BBM 25 Push Mower Model: BB25-Kawasaki. Manual - part 2





5

LAWN MOWER SAFETY

II  SLOPE OPERATION
Slopes are a major factor related to slip and fall accidents,
which can result in severe injury.  Operation on all slopes
requires extra caution.  If you feel uneasy on a slope, do not
mow it.

1. Mow across the face of slopes; never up and down.  Exer-
cise extreme caution when changing direction on slopes.

2. Watch for holes, ruts, bumps, rocks, or other hidden ob-
jects.  Uneven terrain could cause a slip and fall accident.  Tall
grass can hide obstacles.

3. Do not mow on wet grass or excessively steep slopes.
Poor footing could cause a slip and fall accident.

4. Do not mow near drop-offs, ditches, or embankments.  You
could lose your footing or balance.

III. CHILDREN
Tragic accidents can occur if the operator is not alert to the
presence of children.  Children are often attracted to the ma-
chine and the mowing activity.  Never assume that children will
remain where you last saw them.

1. Keep children out of the mowing area and under the watch-
ful care of a responsible adult other than the operator.

2. Be alert and turn mower off if a child enters the area.

3. Never allow children to operate the machine.

4. Use extra care when approaching blind corners, shrubs,
trees, or other objects that may block your view of a child.

IV. SAFE HANDLING OF GASOLINE:
To avoid personal injury or property damage, use extreme care
in handling gasoline.  Gasoline is extremely fl ammable and the
vapors are explosive.

1. Extinguish all cigarettes, cigars, pipes, and other sources of
ignition.

2. Use only an approved gasoline container.

3. Never remove gas cap or add fuel with the engine running.
Allow engine to cool before refueling.

4. Never refuel the machine indoors.

5. Never store the machine or fuel container where there is an
open fl ame, spark, or pilot light such as on a water heater or
on other appliances.

6. Never fi ll containers inside a vehicle or on a truck or trailer
bed with a plastic liner.  Always place containers on the ground
away from your vehicle before fi lling.

7. Remove the mower from the truck or trailer and refuel it on
the ground. If this is not possible, then refuel the mower with
a portable container, rather than from a gasoline dispenser
nozzle.

Continued,

8. Keep the nozzle in contact with the rim of the fuel tank or
container opening at all times until fueling is complete.  Do not
use a nozzle lock-open device.

9. If fuel is spilled on clothing, change clothing immediately.

10. Never overfi ll fuel tank.  Replace gas cap and tighten
securely.

V. GENERAL SERVICE

1. Never operate the mower in a closed area.

2. Keep all nuts and bolts tight to be sure the mower is in safe
working condition.

3. Never tamper with safety devices.  Check their proper
operation before each use of the mower.

4. Keep the mower free of grass, leaves, or other debris build-
up.  Clean up oil or fuel spillage and remove any fuel-soaked



debris.  Allow machine to cool before storing.

5. If you strike a foreign object, stop and inspect the mower.
Repair, if necessary, before starting.

6. Never make any adjustments or repairs with the engine
running.  Disconnect the spark plug wire and ground against



engine to prevent unintended starting.

7. Never attempt to make wheel height adjustments while the
engine is running.

8. Check grass catcher components and the rear discharge
door frequently and replace only with

Bad Boy Mowers original

parts when necessary.

9. Mower blades are sharp.  Wrap the blade or wear gloves,
and use extra caution when servicing them.

10  Do not change engine governor setting or over speed the
engine.

11. Maintain or replace all safety and instruction labels.

CAUTION

Muffl er and other engine parts become extremely
hot during operation and remain hot after engine
has stopped. To avoid severe burns on contact,
stay away from these areas.

6

DECALS AND LOCATIONS

These labels warn you of potential hazards that can cause serious injury.  Carefully read and understand them.
If a label comes off or becomes hard to read, contact

Bad Boy Mowers immediately for a free replacement.

