Military reference books and manuals (2009-2023, Volume 8)

TM 11275-15/3D

HOSE NOZZLE TANK FARM INTERCONNECTION SET

TAMCN: B2136

National Stock Number/ID Number

4610-01-123-7705

09483A

TC-092

DESCRIPTION AND FUNCTION

The Hose Nozzle Tank Interconnection Set provides the low volume, hand held nozzle discharge points for

the water supply tank farm. The kit contains the required four, two, and 1 ½-inch hoses, valves, reducers, cou-

plings, nozzles, and nozzle stands for installation.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

Varies

Weight:

335 lb (152 kg)

Width:

Varies

Width:

24 in. (61 cm)

Length:

Varies

Length:

48 in. (122 cm)

Height:

Varies

Height:

26 in. (66 cm)

Cube:

Varies

Cube:

18 ft³ (0.51 m³)

Square Stowage:

Varies

Square Stowage:

8 ft² (0.74 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

B0571, B1620, B2130, B2131, B2132, B2133, B2134, B2135, B2136, B2137, B2138,

B2139, B2391, B2394, B2395, B2631, B2632

2-138

TM 11275-15/3D

TANK FARM INTERCONNECTION SET, ACCESSORY KIT

TAMCN: B2137

TC-093

National Stock Number/ID Number

4610-01-120-7525

09496A

DESCRIPTION AND FUNCTION

The Accessory Kit is designed to aid in overall water supply tank farm connection. The kit contains four, two,

and 1 ½-inch hoses; victaulic, threaded, and cam-lock type adapters; required valves; and associated hardware.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

3,760 lb (1,706 kg)

Width:

162 in. (411 cm)

Length:

144 in. (366 cm)

Height:

52 in. (132 cm)

Cube:

756 ft³(21.41 m³)

Square Stowage:

162 ft² (15.05 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

B0571, B1620, B2130, B2131, B2132, B2133, B2134, B2135, B2136, B2137, B2138,

B2139, B2391, B2394, B2395, B2631, B2632

2-139

TM 11275-15/3D

TANK FARM INTERCONNECTION SET, 350 GPM PUMP

TAMCN: B2138

National Stock Number/ID Number

4320-01-120-7523

09564A

TC-094

DESCRIPTION AND FUNCTION

The 350 GPM Pump Tank Set provides the means to connect the main 350 GPM Pump into the water sup-

ply tank farm. The kit contains four-inch hoses, valves, couplings, and associated hardware. Also included is an

adapter used to connect the Hypochlorination Unit (TAMCN B1140) into the system.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

Varies

Weight:

930 lb (422 kg)

Width:

Varies

Width:

63 in. (160 cm)

Length:

Varies

Length:

63 in. (160 cm)

Height:

Varies

Height:

46 in. (117 cm)

Cube:

Varies

Cube:

106 ft³ (3.00 m³)

Square Stowage:

Varies

Square Stowage:

28 ft² (2.60 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

B0571, B1620, B2130, B2131, B2132, B2133, B2134, B2135, B2136, B2137, B2138,

B2139, B2391, B2394, B2395, B2631, B2632

2-140

TM 11275-15/3D

TANK FARM INTERCONNECTION SET, 125 GPM PUMP

TAMCN: B2139

National Stock Number/ID Number

4320-01-120-7524

09484A

TC-095

DESCRIPTION AND FUNCTION

The Tank Interconnection Set is designed to install the auxiliary 125 GPM pump into the water supply tank

farm. The kit contains two-inch hoses, reducers, valves, and associated couplings.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

Varies

Weight:

240 lb (109 kg)

Width:

Varies

Width:

28 in. (71 cm)

Length:

Varies

Length:

34 in. (86 cm)

Height:

Varies

Height:

24 in. (61 cm)

Cube:

Varies

Cube:

14 ft³ (0.40 m³)

Square Stowage:

Varies

Square Stowage:

7 ft² (0.65 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

B0571, B1620, B2130, B2131, B2132, B2133, B2134, B2135, B2136, B2137, B2138,

B2139, B2391, B2394, B2395, B2631, B2632

2-141

TM 11275-15/3D

TEST SET, SOIL

TAMCN: B2150

TC-352

National Stock Number/ID Number

6635-01-489-1524

01036C

DESCRIPTION AND FUNCTION

The Test Set, Soil is a collection of equipment necessary for the testing of stratification, degree of compact-

ness, cementation, moisture, and drainage of soils in the construction of roads and runways.

TECHNICAL DESCRIPTION

Manufacturer:

Kessler Engineering, Inc.

Shipping Data

Case #1

Case #3

Weight:

54 lb

Weight:

60 lb

Width:

21 in.

Width:

21 in.

Length:

33 in.

Length:

33 in

Height:

12 in.

Height:

12 in

Cube:

4.8 ft³

Cube:

4.8 ft³

Square Stowage:

4.8 ft²

Square Stowage:

4.8 ft²

Case #2

Weight:

80.5 lb

Width:

18 in.

Length:

53 in.

Height:

6 in.

Cube:

3.3 ft³

Square Stowage:

6.6 ft²

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

N/A

2-142

TM 11275-15/3D

CARPENTER KIT

TAMCN: B2210

TC-236

National Stock Number/ID Number

5180-01-550-8250

11421A

DESCRIPTION AND FUNCTION

The Carpenter Kit consists of carpentry hand tools, materials and battery powered tools used to perform

basic woodworking and wood construction operations at the company level. The kit is comprised of 1 Carpenter

Platoon assembly, sub-kit, and three Carpenter Squad sub-kits per total Carpenter Kit, NSN 5180-01-550-8250.

It is stowed and transported in 5 ruggedized cases transported with a 5-Ton forklift.

PIONEER PLATOON KIT

NSN 5180-01-550-8250

Total Weight lb

# of Cases

Case Dimension

Squad Tools (3 per kit)

275 ea / 825

53”L X 26”W X 22”H

Platoon Tools

320

53”L X 26”W X 22”H

Fastener Tool Kit

30”L X 18”W X 8”H

Total

1,215

OPERATING AND SHIPPING DATA

Shipping Mode

Weight 5 Cases:

1,215 lb (551.1 kg)

Weight Platoon Case:

320 lb (145.1 kg)

Weight Squad Tool Case:

275 lb ea. (125.0 kg)

Weight Fastener Tool Case:

70 lb (32.0 kg)

Replaced Item(s)

B2220 retired and replaced by combined kit B2210

Transportability

5-Ton forklift

Associated TAMCN(s)

N/A

2-143

TM 11275-15/3D

KIT, TOOL, CATERPILLAR

TAMCN: B2238

National Stock Number/ID Number

5180-01-254-7723

09038A

DESCRIPTION AND FUNCTION

The Tool Kit, Intermediate is a 3rd and 4th echelon tool kit for the repair of D7G Caterpillar Bulldozer (B2462)

Chassis and Caterpillar Bulldozer Family of Engines at 4th echelon.

TECHNICAL DESCRIPTION

Panel

Dimensions

Manufacturer:

Caterpillar

Length (in.):

96 in.

Model:

022159SL87

Width (in.):

58 in.

Height (in.):

82 in.

Square Stowage:

39 sq ft

Cube Stowage:

265 cu ft

Weight (lb):

5,729 lb

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

N/A

2-144

TM 11275-15/3D

ELECTRICIAN LINEMAN TOOL KIT

TAMCN: B2240

TC-098

National Stock Number/ID Number

5180-00-596-1531

01204A

DESCRIPTION AND FUNCTION

The Tool Kit, Lineman, Electrician consists of tools and equipment required for installation, maintenance,

and repair of telephone and telegraph lines. Included are pole climbing equipment, cable grip tools, wire splicing

clamps, hand cutting tools, bolt cutters, and miscellaneous items. It is stowed and transported in a single chest.

TECHNICAL DESCRIPTION

Tool Set

Dimensions

Manufacturer:

Multiple

Length (in.):

33.3

Model:

SL3-01204A

Width (in.):

19.6

References

Height (in.):

14.4

SL-3-00192B

Weight (lb)

106

SL-3-01204A

Volume (ft³)

5.4

Replaced Item(s)

N/A

Transportability

Two handle, man portable

Associated TAMCN(s)

N/A

2-146

TM 11275-15/3D

PIONEER PLATOON KIT

TAMCN: B2250

TC-220

National Stock Number/ID Number

5180-00-550-8112

11423A

DESCRIPTION AND FUNCTION

The Pioneer Platoon Kit consists of hand tools and materials used for clearing land, building emplacements,

fortications, and other construction missions. It is stowed and transported in 3 ruggedized cases.

