Vauxhall Vivaro C (2023 year). Manual in english

Keys, doors and windows

Keys, doors and

windows

Keys, locks ..................................... 6

Keys ............................................ 6

Radio remote control ................... 7

Electronic key system .................. 8

Central locking system .............. 10

Automatic locking ...................... 14

Child locks ................................. 14

Doors ........................................... 15

Sliding doors .............................. 15

Load compartment .................... 18

Vehicle security ............................ 21

Anti-theft locking system ........... 21

Anti-theft alarm system .............. 21

Immobiliser ................................ 24

Exterior mirrors ............................ 24

Convex shape ........................... 24

Electric adjustment .................... 24

Folding mirrors .......................... 24

Heated mirrors ........................... 25

Interior mirrors ............................. 25

Manual anti-dazzle .................... 25

Automatic anti-dazzle ................ 26

Child surveillance mirror ............ 26

Windows ...................................... 26

Windscreen ............................... 26

Power windows ......................... 27

Rear windows ............................ 28

Heated rear window .................. 29

Heated windscreen .................... 29

Sun visors .................................. 30

Roller blinds ............................... 30

Roof ............................................. 31

Glass panel ............................... 31

Keys, locks

Keys

Caution

Do not attach heavy or bulky items

to the ignition key.

Danger

Never remove the key from

ignition switch during driving as

this will cause, depending on

version, steering wheel lock.

Replacement keys

The key number is specified on a

detachable tag.
The key number must be quoted

when ordering replacement keys as it

is a component of the immobiliser

system.
Locks

340.

Central locking

10.

Starting the engine

222.

Radio remote control

CarManuals2.com

Keys, doors and windows

Electronic key

The code number of the adapter for

the locking wheel nuts is specified on

a card. It must be quoted when

ordering a replacement adapter.
Wheel changing

330.

Key with foldaway key section

Press button to extend. To fold the

key, first press the button.

Lock cylinders

Designed to free-wheel if they are

forcefully rotated without the correct

key or if the correct key is not fully

inserted. To reset, insert the correct

key only half way and turn cylinder

until its slot is vertical, remove key

then re-insert it. If the cylinder still

free-wheels, insert the key only half

way and turn the key through 180°

and repeat operation.

Radio remote control

: unlocks the vehicle

: locks the vehicle

: locks or unlocks all doors or

selected doors, e.g only the

front doors or only the

sliding doors together with

the the tailgate / rear doors

: opens or closes power

sliding doors

Depending on the version, the radio

remote control enables the operation

of the following functions:

● central locking system

● selective unlocking

● anti-theft locking system

● anti-theft alarm system

● tailgate unlocking

● power sliding doors

● power windows

● mirrors folding

● vehicle locator lighting

131

The remote control has a range of up

to several metres, but may also be

much less due to external influences.

The hazard warning flashers confirm

operation.

CarManuals2.com

Keys, doors and windows

Handle with care, protect from

moisture and high temperatures and

avoid unnecessary operation.

Replacing battery in radio remote

control

Replace the battery as soon as the

range reduces.

Batteries do not belong in household

waste. They must be disposed of at

an appropriate recycling collection

point.

1. Remove the back cover from the

remote control.

2. Extract the flat battery from its

location.

3. Replace battery with a battery of

the same type. Pay attention to

the installation position.

4. Clip the back cover in place.

Fault

If the central locking system cannot

be operated with the radio remote

control, the cause may be one of the

following:

● Fault in radio remote control.
● The battery voltage is too low.

● Overload of the central locking

system by operating at frequent

intervals, the power supply is

interrupted for a short time.

● Interference from higher-power

radio waves from other sources.

Manual unlocking

10.

Electronic key system

Warning

The electronic key can affect a

pacemaker.
Keep the electronic key away from

the breast.

CarManuals2.com

Keys, doors and windows

Depending on the version, the

electronic key system enables a

keyless operation of the following

functions:

● central locking system

● central locking system
● tailgate unlocking
● ignition switching on and starting

the engine

222

● ignition switching on and starting

the engine

● headlight activation

The electronic key simply needs to be

on the driver's person.

