BBM DIESEL 1100cc MODEL ZERO-TURN MOWER. Manual - part 4

PAGE





14

SECTION 7:

 CONTROLS

7.1

Ignition Switch—Bad Boy mowers have a three position ignition switch: off, run, and start.
With key inserted, rotate it clockwise to START position and release key when engine starts.
Switch will automatically return to he RUN position.

7.2

Throttle Control—A cable is connected to the engine throttle for controlling engine speed.
Move lever forward to increase engine rpm, move lever backward to decrease engine rpm.

7.3

Pre-Heat  Button—Before starting engine push to pre-heat for easier starting.

7.4

Control Levers—These levers control the mower’s speed, direction, and neutral lock. These
levers are used to steer, accelerate, decelerate and change direction. (Drive Arms)

7.5

Blade Engage Switch—This switch engages the blades. Pull the switch up to engage the
blades and push the switch down to disengage the blades.

7.6

Deck Lift Control—The deck lift switch is used to raise and lower the deck. Pull the switch
backwards to raise the deck and push the switch forward to lower the deck.

7.5

7.3

7.4

7.1

7.6

7.2

PAGE



15

SECTION 8:

 MOVING INOPERABLE MOWER

8.1  Do not tow machine. Use a winch to load on a trailer for transporting.

8.2

ATTENTION: RETURN BYPASS VALVES TO OPERATING POSITION BEFORE RUNNING
MOWER FOLLOWING REPAIRS.

8.3

If it is necessary to move mower when the engine is inoperable, the hydraulic drive pumps

are equipped with bypass valves. Before moving the mower, turn the bypass valves

counterclockwise one-half to one revolution. The valve stems on each pump are located near

the top and are identified as a hex stud.

8.4  Your Bad Boy Mower Weighs:

DIESEL SERIES:

1607 lbs

*** Weights fluctuate with the addition of accessories.

8.5  As you can see by the weights of the machines, you should

 never try to push or pull a Bad

Boy Mower by hand. This could cause serious bodily injury.

8.6  Hopefully, you’ll never need to use this section of the manual. However, if you do, use

extreme caution when moving machine!

SECTION 9:

 INSTRUMENTATION

99  1

Electronic Hour Meter—Registers Hour increments up to 9,999.9 total hours. This meter
records the cumulative time the engine is running.

9 .2

Oil Light—Alerts the operator that there is a low oil pressure situation inside the engine.

9 .3

Check Engine Light—Alerts the operator that the ECM has detected an issue with the
engine.

PAGE





16

SECTION 10:

 MOWER BLADE MAINTENANCE

10.1  Check mower blades after each use. This is essential for maintaining well-groomed turf. Keep

the blades sharp. If a dull blade is used for cutting, the grass will tear rather than cut. This
could damage the grass leaving a brown frayed top on the grass within a few hours. A dull
blade will also require more power from the engine.

10.2 NEVER attempt to straighten a bent blade by heating. NEVER attempt to weld a cracked

blade. The blades can break and cause serious injury or death.

10.3  NEVER work with blades while engine is running or deck clutch is engaged.
10.4 ALWAYS place deck clutch in DISENGAGE position while performing maintenance.
10.5 Use blocks when you MUST work under mower.
10.6  ALWAYS wear thick gloves when handling blades.
10.7  ALWAYS check for blade damage if mower strikes

rocks, branches, or other objects that

could potentially damage the blade.

(REMEMBER: NEVER CHECK BLADE WHILE ENGINE IS ON!

NEVER CHECK BLADES WHILE BLADES ARE ENGAGED!)

SECTION 11:



EQUIPMENT LUBRICATION

11.1  Park the machine on a level surface and disengage the blade control switch.
11.2  Move the motion control levers outward to the neutral position, engage parking brake, stop

the engine, remove the key, and wait for all moving parts to stop before leaving the operating
position.

11.3  Grease Type: NGLI grade #2 multi-purpose gun grease. Grease the front caster pivots.
11.4  Clean the grease fittings with a cloth. Scrape any paint off the front of the fitting(s).
11.5  Connect a grease gun to each fitting. Pump grease in fittings until grease begins to seep out

of the bearings. Wipe up excess grease.

11.6  Refer to service manual section for grease fitting locations.

PAGE



17

HOW TO CHOOSE THE RIGHT BLADE

Essentially there are only TWO basic styles of mowing blades used or approved for use on our current
products:

1) The standard style of mowing blade is essentially designed for cutting grass and effectively discharging

the clippings out from the deck to fall onto the lawn or to be captured in a grass collection system.
Standard blades are also referred to as “2-in-1” (discharging & bagging ) or “high-lift” blades (because
they are designed to create a higher-lifting airflow).

2) Mulching blades generally have a more curved style surface and frequently include extra cutting

surfaces along the blade edges. These blades may also come in a “+” design (which is actually two
individual blades arranged in a perpendicular fashion to enhance mulching). The “+” blades are usually
found on older style mowers; newer ones utilize blades with more advanced mulching technology.
Mulching blades may also be referred to as “3-in-1” (mulching, discharging & bagging) or “all-purpose”
blades.

Bear in mind that the re-circulating airflow design of 3/1 blades makes them less efficient at discharging
grass clippings than a standard 2/1 blade. As with most all-purpose tools, there is some give and take as
opposed to using a tool designed for a more specific purpose.

If you’re experiencing less-than-desired cutting or discharging performance with a 3/1 blade, you may want
to check into using a 2/1 blade. Conversely, if you’re using a 2/1 blade and want to mulch clippings, you
should see about the availability of mulching blades or a mulching kit.*

The type of blade installed on a new mower is a decision the retailer makes for each model of mower, based
on the expected needs of most customers. If you’re unsure of which blade is on a particular model, inspect
the blade. Blades have part numbers stamped into them. Then compare these part numbers with the unit’s
Operator’s Manual or Parts List.

It is true there are many other styles of blades available. But since we don’t manufacture or recommend
using these other aftermarket styles, we will leave them out of this discussion. Should you want more
information on special application or aftermarket blades, you should contact the companies that make these
products. NOTE: Customers using non-OEM blades do so at their own risk. The use of unapproved (non-
OEM) blades may void any or all of the mower and engine factory warranties.

* MULCHING KITS – These generally consist of mulching blades and a mulching plug (which closes off
the discharge opening to keep the clippings contained under the deck for re-cutting) plus any necessary
hardware for installation. Please check with your parts distributor regarding the contents of a particular
mulching kit.