PIONEER PLATOON KIT

NSN 5180-01-550-8112

Total Weight lb

# of Cases

Case Dimension

Hand Tools

335

53”L X 26”W X 22”H

Pioneer Tools

726

71”L X 18”W X 17”H

Total

1,076

OPERATING AND SHIPPING DATA

Shipping Mode

Weight 3 Cases:

1,076 lb (448.1 kg)

Width Hand Tools:

1 container 26 in. (66.0 cm)

Length Hand Tools:

1 container 53 in. (135.0 cm)

Height Hand Tools:

1 container 22 in. (56.0 cm)

Width Pioneer Tools:

2 containers 18 in. (46.0 cm)

Length Pioneer Tools:

2 containers 71 in. (180.3 cm)

Height Pioneer Tools:

3 containers 17 in. (43.2 cm)

Replaced Item(s)

B1830

Transportability

5-Ton forklift

Associated TAMCN(s)

N/A

2-147

TM 11275-15/3D

PIONEER SQUAD KIT

TAMCN: B2260

TC-221

National Stock Number/ID Number

5180-00-550-8116

11422A

DESCRIPTION AND FUNCTION

The Pioneer Squad Kit consists of hand tools and materials used for clearing land, building emplacements,

fortications, and other construction missions. It is stowed and transported in 2 ruggedized cases.

PIONEER SQUAD KIT

NSN 5180-01-550-8112

Total Weight lb

# of Cases

Case Dimension

Pioneer Tools

435

44”L X 24”W X 17”H

Total

435

OPERATING AND SHIPPING DATA

Shipping Mode

Weight 2 Cases:

435 lb (197.3 kg)

Width Pioneer Tools:

2 containers 24 in. (61.0 cm)

Length Pioneer Tools:

2 containers 44 in. (112.0 cm)

Height Pioneer Tools:

2 containers 17 in. (43.2 cm)

Replaced Item(s)

N/A

Transportability

5-Ton forklift

Associated TAMCN(s)

N/A

2-148

TM 11275-15/3D

MASON AND CONCRETE FINISHERS KIT

TAMCN: B2370

TC-237

National Stock Number/ID Number

5180-01-551-3550

00425B

DESCRIPTION AND FUNCTION

The Masonry Kit consists of hand tools and battery powered tools used in shaping and laying stone, brick

and block. It is stowed and transported in 6 ruggedized cases transported with a 5-Ton forklift.

MASONRY KIT

NSN 5180-01-551-3550

Ea. Weight lb

# of Cases

Case Dimension

Mason Tools and Laser Level

435

53”L X 26”W X 22”H

Scaffolding and Ladders

800

85”L X 28”W X 44”H

Mason Tool Large

442

39”L X 37”W X 37”H

Mason Tool Long

200

71”L X 18”W X 17”H

1 Mixer (not in case) Mix N Go

241

34.68”L X 47.67”W X 23.5”H

Total

2,040

OPERATING AND SHIPPING DATA

Shipping Mode

Weight Total Kit:

2,040 lb (925.3 kg)

Weight Mason Tools and Laser Leveler Case:

306 lb (139.1 kg)

Weight Scaffolding and Ladders Case:

800 lb ea. (363.1 kg)

Weight Mason Tool Large:

442 lb (200.4 kg)

Weight Mason Tool Long:

200 lb (91.1 kg)

Mixer Weight:

241 lb (109.3 kg)

Replace Item(s)

N/A

Transportability

5-Ton forklift

Associated TAMCN(s)

N/A

2-149

TM 11275-15/3D

PUMP STATION, TACTICAL WATER DISTRIBUTION SYSTEM (TWDS)

TAMCN: B2391

TC-104

National Stock Number/ID Number

4320-01-128-4244

09539A

DESCRIPTION AND FUNCTION

The Tactical Water Distribution System (TWDS) provides the capability to connect the 600 GPM pump

(which is not included in the set) into the TWDS. Each station contains the necessary couplings, valves, check

valves, 6-inch hoses, and hardware for installation.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

Varies

Weight:

7,150 lb (3,243 kg)

Width:

Varies

Width:

94 in. (239 cm)

Length:

Varies

Length:

216 in. (549 cm)

Height:

Varies

Height:

86 in. (218 cm)

Cube:

Varies

Cube:

1,010.5 ft³ (28.61 m³)

Square Stowage:

Varies

Square Stowage:

141 ft² (13.10 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

B0571, B1620, B2130, B2131, B2132, B2133, B2134, B2135, B2136, B2137, B2138,

B2139, B2391, B2394, B2395, B2631, B2632

2-150

TM 11275-15/3D

STORAGE ASSEMBLY, TACTICAL WATER DISTRIBUTION SYSTEM (TWDS)

TAMCN: B2392

TC-105

National Stock Number/ID Number

4320-01-128-4245

09538A

DESCRIPTION AND FUNCTION

The Tactical Water Distribution System (TWDS) is designed to provide an in-line storage and distribution

capability when used in conjunction with the TWDS Distribution Point. Each Storage Assembly consists of two

20,000 gallon tanks (TAMCN supplied separately), hoses, valves, and related hardware for installation.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

Varies

Weight:

1,000 lb (454 kg)

Width:

Varies

Width:

36 in. (91 cm)

Length:

Varies

Length:

60 in. (152 cm

Height:

Varies

Height:

36 in. (91 cm)

Cube:

Varies

Cube:

30 ft³ (0.85 m³)

Square Stowage:

Varies

Square Stowage:

15 ft² (1.39 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

B0571, B1620, B2130, B2131, B2132, B2133, B2134, B2135, B2136, B2137, B2138,

B2139, B2391, B2394, B2395, B2631, B2632

2-151

TM 11275-15/3D

DISTRIBUTION POINT TACTICAL WATER DISTRIBUTION SYSTEM (TWDS)

TAMCN: B2393

National Stock Number/ID Number

4320-01-128-4246

09536A

TC-106

DESCRIPTION AND FUNCTION

Tactical Water Distribution System (TWDS) is designed to be used in conjunction with the Tactical Water

Distribution System (TWDS) Storage Assembly (TAMCN B2392), the TWDS Distribution Point contains the

Hypochlorination Unit (TAMCN B1140), the 125 GPM pump, Lister Bags, valves, hoses, and related compo-

nents for installation.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

Varies

Weight:

1,500 lb (680 kg)

Width:

Varies

Width:

63 in. (160 cm)

Length:

Varies

Length:

63 in. (160 cm)

Height:

Varies

Height:

48 in. (122 cm)

Cube:

Varies

Cube:

111 ft³ (3.14 m³)

Square Stowage:

Varies

Square Stowage:

28 ft² (2.60 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

B0571, B1620, B2130, B2131, B2132, B2133, B2134, B2135, B2136, B2137, B2138,

B2139, B2391, B2394, B2395, B2631, B2632

2-152

TM 11275-15/3D

600 GPM PUMP TACTICAL WATER DISTRIBUTION SYSTEM (TWDS)

TAMCN: B2394

National Stock Number/ID Number

4220-01-533-6418

11223A

TC-107

DESCRIPTION AND FUNCTION

The 600 GPM Pump assembly is designed to be used as the lead pumping station and up to a maximum of

five boost pumping stations, within the Tactical Water Distribution System (TWDS).

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

6,250 lb (1,474 kg)

Weight:

6,250 lb (1,474 kg)

Width:

94 in. (239 cm)

Width:

94 in. (239 cm)

Length:

168 in. (427 cm)

Length:

168 in. (427 cm)

Height:

86 in. (218 cm)

Height:

86 in. (218 cm)

Cube:

786 ft³ (22.25 m³)

Cube:

786 ft³ (22.25 m³)

Square Stowage:

110 ft² (10.22 m²)

Square Stowage:

110 ft²(10.22 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

B0571, B1620, B2130, B2131, B2132, B2133, B2134, B2135, B2136, B2137, B2138,

B2139, B2391, B2394, B2395, B2631, B2632

2-153

TM 11275-15/3D

TWDS 5 MILE HOSE SEGMENT KIT

TAMCN: B2395

TC-349

National Stock Number/ID Number

4320-01-377-4577

09854A

DESCRIPTION AND FUNCTION

The TWDS 5 Mile Hose Segment contains the Hoseline Repair Kit, Pullboard Assembly, Displacement and

Evaluation Kit, Roadway Crossing Guards, Suspension Kits, hoseline swivel joints, tools, and associated hard-

ware required to install the Hose Assemblies for the Tactical Water Distribution System (TWDS).

TECHNICAL DESCRIPTION

Capacity:

N/A

Lift Capacity:

N/A

Fuel Consumption per Hour:

N/A

OPERATING AND SHIPPING DATA

Operating Mode

N/A

Shipping Mode

Weight:

11,512 lb

Width:

Length:

Height:

Cube:

1,573 ft³

Square Stowage:

Replaced Item(s)

N/A

Transportability

MTVR, LVSR

Associated TAMCN(s)

B0570, B0571, B0571, B0573, B1137, B1140, B1620, B2131, B2132, B2133, B2134,

B2135, B2136, B2137, B2138, B2139, B2391,B2394, B2395,B2631, B2632

2-154

TM 11275-15/3D

FULL-TRACKED, TRACTOR WITH ANGLE BLADE

TAMCN: B2460

TC-108

National Stock Number/ID Number

2410-01-254-1667

09062A

DESCRIPTION AND FUNCTION

The 1150 Tractor is a full-tracked, diesel engine driven tractor with a hydraulically operated angle blade and

winch. It is air transportable. It is used for earthmoving and general construction work. The manufacturer is Case

and it travels up to 6.3 mph (10 km/h).