WHAT IS WHAT

Cutting height adjustment - page 11

Lower control bar, drive control - page 11

Throttle cable adjustment
at the engine - page 8, 9

Upper control bar/Operator’s presence
control, BBC control - page 10

Drive control, cable adjustment - page 11

Oil fi ller cap and dipstick - page 8, 9

Gasoline - page 9

Throttle control - page 8, 9

Gear shift lever - page 11
HI and LO range

Lock for upper control bar- page 10

Spark Plug - Engine Owner’s Manual

Blade Brake Clutch cable
adjustment - page 14

Part #: 201155-1

Part #: 201157-1

Part #: 201439-1

Part #: 201442-1

Part #: 201437-1

Label on grass bag

Part #: 201443-1

7

ASSEMBLY - SETUP

STEP 2
Slide the upper handle assembly into the two lower tubes.
Insert the two carriage bolts and use one square washer (1) on
each side of the handle tube.

STEP 3
To simplify the alignment of the handle, install the grass
catcher.
Tighten the bolts in the following order:
1 - Tighten the two bolts crews on the right side tube clamps
2 - Align the left tube with the catcher (same as the right side)
and tighten the clamps.
3 - Tighten the upper bolts that attaches the handle assembly
to the tubes.

I

nstall the right side front

bolt and insert the mulch
plug to hold the bolt
during installation.

I

nstall the nuts fi nger

tight.  Tighten completely
in step 3.

1

2

3

STEP 1
Install the black handle tubes to the mower with the M8
carriage bolts.  Do not tighten the nuts.  There are three holes
for the upper clamp to enable height adjustment.  A good start-
ing point is the middle hole for a medium height setting.

UNPACKING:

Carefully remove the mower from its packaging and check that
you have all the following items:
Upper Handle complete
(2)

 Lower Handle tubes

Mower Bag and Mulch Plug (installed on the mower)



Engine Owner’s Manual and Warranty Statement
B

B25 Operator’s Manual.

NOTICE:

If you are missing any of these items or if you are unsure of
how to properly assemble this mower please contact

Bad Boy

Mowers by phone: (866) 622-3269

Tools needed for assembly:
2 pcs  10mm wrenches
1 pcs  13mm wrench
1 pcs   Needle nose pliers

Needle Nose

Pliers

10 mm

13 mm

10 mm

1

8

ASSEMBLY - SETUP

All BBC Models

Kawasaki

Zone Start



Note: The control

panel does not

have to be removed

to install the cables

STEP 5
Install the blade brake control cable in the upper control bar.
Note that there are three holes for the control cable . All
B

B25 models uses the BBC hole position (1).

Pull on the cable sheath and insert into the upper hole (2) of
the handle bracket.

STEP 4
Insert the throttle cable inside the left handle tube.  Install the
cable into the throttle control.  The cable has been adjusted at
the factory (1) and the nut locked in place.  However verify
the proper throttle cable adjustment per the instructions for

the Kawasaki engine enclosed.  See “STEP 7” .

1

1

2

STEP 6
Install the drive cable into the lower control bar (1) and insert
the cable sheath fi tting into the lower hole of the handle
bracket (2).

1

2

STEP 8 Kawasaki Engine
Fill a new engine with an SAE 10W-30 engine oil.
Fill; 22 Fl.Oz (0.7 Qt. - 0.65 Liters)
If the oil fi lter is changed the fi ll volume is;
 29 Fl.Oz (0.9 Qt - 0.85 Liters)
Please read the Kawasaki engine Owner’s Manual for full
information.

STEP 7  Kawasaki Engine
Verify that the throttle control is adjusted correctly as follows:

- Move the throttle control to the Choke position.
- In the Choke position the arm attached to the throttle cable at
the engine should bottom out at the arrow (1).
- If needed an adjustment can be made at the throttle control.

Following these steps for the throttle adjustment will ensure
that the Kawasaki engine performs properly for this mower.
The engine speed is adjusted to approximately 3600 RPM at
the factory.

NOTICE:
The engine speed should preferably be checked and verifi ed
with a tachometer.  Normal full throttle speed of the engine
should be adjusted to 3600 RPM.  An authorized Kawasaki
Engine Dealer can verify and adjust the engine speed.

Choke

Full Throttle Idle Throttle

Engine Off
(BBC version)

1

Follow these steps to verify proper setup of the mower
equipped the KAWASAKI engine.