Additionally, the electronic key

includes the functionality of the radio

remote control

Handle with care, protect from

moisture and high temperatures and

avoid unnecessary operation.

Notice

To save battery power, the keyless

functions are set to stand-by after 21

days of non-use. To reactivate the

functions, press a button on the

electronic key.

Replacing battery in electronic

key

Replace the battery as soon as the

system no longer operates properly

or the range is reduced.

Batteries do not belong in household

waste. They must be disposed of at

an appropriate recycling collection

point.

1. Remove the cover.
2. Extract the flat battery from its

location.

3. Replace battery with a battery of

the same type. Pay attention to

the installation position.

4. Clip the cover in place.

Fault

If the central locking cannot be

operated or the engine cannot be

started, the cause may be one of the

following:

● Fault in electronic key.
● Electronic key is out of reception

range.

CarManuals2.com

Keys, doors and windows

● The battery voltage is too low.
● Overload of the central locking

system by operating at frequent

intervals, the power supply is

interrupted for a short time.

● Interference from higher-power

radio waves from other sources.

To rectify the cause of the fault,

change the position of the electronic

key.
Manual unlocking

10.

Central locking system

Unlocks and locks doors, load

compartment and fuel filler flap.
A pull on an interior door handle

unlocks and opens the respective

door.

Notice

In the event of an accident in which

airbags or belt pretensioners are

deployed, the vehicle is

automatically unlocked.
Notice

A short time after unlocking with the

remote control the doors are locked

automatically if no door has been

opened. A precondition is that the

setting is activated in the vehicle

personalisation

116.

Selective unlocking

Selective unlocking allows you to

unlock either the front doors and the

fuel filler flap or the sliding doors, the

rear doors / the tailgate. Selective

unlocking has to be configured.

To activate, switch on the ignition and

then press

more than 2 seconds.

The LED illuminates. An audible

signal is given and depending on the

configuration of the vehicle, a

message is displayed in Info Display.

To deactivate, switch on the ignition

and then press

for more than 2

seconds. The LED extinguishes.

Remote control operation

Unlocking

Press

Unlocking mode can be set. Two

settings are selectable:

● All doors and load compartment

will be unlocked by pressing

● Only the driver's door and the

passenger door will be unlocked

by pressing

CarManuals2.com

Keys, doors and windows

Unlocking the load compartment

Press

or press

two times to

unlock the load compartment only,

i.e. sliding doors and rear doors or

tailgate.

Locking

Close doors and the load

compartment.

Press

If the vehicle is not closed properly,

the central locking system will not

work.

Confirmation

Operation of the central locking

system is confirmed by the hazard

warning flashers. A precondition is

that the setting is activated in the

vehicle personalisation

116.

Electronic key system operation

This system allows automatic vehicle

locking and unlocking simply by

detection of the electronic key. The

electronic key must be outside the

vehicle.

Notice

If the vehicle is not closed properly

or the electronic key remains in the

vehicle, locking will not be permitted.

If the vehicle is equipped with an

anti-theft alarm system, a warning

chime sounds after a few seconds.
Notice

The electronic key may not operate

if placed close to electronic devices

such as mobile phones or laptop

computers.

The electronic key must be outside

the vehicle, within a range of approx.

one metre of the relevant door side.

Unlocking

CarManuals2.com

Keys, doors and windows

Pass a hand behind the door handle

of one of the front doors, the sliding

doors, the hinged doors or press the

tailgate button.
Unlocking mode can be set in the

vehicle personalisation menu in the

Info Display. Two settings are

selectable:

● All doors, the hinged doors / the

load compartment and the fuel

filler flap will be unlocked by

passing a hand behind one of the

front door handles, the handles of

the sliding doors or the handles

of the hinged doors. If the vehicle

is equipped with a tailgate, press

the tailgate button.

● Only the front doors and the fuel

filler flap will be unlocked by

passing a hand behind one of

front door handles.

