BBM DIESEL 1100cc MODEL ZERO-TURN MOWER. Manual - part 12
Diesel Suspension & Back Pump Cover Assemblies
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
014-592 0-00
Diesel Back Pump Cover 2008 Bottom
2
1
039-0070-00
Back
Cover
Hinge Bracket
3
1
014-5921-00
Diesel Back Pump
Cover
2008 Top
4
1
059-8020-00
Diesel Hood 3 Cyl
5
2
018-8065-00
5/16" x 1" Carriage Bolt
6
5
019-6042-00
. 360 ID Plastic Washer
7
7
018-8064-00
1/4" x 5/8" BS C/S 18-6 55
8
2
018-8062-00
S/16-18x3/4 carriage bolt
9
5
013-9002-00
5/16" Flange Nut
10
7
013-8073-00
1/4 Nylock Nut
11
3
014-3010-00
5 /8 Round Insert
12
2
018-2007-00
5/16" X 1" Bolt
13
2
013-8047-00
5/16-18 Nylock Insert Locknut
14
1
045-604 3-00
5/16" Knob
15
1
018-4703-00
5/16" x 1 1/4" Carriage Bolt
16
4
030-7039-00
1/4" x 1 1/2" Self Tapping Screw
17
4
019-7040-00
1/4" Flat Washer
18
2
029-7038-00
8" Rubber Bumper
19
2
018-2051-00
5/B"xlO" Hex Bolt (Grades)
20
2
013-5301-00
5/8" Nylock (1/2 Jam)
21
8
019-5702-00
1/2" Washer (Grade 8)
22
8
019-5007-00
1/2" Lock Washer
23
4
018-2030-00
1/2" x 1" Hex Bolt
24
2
013-7021-00
5/8 Std NC Nylock Nut
25
1
070-8000-00
60 Suspension kit Wheel Motor
26
4
032-8999-00
Vibration Mount-Blue Dot
27
2
020-7022-00
l/8x2-l/4 cotter pin Zinc
28
2
042-7041-00
Woodruff Key
29
2
013-7050-00
1" Castle Nut for Wheel Motor
30
8
013-5300-00
1/2" Flange Nut
31
8
018-6036-00
1/2" x 2 1/2" Hex Bolt
32
2
013-8047-00
5/16-18 Nylock Insert Locknut
33
1
015-4600-00
18cc Parker Wheel Motor- Right
34
4
024-2050-00
45 Degree Wheel Motor Fitting -6802-10-10
35
1
092-7000-00
XP/AOS Right Brake Caliper
36
2
092-5201-00
Brake Disk
37
2
018-6049-00
3/8" x 1" Hex Bolt
38
1
015-4601-00
18cc Parker Wheel Motor- Left
39
1
092-7001-00
XP/AOS Left Brake Caliper
40
4
051-2080-00
26" Hose Assembly with Adaptors
41
2
018-6059-00
5/8" x 2 1/2" Grade 5 Hex Bolt (Coarse)
42
2
013-7021-00
5/8 Std NC Nylock Nut
43
2
033-7025-00
5 V Idler Pulley - BCV!- 81
44
2
025-7020-00
5/8" x 1/" Collar W/One Set Screw
45
1
052-3000-00
Steel Pump Cover Latch
46
2
018-5200-00
10-24 X 5/8 BS Button Head Belt
47
10
018-7033-00
1/2-20 x 1-1/2 Lug Bolts Zinc
48
2
022-7031-00
26 x 12.00 - 12 Tire and Orange Wheel Assembly
49
2
022-7032-00
26 x 12.00 - 12 Tire
so
2
022-7034-00
12 x 10.5 Wheel AOS Rear
51
4
018-2080-00
1/2-13 1-1/4 Hex bolt
52
4
051-6085-00
26" Hose Only
53
4
032-6033-00
Brass Bushing
54
2
013-5019-00
10-24 Nylock Locknut
PAGE
46