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

25,100 lb (11,385 kg)

Weight:

25,100 lb (11,385 kg)

Width:

110 in. (279 cm)

Width:

110 in. (279 cm)

Length:

191 in. (485 cm)

Length:

191 in. (485 cm)

Height:

116 in. (295 cm)

Height:

116 in. (295 cm)

Cube:

1,410.4 ft³ (39.94 m³)

Cube:

1,410.4 ft³ (39.94 m³)

Square Stowage:

145.9 ft² (13.55 m²)

Square Stowage:

145.9 ft²(13.55 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

U0008

2-157

TM 11275-15/3D

MEDIUM, FULL-TRACKED TRACTOR

TAMCN: B2462

TC-109

National Stock Number/ID Number

2410-01-155-1588

08757A

DESCRIPTION AND FUNCTION

The Tractor is a diesel-powered, full-tracked, medium size tractor (Model D7G) for earthmoving and general

construction work. The tractor is capable of mine clearing. Manufactured by Caterpillar.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

50,000 lb (22,680 kg)

Weight:

44,300 lb (20,094 kg)

Width:

144 in. (366 cm)

Width:

144 in. (366 cm)

Length:

273 in. (693 cm)

Length:

208 in. (528 cm)

Height:

132 in. (335 cm)

Height:

132 in. (335 cm)

Cube:

3,003 ft³ (85.03 m³)

Cube:

2,288 ft³ (64.79 m³)

Square Stowage:

273 ft² (25.36 m²)

Square Stowage:

208 ft² (19.32 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

B1775, B2705, B0525, U3187

2-158

TM 11275-15/3D

FULL-TRACKED TRACTOR WITH MULTI-PURPOSE BUCKET

TAMCN: B2464

TC-110

National Stock Number/ID Number

3805-01-315-1091

09426A

3805-00-140-2427

07542A

DESCRIPTION AND FUNCTION

The 1155 Bucket Tractor is a diesel engine-driven, hydraulically operated, crawler-type front-end loader.

The multipurpose bucket is capable of performing operations of clamshell, dozer, and scraper, as well as front

and shovel. The tractor is intended for digging, lifting, transporting, and dumping operations under rough terrain

conditions.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

27,750 lb (12,585 kg)

Weight:

27,750 lb (12,587 kg)

Width:

81.2 in. (206 cm)

Width:

81.2 in. (206 cm)

Length:

196 in. (498 cm)

Length:

196 in. (498 cm)

Height:

114 in. (290 cm)

Height:

114 in. (290 cm)

Cube:

1,049.5 ft³ (29.72 m³)

Cube:

1,049.5 ft³ (29.72 m³)

Square Stowage:

110.5 ft² (10.27 m²)

Square Stowage:

110.5 ft² (10.27 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

U0009

2-159

TM 11275-15/3D

BACKHOE LOADER (BHL)

TAMCN: B2483

TC-308

National Stock Number/ID Number

3805-01-514-7166

10996A

DESCRIPTION AND FUNCTION

The Backhoe Loader (BHL) is a highly mobile, lightweight, rubber-tired tractor equipped with a front-end

loader and backhoe excavator. It can maintain pace with other wheeled vehicles of the maneuver force and can

reach road speeds in excess of 20 mph. The BHL has the capability to operate hydraulic power tools and can be

externally transported by CH-53 helicopter.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

21,605 lb (9,800 kg)

Weight:

21,605 lb (9,800 kg)

Width:

89 in. (226 cm)

Width:

89 in. (226 cm)

Length:

279 in. (709 cm)

Length:

279 in. (709 cm)

Height:

142 in. (361 cm)

Height:

142 in. (361 cm)

Cube:

2,040.5 ft³ (57.78 m³)

Cube:

2,040.5 ft³ (57.78 m³)

Square Stowage:

275.1 ft² (25.56 m²)

Square Stowage:

275.1 ft² (25.56 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

U0010

2-160

TM 11275-15/3D

EXTENDABLE BOOM FORKLIFT TRUCK (EBFL)

TAMCN: B2561

National Stock Number/ID Number

3930-01-508-0886

10794B

TC-240

DESCRIPTION AND FUNCTION

The Extendable Boom Forklift (EBFL) is a diesel powered, telehandler for lifting loads up to 10,000 pounds,

air transportable, rough-terrain, self-deployable material handler. Its primary function is to provide operating

forces, provides the capability to move/load/unload supplies, equipment, vehicles, containers, and palletized

cargo from amphibious/merchant ships, aircraft, and vehicles over beaches as well as inland via unimproved/

hard surfaces.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight: (w/ 7k fork carriage)

29,300 lb (13,290 kg)

Weight: (w/ both carriages)

30,500 lb (13,834 kg)

Weight: (w/ 11k fork carriage)

28,100 lb (12,746 kg)

Weight: (w/o any carriage)

26,900 lb (12,202 kg)

Width:

100.2 in. (255 cm)

Width:

100.2 in. (255 cm)

Length:

298 in. (757 cm)

Length:

330 in. (838 cm)

Height:

93.6 in. (238 cm)

Height:

93.6 in. (238 cm)

Cube:

1,346 ft³ (38.11 m³)

Cube:

1,791 ft³ (50.72 m³)

Square Stowage:

207.3 ft² (19.26 m²)

Square Stowage:

229.5 ft² (21.32 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

U0011

2-161

TM 11275-15/3D

ENGINEER EQUIPMENT TRAILER (EET)

TAMCN: B2565

TC-204

National Stock Number/ID Number

2330-01-547-0272

11026B

2330-01-518-3809

11026A

DESCRIPTION AND FUNCTION

The Engineer Equipment Trailer (EET) is designed to transport the Backhoe Loader (BHL), Light-Capability

Rough Terrain Forklift (LRTF), or ammunition loads. The trailer is capable of hauling 10 tons on highways,

improved roads (graded gravel), and off roads.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

11,700 lb (5,307 kg)

Weight:

11,700 lb (5,307 kg)

Width:

8 ft 1 in. (2.47 m)

Width:

8 ft 1 in. (2.47 m)

Length:

30 ft 11.5 in. (9.43 m)

Length:

30 ft 11.5 in. (9.43 m)

Height:

12 ft 9 in. (3.89 m)

Height:

12 ft 9 in. (3.89 m)

Cube:

3,191 ft³ (90.29 m³)

Cube:

3,191 ft³ (90.29 m³)

Square Stowage:

249 ft² (23.1 m²)

Square Stowage:

249 ft² (23.1 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

N/A

2-162

TM 11275-15/3D

LIGHT CAPACITY ROUGH TERRAIN TRUCK FORKLIFT (LRTF)

TAMCN: B2566

TC-208

National Stock Number/ID Number

3930-01-478-3519

09135B

3930-01-533-0855

09135C

DESCRIPTION AND FUNCTION

The Rough Terrain Forklift is a lightweight, diesel powered, air transportable forklift used for lifting palletized

loads up to 5,070 pounds. Equipped with a telescopic boom, 4-wheel, crab, and circle steering modes. It will be

employed by the combat engineer battalion, artillery units, the engineer support battalion, landing support battal-

ion company, other ground support combat service support units, and various Marine aircraft wing units. It is

required to clear landing zones of supplies and equipment, to load and unload combat vehicles, aircraft, and ISO

containers.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

13,450 lb (6,101 kg)

Weight:

13,450 lb (6,101 kg)

Width:

80.8 in. (205 cm)

Width:

80.8 in. (205 cm)

Length:

228 in. (579 cm)

Length:

228 in. (579 cm)

Height:

89 in. (226 cm)

Height:

89 in. (226 cm)

Cube:

949.2 ft³ (26.88 m³)

Cube:

949.2 ft³ (26.88 m³)

Square Stowage:

127.9 ft² (11.88 m²)

Square Stowage:

127.9 ft² (11.88 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

U0012

2-163

TM 11275-15/3D

RUBBER-TIRED, ARTICULATED STEERING, MULTI-PURPOSE TRACTOR (TRAM)

TAMCN: B2567

TC-116

National Stock Number/ID Number

3805-01-279-3635

09148A

DESCRIPTION AND FUNCTION

The Multi-Purpose Tractor is a diesel-powered, four-wheel drive, rubber-tired, articulated steering tractor

capable of operating in rough terrain and in 60 inches of water. The TRAM is outfitted with a Bucket, Multi-Pur-

pose, 4-In-1, 2-1/2 Yard (TAMCN B0215) and a Forklift Attachment, 10,000 pounds (TAMCN B0647). The

TRAM will travel a maximum of 24 mph (39 km/h) and is manufactured by John Deere Co.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

w/ Fork att.:

Weight:

33,426 lb (15,162 kg)

Weight:

36,686 lb (16,640 kg)

Width:

104 in. (264 cm)

Width:

104 in. (264 cm)

Length:

266.7 in. (677 cm)

Length:

342.6 in. (870 cm)

Height:

131.7 in. (335 cm)

Height:

131.7 in. (335 cm)

Cube:

2,113.9 ft³ (59.86 m³)

Cube:

2,715.6 ft³ (76.90 m³)