Vehicle personalisation

116.

Unlocking the load compartment

Only the load compartment, i.e. the

hinged doors or the tailgate, will be

unlocked by passing a hand behind

the hinged doors handle or pressing

the tailgate button.

Locking

Press on one of the door handles or

press the tailgate button.
All doors, load compartment and fuel

filler flap will be locked.

Confirmation

Operation of central locking system is

confirmed by the hazard warning

flashers.

Central locking button

Locks or unlocks all doors and the

load compartment from inside the

passenger compartment. If the

vehicle is equipped with electronic

key system, the fuel filler flap is locked

or unlocked, too.

Press

to lock. The LED in the button

illuminates.
Press

again to unlock. The LED in

the button extinguishes.

Operation with the key in case of

a central locking system fault

In case of a fault, e.g. vehicle battery

or remote control / electronic key

battery is discharged, the driver's

door can be locked or unlocked with

the mechanical key.

CarManuals2.com

Keys, doors and windows

Manual unlocking

Electronic key: press and hold the

latch to extract the integral key.

Manually unlock the left front door by

inserting and turning the key in the

lock cylinder. With working central

locking system the vehicle will be

unlocked.
Without a working central locking

system, the other doors can be

opened by pulling the interior handle.

The load compartment and fuel filler

flap will possibly not be unlocked.
By switching on the ignition, the anti-

theft locking system is deactivated.

Manual locking

Manually lock the left front door by

inserting and turning the key in the

lock cylinder. With working central

locking system the vehicle will be

locked.

To lock the other doors if the central

locking system is not working:

● Make sure the child lock is not

activated.

● Remove the black cover by using

a key and turning clockwise.

● Insert key carefully and move to

the inner side of the door without

turning the key.

● Remove key and attach black

cover.

The fuel filler flap and tailgate are

possibly not locked.

CarManuals2.com

Keys, doors and windows

Automatic locking

Automatic locking after driving off

This system allows automatic locking

of the doors and the tailgate as soon

as the speed of the vehicle exceeds

6 mph.
If one of the doors or the tailgate is

open, the automatic central locking

does not take place. This is signalled

by the sound of the locks rebounding,

accompanied by illumination of

the instrument cluster, an audible

signal and the display of an alert

message.

This function can be activated or

deactivated at any time. With the

ignition on, press

until an audible

signal starts and a corresponding

message is displayed.
The state of the system stays in

memory when switching off the

ignition.

Automatic relock after unlocking

This feature automatically locks all

doors, load compartment and fuel

filler flap a short time after unlocking

with the remote control or electronic

key, provided no door has been

opened.

Child locks

Warning

Use the child locks whenever

children are occupying the rear

seats.

Mechanical child locks

To activate, turn the child lock

upwards. The sliding door cannot be

opened from the inside.
To deactivate, turn the child lock

downwards. The sliding door can be

opened from the inside.

CarManuals2.com

Keys, doors and windows

Electric child locks

Remotely operated system to prevent

opening of the sliding doors via the

interior door handles.

Switching on

Press

. The indicator lamp in the

button comes on, accompanied by a

confirmation message. This indicator

lamp remains on until the child lock is

switched off.

Switching off

Press

again. The indicator lamp on

button goes off, accompanied by a

confirmation message. This indicator

lamp remains on while child lock is

switched on.

Doors

Sliding doors

Opening

After unlocking, pull the outside door

handle and slide the door towards the

rear beyond the point of resistance.

CarManuals2.com

Keys, doors and windows

To open from inside, push the handle

and slide the door towards the rear

beyond the point of resistance.

Closing

To close from outside, pull the door

handle and slide the door towards the

front until it locks.

To close from inside, push the handle

and slide the door towards the front

until it locks.

Caution

Ensure the sliding side door is fully

closed and secure before driving

the vehicle.

Caution

To avoid damage, do not attempt

to operate the sliding side door

when the fuel filler flap is open.

