tyre repair kit. Move

the vehicle one tyre rotation.

Reattach the tyre repair kit and

continue the filling procedure for

ten minutes. If the prescribed tyre

pressure is still not obtained, the

tyre is too badly damaged. Seek

the assistance of a workshop.

Drain excess tyre pressure with

the button on the air hose.
Do not run the compressor longer

than ten minutes.

15. Detach the tyre repair kit. Remove

sealant bottle from compressor.

Screw the filler hose to the free

connection of the sealant bottle.

This prevents sealant from

escaping. Stow tyre repair kit.

16. Remove any excess sealant

using a cloth.

17. Continue driving immediately so

that sealant is evenly distributed

in the tyre. Drive between

13 mph and 37 mph. After driving

approx. 3 miles but no more than

ten minutes, stop and check tyre

pressure. Screw compressor air

hose directly onto tyre valve when

doing this. Fill tyre as described

before. Drain excess tyre

pressure with the button on the air

hose.
If tyre pressure hasn't decreased

under 200 kPa (2 bar), set it to the

correct value. Otherwise the

vehicle must not be used. Seek

assistance of a workshop.
Repeat the checking procedure

once more after driving further

6 miles but no more than ten

CarManuals2.com

Vehicle care

327

minutes to check that there is no

more loss of pressure.
If the tyre pressure has fallen

below 200 kPa (2 bar), the vehicle

must not be used. Seek the

assistance of a workshop.

18. Stow away tyre repair kit.

Notice

The driving characteristics of the

repaired tyre are severely affected,

therefore have this tyre replaced.
If unusual noise is heard or the

compressor becomes hot, turn

compressor off for at least 30 min.
The built-in safety valve opens at a

pressure of seven bar (102 psi).
Note the expiry date of the kit. After

this date its sealing capability is no

longer guaranteed. Pay attention to

storage information on sealant

bottle.
Replace the used sealant bottle.

Dispose of the bottle as prescribed

by applicable laws.
The compressor and sealant can be

used from approx. -30 °C.

Type B

1. Pull speed limit label from the tyre

repair kit and place it in driver's

visible area.

2. Pull the electric cord and the air

hose out of their respective

compartments on the bottom of

the kit.

3. Turn selector A to the "sealant"

position. Check that switch B is in

position

4. Uncoil the air hose fully and

unscrew the cap from the end of

the hose. Connect hose to the

valve of the defective tyre.

CarManuals2.com

328

Vehicle care

5. Connect the electrical cable to the

vehicle's 12 V front power outlet

89.

To avoid discharging the vehicle

battery, we recommend to use the

tyre repair kit only when the

engine is running or when the

electric engine is ready.

6. Set the rocker switch on the

compressor to I. The tyre is filled

with sealant.

7. The compressor pressure gauge

briefly indicates up to

600 kPa (6 bar) whilst the sealant

cartridge is emptying (approx.

30 s). Then the pressure starts to

drop.

8. All of the sealant is pumped into

the tyre. Then the tyre is being

inflated.

9. The prescribed tyre pressure

should be obtained within ten

minutes.
Tyre pressure

355.

When the correct pressure is

obtained, switch off the

compressor.
If the prescribed tyre pressure is

not obtained within ten minutes,

remove the tyre repair kit. Move

the vehicle one tyre rotation.

Reattach the tyre repair kit and

continue the filling procedure for

ten minutes. If the prescribed tyre

pressure is still not obtained, the

tyre is too badly damaged. Seek

the assistance of a workshop.

Drain excess tyre pressure with

the button.
Do not run the compressor longer

than ten minutes.

10. Detach the tyre repair kit. Stow

tyre repair kit.

11. Remove any excess sealant

using a cloth.

CarManuals2.com

Vehicle care

329

12. Continue driving immediately so

that sealant is evenly distributed

in the tyre. Drive between

13 mph and 37 mph. After driving

approx. 3 miles but no more than

ten minutes, stop and check tyre

pressure. Screw compressor air

hose directly onto tyre valve when

doing this. Fill tyre as described

before. Drain excess tyre

pressure with the button on the air

hose.
If tyre pressure hasn't decreased

under 200 kPa (2 bar), set it to the

correct value. Otherwise the

vehicle must not be used. Seek

assistance of a workshop.

Repeat the checking procedure

once more after driving further

6 miles but no more than ten

minutes to check that there is no

more loss of pressure.
If the tyre pressure has fallen

below 200 kPa (2 bar), the vehicle

must not be used. Seek the

assistance of a workshop.

13. Stow away tyre repair kit.

Notice

The driving characteristics of the

repaired tyre are severely affected,

therefore have this tyre replaced.
If unusual noise is heard or the

compressor becomes hot, turn

compressor off for at least

30 minutes.
Note the expiry date of the kit. After

this date its sealing capability is no

longer guaranteed. Pay attention to

storage information on sealant

bottle.
Replace the used sealant cartridge.

Dispose of the bottle as prescribed

by applicable laws.
The compressor and sealant can be

used from approx. -30 °C.

Removing the pipe and cartridge

(Type B)

1. Turn pipe assembly to the left until

it contacts the unit.

CarManuals2.com

330

Vehicle care

2. Disconnect the connector from

the cartridge by turning it a quarter

turn anti-clockwise.

3. Pull pipe assembly out slightly,

then disconnect connector from

the air hose by turning it a quarter

turn anticlockwise.

4. Remove air hose.

Keep the kit vertical and unscrew

the cartridge from the bottom.

5. To fit the new cartridge and new

pipe, carry out these operations in

reverse order.

Wheel changing

Make the following preparations and

observe the following information:

● Park the vehicle on a level, firm

and non-skid surface. The front

wheels must be in the straight-

ahead position.

● If necessary, place a chock under

the wheel diagonally opposite the

wheel to be changed.

● Apply the parking brake and

engage first gear, reverse gear or

● If the ground on which the vehicle

is standing is soft, a solid board

(max. 1 cm thick) should be

placed under the jack.

● Take heavy objects out of the

vehicle before jacking up.

● No people or animals may be in

the vehicle when it is jacked-up.

● Never crawl under a jacked-up

vehicle.

● Do not start the vehicle when it is

raised on the jack.

● Before screwing in the wheel

bolts, clean them.

Warning

Do not grease wheel bolts.

CarManuals2.com

Vehicle care

331

Tightening torques

Caution

If the vehicle is equipped with alloy

wheel rims, tighten the wheel bolts

manually at least for the first five

turns.

Depending on the wheel rim material,

two different bolts with different

tightening torques are available.

Tightening torque for alloy wheel rims

is 125 Nm.

Tightening torque for steel wheel rims

is 125 Nm.
Use the correct wheel bolts for the

respective wheel rims.

Jacking positions

The jacking positions shown refer to

the use of lifting arms and accessory

jacks used for changing winter /

summer tyres.

The rear arm position of the lifting

platform is centrically under the

relevant vehicle jacking point.

The front arm position of the lifting

platform is centrically under the

relevant vehicle jacking point.