Square Stowage:

247.4 ft² (22.98 m²)

w/ Bucket:

Weight:

36,336 lb (16,482 kg)

Width:

108 in. (274 cm)

Length:

308 in. (782 cm)

Height:

131.7 in. (335 cm)

Cube:

2,535.2 ft³ (71.79 m³)

Square Stowage:

231 ft² (21.46 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

U0003

2-164

TM 11275-15/3D

FORKLIFT ATTACHMENT

TAMCN: Not TAMCN Controlled

National Stock Number/ID Number

3830-01-482-8569

09146C

TC-042

DESCRIPTION AND FUNCTION

The Forklift Attachment is for lifting and positioning various types of loads weighing up to 10,000 pounds. It

is used on the Tractor, Rubber-Tired, Articulated Steering, Multi-Purpose (TRAM) TAMCN B2567 and B0063.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

3,260 lb (1,479 kg)

Weight:

3,260 lb (1,479 kg)

Width:

78.8 in. (200 cm)

Width:

78.8 in. (200 cm)

Length:

88.5 in. (225 cm)

Length:

88.5 in. (225 cm)

Height:

62.5 in. (159 cm)

Height:

62.5 in. (159 cm)

Cube:

252.9 ft³ (7.16 m³)

Square Stowage:

48.4 ft² (4.5 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

B2567, B0063

2-165

TM 11275-15/3D

MULTI-PURPOSE BUCKET

TAMCN: Not TAMCN Controlled

National Stock Number/ID Number

3830-01-482-8567

09149C

TC-013

DESCRIPTION AND FUNCTION

The Multi-Purpose Bucket, 4-in-1, 2 1/2 yd (2.29 m) is used as a front end scoop bucket for picking up vari-

ous types of fill material and loading the same into fill haulers. The Bucket, is used on the Tractor, Rubber-Tired,

Articulated Steering, Multi-Purpose (TRAM) TAMCN B2567 and B0063.

OPERATING AND SHIPPING DATA

Manufacturer:

ACS Industries

Operating/Shipping Mode

Capacity

Weight:

3,400 lb (1,542 kg)

Fuel Consumption per Hour:

N/A

Width:

108 in. (274 cm)

Length:

52 in. (132 cm)

Height:

48 in. (122 cm)

Cube:

156.1 ft³(4.42 m³)

Square Stowage:

39 ft² (3.62 m²)

Replaced Item(s)

N/A

Transportability

Can be transported on an MTVR

Associated TAMCN(s)

B2567, B0063

2-166

TM 11275-15/3D

TACTICAL WATER PURIFICATION SYSTEM (TWPS)

TAMCN: B2605

TC-200

National Stock Number/ID Number

4610-01-488-6961

10802A

DESCRIPTION AND FUNCTION

The TWPS (MC-TWPS) is a skid -mounted unit transportable by the Medium Tactical Vehicle Replacement

(MTVR) truck (MK 23, MK 25) or by a 5-Ton forklift. The system includes the basic TWPS skid, 6,000-gallon

water storage capability, and all BII, but does not include the power source (i.e. generator) or the extended

capability modules. The system can be powered by a 60 kW, 416VAC high, WYE source. Five extended capabil-

ity modules are purchased and deployed separately as required by their mission; (a) Ocean Intake Structure

System, (b) Supplemental Cleaning, Waste and Storage, (c) Cold Weather, and (d) Nuclear Biological and

Chemical (NBC) Treatment and (e) MBC Survivability.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

9,552 lb (3,565 kg)

Weight:

12,703 lb (4,741 kg)

Width:

86 in. (218 cm)

Width:

96 in. (244 cm)

Length:

165 in. (419 cm)

Length:

240 in. (610 cm)

Height:

72.5 in. (184 cm)

Height:

96 in. (244 cm)

Cube:

595 ft³ (16.85 m³)

Cube:

1280 ft³ (36.22 m³)

Square Stowage:

98 ft² (9.10 m²)

Square Stowage:

159 ft² (14.8 m²)

Replaced Item(s)

B2604

Transportability

Truck, rail, air (C130 or larger), ship (Sealift transport, roll-on roll-off ships)

Associated TAMCN(s)

B2130, B2131, B2132, B1010, B1021

2-167

TM 11275-15/3D

WQAS-P

TAMCN: B2630

TC-329

National Stock Number/ID Number

6630-01-477-2395

09241D

DESCRIPTION AND FUNCTION

The WQAS-P is a one person portable suitcase-set containing equipment for testing and monitoring water

quality. The set is self-contained in a watertight, airtight, dustproof, crush resistant case containing Commercial-

Off-The-Shelf components capable of measuring the temperature, chlorine, pH, turbidity, and total dissolved sol-

ids (TDS), concentration of the water being tested and monitored.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

28 lb (12.7 kg)

Weight:

28 lb (12.7 kg)

Width:

19.50 in. (49.53 cm)

Width:

19.50 in. (49.53 cm)

Length:

24.25 in. (61.6 cm)

Length:

24.25 in. (61.6 cm)

Height:

8.75 in. (22.2 cm)

Height:

8.75 in. (22.2 cm)

Cube:

2.39 ft³ (0.10 m³)

Cube:

2.39 ft³ (0.10 m³)

Square Stowage:

3.96 ft² (0.48 m²)

Square Stowage:

3.96 ft² (0.48 m²)

Replaced Item(s)

N/A

Transportability

Case configured to allow easy transportability by truck, train, ship, or air

Associated TAMCN(s)

C2375

2-168

TM 11275-15/3D

TANK, FABRIC, COLLAPSIBLE, POTABLE WATER, 50,000 GALLON

TAMCN: B2631

TC-118

National Stock Number/ID Number

5430-01-200-4831

08938B

DESCRIPTION AND FUNCTION

The 50,000 Gallon Collapsible Fabric Potable Water Tank is a pillow type, synthetic rubber-impregnated

nylon tank. It is fitted with 4-inch camlock type filler/discharge ports and may be folded for storage. A repair kit is

also provided.

TECHNICAL DESCRIPTION

Manufactured By

Wood Williams

Capacity

N/A

AMFUEL, GTA Containers

Fuel Consumption per Hour:

N/A

Lift Capacity:

N/A

OPERATING AND SHIPPING DATA

Operating Mode

N/A

Shipping Mode

Weight:

425,000 lb full

Weight:

1,640 lb

Width:

25 ft

Width:

46 in.

Length:

65 ft

Length:

96 in.

Height:

60 in.

Height:

46 in.

Cube:

118 ft³

Square Stowage:

31 ft²

Replaced Item(s)

N/A

Transportability

MTVR, LVSR

Associated TAMCN(s)

B0571, B1137, B1140, B1620, B2130, B2131, B2132, B2133, B2134, B2135, B2136,

B2137, B2138, B2139, B2391, B2394, B2395, B2631, B2632

2-169

TM 11275-15/3D

TANK, FABRIC, COLLAPSIBLE, POTABLE WATER, 20,000 GALLON

TAMCN: B2632

TC-119

National Stock Number/ID Number

5430-01-351-7813

08845B

DESCRIPTION AND FUNCTION

The 20,000 Gallon Collapsible Fabric Potable Water Tank is a pillow type, synthetic rubber-impregnated

nylon tank. It is fitted with 4-inch camlock type filler/discharge ports and may be folded for storage. A repair kit is

also provided.

TECHNICAL DESCRIPTION

Manufactured By

Good Year Aero Space

Capacity

N/A

Corporation ™, Engineer

Air System and California

Inflatable's (TFSMS)

OPERATING AND SHIPPING DATA

Operating Mode

N/A

Shipping Mode

Weight:

170,000 lb full

Weight:

1,100 lb

Width:

28 ft

Width:

31 in.

Length:

32 ft

Length:

138 in.

Height:

68 in.

Height:

18 in.

Cube:

45 ft³

Square Stowage:

30 ft²

Replaced Item(s)

N/A

Transportability

MTVR, LVSR

Associated TAMCN(s)

B0571, B0573, B1137, B1140, B1620, B2130, B2131, B2132, B2133, B2134, B2136,

B2137, B2138, B2139, B2391, B2394, B2395, B2631, B2632

2-170

TM 11275-15/3D

MARINE CORPS TACTICAL WELDING SHOP (MCTWS)

TAMCN: B2685

TC-233

National Stock Number/ID Number

3431-01-498-4423

04055D

DESCRIPTION AND FUNCTION

The Marine Corps Tactical Welding Shop (MCTWS) consists of selected tools and equipment integrated

with an enclosure mounted on a 1/2-Ton modified, two-wheeled military trailer, chassis model M103A3. The

MCTWS provides compressed air on demand, electrical power for lights and electric hand tools, and an illumi-

nated work surface with a vise. The welder can also be operated by external 230V/3-Phase/single phase power.