Danger

Do not drive with the sliding side

door open or ajar, e.g. when

transporting bulky objects, since

toxic exhaust gases, which cannot

be seen or smelled, could enter

the vehicle. This can cause

unconsciousness and even death.

Refuelling

286.

CarManuals2.com

Keys, doors and windows

Power sliding doors

Warning

Take care when operating the

power sliding doors. Risk of injury,

particularly to children.
Take particular care when the

vehicle is parked on a slope: open

or close the door fully until it

latches into its locking position.
Keep a close watch on the moving

doors when operating. Ensure that

nothing becomes trapped during

operation and no-one is standing

within the moving area.

The power sliding doors can be

operated by:

● pressing

on the radio

remote control

● pressing

on the electronic

key

● pressing

on the

instrument panel

● pressing

on the door

frame

● hands-free operation with motion

sensors below the rear bumper

● pulling the respective door

handle.

Operation with the electronic key

Press

longer to open or close

the respective power sliding door.

Hands-free operation

Depending on the vehicle

configuration, the vehicle may have

one or two hands-free operated

sliding doors.

To open or close a sliding door, move

the foot below the rear bumper on the

respective side back and forth.

CarManuals2.com

Keys, doors and windows

The electronic key must be outside

the vehicle, within a range of approx.

1 m of the motion sensors. Depending

on the configuration of the vehicle, the

electronic key has to be located in the

respective area. Do not hold the foot

longer or move too slow below the

bumper.
Activation or deactivation of hands-

free operation can be set in the Info

Display

112.

Initialising the power sliding doors

If the power sliding doors cannot be

operated, initialise as follows:

1. Fully close the door manually.
2. Fully open the door electrically.
3. Fully close the door electrically.
4. Repeat for second door.

Load compartment

Tailgate

Tailgate window

28.

Opening

After unlocking, press the tailgate

button and open the tailgate.

Depending on the version, press

to unlock the tailgate from the inside.

Closing

To lower the tailgate use the interior

handle. Push the tailgate from above

until it is fully closed.
Do not push the tailgate button whilst

closing as this will unlock the tailgate

again.

CarManuals2.com

Keys, doors and windows

With the electronic key outside the

vehicle and within a range of approx.

1 m of the tailgate, press the right

tailgate button to lock the vehicle.
Central locking system

10.

General hints for operating

tailgate

Danger

Do not drive with the tailgate open

or ajar, e.g. when transporting

bulky objects, since toxic exhaust

gases, which cannot be seen or

smelled, could enter the vehicle.

This can cause unconsciousness

and even death.

Caution

Before opening the tailgate, check

overhead obstructions, e.g. a

garage door, to avoid damage to

the tailgate. Always check the

moving area above and behind the

tailgate.

Notice

The installation of certain heavy

accessories onto the tailgate may

affect its ability to remain open.
Notice

At low outside temperatures the

tailgate may not open fully by itself.

In this case lift the tailgate manually

to its normal end position.

Emergency tailgate opening from

inside the vehicle

An access hole between the door and

the floor enables the tailgate latch to

be released using a suitable tool.

Push lever to the left to unlock and

open the tailgate.

Hinged doors

Unlock the hinged doors with the

remote control or by turning the key in

the rear door lock cylinder.
Central locking

10.

CarManuals2.com

Keys, doors and windows

To open the hinged doors, pull the

exterior handle.

To release the right hinged door, pull

the lever.

To open the door from inside the

vehicle, pull the interior handle.

Warning

The rear lights may be obscured if

the rear doors are open and the

vehicle is parked on the roadside.
Make other road users aware of

the vehicle, by using a warning

triangle or other equipment

specified in the road traffic

regulations.

The doors are retained in the 90º

position by locking stays. To open the

doors to 180º, push the latch and

swing open to the desired position.

Before closing the doors ensure that

the locking stays are in the 90º

position.

Warning

Ensure extended opening doors

are secured when fully opened.
Opened doors may slam closed

due to the force of the wind!

Always close the right hand door

before the left hand door.

CarManuals2.com

Keys, doors and windows

Central locking system

10.