Spare wheel

The spare wheel is located in a holder

beneath the vehicle floor.
The tools are in a box in the left front

seat

318.

Use the jack only on the specific

jacking positions

330.

The spare wheel can be classified as

a temporary spare wheel depending

on the size compared to the other

mounted wheels and country

regulations. In this case, a

CarManuals2.com

332

Vehicle care

permissible maximum speed applies,

even though no label at the spare

wheel indicates this.
If there is a label on the spare wheel,

the permissible speed still depends

on the country regulations.
Only mount one temporary spare

wheel. Take curves slowly. Do not

use for a long period of time.

Caution

The use of a spare wheel that is

smaller than the other wheels or in

combination with winter tyres

could affect driveability. Have the

defective tyre replaced as soon as

possible.

If the vehicle is equipped with a trailer

hitch, lift the back of the vehicle on

one of the rear vehicle jacking points

for easier access to the spare wheel.

1. Depending on the version, open

the tailgate or the rear doors.

2. Remove the cover of the carrier

bolt, located on the rear door sill

3. Fit the wheel wrench on the

hexagon bolt. Turn it

anticlockwise until the spare

wheel holder is low enough to

allow the catch to be unhooked.

4. Lift the spare wheel holder and

unhook the catch.
Lower the spare wheel holder.

CarManuals2.com

Vehicle care

333

5. Remove the spare wheel.
6. Change the wheel.
7. Position the damaged wheel with

the outside down in the spare

wheel holder.

8. Lift the spare wheel holder and

engage in the catch. The open

side of the catch must point in the

direction of travel.

9. Close the spare wheel holder by

turning the hexagon bolt

clockwise using the wheel

wrench.

10. Stow wheel wrench in the storage.
11. Close the tailgate or the rear

doors.

Only mount one temporary spare

wheel. The permissible maximum

speed on the label on the temporary

spare wheel is only valid for the

factory-fitted tyre size.

Fitting the spare wheel

Make the following preparations and

observe the following information:

● Park the vehicle on a level, firm

and non-skid surface. The front

wheels must be in the straight-

ahead position.

● If necessary, place a chock under

the wheel diagonally opposite the

wheel to be changed.

● Apply the parking brake and

engage first gear, reverse gear or

● Remove the spare wheel

331.

● Never change more than one

wheel at once.

● Use the jack only to change

wheels in case of puncture, not

for seasonal winter or summer

tyre change.

● The jack is maintenance-free.

● If the ground on which the vehicle

is standing is soft, a solid board

(max. 1 cm thick) should be

placed under the jack.

● Take heavy objects out of the

vehicle before jacking up.

● No people or animals may be in

the vehicle when it is jacked-up.

● Never crawl under a jacked-up

vehicle.

● Do not start the vehicle when it is

raised on the jack.

● Before screwing in the wheel

bolts, clean them.

Warning

Do not grease wheel bolts.

Warning

Ensure to use always the correct

wheel bolts if changing the

wheels. When installing the spare

wheel for temporary usage, the

bolts for alloy wheel rims can also

be used.

CarManuals2.com

334

Vehicle care

● Note that the spare wheel is

secured by the conical contact of

each bolt if the wheel bolts for the

alloy wheel rims are used. In this

case, the washers do not come

into contact with the spare wheel.

1. Steel wheel rims with cover: Pull

off the wheel cover with the

designated tool

318.

Alloy wheel rims: Disengage

wheel bolt caps with the

designated tool

318.

2. Attach the wheel wrench and

loosen each wheel bolt by half a

turn.
The wheels might be protected by

security wheel bolts. To loosen

these specific bolts, attach the

adapter onto the head of the bolt

before installing the wheel

wrench. The adapter is located in

the tool box.

318

3. Ensure the jack is correctly

positioned under the relevant

vehicle jacking point. Position it

directly below the jacking point in

a manner that prevents it from

slipping.

CarManuals2.com

Vehicle care

335

4. Set the jack to the necessary

height by turning the hand wheel.

Ensure that the edge of the body

fits into the notch of the jack.

With the jack correctly aligned,

jack up until wheel is clear of the

ground.

5. Unscrew the wheel bolts.
6. Change the wheel.
7. Screw on the wheel bolts.
8. Lower the vehicle and remove

jack.

9. Install the wheel wrench ensuring

that it is located securely and

tighten each bolt in a crosswise

sequence. Tightening torque is

115 Nm.
If the vehicle is equipped with

alloy wheel rims, note that the

wheel bolts can also be used for

the steel spare wheel. In this case,

the spare wheel is secured by the

conical contact of each bolt.

10. Align the valve hole in the wheel

cover with the tyre valve before

installing.
Install wheel bolt caps.

11. Stow the replaced wheel

331,

the vehicle tools

318 and the

adapter for the security wheel

bolts.

12. Check the tyre pressure of the

installed tyre and the wheel bolt

torque as soon as possible.

CarManuals2.com

336

Vehicle care

Jump starting

Do not start with quick charger.
A vehicle with a discharged vehicle

battery can be started using jump

leads and the vehicle battery of

another vehicle.

Caution

Never jump start another vehicle

with an electric vehicle.

Warning

Be extremely careful when starting

with jump leads. Any deviation

from the following instructions can

lead to injuries or damage caused

by battery explosion or damage to

the electrical systems of both

vehicles.

Warning

Avoid contact of the battery with

eyes, skin, fabrics and painted

surfaces. The fluid contains

sulphuric acid which can cause

injuries and damage in the event

of direct contact.

● Never expose the vehicle battery

to naked flames or sparks.

● A discharged vehicle battery can

already freeze at a temperature

of 0 °C. Defrost the frozen battery

before connecting jump leads.

● Wear eye protection and

protective clothing when

handling a battery.

● Use a booster battery with the

same voltage (12 V). Its capacity

(Ah) must not be much less than

that of the discharged vehicle

battery.

● Use jump leads with insulated

terminals and a cross section of

at least 16 mm

(25 mm

for

diesel engines).

● Do not disconnect the discharged

vehicle battery from the vehicle.

● Switch off all unnecessary

electrical consumers.

● Do not lean over the vehicle

battery during jump starting.

● Do not allow the terminals of one

lead to touch those of the other

lead.

● The vehicles must not come into

contact with each other during

the jump starting process.

● Apply the parking brake,

transmission in neutral,

automatic transmission in P.

CarManuals2.com

Vehicle care

337

Open the positive terminal protection

caps of both vehicle batteries.
Lead connection order:

1. Connect the red lead to the

positive terminal of the booster

battery.

2. Connect the other end of the red

lead to the positive terminal of the

discharged battery.

3. Connect the black lead to the

negative terminal of the booster

battery.

4. Connect the other end of the black

lead to a vehicle grounding point

of your vehicle in the engine

compartment.

Route the leads so that they cannot

catch on rotating parts in the engine

compartment.
To start the engine:

1. Start the engine of the vehicle

providing the jump.

2. After 5 minutes, start the other

engine. Start attempts should be

made for no longer than 15

seconds at an interval of 1 minute.