This self-contained shop set will enable Marine maintenance personnel to perform a variety of welding pro-

cesses for maintenance and repair of equipment in remote locations.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

6,040 lb (2,254 kg)

Weight:

6,040 lb (2,254 kg)

Width:

91 in. (231 cm)

Width:

91 in. (231 cm)

Length:

166 in. (422 cm)

Length:

166 in. (422 cm)

Height:

81 in. (206 cm)

Height:

81 in. (206 cm)

Cube:

709 ft³ (20.03 m³)

Cube:

709 ft³ (20.03 m³)

Square Stowage:

104 ft² (9.70 m²)

Square Stowage:

104 ft² (9.70 m²)

Replaced Item(s)

N/A

Transportability

Flatbed truck, aircraft, rail, and helicopter

Associated TAMCN(s)

B2686, B2687

2-171

TM 11275-15/3D

MARINE CORPS TACTICAL WELDING SHOP (MCTWS) ARMOR WELDING KIT

TAMCN: B2686

TC-234

National Stock Number/ID Number

3431-01-505-0248

10926A

DESCRIPTION AND FUNCTION

The Armor Welding Kit consists of selected tools and equipment that are integrated with the existing equip-

ment on the Marine Corps Tactical Weld Shop (MCTWS), which allows the user to perform field-welding repairs

of armor plate equipment. Welding repairs of armor plate using GAS Metal Arc Welding (GMAW) (preferred) and

Shielded Metal Arc Welding (SMAW) secondary repair option.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

6,040 lb (2,254 kg)

Weight:

6,040 lb (2,254 kg)

Width:

91 in. (231 cm)

Width:

91 in. (231 cm)

Length:

166 in. (422 cm)

Length:

166 in. (422 cm)

Height:

81 in. (206 cm)

Height:

81 in. (206 cm)

Cube:

709 ft³ (20.03 m³)

Cube:

709 ft³ (20.03 m³)

Square Stowage:

104 ft² (9.70 m²)

Square Stowage:

104 ft² (9.70 m²)

Replaced Item(s)

N/A

Transportability

Flatbed truck, aircraft, rail, and helicopter

Associated TAMCN(s)

B2685, B2687

2-172

TM 11275-15/3D

MARINE CORPS TACTICAL WELDING SHOP (MCTWS) TITANIUM KIT

TAMCN: B2687

TC-235

National Stock Number/ID Number

3431-01-505-0888

10927A

DESCRIPTION AND FUNCTION

The Titanium Kit consists of selected tools and equipment that are integrated with the existing equipment on

the Marine Corps Tactical Weld Shop (MCTWS), which allows the user to perform field-expedient repairs of tita-

nium-based metals and equipment.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

TBD

Weight:

TBD

Width:

20.4 in. (52 cm)

Width:

20.4 in. (52 cm)

Length:

31.3 in. (78 cm)

Length:

31.3 in. (78 cm)

Height:

15.4 in. (39 cm)

Height:

15.4 in. (39 cm)

Cube:

5.70 ft³ (0.16 m³)

Cube:

5.70 ft³ (0.16 m³)

Square Stowage:

4.41 ft² (0.41 m²)

Square Stowage:

4.41 ft² (0.41 m²)

Replaced Item(s)

N/A

Transportability

Flatbed truck, aircraft, rail, and helicopter

Associated TAMCN(s)

B2685, B2686

2-173

TM 11275-15/3D

D7G WINCH, ATTACHMENT, SINGLE DRUM

TAMCN: B2705

National Stock Number/ID Number

3830-01-155-1587

06537B

TC-120

DESCRIPTION AND FUNCTION

The Winch is hydraulically powered. It is mounted on the Tractor, Medium, Full-Tracked (TAMCN B2462, pg.

2-33). The winch is used for towing, loading, recovery, and self-recovery operations.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

3,165 lb (1,435 kg)

Weight:

3,165 lb (1,435 kg)

Width:

43 in. (109 cm)

Width:

43 in. (109 cm)

Length:

39 in. (99 cm)

Length:

39 in. (99 cm)

Height:

47 in. (119 cm)

Height:

47 in. (119 cm)

Cube:

45.6 ft³ (1.29 m³)

Cube:

45.6 ft³ (1.29 m³)

Square Stowage:

11.6 ft² (1.08 m²)

Square Stowage:

11.6 ft² (1.08 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

N/A

2-174

TM 11275-15/3D

TOWING AND LIFTING YOKE

TAMCN: B2730

TC-121

National Stock Number/ID Number

8110-00-856-6243

04485B

DESCRIPTION AND FUNCTION

The Towing and Lifting Yoke provides the means for towing the Drum, Fabric, Collapsible, Liquid Fuel, 500

Gallon (TAMCN B0570) and the Drum, Fabric, Collapsible, Potable Water, 500 Gallon (TAMCN B0571) short

distances and lifting them with power equipment or by helicopter. The yoke is collapsible and is constructed of

two sections consisting of an upper leg, connecting leg, and brace. When assembled, the two sections connect

at the braces with the upper leg forming an eye attaching to a shackle on each end of the drum.

OPERATING AND SHIPPING DATA

Operating Mode

Shipping Mode

Weight:

Varies

Weight:

80 lb (36 kg)

Width:

Varies

Width:

Varies

Length:

Varies

Length:

Varies

Height:

Varies

Height:

Varies

Cube:

Varies

Cube:

1 ft³ (0.03 m³)

Square Stowage:

Varies

Square Stowage:

2 ft² (0.19 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

B0571, B0676

2-175

TM 11275-15/3D

TOOL KIT, INTERMEDIATE LEVEL ELECTRICIANS (L-LEVEL TOOL KIT)

TAMCN: B7900

TC-272

National Stock Number/ID Number

5180-01-546-8026

11390A

DESCRIPTION AND FUNCTION

The I-Level Tool Kit is comprised of various hand tools and accessories to aide Marines in Military Occupa-

tional Specialty (MOS) 1141 to install and maintain interior wiring in fixed structures. The I-Level Tool Kit will come

in a rugged/transportable case, and will include electrician’s tools, testers, and meters contained within its own rug-

ged/transportable case with foam inserts and molded plastic trays for tool storage and protection. These new mod-

ernized tools are configuration controlled. Refer to SL-3-11390A for complete listing and description of tools.

TECHNICAL DESCRIPTION

Panel

Dimensions

Black & Company

Manufacturer:

Length (in.):

Management INC.

Model:

1-Level

Width (in.):

Height (in.):

Weight (lb):

510

Volume (ft³):

18.75

Replaced Item(s)

N/A

Transportability

Forklift Portable

Associated TAMCN(s)

N/A

2-176

TM 11275-15/3D

POWER DISTRIBUTION SYSTEM, FFSS BUS DUCT

TAMCN: C0200

National Stock Number/ID Number

6110-01-522-3067

11060A

TC-279

DESCRIPTION AND FUNCTION

The Field Food Service System Bus Duct (FFSSBD) will allow for multiple configurations; two 60 kW, three

60 kW, one 100 kW, or two 100 kW, 120/208, 3-Phase, 60 Hz generators to power the Marine Rapid Deploy-

ment Kitchen (MRDK), Field Sanitation Unit (FSU), and Refrigerator Box (REEFER). Each FFSSBD is com-

pletely self-contained in a weather resistant enclosure and is capable of distributing power from generators

configured for 120/208VAC. The FFSSBD is configured so that loads and/or generators may be safely added

and removed without disrupting power. The FFSSBD does not automatically synchronize generator inputs. Syn-

chronization must be accomplished by the generator sets.

TECHNICAL DESCRIPTION

Panel

Dimensions

Manufacturer:

EPE Company

Length (in.):

Model:

03-1172A

Width (in.):

Volts:

120/208

Height (in.):

Frequency (Hz):

Weight (lb):

243

Phase:

Volume (ft³):

Circuit Breakers

MRDK:

600AF, 600A

Height (in.):

FSU:

400AF, 250A

Weight (lb):

243

AUX 60 kW:

400AF, 250A

Volume (ft³):

Connectors

Cam-Loc, 5-Wire (GWBRB), Male, 3 sets on input.

Cam-Loc, 5-Wire (GWBRB), Female, 3 sets on output.

Replaced Item(s)

N/A

Transportability

Forklift Portable

Associated TAMCN(s)

N/A

2-177

TM 11275-15/3D

DRY CHEM, SELF-CONTAINED FIRE EXTINGUISHER

TAMCN: C4765

TC-122

National Stock Number/ID Number

4210-01-354-9893

07661C

4210-01-205-2246

07661B

DESCRIPTION AND FUNCTION

The Fire Extinguisher is a self-contained unit designed and constructed to be particularly effective in fighting

fire generated by hydrocarbon fuels. This twin agent fire extinguisher is skid-mounted and easily relocated when

necessary.