Vehicle security

Anti-theft locking system

Warning

Do not use the system if there are

people in the vehicle! The doors

cannot be unlocked from the

inside.

The system deadlocks all the doors.

All doors must be closed otherwise

the system cannot be activated.
Unlocking the vehicle disables the

mechanical anti-theft locking system.

This is not possible with the central

locking button.

Activating

Simple key: Insert the key and turn it

clockwise twice within 5 seconds.
Remote control: Press

on the radio

remote control twice within five

seconds.
Electronic key: Press twice on one of

the door handles within five seconds

Anti-theft alarm system

Warning

Do not use the system if there are

people in the vehicle! The doors

cannot be unlocked from the

inside.

The anti-theft alarm system has been

designed to protect the vehicle

against theft and break-ins.
The anti-theft alarm system is

combined with the central locking

system.
The system monitors doors, tailgate,

bonnet and the passenger

compartment.
Depending on the version of the

vehicle, it may not monitor the

adjoining load compartment.

Activation

Ignition must be switched off. All

doors must be closed and the

electronic key must not remain in the

vehicle. Otherwise the system cannot

be activated.

CarManuals2.com

Keys, doors and windows

● Radio remote control: Monitoring

of the doors, the tailgate and the

bonnet is activated 5 seconds

after locking the vehicle by

pressing

. Monitoring of the

passenger compartment is

activated 45 seconds after

locking the vehicle by pressing

● Electronic key system:

Monitoring of the doors, the

tailgate and the bonnet is

activated 5 seconds after locking

the vehicle by pressing with a

finger or thumb on one of the front

door handles at the markings.

Monitoring of the passenger

compartment is activated

45 seconds after locking the

vehicle by pressing with a finger

or thumb on one of the front door

handles at the markings.

Activation is confirmed by the flashing

of the status LED and coming on of

the turn lights for a short time.
If a door or the tailgate is not correctly

closed and the vehicle is locked via

remote control or electronic key

system, the vehicle remains

unlocked. However, the anti-theft

alarm system will be activated after

45 seconds.

Notice

Changes to the vehicle interior such

as the use of seat covers and open

windows, could impair the function

of passenger compartment

monitoring.

Activation without monitoring of

passenger compartment

Switch off the monitoring of

passenger compartment when

animals are being left in the vehicle,

because of high volume ultrasonic

signals or movements triggering the

alarm. Also switch off when the

vehicle is on a ferry or train.

1. Switch of ignition.
2. Press

within the next

10 seconds until the LED of the

button illuminates constantly.

3. Get out of the vehicle.
4. Lock the vehicle immediately by

using the remote control, pressing

one of the door handles or by

pressing the tailgate button.

Activation is indicated by the flashing

of the status LED.

Indication

LED in the central locking button

flashes if the anti-theft alarm system

is activated.
Seek the assistance of a workshop in

the event of faults.

Deactivation

Radio remote control: Unlocking the

vehicle by pressing

deactivates the

anti-theft alarm system.

CarManuals2.com

Keys, doors and windows

Electronic key system: Unlocking the

vehicle by pressing on one of the front

door handles at the markings

deactivates the anti-theft alarm

system.
The electronic key must be outside

the vehicle, within a range of approx.

one metre of the relevant door side.
The system is not deactivated by

unlocking the driver's door with the

key or with the central locking button

in the passenger compartment.

Notice

If the vehicle is unlocked and no door

is opened, the vehicle is

automatically relocked after 30

seconds. In this case, the anti-theft

alarm will be reactivated, too.

Alarm

When triggered, the alarm horn

sounds and the hazard warning lights

flash simultaneously. The number

and duration of alarm signals are

stipulated by legislation.
The anti-theft alarm system can be

deactivated by pressing

, by

pressing on one of the front door

handles at the markings with

electronic key system. The LED of

the

button will extinguish and the

turn lights flash for a short time.
A triggered alarm, which has not been

interrupted by the driver, will be

indicated by the rapid flashing of the

LED of the

button. If the ignition is

switched on, the flashing stops

immediately.
If the vehicle's battery is to be

disconnected (e.g. for maintenance

work), the alarm siren must be

deactivated as follows: switch the

ignition on then off, then disconnect

the vehicle's battery within

15 seconds.
If the battery has been reconnected,

wait for 10 minutes to restart the

engine.