3. Allow both engines to idle for

approx. three minutes with the

leads connected.

4. Switch on electrical consumers

e.g. headlights, heated rear

window of the vehicle receiving

the jump start.

5. Reverse above sequence exactly

when removing leads.

Towing

Towing the vehicle

Press in the middle of the cover plate

and slide to the upper left corner to

unclip it.
The towing eye is stowed with the

vehicle tools

318.

CarManuals2.com

338

Vehicle care

Screw in the towing eye clockwise as

far as it will go until it stops in a

horizontal position.
Attach a tow rope – or better a tow rod

– to the towing eye.
The towing eye must only be used for

towing and not for recovering the

vehicle.
Switch on ignition to release steering

wheel lock and to permit operation of

brake lights, horn and windscreen

wiper.

Caution

Deactivate the driver assistance

systems like active emergency

braking

262, otherwise the

vehicle may automatically brake

during towing.

Switch the selector lever to neutral.
Release the parking brake.

Caution

Drive slowly. Do not drive jerkily.

Excessive tractive force can

damage the vehicle.

When the engine is not running,

considerably more force is needed to

brake and steer.
To prevent the entry of exhaust gases

from the towing vehicle, switch on the

air recirculation and close the

windows.
Vehicles with automatic transmission:

The vehicle must be towed facing

forwards, not faster than 50 mph nor

further than 60 miles. In all other

cases and when the transmission is

defective, the front axle must be

raised off the ground.

When towing a BEV or a vehicle

equipped with an automatic

transmission, transport the vehicle on

a platform or tow it with the front

wheels lifted.
Seek the assistance of a workshop.
After towing, unscrew the towing eye.
Insert cap with the flange into the

recess and fix cap by pushing.
Propulsion types

CarManuals2.com

Vehicle care

339

Towing another vehicle

On the rear bumper, press the cover

plate on its upper left corner to unclip

it.
The towing eye is stowed with the

vehicle tools

318.

Screw in the towing eye clockwise as

far as it will go until it stops in a

horizontal position.
The lashing eye at the rear

underneath the vehicle must never be

used as a towing eye.
Attach a tow rope – or better a tow rod

– to the towing eye.
The towing eye must only be used for

towing and not for recovering a

vehicle.

Caution

Drive slowly. Do not drive jerkily.

Excessive tractive force can

damage the vehicle.

After towing, unscrew the towing eye.
Insert cap with the upper flange into

the recess and fix cap by pushing.

CarManuals2.com

340

Vehicle care

Appearance care

Exterior care

Locks

The locks are lubricated at the factory

using a high quality lock cylinder

grease. Use a de-icing agent only

when absolutely necessary, as this

has a degreasing effect and impairs

lock function. After using a de-icing

agent, have the locks regreased by a

workshop.

Washing

The paintwork of your vehicle is

exposed to environmental influences.
Bird droppings, dead insects, resin,

pollen and the like should be cleaned

off immediately, as they contain

aggressive constituents which can

cause paint damage.
If using a vehicle wash, comply with

the vehicle wash manufacturer's

instructions. The windscreen wiper

and rear window wiper must be

switched off. Remove antenna and

external accessories such as roof

racks etc.
If you wash your vehicle by hand,

make sure that the insides of the

wheel housings are also thoroughly

rinsed out.
Clean edges and folds on opened

doors and the bonnet as well as the

areas they cover.
Clean bright metal mouldings with a

cleaning solution approved for

aluminium to avoid damages.

Caution

Always use a cleaning agent with

a pH value of 4 to 9.
Do not use cleaning agents on hot

surfaces.

Do not clean the engine compartment

with a steam-jet or high-pressure jet

cleaner.
Thoroughly rinse and leather-off the

vehicle. Rinse leather frequently. Use

separate leathers for painted and

glass surfaces: remnants of wax on

the windows will impair vision.

Have the door hinges of all doors

greased by a workshop.

Exterior lights

Headlight and other light covers are

made of plastic. Do not use any

abrasive or caustic agents, do not use

an ice scraper, and do not clean them

dry.

Polishing

Polishing is necessary only if the paint

has become dull or if solid deposits

have become attached to it.
Plastic body parts must not be treated

with wax or polishing agents.

Windows and wiper blades

Switch off wipers before handling in

their areas.
Use a soft lint-free cloth or chamois

leather together with window cleaner

and insect remover.
When cleaning the rear window from

inside, always wipe in parallel to the

heating element to prevent damage.

CarManuals2.com

Vehicle care

341

For mechanical removal of ice, use a

sharp-edged ice scraper. Press the

scraper firmly against the glass so

that no dirt can get under it and

scratch the glass.
Clean smearing wiper blades with a

soft cloth and window cleaner. Also

make sure to remove any residues

such as wax, insect residues and

similar from the window.
Ice residues, pollution and continuous

wiping on dry windows will damage or

even destroy the wiper blades.

Glass panel

Use a soft lint-free cloth or chamois

leather together with window cleaner

to clean the glass panel.

Wheels and tyres

Do not use high-pressure jet

cleaners.
Clean rims with a pH-neutral wheel

cleaner.
Rims are painted and can be treated

with the same agents as the body.

Paintwork damage

Rectify minor paintwork damage with

a touch-up pen before rust forms.

Have more extensive damage or rust

areas repaired by a workshop.

Underbody

Some areas of the vehicle underbody

have a PVC undercoating while other

critical areas have a durable

protective wax coating.
After the underbody is washed, check

the underbody and have it waxed if

necessary.
Bitumen / rubber materials could

damage the PVC coating. Have

underbody work carried out by a

workshop.
Before and after winter, wash the

underbody and have the protective

wax coating checked.

Liquid gas system

Danger

Liquid gas is heavier than air and

can collect in sink points.
Take care when performing work

at the underbody in a pit.

For painting work and when using a

drying booth at a temperature above

60 °C, the liquid gas tank must be

removed.
Do not make any modifications to the

liquid gas system.

Towing equipment

Do not clean the coupling ball bar with

a steam-jet or high-pressure jet

cleaner.

Interior care

Interior and upholstery

Only clean the vehicle interior,

including the instrument panel fascia

and panelling, with a dry cloth or

interior cleaner.

CarManuals2.com

342

Vehicle care

Clean the leather upholstery with

clear water and a soft cloth. In case of

heavy soiling, use leather care.
The instrument cluster and the

displays should only be cleaned using

a soft damp cloth. If necessary use a

weak soap solution.
Clean fabric upholstery with a

vacuum cleaner and brush. Remove

stains with an upholstery cleaner.
Clothing fabrics may not be

colourfast. This could cause visible

discolourations, especially on light-

coloured upholstery. Removable

stains and discolourations should be

cleaned as soon as possible.
Clean seat belts with lukewarm water

or interior cleaner.

Caution

Close Velcro fasteners as open

Velcro fasteners on clothing could

damage seat upholstery.
The same applies to clothing with

sharp-edged objects, like zips or

belts or studded jeans.