OPERATING AND SHIPPING DATA

Operating Mode

Base Unit

Cart

Weight:

3,600 lb (1,633 kg)

Weight:

455 lb (206 kg)

Width:

52 in. (132 cm)

Width:

46 in. (117 cm)

Length:

96 in. (244 cm)

Length:

48 in. (122 cm)

Height:

51 in. (130 cm)

Height:

59 in. (150 cm)

Cube:

207.84 ft³ (5.89 m³)

75.4 ft³ (2.14 m³)

Square Stowage:

34.7 ft² (3.22 m²)

Square Stowage:

15.4 ft² (1.43 m²)

Shipping Mode

Base Unit

Cart

Weight:

4,460 lb (2,023 kg)

Weight:

744 lb (337 kg)

Width:

53 in. (135 cm)

Width:

50 in. (127 cm)

Length:

103 in. (262 cm)

Length:

52 in. (132 cm)

Height:

68 in. (173 cm)

Height:

63 in. (160 cm)

Cube:

214.9 ft³ (6.08 m³)

94.8 ft³ (2.68 m³)

Square Stowage:

38.0 ft² (3.53 m²)

18.1 ft² (1.68 m²)

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

N/A

2-178

TM 11275-15/3D

LASERPLANE, LEVEL SYSTEM

TAMCN: J3087

National Stock Number/ID Number

3805-01-457-1962

81000B

TC-310

DESCRIPTION AND FUNCTION

The Laserplane Level System is comprised of a Blade Pro, model MG2P351T/E and a Laserplane Dual

Slope Transmitter Kit, Model 1145-2. The Blade-Pro System contains all of the required hardware for mounting

the Blade-Pro System to the 130G Grader, TAMCN B1082. Installation kit, NSN 5860-01-278-8963 provides all

the necessary cables, hoses, fittings, brackets, and fasteners required to move components from grader to

grader. Also, the Terramodel ConstructionPak Software Package is an important part of the total system. The

packages are a complete high performance 3D surface modeling solution for heavy and highway construction.

ConstructionPak is a single software solution for quantity verifications, tracking of built earthwork quantities and

performing total construction layout. The LLS system will increase grading productivity by cutting to grade in

fewer passes, with consistent accuracy, at high operating speeds, day or night. DOD equipment operators have

achieved typical production increases of 30 to 50 percent. This system has the ability to control cross slope; or

the elevation of one or both sides of the blade by using a device called a Tracer. Operator selectable features

and functions customize the system to meet particular job requirements. Proportional hydraulic control valves

provide fast and smooth automatic control of the blade.

TECHNICAL DESCRIPTION

Panel

Dimensions

Manufacturer:

Trimble Navigation Limited.

Length (in.):

Width (in.):

Model:

Height (in.):

Square Stowage:

Cube Stowage:

Weight (lb):

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

B1082

2-179

TM 11275-15/3D

KIT, ARMOR TRACTOR, RUBBER TIRE, ARTICULATED STEERING, MULTI-PURPOSE

TAMCN: U0003

National Stock Number/ID Number

9515-01-545-2474

11367A

TC-319

DESCRIPTION AND FUNCTION

The Kit, Armor, is a 3rd and 4th echelon tool kit for the Tractor, Rubber Tire, Articulated Steering, Multi-Pur-

pose (TAMCN B0063, pg. 2-33).

TECHNICAL DESCRIPTION

Panel

Dimensions

Manufacturer:

ADSI

Length (with no attachment on

267 in.

Model:

CPK644E

vehicle):

Length (with bucket on vehicle):

308 in.

Length (with forks on vehicle):

343 in.

Width (with no attachment on vehicle):

105 in.

Width (with bucket on vehicle):

108 in.

Width (with forks on vehicle):

105 in.

Height:

146 in.

Weight (with no attachment on

37,880 lb

vehicle):

Weight (with bucket on vehicle):

41,540 lb

Weight (with forks on vehicle):

41,080 lb

Square Stowage (with bucket stowed

257.25ft²

on forks and attached to vehicle):

Cube Stowage (with bucket stowed

3,130 ft³

on forks and attached to vehicle):

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

B2567

2-180

TM 11275-15/3D

KIT, ARMOR, MEDIUM CRAWLER TRACTOR

TAMCN: U0013

TC-328

National Stock Number/ID Number

9515-01-563-0360

11575A

DESCRIPTION AND FUNCTION

The Kit, Armor, is a 3rd and 4th echelon tool kit for the Medium Crawler Tractor (TAMCN B0060, pg. 2-30).

TECHNICAL DESCRIPTION

Panel - Interchangeable Cab

Dimensions

Manufacturer:

BAE (Armor only)

Length (with no attachment on vehicle):

218.6 in.

Length (with ripper on vehicle):

258.3 in.

Length (with winch on vehicle):

236 in.

Width:

140 in.

Width (reduced with blade removed):

104 in.

Height:

131 in.

Weight (with no attachment on vehicle)

51,160 lb

Weight (with ripper on vehicle):

56,220 lb

Weight (with winch on vehicle):

54,700 lb

Square Stowage (worst case with Ripper

251.1ft²

Attachment attached to vehicle):

Cube Stowage (worst case with Ripper

2,741.5 ft³

Attachment attached to vehicle):

Replaced Item(s)

N/A

Transportability

N/A

Associated TAMCN(s)

B0060

2-181

TM 11275-15/3D

SYNCHRONIZER BOX, GENERATOR, 20 kW, 60 Hz

TAMCN: NA

National Stock Number/ID Number

6110-01-559-0584

8J908B

TC-292

DESCRIPTION AND FUNCTION

The synchronizer box, Model MSB25, is a stand alone assembly designed to allow synchronous power

transfer between two MMG25 generators, or between a single MMG25 generator and utility power, without dis-

rupting and loads connected to the generator. This will allow the removal of the primary generator from the grid

for service or extended maintenance. The MSB25 is capable of handling current up to 100 amperes of 120/

208VAC, 60 Hz, 3-Phase power. It has two 5-Wire grounded input connections and a single 5-Wire grounded

output connection. This is a special usage item managed by the Project Officer for Mobile Electric Power at PM

EPS MARCORSYSCOM. Units desiring to use this item should contact PM EPS, MARCORSYSCOM.

TECHNICAL DESCRIPTION

Set

Dimensions

Manufacturer:

Magnum

Length (in.):

25.5

Model:

MSB25

Width (in.):

27.5

Volts:

120/208

Height (in.):

9.2

Frequency (Hz):

Weight (lb):

Phase:

Volume (ft³):

3.73

Construction

Aural Signature

Welded steel enclosure

Audio Rating:

N/A

Replaced Item(s)

N/A

Transportability

Two-man Portable, requires no special support or trailer equipment

Associated TAMCN(s)

B0930

2-183/(2-184 blank)

TM 11275-15/3D

Equipment Listings by TAM-Number Sequence.

TAMCN

NSN

EQUIPMENT

PAGE

B0001

07579C

4120-01-164-7420

Air Conditioner, MCS, Horizontal, 0.75-Ton

2-1

07579B

4120-01-093-3385

10212A

4120-01-330-6542

07579D

4120-01-193-4998

B0002

10140A

4120-01-327-1316

Air Conditioner, MCS, Horizontal, 60 Hz, 1.5-Ton

2-2

07592F

4120-01-237-4463

07592C

4120-01-122-0626

07592D

4120-01-076-1753

07592A

4120-00-411-3730

09265A

4120-01-268-4451

B0003

11080A

4120-01-526-1588

Air Conditioner, 1.5-Ton, 18,000 BTU/HR

2-3

B0004

11286A

4120-01-539-4630

Air Conditioner, MCS, Horizontal, 400 HZ, 1.5-Ton

2-4

07418D

4120-01-168-1775

07418C

4120-01-073-9095

07418A

4120-01-350-0185

08714B

4120-01-220-7381

04984A

4120-01-286-8854

B0006

06503C

4120-01-072-6388

Air Conditioner, MCS, Vertical, 400 Hz, 3-Ton

2-5

09063A

4120-01-244-6385

09235A

4120-01-110-2034

B0008

11084A

4120-01-526-1060

Air Conditioner, 5-Ton, 60,000 BTU/Hr

2-6

B0010

11079A

4120-01-526-1120

Air Conditioner, 10-Ton, 120,000 BTU/Hr

2-7

11079A

4120-01-564-7844

B0012

09857A

4120-01-325-7062

Air Conditioner, MCS, Vertical, 50/60 or 400 Hz,

2-8

18,000 BTU

B0014

11082A

4120-01-526-2397

Air Conditioner, 3-Ton, 36,000 BTU/Hr

2-9

B0016

11559A

6115-01-431-3062

Generator Set, Diesel Engine, Model MEP-903A

2-10

B0017

11703A

5280-01-571-4894

Tool Kit

2-11

B0018

11490A

2330-01-556-9648

Integrated Trailer-ECU-Generator (ITEG)

2-12

B0024

11243A

3825-01-497-0690

613C Water Distributor

2-13

B0025

11241A

3710-01-535-7449

Trailer-Mounted Hydroseeder

2-14

B0026

11234A

3710-01-534-9817

Skid-Mounted Hydroseeder

2-15

B0027

11185A

6110-01-532-1794

MEPDIS-Replacement, Power Distribution Box,

2-16

Indoor Model, 5 kW, GFCI Protected

B0028

11186A

6110-01-532-1821

MEPDIS-Replacement, Power Distribution Box,

2-17

Outdoor Model, 5 kW Non-GFCI Protected

B0029

11183A

6110-01-532-1764

MEPDIS-Replacement, Power Distribution Box, 15

2-18

B0030

11184A

6110-01-532-1809

MEPDIS-Replacement, power Distribution Box, 30

2-19

B0031

11182A

6110-01-532-1835

MEPDIS-Replacement, Power Distribution Box, 100

2-20

B0032

11187A

6110-01-532-1776

MEPDIS-Replacement, Power Distribution Box, 300

2-21

3-1

TM 11275-15/3D

Equipment Listings by TAM-Number Sequence - Continued.