Locking the vehicle without

activation of the anti-theft alarm

Lock the vehicle by inserting and

turning the integrated key of the

remote control or the electronic key

system in the lock cylinder of the

driver's door.

Malfunction of the remote control

Unlock the vehicle by inserting and

turning the integrated key of the

remote control or the electronic key

system in the lock cylinder of the

driver's door.
Open the driver's door.
The horn of the anti-theft alarm will

sound.
Switch on ignition.
The horn will stop sounding and the

status LED extinguishes.

CarManuals2.com

Keys, doors and windows

Immobiliser

The system is part of the ignition

switch and checks whether the

vehicle is allowed to be started with

the key being used.
The immobiliser is activated

automatically after the key has been

removed from the ignition switch.

Notice

Radio Frequency Identification

(RFID) tags may cause interference

with the key. Do not have it placed

near the key when starting the

vehicle.
Notice

The immobiliser does not lock the

doors. Always lock the vehicle after

leaving it

10.

Switch on the anti-theft alarm

system

21.

Emergency operation of electronic

key

221.

Exterior mirrors

Convex shape

The shape of the mirror makes

objects appear smaller, which will

affect the ability to estimate

distances.
Side blind spot alert

268.

Electric adjustment

Select the relevant exterior mirror by

pushing the mirror button

to the

left or right.
Adjust the respective mirror with the

four-way control.

Folding mirrors

For pedestrian safety, the exterior

mirrors will swing out of their normal

mounting position if they are struck

with sufficient force. Reposition the

mirror by applying slight pressure to

the mirror housing.

CarManuals2.com

Keys, doors and windows

Electric folding

Pull the mirror button

rearwards.

Both exterior mirrors will fold.
Pull the mirror button rearwards again

to return both exterior mirrors to their

original position.
If an electrically folded mirror is

manually extended, pulling mirror

button rearwards will only electrically

extend the other mirror.

Automatic folding

When the vehicle is being locked,

both mirrors will fold.

When the vehicle is being unlocked,

the mirrors return to their original

position.
The function can be deactivated in the

vehicle personalisation

116.

Heated mirrors

Depending on the version, heating is

operated by pressing

The heating switches off

automatically after a certain time

depending on the outside

temperature.
Heated rear window

29.

Interior mirrors

Manual anti-dazzle

To reduce dazzle, adjust the lever on

the underside of the mirror housing.

CarManuals2.com

Keys, doors and windows

Automatic anti-dazzle

Dazzle from following vehicles is

automatically reduced, when driving

in the dark.

Child surveillance mirror

A child surveillance mirror allows to

observe the rear seats. The mirror

can be adjusted.

Windows

Windscreen

Windscreen stickers

Do not attach stickers such as toll

road stickers or similar on the

windscreen in the area of the interior

mirror. Otherwise the detection zone

of the sensor and the view area of the

camera in the mirror housing could be

restricted.

Windscreen replacement

Caution

If the vehicle has a front-looking

camera sensor for the driver

assistance systems, it is very

important that any windscreen

replacement is performed

accurately according to Vauxhall

specifications. Otherwise, these

systems may not work properly

and there is a risk of unexpected

behaviour and / or messages from

these systems.

CarManuals2.com

Keys, doors and windows

Power windows

Warning

Take care when operating the

power windows. Risk of injury,

particularly to children.
If there are children on the rear

seats, switch on the child safety

system for the power windows.
Keep a close watch on the

windows when closing them.

Ensure that nothing becomes

trapped in them as they move.

Switch on ignition to operate power

windows.