Plastic and rubber parts

Plastic and rubber parts can be

cleaned with the same cleaner as

used to clean the body. Use interior

cleaner if necessary. Do not use any

other agent. Avoid solvents and petrol

in particular. Do not use high-

pressure jet cleaners.

Floor mats

Warning

If a floor mat has the wrong size or

is not properly installed, it can

interfere with the accelerator pedal

and/or brake pedal, what can

cause unintended acceleration

and/or increased stopping

distance which can cause a crash

and injury.

Use the following guidelines for

proper floor mat usage.

● The original equipment floor mats

were designed for this vehicle. If

the floor mats need to be

replaced, it is recommended to

buy certified floor mats which fit

properly and are fixed by the

retainers on the driver side.

Always check that the floor mats

do not interfere with the pedals.

● Use the floor mat with the correct

side up. Do not turn it over.

● Do not place anything on top of

the driver side floor mat.

● Use only a single floor mat on the

driver side.

● Do not place one floor mat on top

of another.

Inserting and removing the floor

mats

The driver side floor mat is held in

place by two retainers.
To install the driver's side floor mat:

1. Move the driver's seat backwards

as far as possible.

CarManuals2.com

344

Service and maintenance

Service and

maintenance

General information ................... 344

Service information .................. 344

Recommended fluids, lubricants

and parts .................................... 347

Recommended fluids and

lubricants ................................ 347

General information

Service information

In order to ensure economical and

safe vehicle operation and to

maintain the value of your vehicle, it

is of vital importance that all

maintenance work is carried out at the

proper intervals as specified.
The detailed, up-to-date service

schedule for your vehicle is available

at the workshop.
Severe operating conditions exist if

one or more of the following

circumstances occur frequently: Cold

starting, stop and go operation, e.g.

for taxis and police vehicles, trailer

operation, mountain driving, driving

on poor and sandy road surfaces,

increased air pollution, presence of

airborne sand and high dust content,

driving at high altitude and large

variations of temperature.
Under these severe operating

conditions, certain service work may

be required more frequently than the

regular service interval indicated in

the service display. Contact a

workshop for customised service

schedules.
Service display

96.

CarManuals2.com

Service and maintenance

345

Service intervals

Engine code

DV5RC
DV5RD

DW10FDU
DW10FCU
DW10FEU

DV6DU
DW10F

Electric engine

Country group 1

25,000 miles / 2 year

32,000 miles / 2 year

25,000 miles / 2 years

Unless otherwise indicated in the service display.

Initial service interval is 12,500 miles / 1year

Country Group 1:

Andorra, Austria, Belgium, Cyprus, Denmark, Finland, France, Germany, Greece, Iceland, Italy, Liechtenstein,

Luxembourg, Malta, Monaco, Netherlands, Norway, Portugal, Republic of Ireland, San Marino, Spain, Sweden,

Switzerland, United Kingdom.
Country Group 2:

Bosnia-Herzegovina, Bulgaria, Croatia, Czech Republic, Estonia, Hungary, Latvia, Lithuania, North Macedonia, Poland,

Romania, Slovakia, Slovenia.
Country Group 3:

Albania, Kosovo, Montenegro, New Zealand, Serbia.
Country Group 4:

Israel, Lesotho, South Africa, Swaziland, Turkey.
Country Group 5:

Russia.
Country Group 6:

All other countries which are not listed in the previous country groups.

CarManuals2.com

Service and maintenance

347

Recommended fluids,

lubricants and parts

Recommended fluids and

lubricants

Only use products that meet the

recommended specifications.

Warning

Operating materials are

hazardous and could be

poisonous. Handle with care. Pay

attention to information given on

the containers.

Engine oil

Engine oil is identified by its quality

and its viscosity. Quality is more

important than viscosity when

selecting which engine oil to use. The

oil quality ensures e.g. engine

cleanliness, wear protection and oil

aging control, whereas viscosity

grade gives information on the oil's

thickness over a temperature range.

Select the appropriate engine oil

based on its quality and on the

minimum ambient temperature

351.

Topping up engine oil

Caution

In case of any spilled oil, wipe it up

and dispose it properly.

Engine oils of different manufacturers

and brands can be mixed as long as

they comply with the required engine

oil quality and viscosity.
Use of engine oils for all petrol

engines with only ACEA quality is

prohibited, since it can cause engine

damage under certain operating

conditions.
Select the appropriate engine oil

based on its quality and on the

minimum ambient temperature

351.

Additional engine oil additives

The use of additional engine oil

additives could cause damage and

invalidate the warranty.

Engine oil viscosity grades

The SAE viscosity grade gives

information of the thickness of the oil.
Multigrade oil is indicated by two

figures, e.g. SAE 5W-30. The first

figure, followed by a W, indicates the

low temperature viscosity and the

second figure the high temperature

viscosity.
Select the appropriate viscosity grade

depending on the minimum ambient

temperature

351.

All of the recommended viscosity

grades are suitable for high ambient

temperatures.

Coolant and antifreeze

Use only antifreeze approved for the

vehicle. Consult a workshop.
The system is factory filled with

coolant designed for excellent

corrosion protection and frost

protection down to approx. -37 °C.

This concentration should be

maintained all year round. The use of

additional coolant additives that

intend to give additional corrosion

protection or seal against minor leaks

CarManuals2.com

348

Service and maintenance

can cause function problems. Liability

for consequences resulting from the

use of additional coolant additives will

be rejected.

Washer fluid

Use only washer fluid approved for

the vehicle to prevent damage of

wiper blades, paintwork, plastic and

rubber parts. Consult a workshop.

Brake and clutch fluid

Over time, brake fluid absorbs

moisture which will reduce braking

effectiveness. The brake fluid should

therefore be replaced at the specified

interval.

AdBlue

Only use AdBlue to reduce the

nitrogen oxides in the exhaust

emission

229.

CarManuals2.com

Technical data

349

Technical data

Vehicle identification .................. 349

Vehicle Identification Number .. 349

Identification plate ................... 349

Engine identification ................ 350

Vehicle data ............................... 351

Recommended fluids and

lubricants ................................ 351

Engine data ............................. 352

Vehicle dimensions ................. 354

Capacities ................................ 354

Tyre pressures ........................ 355

Vehicle identification

Vehicle Identification

Number

The Vehicle Identification Number

may be embossed on the instrument

panel, visible through the windscreen.

Identification plate

The identification plate is located on

the front left or right door frame. The

layout and position differ for some

export countries.

CarManuals2.com

350

Technical data

Information on identification label:
1 : manufacturer

2 : type approval number

3 : vehicle identification number

4 : permissible gross vehicle weight

rating in kg

5 : permissible gross train weight

in kg

6 : maximum permissible front axle

load in kg

7 : maximum permissible rear axle

load in kg

8 : manufacturer address, vehicle-

specific or country-specific data

The combined total of front and rear

axle loads must not exceed the

permissible gross vehicle weight.

Vehicle's kerb weight depends on the

specification of the vehicle, e.g.

optional equipment and accessories.

Refer to the EEC Certificate of

Conformity provided with your vehicle

or other national registration

documents.
The technical data is determined in

accordance with European

Community standards. We reserve

the right to make modifications.