TAMCN

NSN

EQUIPMENT

PAGE

B0036

11219A

4930-01-533-9826

Ground Expedient Refueling System (GERS),

2-22

Medium

B0037

11220A

4930-01-533-9830

Ground Expedient Refueling System (GERS), Small

2-23

B0038

11262A

3810-01-538-4030

All Terrain Crane (ATC)

2-24

B0039

11275A

3895-01-539-0585

Airfield Damage Repair (ADR) Kit

2-25

B0040

11284B

3805-01-550-0883

277C Multi-Terrain Loader

2-26

B0049

11574A

4130-01-562-9914

Large Field Refrigeration System (LFRS)

2-27

B0055

10006A

4510-01-163-6775

Bath Shower Unit

2-28

B0057

11374A

5420-01-545-7365

Joint Assault Bridge (JAB)

2-29

B0060

11503A

2320-01-558-5671

Medium Crawler Tractor (MCT)

2-30

B0061

11502A

4120-01-558-5664

Cooling and Refrigeration Expeditionary Kit (CREK)

2-31

B0062

11509A

5180-01-550-0145

Lineman’s Tool Kit

2-32

B0063

11412A

3805-01-549-7814

Tractor, Rubber-tired, Articulated Steering, Multi-

2-33

Purpose (TRAM)

B0066

B00667B

3510-01-549-8384

Containerized Batch Laundry (CBL) Unit

2-36

B0069

11418A

5180-01-550-8373

Climber’s Set, Tree, and Pole

2-37

B0071

TBD

Lightweight Water Purification System (LWPS)

2-38

B0074

11453A

4120-01-552-5223

Air Conditioner, 0.75-Ton, 9,000 BTU/Hr, 60 Hz

2-39

B0075

11609A

4130-01-565-7655

Small Field Refrigeration System (SFRS)

2-40

B0076

11470A

3805-01-553-4073

Multi-Terrain Loaded Work Tool

2-41

B0077

09292A

6115-01-274-7387

Generator Set, Diesel Engine, Model MEP-802A

2-42

B0078

11621A

3805-01-566-0558

120M Motorized Road Grader

2-43

B0079

11569A

3830-01-562-6715

Ripper Attachment, 3-Shank, Rear Mtg F/Tractor

2-44

B0081

11570A

3830-01-562-6695

Winch Attachment, Single Drum

2-45

B0083

11589A

6115-01-296-1462

Generator Set, Diesel Engine, Model MEP-809A

2-46

B0114

10020C

1940-01-526-7164

Bridge Erection Boat (BEB)

2-47

B0115

11104A

1940-01-527-9596

Bridge Erection Boat MKII Tactical Trailer

2-48

B0120

108675A

5420-00-172-3519

Bridge Erection Set

2-49

B0152

08676A

5420-00-172-3520

Medium Girder Bridge (MGB)

2-50

B0155

11518A

5420-01-550-5433

Bridge, Floating, IRB 80T, 100T Rafting Set, Ribbon

2-51

Bridge, Construction Outfit Ramp Bay and Interior Bay

Data

B01607B

10984A

2350-01-511-7783

Assault Breacher Vehicle (ABV)

2-52

B0171

09198A

3815-01-551-5938

Bucket, Clamshell

2-53

B0176

09197A

3815-01-291-9223

Bucket, Concrete

2-54

B0391

08758A

3930-01-082-3758

Rough Terrain Container Handler (RTCH) Vehicle

2-55

09117A

3930-01-269-4938

B0392

11078A

3930-01-522-7364

Rough Terrain Container Handler (RTCH), Kalmar

2-56

B0395

08917B

4310-01-498-8886

Air Compressor with Pneumatic Tools

2-57

B0443

09109A

3810-01-268-1737

High Speed, High Mobility, (HSHM) Crane

2-58

(w/o Pile Driver

Capability)

09109B

3810-01-320-1920

B0446

09166A

3810-01-165-0646

Rough Terrain Air Mobile Crane (AMC)

2-59

09166B

3810-01-516-9718

3-2

TM 11275-15/3D

Equipment Listings by TAM-Number Sequence - Continued.

TAMCN

NSN

EQUIPMENT

PAGE

B0471

00482B

1375-01-468-4400

Squad Demolition Kit (SDK)

2-60

B0472

01518A

1385-00-212-4591

Demolition Equipment Set

2-61

B0475

03701E

6665-21-906-1023

Mine Detector, AN/PSS-12

2-62

B0476

11001B

6665-01-527-4643

Advanced Mine Detector, AN/PSS-14

2-63

B0525

06536B

2590-01-155-1586

Fixed Drawbar Attachment

2-64

B0570

04486B

8110-00-965-2313

500 Gallon Collapsible Coated-Fabric Potable Water

2-65

Drum.

B0571

08935A

8110-01-122-0015

500 Gallon Collapsible Coated-Fabric Potable Water

2-66

Drum

B0572

10761A

5430-01-479-5116

50,000 Gallon Collapsible, Coated-Fabric, Fuel Tank

2-67

Assembly

B0573

10803A

5430-01-485-0103

3,000 Gallon Collapsible, Coated-Fabric, Fuel Tank

2-68

Assembly

B0574

08106A

5430-01-058-6293

20,000 Gallon Collapsible, Coated-Fabric, Fuel Tank

2-69

Assembly

B0579

07500A

5985-00-471-0223

Dummy Load, Generator Set, 100 kW

2-70

07500B

6150-01-306-2943

2-71

B0589

09599A

2350-00-808-7100

M9 ACE Armored Combat Earthmover

2-72

B0595

09127A

6110-01-273-2387

Mobile Electric Power Distribution, 15 KW Panel

2-73

B0600

09125A

6110-01-272-6953

Mobile Electric Power Distribution, 30 kW Panel

2-74

B0605

09124A

6110-01-272-6952

Mobile Electric Power Distribution, 100 kW Panel

2-75

B0608

09049A

6150-01-254-1666

Field Wiring Harness

2-76

B0625

10671A

4210-01-468-3460

Compressed Air Foam System-Mobile (CAFS-M)

2-77

B0626

10840A

4210-01-494-4642

Fire Suppression System (FSS)

2-78

B0640

11120A

6230-01-530-8890

Floodlight Set, Self-Contained

2-79

B0675

07391B

4930-01-094-0026

Tactical Airfield Fuel Dispensing System (TAFDS)

2-80

B0676

08936A

4320-01-110-1993

Forward Area Water Point Supply System

2-81

B0685

06674C

4930-01-113-9173

Amphibious Assault Fuel System

2-82

B0695

10188A

6640-01-399-0483

Tactical Petroleum Laboratory, Medium

2-83

B0730

10155A

6115-01-285-3012

Generator Set, Diesel Engine, 3 kW, 60 Hz

2-84

B0891

09247A

6115-01-275-5061

Generator Set, Diesel Engine, 10 kW, 60 Hz

2-85

B0921

09248A

6115-01-274-7392

Generator Set, Diesel Engine, 10 kW, 400 Hz

2-86

B0930

11125A

6115-01-531-0571

Generator Set, Diesel Engine, 20 kW, 60 Hz

2-87

B0953

09249A

6115-01-274-7389

Generator Set, Diesel Engine, 30 kW, 60 Hz

2-88

09249B

611501-461-9335

2-89

B0971

09246A

6115-01-462-0290

Generator Set, Diesel Engine, 30 kW, 400 Hz

2-90

09246B

6115-01-274-7394

2-91

B0980

11101A

6115-01-435-1565

Generator Set, Diesel Engine, 2 kW, 60 Hz

2-92

B1010

Cold Weather Kit

2-93

B1016

09245B

6115-01-462-0292

Generator Set, Diesel Engine, 60 kW, 400 Hz

2-94

09245A

6115-01-274-7395

2-95

B1021

09244A

6115-01-274-7390

Generator Set, Diesel Engine, 60 kW, 60 Hz

2-96

09244B

6115-01-462-0291

3-3

TM 11275-15/3D

Equipment Listings by TAM-Number Sequence - Continued.