Operate

for the respective window

by pushing to open or pulling to close.
Pushing or pulling gently to the first

detent: window moves up or down as

long as the switch is operated.
Pushing or pulling firmly to the second

detent then releasing: window moves

up or down automatically with safety

function enabled. To stop movement,

operate the switch once more in the

same direction.

Safety function

This function depends upon version.

If the window glass encounters

resistance above the middle of the

window during automatic closing, it is

immediately stopped and opened

again.

Override safety function

In the event of closing difficulties due

to frost or the like, switch on the

ignition, then pull the switch to the first

detent and hold. The window moves

up without safety function enabled.

To stop movement, release the

switch.

Operating windows from outside

The windows can be closed remotely

from outside the vehicle.
Press and hold

to close windows.

Release button to stop window

movement.

CarManuals2.com

Keys, doors and windows

Overload

If the windows are repeatedly

operated within short intervals, the

window operation is disabled for

some time.

Initialising the power windows

If the windows cannot be closed

automatically (e.g. after

disconnecting the vehicle battery), a

warning message is displayed in the

Driver Information Centre.
Vehicle messages

115.

Activate the window electronics as

follows:

1. Close doors.
2. Switch on ignition.
3. Push switch until the window is

completely open.

4. Pull switch until the window is

completely closed and keep

pulling for additional two seconds.

5. Repeat for each window.

Rear windows

To open and close the rear windows,

push the lever and slide the windows

backwards or forwards.

Mechanical child lock for rear

windows

To activate, turn the child lock with the

key upwards. The sliding window

cannot be opened from the inside.
To deactivate, turn the child lock with

the key downwards. The sliding

window can be opened from the

inside.

Tailgate window

The tailgate window can be opened to

give access to the load compartment

without opening the tailgate.
The tailgate and the tailgate window

cannot be opened at the same time.

CarManuals2.com

Keys, doors and windows

Opening

After unlocking, press the button and

open the window until it is fully

opened.

Closing

Press on the centre of the window

until it is fully closed.

Heated rear window

Operated by pressing

. Depending

on the version, the heated rear

window is operated together with the

heated exterior mirrors.
The heating switches off

automatically after a certain time

depending on the outside

temperature.
Depending on climate control system,

is located at a different position.

Heated windscreen

CarManuals2.com

Keys, doors and windows

This function heats the windscreen

along its bottom and along both sides

of the windscreen.
Thus, the function allows a fast

detaching of the windscreen wiper

blades if they are frozen to the

windscreen. Additionally, an

accumulation of snow caused by the

operation of the windscreen wipers is

prevented.

Heating is operated by pressing

LED in button illuminates.

The heating works only with freezing

outside temperatures and switches

off automatically after a certain time

depending on the outside

temperature.
Pressing

again switches off the

heating operation. LED in button is

extinguished.

Sun visors

The sun visors can be folded down or

swivelled to the side to prevent

dazzling.
The cover of the mirrors should be

closed when driving.
A ticket holder is located on the

backside of the sun visor.

Roller blinds

To reduce sunlight at the second row

seats, pull the blind upwards using

the grip and engage it at the top of the

door frame.

CarManuals2.com

Seats, restraints

Head restraints ............................ 32
Front seats ................................... 33

Seat position .............................. 33

Manual seat adjustment ............ 33

Power seat adjustment .............. 35

Seat folding ............................... 36

Armrest ...................................... 37

Heating ...................................... 37

Massage .................................... 38

Rear seats ................................... 39
Seat belts ..................................... 42

Three-point seat belt ................. 43

Airbag system .............................. 46

Front airbag system ................... 49

Side airbag system .................... 50

Curtain airbag system ............... 50

Airbag deactivation .................... 51

Child restraints ............................. 52

Child restraint systems .............. 52

Child restraint installation

locations ................................... 56

Head restraints

Position

Warning

Only drive with the head restraint

set to the proper position.

The upper edge of the head restraint

should be at upper head level. If this

is not possible for extremely tall

people, set to highest position, and

set to lowest position for small people.

Adjustment

Height adjustment

Move the head restraint upwards or

downwards. If the head restraint is

engaged press the catch and move

the head restraint.