Specifications in the vehicle

documents always have priority over

those given in this manual.

Engine identification

The technical data tables show the

engine identifier code.
Engine data

352.

To identify the respective engine,

refer to the engine power in the EEC

Certificate of Conformity provided

with your vehicle or other national

registration documents.

CarManuals2.com

352

Technical data

Engine data

Engine identifier code

D15DT / F15DT

D15DTH / F15DTH

D20DTL

F20DT

Sales designation

1.5 Turbo

2.0 Turbo

Engineering code

DV5RUCd

DV5RUC

DW10FEU

DW10FDDU

Piston displacement [cm

]

1499

1997

Engine power [kW]

103

at rpm

3500

3750

Torque [Nm]

270

300

340

340 / 370

at rpm

1600

1750

2000

Fuel type

Diesel

Engine identifier code

A20DTH / D20DTH

D20DTR / F20DTR

Z16DT / B16DT

Electric engine

Sales designation

2.0 Turbo

1.5 Turbo

Engineering code

DW10FDU

DW10FDCU

DV6DU

ZAE

Piston displacement [cm

]

1997

1560

Engine power [kW]

110

130

100

at rpm

4400

3750

CarManuals2.com

Technical data

353

Engine identifier code

A20DTH / D20DTH

D20DTR / F20DTR

Z16DT / B16DT

Electric engine

Sales designation

2.0 Turbo

1.5 Turbo

Engineering code

DW10FDU

DW10FDCU

DV6DU

ZAE

Torque [Nm]

370

400

–

260

at rpm

2000

–

Fuel type

Diesel

not available at time of printing

CarManuals2.com

354

Technical data

Vehicle dimensions

Size

Length [mm]

4609

4959

5306 / 5309

Width without exterior mirrors [mm]

1920

Width with exterior mirrors [mm]

2204

Height without roof railing [mm]

1892 - 1950

1881 - 1949

1890 - 1940

Wheelbase [mm]

2925

3275

Turning circle diameter [m]

11.8

12.9

with increased payload

Capacities

Engine oil

Engine

DV5RUCd
DV5RUC

DV6DU

DW10FEU
DW10FD
DW10FDCU
DW10FDDU

including filter [l]

5.75

3.75

6.0

between MIN and MAX [l]

1.5

1.2

CarManuals2.com

356

Technical data

Standard payload

Vehicle with up to 3 people

With full load

Tyres

front

rear

front

rear

[kPa/bar] ([psi])

215/65 R16

280/2.8 (41)

310/3.1 (45)

300/3.0 (44)

350/3.5 (51)

215/60 R17

280/2.8 (41)

310/3.1 (45)

320/3.2 (46)

350/3.5 (51)

225/55 R17

300/3.0 (44)

250/2.5 (36)

300/3.0 (44)

280/2.8 (41)

Increased payload

Vehicle with up to 3 people

With full load

Tyres

front

rear

front

rear

[kPa/bar] ([psi])

215/65 R16

300/3.0 (44)

370/3.7 (54)

215/60 R17

300/3.0 (44)

370/3.7 (54)

CarManuals2.com

Customer information

357

Customer

information

Customer information ................ 357

Declaration of conformity ......... 357

REACH .................................... 359

Registered trademarks ............ 359

Vehicle data recording and pri‐

vacy ........................................... 359

Emergency call data recording

and privacy ............................. 359

Event data recorders ............... 360

Radio Frequency Identification

(RFID) ..................................... 363

Customer information

Declaration of conformity

Radio transmission systems

This vehicle has systems that

transmit and / or receive radio waves

subject to Directive 2014/53/EU and

The Radio Equipment Regulations

2017 by the United Kingdom. The

manufacturers of the systems listed

below declare conformity with

Directive 2014/53/EU and

The Radio Equipment Regulations

2017. The full text of the EU

declaration of conformity for each

system is available at the following

internet address: www.opel.com/

conformity.
Importer is Vauxhall Motors Limited,

MP UK 1-101-135, Chalton House,

Luton Road, Chalton, Luton,

Bedfordshire, LU4 9TT, United

Kingdom.

Infotainment system Multimedia Navi

Continental

LCIE Bureau Veritas-Site de

Fontenay aux Roses, 33 avenue du

général Leclerc, 92260 Fontenay aux

Roses, France
Operation

frequency (MHz)

Maximum output

(dBm)

2400.0 - 2483.5 2.2
2400.0 - 2483.5 15

Infotainment system Radio

Clarion
244 rue du Pré à Varois, 54670

Custines, France
Operation frequency:

2400 - 2480 MHz
Maximum output: 4 dBm

Infotainment system Multimedia

Robert Bosch Car Multimedia GmbH
Robert-Bosch-Straße 200, 31139

Hildesheim, Germany

CarManuals2.com

358

Customer information

Operation

frequency (MHz)

Maximum output

(dBm)

2402.0 - 2480.0 17
2412.0 - 2472.0 4.15

BTA Module

Magneti Marelli S.p.A.
Viale A. Borletti 61/63, 20011

Corbetta, Italy
Operation

frequency (MHz)

Maximum output

(dBm)

880 -915

1710 - 1785

1850 -1910

1920 - 1980

2500 - 2570

Antenna module

Hirschmann Car Communication

GmbH
Stuttgarter Strasse 45-51, 72654

Neckartenzlingen, Germany
Operation frequency: N/A

Maximum output: N/A

Radio remote control transmitter

Hülsbeck & Fürst GmbH & Co. KG
Steeger Straße 17, 42551 Velbert,

Germany
Operation frequency: 433.92 MHz
Maximum output: 10 dBm

Radio remote control receiver

Delphi European, Middle Eastern &

African Regional Offices Customer

Technology
Center Avenue de Luxembourg,

L-4940 Bascharage, G.D. of

Luxembourg
Operation frequency: 119 - 128.6
Maximum output:

16 dBµA/m @ 10 m

Electronic key transmitter

Valeo
43 Rue Bayen, 75017 Paris, France
Operation frequency: 433.92 MHz
Maximum output: 10 dBm

Radar unit

ZF TRW Autocruise SAS

Secteur de la Pointe du Diable,

Avenue du technopôle, 29280

Plouzane, France
Operation frequency:

24.15 - 24.25 GHz
Maximum output: 20 dBm

Immobiliser

KOSTAL of America, Inc.
350 Stephenson Hwy, Troy MI 48083,

USA
Operation frequency: 125 kHz
Maximum output: 5 dBμA/m at 10 m

ICASA type approval numbers

List of all Independent

Communications Authority of South

Africa (ICASA) type approval

numbers:
TA-2016/121, TA-2016/3261,

TA-2017/2387,TA-2017/2745,

TA-2013/430, TA-2017/1106,

TA-2016/929, TA-2017/3180

CarManuals2.com

Customer information

359

REACH

Registration, Evaluation,

Authorisation and Restriction of

Chemicals (REACH) is a European

Union regulation adopted to improve

the protection of human health and

the environment from the risks that

can be posed by chemicals. Visit

www.opel.com/reach for further

information and for access to the

Article 33 communication.