TAMCN

NSN

EQUIPMENT

PAGE

B1045

07464A

6115-00-133-9101

Generator Set, Diesel Engine, 100 kW, 60 Hz

2-98

07464B

6115-01-036-6374

2-99

07464C

6115-01-296-1463

2-100

B1082

09089A

3805-01-303-6152

Motorized Road Grader

2-101

(MPS and Prepo

Norway only)

09089B

3805-01-150-4795

(All Others)

B1135

07387C

4930-01-114-9930

Helicopter Expedient Refueling System

2-102

B1139

10596A

4930-01-462-1304

Hose Reel System

2-103

B1140

09476B

4610-01-364-4485

Hypochlorination Unit, Purification, 2-350

2-104

B1191

09085A

5180-01-261-7881

Tool Kit, Intermediate, F/Tractor, Full-Tracked, w/Angle

2-105

Blade

B1298

09153A

1055-01-281-2770

MK 2 MOD 0 Mine Clearance System Trailer Mounted

2-106

B1300

09377A

2320-01-312-2616

Maintenance Platform, Air Mobile Crane

2-107

B1315

09962A

1055-01-226-6338

MK 1 MOD Mine Clearance System

2-108

B1320

01291B

9905-01-186-7253

Minefield Marking Set

2-109

B1420

01461B

6630-01-008-5524

Aviation Fuel Contamination Test Kit

2-110

B1570

03707F

4930-01-182-5028

Expedient Refueling System (ERS)

2-111

B1580

09003A

4030-01-240-4579

Pump Module, Fuel Six Container (SIXCON)

2-112

B1581

09444A

4320-01-318-1853

Pump Module, Water Six Container (SIXCON)

2-113

B1582

09540A

4320-01-158-2954

Pump, Water, 350 GPM

2-114

B1583

11222A

4320-01-533-6417

Pump, Fuel, 600 GPM

2-115

B1620

00970C

4320-01-149-7857

Pump Set, 65 GPM, 50 Ft Head

2-116

B1625

09439A

2090-01-316-2576

Improved Ribbon Bridge Raft Set Ramp BayI

2-117

B1645

10673A

4110-01-468-9792

Refrigeration Unit, Enhance

2-118

B1710

08407A

4110-01-107-9078

Refrigerator, Rigid Box

2-119

B1720

08710A

5420-01-139-1503

Reinforcement Set, Medium Girder Bridge (MGB)

2-120

B1775

06538D

3830-01-171-5776

Three Shank, Rear Mounting Ripper Attachment

2-121

B1785

10494A

3895-01-453-8573

Roller, Compactor, Vibratory, Self-Propelled

2-122

10494B

3895-01-550-8369

B1922

08900A

3805-01-153-1854

621B Wheeled Tractor-Scraper (WTS)

2-123

08900B

3805-01-550-7164

B1942

08165B

4910-01-550-7118

Construction Shop Kit

2-124

B1951

09018A

4940-01-235-5080

Shop Equipment, General Purpose, Set No 1

2-125

B2004

07678A

4120-00-327-5035

Skid-Mounting Assembly, Small, Remote, Air

2-126

Conditioner

B2006

07768A

4120-00-575-7200

Skid-Mounting Assembly, Large, Remote Air

2-127

Conditioner

B2085

09002A

5430-01-240-4578

SIXCON, Fuel Storage Tank Module

2-128

B2086

08990A

5430-01-203-9971

Water Six Container (SIXCON) Storage Tank Module

2-129

B2120

09130A

6675-01-273-7812

Survey Set, General Purpose

2-130

B2127

09199B

3830-01-504-2618

Sweeper, Rotary, Vehicle Mounting

2-131

3-4

TM 11275-15/3D

Equipment Listings by TAM-Number Sequence - Continued.

TAMCN

NSN

EQUIPMENT

PAGE

B2130

01034F

5430-01-469-8774

Collapsible Fabric 3,000 Gallon Water Tank

2-132

01034E

5430-01-359-4774

01034H

5430-01-540-5357

01034G

5430-01-470-7380

B2131

09495A

4610-01-120-7526

Tank Farm Interconnection Set, Dual Tank

2-133

B2132

09537A

4610-01-120-7528

Bag Filler Tank Farm Interconnection Set

2-134

B2133

09721A

4610-01-140-6775

Four Inch Hose Tank Farm Interconnection Set

2-135

B2134

09481A

4610-01-140-6776

2-Inch Hose Tank Farm Interconnection Set

2-136

B2135

07563A

4610-01-120-7522

Four Inch Discharge Hose Tank Farm Interconnection

2-137

Set

B2136

09483A

4610-01-123-7705

Hose Nozzle Tank Farm Interconnection Set

2-138

B2137

09496A

4610-01-120-7525

Tank Farm Interconnection Set, Accessory Kit

2-139

B2138

09564A

4320-01-120-7523

Tank Farm Interconnection Set, 350 GPM Pump

2-140

B2139

09484A

4320-01-120-7524

Tank Farm Interconnection Set, 125 GPM Pump

2-141

B2150

01036B

6635-00-641-3643

Test Set, Soil

2-142

B2210

11421A

5180-01-550-8250

Carpenter Kit

2-143

B2238

09038A

5180-01-254-7723

Tool Kit, Caterpillar

2-144

B2239

09288A

5180-01-306-4343

Tool Kit, Intermediate Maintenance for TRAM

2-145

B2240

01204A

5180-00-596-1531

Tool Kit, Electrician Lineman

2-146

B2250

11423A

5180-00-550-8112

Pioneer Platoon Kit

2-147

B2260

11422A

5180-00-550-8116

Pioneer Squad Kit

2-148

B2370

00425B

5180-01-551-3550

Mason and Concrete Finisher’s Kit

2-149

B2391

09539A

4320-01-128-4244

Pump Station, Tactical Water Distribution System

2-150

(TWDS)

B2392

09538A

4320-01-128-4245

Storage Assembly, Tactical Water Distribution System

2-151

(TWDS)

B2393

09536A

4320-01-128-4246

Distribution Point Tactical Water Distribution System

2-152

(TWDS)

B2394

09482A

4320-01-261-6470

600 GPM Pump Tactical Water Distribution System

2-153

(TWDS)

B2395

09854A

4320-01-377-4577

Tactical Water Distribution System, 5 Mile Segment

2-154

B2410

10259A

5180-01-428-0959

Tool Kit, M9 ACE, Organizational Maintenance

2-155

B2420

10258A

5180-01-429-2683

Tool Kit, M9 ACE, Intermediate Maintenance

2-156

B2460

09062A

2410-01-254-1667

Full-Tracked, Tractor with Angle Blade

2-157

B2462

08757A

2410-01-155-1588

Medium, Full-Tracked Tractor

2-158

B2464

09426A

3805-01-315-1091

Full-Tracked Tractor with Multi-Purpose Bucket

2-159

07542A

3805-00-140-2427

B2483

10996A

3805-01-514-7166

Backhoe Loader (BHL)

2-160

B2561

10794B

3930-01-508-0886

Extendable Boom Forklift Truck (EBFL)

2-161

B2565

11026A

2330-01-518-3809

Engineer Equipment Trailer (EET)

2-162

11026B

2330-01-547-0272

B2566

09135B

3930-01-478-3519

Light Capacity Rough Terrain Truck Forklift (LRTF)

2-163

09135C

3930-01-533-0855

B2567

09148A

3805-01-279-3635

Rubber-Tired, Articulated Steering, Multi-Purpose

2-164

Tractor (TRAM)

3-5

TM 11275-15/3D

Equipment Listings by TAM-Number Sequence - Continued.

TAMCN

NSN

EQUIPMENT

PAGE

08580C

4610-01-295-2719

B2605

10802A

4610-01-488-6961

Tactical Water Purification System (TWPS)

2-167

B2630

08580A

6630-01-477-2395

Water Quality Analysis Set - Purification

2-168

B2631

08938B

5430-01-200-4831

Tank, Fabric, Collapsible, Potable Water, 50,000

2-169

Gallon

B2632

08845B

5430-01-351-7813

Tank, Fabric, Collapsible, Potable Water, 20,000

2-170

Gallon

B2685

04055D

3431-01-498-4423

Marine Corps Tactical Welding Shop (MCTWS)

2-171

B2686

10926A

3431-01-505-0248

Marine Corps Tactical Welding Shop (MCTWS) Armor

2-172

Welding Kit

B2687

10927A

3431-01-505-0888

Marine Corps Tactical Welding Shop (MCTWS)

2-173

Titanium Kit

B2705

06537B

3830-01-155-1587

D7G Winch, Attachment, Single Drum

2-174

B2730

04485B

8110-00-856-6243

Towing and Lifting Yoke

2-175

B7900

11390A

5180-01-546-8026

Tool Kit, Intermediate Level Electricians (L-Level Tool

2-176

Kit)

C0200

11060A

6110-01-522-3067

Power Distribution System, FFSS Bus Duct

2-177

C4765

07661C

4210-01-354-9893

Dry Chem, Self-Contained Fire Extinguisher

2-178

07661B

4210-01-205-2246

J3087

81000B

3805-01-457-1962

Laserplane, Level System

2-179

U0003

11367A

9515-01-545-2474

Kit, Armor Tractor, Rubber Tire, Articulated Steering,

2-180

Multi-Purpose

U0013

11575A

9515-01-563-0360

Kit, Armor, Medium Crawler Tractor

2-181

U0014

11580A

2540-01-563-3905

Tram Armored Cab

2-182

8J9088

6110-01-559-0584

Synchronizer Box, Generator, 20 kW, 60 Hz

2-183

09146C

3830-01-482-8569

Forklift Attachment

2-34, 2-166

09149C

3830-01-482-8567

Multi-Purpose Bucket

2-35, 2-167

3-6

Military reference books and manuals (2009-2023, Volume 8) - page 37