Removal

Move the head restraint upwards and

remove it. If the head restraint is

engaged press the catch and move

the head restraint.

Installation

Engage the head restraint rods in the

openings and push it downwards.

CarManuals2.com

Seats, restraints

Front seats

Seat position

Warning

Only drive with the seat correctly

adjusted.

Warning

Never adjust seats while driving as

they could move uncontrollably.

Danger

Do not sit closer than 25 cm to the

steering wheel, to permit safe

airbag deployment.

Warning

Never store any objects under the

seats.

● Sit with buttocks as far back

against the backrest as possible.

Adjust the distance between the

seat and the pedals so that legs

are slightly angled when pressing

the pedals. Slide the front

passenger seat as far back as

possible.

● Set seat height high enough to

have a clear field of vision on all

sides and of all display

instruments. There should be at

least one hand of clearance

between head and the roof

frame. Your thighs should rest

lightly on the seat without

pressing into it.

● Adjust the head restraint so that

its upper edge is at upper head

level.

● Sit with shoulders as far back

against the backrest as possible.

Set the backrest rake so that it is

possible to easily reach the

steering wheel with arms slightly

bent. Maintain contact between

shoulders and the backrest when

turning the steering wheel. Do

not angle the backrest too far

back. We recommend a

maximum rake of approx. 25°.

● Adjust seat and steering wheel in

a way that the wrist rests on top

of the steering wheel while the

arm is fully extended and

shoulders are on the backrest.

● Adjust the lumbar support so that

it supports the natural shape of

the spine

Head restraint adjustment

32.

Steering wheel adjustment

85.

Manual seat adjustment

Drive only with engaged seats and

backrests.

CarManuals2.com

Seats, restraints

Longitudinal adjustment

Pull the handle, slide the seat, then

release the handle. Try to move the

seat back and forth to ensure that the

seat is locked in place.

Backrest inclination

Turn handwheel to adjust inclination.

Do not lean on the backrest while

adjusting.

Seat height

Lever pumping motion
up

: seat higher

down : seat lower

CarManuals2.com

Seats, restraints

Lumbar support

Turn the handwheel to suit personal

requirements.

Power seat adjustment

Warning

Care must be taken when

operating the power seats. There

is a risk of injury, particularly for

children. Objects could become

trapped.

Keep a close watch on the seats

when adjusting them. Vehicle

passengers should be informed

accordingly.

Longitudinal adjustment

Move the switch forwards /

backwards.

Seat height

Move the switch upwards /

downwards.

CarManuals2.com

Seats, restraints

Backrest inclination

Tilt the switch forwards / backwards.

Lumbar support

Press

to suit personal

requirements.

Seat folding

Depending on version, the front seats

can be folded flat to the table position.

Front seats backrest

Folding

Slide the front seat as far back as

possible, to avoid contact with the

instrument panel during folding.
Push the head restraint down or

remove it before folding backrest.
Head restraints

32.

If available fold up the armrest.
Armrest

37.

Pull the lever, fold the backrest fully

forwards and release the lever.

Warning

When the front passenger seat is

in the folded position, the front

passenger airbag system must be

deactivated.
Airbag deactivation

51.

Unfolding

To restore the seat to the upright

position, pull the lever and raise

backrest fully. Then release the lever.

CarManuals2.com

Seats, restraints

Bench seat front passenger side

Folding

To lift the seat cushion pull the loop

and raise the seat cushion against the

backrest.
Cargo management system

70.

Warning

Never put the hand underneath

the seat while folding the seat.

Risk of injury.

Unfolding

To restore the seat cushion to the

original position, lower the seat

cushion till it is engaged.

Armrest

The armrest has several adjustment

options.

1. Fold it completely up.
2. Fold it completely down.
3. Raise the armrest slowly and

engage it at the desired position.

Heating

The seat heating thumb wheel can be

located at the seat or on the

instrument panel.

CarManuals2.com

Vauxhall Vivaro C (2023 year). Manual in english - page 1