Registered trademarks

Apple Inc.

Apple CarPlay™ is a trademark of

Apple Inc.
App Store

and iTunes Store

are

registered trademarks of Apple Inc.
iPhone

, iPod

, iPod touch

, iPod

nano

, iPad

and Siri

are registered

trademarks of Apple Inc.

Bluetooth SIG, Inc.

Bluetooth

is a registered trademark

of Bluetooth SIG, Inc.

DivX, LLC

DivX

and DivX Certified

are

registered trademarks of DivX, LLC.

Google Inc.

Android™ and Google Play™ Store

are trademarks of Google Inc.

Verband der Automobilindustrie

e.V.

AdBlue

is a registered trademark of

the VDA.

Vehicle data recording

and privacy

Emergency call data

recording and privacy

Data processing

All processing of personal information

by the emergency call function

complies with the framework for

protection of personal information

established by regulation 2016/679

(GDPR) and directive 2002/58/EC of

the European Parliament and the

Council, and in particular, seeks to

protect the vital interests of the data

subject, in accordance with article

6.1, paragraph d) of regulation

2016/679.
The processing of personal

information is strictly limited to the

requirements of the emergency call

function used with the European

emergency call number.
The emergency call function is only

able to collect and process the

following data relating to the vehicle:

chassis number, type (passenger

CarManuals2.com

360

Customer information

vehicle or light commercial vehicle),

fuel type or power source, three most

recent locations and direction of

travel, number of passengers and a

timestamped log file recording

technical data related to the system's

operation.
The recipients of the processed data

are the emergency call handling

centres designated by the relevant

national authorities in the territory in

which they are located, enabling

priority routing and handling of calls to

the emergency number.

Data storage

Data contained in the system's

memory is not accessible from

outside the system until a call is

made. The system is not traceable

and is not continuously monitored in

its normal operation mode.
The data in the system's internal

memory is automatically and

continuously erased. Only the

vehicle's three most recent locations,

necessary for the normal functioning

of the system, are stored.

When an emergency call is triggered,

the data log is stored for no more than

13 hours.

Access to data

You have the right to access the data

and, if necessary, submit a request to

rectify, erase or restrict the

processing of any personal

information not processed in

accordance with the provisions of

Regulation 2016/679 (GDPR). Third

parties to which data has been

communicated shall be notified of any

rectification, erasure or restriction

carried out in accordance with the

aforementioned directive, unless

doing so would be impossible or

require a disproportionate effort.
You also have the right to lodge a

complaint with the relevant data

protection authority.
If you want to claim your above-

mentioned rights please contact us

per email at

privacyrights@mpsa.com.

For more information regarding our

contact details please take a look at

our Privacy & Cookies Policy on our

website.

Event data recorders

Electronic control units are installed in

your vehicle. Control units process

data which is received by vehicle

sensors, for example, or which they

generate themselves or exchange

amongst themselves. Some control

units are necessary for the safe

functioning of your vehicle, others

assist you while you drive (driver

assistance systems), while others

provide comfort or Infotainment

functions.
The following contains general

information about data processing in

the vehicle. You will find additional

information as to which specific data

is uploaded, stored and passed on to

third parties and for what purpose in

your vehicle under the key word Data

Protection closely linked to the

references for the affected functional

characteristics in the relevant

CarManuals2.com

Customer information

361

Owner's Manual or in the general

terms of sale. These are also

available online.

Operating data in the vehicle

Control units process data for

operation of the vehicle.
This data includes, e.g.:

● vehicle status information (e.g.

speed, movement delay, lateral

acceleration, wheel rotation rate,

"seat belts fastened" display)

● ambient conditions (e.g.

temperature, rain sensor,

distance sensor)

As a rule such data is transient, not

stored for longer than an operational

cycle, and only processed on board

the vehicle itself. Control units often

include data storage (including the

vehicle key). This is used to allow

information to be documented

temporarily or permanently on vehicle

condition, component stress,

maintenance requirements and

technical events and errors.

Depending on technical equipment

level, the data stored is as follows:

● system component operating

states (e.g. fill level, tyre

pressure, battery status)

● faults and defects in important

system components (e.g. lights,

brakes)

● system reactions in special

driving situations (e.g. triggering

of an airbag, actuation of the

stability control systems)

● information on events damaging

the vehicle

● for electric vehicles the amount of

charge in the high-voltage

battery, estimated range

In special cases (e.g. if the vehicle

has detected a malfunction), it may be

necessary to save data that would

otherwise just be volatile.
When you use services (e.g. repairs,

maintenance), the operating data

saved can be read together with the

vehicle identification number and

used when necessary. Staff working

for the service network (e.g. garages,

manufacturers) or third parties (e.g.

breakdown services) can read the

data from the vehicle. The same

applies to warranty work and quality

assurance measures.
Data is generally read via the OBD

(On-Board Diagnostics) port

prescribed by law in the vehicle. The

operating data which is read out,

documents the technical condition of

the vehicle or individual components

and assists with fault diagnosis,

compliance with warranty obligations

and quality improvement. This data,

in particular information on

component stress, technical events,

operator errors and other faults, is

transmitted to the manufacturer

where appropriate, together with the

vehicle identification number. The

manufacturer is also subject to

product liability. The manufacturer

potentially also uses operating data

from vehicles for product recalls. This

data can also be used to check

customer warranty and guarantee

claims.
Fault memories in the vehicle can be

reset by a service company when

carrying out servicing or repairs or at

your request.

CarManuals2.com

362

Customer information

Comfort and Infotainment

functions

Comfort settings and custom settings

can be stored in the vehicle and

changed or reset at any time.
Depending on the equipment level in

question, these include

● seat and steering wheel position

settings

● chassis and air conditioning

settings

● custom settings such as interior

lighting

You can input your own data in the

Infotainment functions for your

vehicle as part of the selected

features.
Depending on the equipment level in

question, these include

● multimedia data such as music,

videos or photos for playback in

an integrated multimedia system

● address book data for use with an

integrated hands-free system or

an integrated navigation system

● input destinations
● data on the use of online services

This data for comfort and

Infotainment functions can be stored

locally in the vehicle or be kept on a

device that you have connected to the

vehicle (e.g. a smartphone, USB stick

or MP3 player). Data that you have

input yourself can be deleted at any

time.
This data can only be transmitted out

of the vehicle at your request,

particularly when using online

services in accordance with the

settings selected by you.

Smartphone integration, e.g.

Android Auto or Apple CarPlay

If your vehicle is equipped

accordingly, you can connect your

smartphone or another mobile device

to the vehicle so that you can control

it via the controls integrated in the

vehicle. The smartphone image and

sound can be output via the

multimedia system in this case. At the

same time, specific information is

transmitted to your smartphone.

Depending on the type of integration,

this includes data such as position

data, day / night mode and other

general vehicle information. For more

information, please see the operating

instructions for the vehicle /

Infotainment system.
Integration allows selected

smartphone apps to be used, such as

navigation or music playback. No

further integration is possible

between smartphone and vehicle, in

particular active access to vehicle

data. The nature of further data

processing is determined by the

provider of the app used. Whether

you can define settings, and if so

which ones, is dependent on the app

in question and your smartphone's

operating system.

CarManuals2.com

Customer information

363

Online services

If your vehicle has a radio network

connection, this allows data to be

exchanged between your vehicle and

other systems. The radio network

connection is made possible by

means of a transmitter device in your

vehicle or a mobile device provided

by you (e.g. a smartphone). Online

functions can be used via this radio

network connection. These include

online services and applications /

apps provided to you by the

manufacturer or other providers.

Proprietary services

In the case of the manufacturer's

online services, the relevant functions

are described by the manufacturer in

an appropriate location (e.g. Owner's

Manual, the manufacturer's website)

and the associated data protection

information is provided. Personal

data may be used to provide online

services. Data exchange for this

purpose takes place via a protected

connection, e.g. using the

manufacturer's IT systems provided

for the purpose. Collection,

processing and use of personal data

for the purposes of preparation of

services take place solely on the

basis of legal permission, e.g. in the

case of a legally prescribed

emergency communication system or

a contractual agreement, or by virtue

of consent.
You can activate or deactivate the

services and functions (which are

subject to charges to some extent)

and, in some cases, the vehicle's

entire radio network connection. This

does not include statutory functions

and services such as an emergency

communication system.

Third party services

If you make use of online services

from other providers (third parties),

these services are subject to the

liability and data protection and usage

conditions of the provider in question.

The manufacturer frequently has no

influence over the content exchanged

in this regard.

Therefore, please note the nature,

scope and purpose of the collection

and use of personal data within the

scope of third party services provided

by the service provider in question.

Radio Frequency

Identification (RFID)

RFID technology is used in some

vehicles for functions such as tyre

pressure monitoring and immobiliser.

It is also used in connection with

conveniences such as radio remote

controls for door locking / unlocking

and starting. RFID technology in

Vauxhall vehicles does not use or

record personal information or link

with any other Vauxhall system

containing personal information.

CarManuals2.com

364

Index

Accessories and vehicle

modifications .......................... 295

Active emergency braking. . 105, 262

AdBlue................................ 103, 229

Adjustable air vents ................... 216

Airbag and belt tensioners ........... 99

Airbag deactivation .............. 51, 100

Airbag label................................... 46

Airbag system .............................. 46

Air conditioning regular

operation ................................ 218

Air conditioning system .............. 207

Air intake .................................... 218

Air vents...................................... 216

Antilock brake system ................ 239

Antilock brake system (ABS) ..... 102

Anti-theft alarm system ................ 21

Anti-theft locking system .............. 21

Appearance care........................ 340

Armrest......................................... 37

Audio.......................... 145, 176, 195

Automatic anti-dazzle .................. 26

Automatic crash notification....... 120

Automatic light control ............... 124

Automatic locking ........................ 14

Automatic operation of electric

parking brake off..................... 101

Automatic transmission ............. 234

Autostop............................. 104, 224

Battery discharge protection ...... 131

BlueInjection............................... 229

Bluetooth audio streaming. 148,

178, 195, 197

Bluetooth connection.. 164, 182, 200

Bonnet ....................................... 299

Brake and clutch fluid................. 347

Brake assist ............................... 243

Brake fluid .................................. 302

Brakes ............................... 239, 302

Brake system ............................. 101

Breakdown.................................. 337

Bulb replacement ....................... 307

Capacities .................................. 354

Cargo management system ........ 70

Car wash mode.......................... 232

Catalytic converter ..................... 228

Central locking system ................ 10

Centre console lighting .............. 130

Centre high-mounted brake light 315

Changing tyre and wheel size ... 323

Charging..................................... 281

Charging cable........................... 279

Charging cable connected.......... 104

Charging status.......................... 285

Charging system ........................ 100

Charging types........................... 278

CarManuals2.com

365

child lock....................................... 28

Child locks ................................... 14

Child restraint installation

locations ................................... 56

Child restraints.............................. 52

Child restraint systems ................ 52

Child surveillance mirror............... 26

Climate control systems............. 205

Clock............................................. 89

Comfort consumption gauge........ 95

Control indicators.......................... 97

Control of the vehicle ................. 220

Controls........................................ 85

Convex shape .............................. 24

Coolant and antifreeze............... 347

Cornering lights.......................... 126

Cruise control .................... 105, 246

Cupholders .................................. 66

Curtain airbag system .................. 50

DAB.................................... 145, 176

Danger, Warnings and Cautions ... 4

Daytime running lights ............... 126

Declaration of conformity............ 357

DEF............................................ 229

Deflation detection system......... 103

Diesel exhaust fluid.................... 229

Diesel fuel system bleeding ....... 305

Door open .................................. 105

Doors...................................... 15, 18

Drive modes............................... 239

Driver alert.................................. 276

Driver assistance systems.......... 246

Driver Information Centre........... 106

Driving characteristics and

towing tips .............................. 288

Driving hints................................ 220

Electric adjustment ...................... 24

Electrical system......................... 317

Electric drive unit........................ 232

Electric parking brake................. 101

Electric parking brake fault......... 101

Electronic climate control system 209

Electronic key system..................... 8

Electronic Stability Control and

Traction Control system. . 102, 244

Emergency call........................... 120

Emergency call data recording

and privacy.............................. 359

End-of-life vehicle recovery ....... 298

Engine coolant ........................... 301

Engine coolant temperature ...... 102

Engine coolant temperature

gauge ....................................... 95

Engine data ............................... 352

Engine exhaust .......................... 228

Engine identification................... 350

Engine oil ................... 300, 347, 351

Engine oil level monitor................ 96

Engine oil pressure .................... 103

Entry lighting .............................. 130

ERA GLONASS.......................... 121

Event data recorders.................. 360

Exhaust filter....................... 103, 228

Exit lighting ................................ 131

Exterior care .............................. 340

Exterior light ............................... 104

Exterior lighting........................... 123

Exterior mirrors............................. 24

External devices......... 148, 178, 197

Fixed air vents ........................... 218

Floor mats................................... 342

Folding front seat.......................... 36

Folding mirrors ............................. 24

Folding tray .................................. 74

Forward collision alert................. 260

Front airbag system ..................... 49

Front fog lights ........... 105, 127, 311

Front pedestrian protection........ 264

Front seats.................................... 33

Front storage................................ 67

Front turn lights .......................... 312

Fuel consumption - CO

Emissions ............................... 287

Fuel for diesel engines .............. 285

CarManuals2.com

366

Fuel gauge ................................... 93

Fuses ......................................... 317

Gauges......................................... 91

Gear selector.............................. 234

Gear shifting............................... 102

General information............ 277, 288

Glass panel .................................. 31

Glovebox ..................................... 66

Halogen headlights .................... 307

Hand brake................................. 240

Hazard warning flashers ............ 126

Headlight flash ........................... 125

Headlight range adjustment ...... 125

Headlights................................... 123

Headlights when driving abroad 126

Head restraints ............................ 32

Head-up display.......................... 113

Heated mirrors ............................. 25

Heated rear window ..................... 29

Heated windscreen....................... 29

Heating ........................................ 37

Heating and ventilation system . 205

High beam ......................... 104, 124

High beam assist................ 104, 124

High voltage battery................... 305

High voltage battery gauge.......... 94

Hill start assist ........................... 243

Hinged doors................................ 18

Horn ............................................. 86

Identification plate ..................... 349

Ignition switch positions ............. 220

Immobiliser .................................. 24

Indicators................................ 91, 97

Info Display................................. 112

Instrument panel illumination

control .................................... 128

Instrument panel overview ........... 83

Interior care ............................... 341

Interior lighting............................ 128

Interior lights ...................... 129, 317

Interior mirrors.............................. 25

Introduction .................................... 3

Jump starting ............................. 336

Keys ............................................... 6

Keys, locks..................................... 6

Lane departure warning..... 102, 274

Lashing eyes ............................... 70

LED headlights........................... 105

Lighting features......................... 130

Light switch ................................ 123

load compartment....................... 129

Load compartment ................ 18, 69

Load compartment cover ............. 69

load compartment lighting.......... 129

Loading......................................... 36

Loading information ..................... 79

Low beam................................... 104

Low fuel ..................................... 104

Malfunction indicator light .......... 100

Manual anti-dazzle ...................... 25

Manual seat adjustment............... 33

Manual transmission .................. 238

Massage....................................... 38

mechanical child lock.................... 28

Misted light covers ..................... 128

Multimedia.......................... 116, 166

Multimedia Navi.................. 116, 132

Navigation................................... 151

New vehicle running-in .............. 220

Number plate light ..................... 316

Object detection systems........... 265

Odometer ..................................... 92

Oil, engine.......................... 347, 351

Outside temperature .................... 89

Overrun cut-off ........................... 224

CarManuals2.com

367

Panoramic roof............................. 31

Parking ...................................... 227

Parking assist ............................ 265

Parking brake..................... 101, 240

Parking heater............................ 213

Particulate filter........................... 228

Pedestrian safety alert.................. 86

Pedestrian safety alert fault........ 105

Performing work ........................ 298

Phone......................... 164, 182, 200

Phone projection................ 148, 178

Power button.............................. 221

Power indicator gauge.................. 94

Power outlets ............................... 89

Power seat adjustment ................ 35

Power sliding doors...................... 15

Power windows ............................ 27

Preheating ................................. 103

Programmable charging............. 284

Propulsion types............................. 4

Puncture..................................... 331

Radio.......................................... 186

Radio Frequency Identification

(RFID)..................................... 363

Radio (Infotainment system)....... 116

Radio remote control ..................... 7

Rain sensor................................ 105

RDS............................ 145, 176, 195

REACH....................................... 359

Reading lights ............................ 130

Rear doors.................................... 15

Rear fog light ............. 105, 127, 313

Rear seats ................................... 39

Rear view camera ...................... 270

Rear windows .............................. 28

Rear window wiper and washer . . 88

Recommended fluids and

lubricants ........................ 347, 351

Reduced engine power.............. 104

Refuelling ................................... 286

Regenerative braking................. 243

Registered trademarks............... 359

Reversing lights ......................... 128

Ride control systems.................. 244

Roadside assistance.................. 121

Roller blinds ................................. 30

Roof.............................................. 31

Roof bars...................................... 78

Roof load...................................... 79

Roof rack ..................................... 78

Safety net .................................... 72

Seat belt reminder ....................... 99

Seat belts ..................................... 42

Seat folding .................................. 36

Seat heating................................. 37

Seat position ................................ 33

Selective catalytic reduction....... 229

Selective ride control.................. 245

Semi-adaptive cruise control.....

........................................ 105, 253

Service ............................... 218, 344

Service display ............................ 96

Service information .................... 344

Service vehicle soon .................. 100

Side airbag system ...................... 50

Side blind spot alert............ 105, 268

Sidelights.................................... 123

Side turn lights ........................... 315

Sliding doors ................................ 15

Sliding side doors......................... 15

SOS............................................ 120

Spare wheel ............................... 331

Speech recognition..... 162, 181, 200

Speed limiter....................... 105, 250

Speed limit recognition 246, 250, 253

Speedometer ............................... 91

Starting and operating................ 220

Starting the engine .................... 222

Steering...................................... 220

Steering column controls.............. 86

Steering wheel.............................. 86

Steering wheel adjustment .......... 85

Steering wheel controls ............... 85

Stop engine................................ 100

Stop-start system........................ 224

CarManuals2.com

368

Storage......................................... 66

Storage compartments................. 66

Sunvisor lights ........................... 130

Sun visors .................................... 30

Symbols ......................................... 4

System check............................. 101

Table............................................. 75

Tachometer ................................. 93

Tailgate......................................... 18

tailgate window............................. 28

Tail lights ................................... 313

Temperature preconditioning..... 214

Three-point seat belt .................... 43

Tools .......................................... 318

torch............................................ 129

Tow bar....................................... 288

Towing................................ 288, 337

Towing another vehicle ............. 339

Towing equipment ..................... 290

Towing the vehicle ..................... 337

Traffic Announcements 145, 176, 195

Traffic sign assistant................... 273

Trailer coupling........................... 288

Trailer stability assist ................. 293

Trailer towing ............................. 289

Tread depth ............................... 323

Trip odometer .............................. 92

Turn lights ............................ 99, 127

Tyre chains ................................ 324

Tyre deflation detection system . 322

Tyre designations ...................... 320

Tyre pressure ............................ 321

Tyre pressures ........................... 355

Tyre repair kit ............................. 324

Ultrasonic parking assist............. 265

Underseat storage ....................... 68

Upholstery.................................. 341

USB devices....... 148, 178, 195, 197

USB port....................................... 89

Using this manual .......................... 3

Valet mode................................. 112

Vauxhall Connect....................... 121

Vehicle battery ........................... 303

Vehicle checks............................ 298

Vehicle data................................ 351

Vehicle data recording and

privacy..................................... 360

Vehicle dimensions .................... 354

Vehicle Identification Number .... 349

Vehicle jack................................ 318

Vehicle locator lighting............... 131

Vehicle messages ..................... 115

Vehicle personalisation ............. 116

Vehicle ready.............................. 104

Vehicle security............................ 21

Vehicle specific data ...................... 3

Vehicle storage........................... 296

Vehicle tools............................... 318

Ventilation................................... 213

Warning chimes ......................... 115

Warning lights......................... 91, 97

Washer fluid ............................... 302

Wheel changing ......................... 330

Wheel covers ............................. 323

Wheels and tyres ....................... 320

Windows....................................... 26

Windscreen................................... 26

Windscreen wiper and washer .... 86

Winter tyres ............................... 320

Wiper blade replacement .......... 306

Xenon headlights ....................... 310

CarManuals2.com

Vauxhall Vivaro C (2023 year). Manual in english - page 11
