Chapter Twenty: Risk Management Security Policy

20. CHAPTER TWENTY: RISK MANAGEMENT SECURITY POLICY

a. General Policy Statement

Protection of information assets and maintaining the confidentiality, integrity, and availability of

USDA Office of the Chief Information Officer (OCIO), Information Technology Services (ITS)

information technology assets and telecommunications resources are vital in meeting the USDA’s

overall program delivery requirements. Implementation of security measures such as a risk

management program, effective security controls, certification and accreditation of information

systems, and updated security plans are vital components.

b. Policy Detail

The OCIO-ITS will perform formal Risk Assessments (RA) of all IT systems. RAs will be

conducted using the same processes and procedures as defined in the DM3540-000 Risk

Management Program, dated August 19, 2004, inclusive of Table 1: USDA Risk Assessment

Methodology dated, dated February 11, 2003, or their replacements. Risk assessments typically

identify risks that a system could be affected by. Risk mitigation plans are required as a follow-

up document to an RA.

A formal system risk analysis is required every three years or when a major change is made in a

General Support System (GSS) or Major Application (MA). Major changes are defined as

modifications to the system that affect the security controls and which render the system

vulnerable to compromise or intrusion. Waiver requests will be considered for extensions in

compliance time only; all IT systems will undergo regular risk assessments. The OCIO-ITS will

include the cost for IT system mitigations in budgetary planning and prepare a business case to

ensure that funding is available to implement protection against identified vulnerabilities.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 70

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-One: Router and Switch Management Security Policy

21. CHAPTER TWENTY-ONE: ROUTER AND SWITCH MANAGEMENT

SECURITY POLICY

General Policy Statement

This policy establishes requirements for access to USDA Office of the Chief Information Officer

(OCIO), Information Technology Services (ITS) router and switch resources. These

environments shall require authorization and access control through the use of individual

credentials as outlined in Chapter 3: Authorization and Access Control Security Policy or its

replacement. Where possible, the Terminal Access Controller Access System (TACAS+) is to be

used for authentication. Additionally, the use of local system accounts shall be limited and used

on an exception basis.

Policy Detail

(1).

Router and Switch Configuration

(a).

Configuration standards and management procedures shall be used to control usability,

efficiency, and security of the overall router and switch environment, and shall be kept

in a Trusted Facility Manual (TFM) in accordance with Chapter 5: Certification and

Accreditation Security Policy or its replacement. These standards and other procedures

shall be followed when designing, implementing, or managing router and switch

configurations. Written approval from the Change Control Board (CCB) is required to

deviate from these standards.

(b).

The following shall be disallowed on all routers and switches:

1. IP direct Broadcasts

2. Incoming packets with invalid source address.

3. TCP and UDP small servers

4. Router web services

(c).

All routers and switches shall use Access Control Lists (ACL) to only permit traffic that

has a recognizable business need.

(d).

Traffic shall be denied unless permitted.

(e).

All security related service packs, patches, and hot-fixes shall be tested and applied to

all routers and switches in a timely manner.

(f).

All routers and switches must present and display a warning banner in accordance with

Chapter 14: Network Access Security Policy or its replacement.

(g).

All back-up media shall be kept in a secured manner consistent with Chapter 17:

Physical Access Security Policy, or its replacement, and be protected by a password.

(h).

A selected portion of backup media shall be kept in an alternate physical location and

shall be secured in a manner consistent with Chapter 17: Physical Access Security

Policy or its replacement.

(i).

The Administrator/Root Account is the original administrative account of the router and

switch. This account shall be renamed and used only on a limited or emergency basis.

Only select administrative personnel shall have knowledge of these account credentials,

which must be stored in a locked environment.

(2).

Router and Switch Management

(a). All routers and switches shall be physically secured in accordance with Chapter 17:

Physical Access Security Policy or its replacement.

(b). All routers and switches shall be backed up in a manner that permits a complete

recovery of routers and switches on a weekly basis. Archives of router and switch

backups shall be maintained until no longer required by management.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 71

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-One: Router and Switch Management Security Policy

(c). Any prolonged or delayed application of a security-related service pack, patch, or hot-

fix shall be documented and an application for a wavier to this policy must be applied

for.

(3).

Router and Switch Management Access

(a). Access to router and switch consoles and operating systems shall be limited to network

administrator personnel only. All router and switch user accounts shall comply with

password requirements in accordance with Chapter 3: Authorization and Access

Control Security Policy or its replacement.

(b). Permitted access shall be limited to only essential users and service accounts.

(c). Only one person shall have access to one user account - that is, more than one person

shall not have access to the same account.

(d). All network administrators shall receive the appropriate level of training to perform

their duties in a competent manner.

(4).

Router and Switch Information Access

Access to router and switch information shall be restricted to the network administrator,

CCB, OCIO-ITS Information Systems Security Program Manager (ISSPM) or designated

representative, and/or persons with written permission from the CCB or ISSPM. Restricted

information shall minimally include documents, details, drawings, diagrams, or screen prints

containing any information regarding router and switch configurations, installed

applications, data storage, scripts, pass codes, or log files. Any account with administrative

privileges shall be issued to network administrators only.

(5).

Router and Switch Logs

(a). All routers and switches shall maintain and record security auditing events to logs.

(b). All routers and switches shall log security auditing events that display both successful

and unsuccessful incidents.

(c). All log files and events shall be managed in a manner that maintains their integrity and

authenticity. These logs are to be stored or archived for a minimum of six (6) months.

(d). Requests for access to router and switch logs shall be made to the appropriate network

administrator and Agency ISSPM.

(e). Event logs shall be reviewed by the network administrator and ISSPM or designated

representative on a regular basis.

(6).

Change Request

Change requests for any modifications to a router and switch system, configuration, or

design shall be submitted in writing to as a Request for Change (RFC) following Change

Management (CM) procedures. All change requests shall include the reason and timeframe

for the request as well as all risks, threats, and known issues associated with this change.

Only after CCB approval shall network administrator personnel proceed with the router and

switch changes. Any changes from the original design once approved, and not yet

implemented or in the process of implementation, will require a formal change request form.

(7).

Router and Switch Implementation

A request for implementation of new routers and switches shall be submitted to the CM.

This request shall include all configuration settings together with other pertinent system

information. Only after obtaining approval from the CCB shall authorized personnel

proceed with the router and switch implementation.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 72

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-One: Router and Switch Management Security Policy

(8). Implied Authority

(a). All network administration personnel have the implied authority and responsibility to

take action(s) to protect OCIO-ITS assets from loss without approval from the CCB in

an emergency only to include modifying router and switch operating systems,

hardware, or configurations. This authority is only justified if a direct threat or attack

has been discovered and prompt action is required to reduce the risk and/or loss.

(b). The OCIO-ITS ISSPM has the implied authority and responsibility to direct and

authorize action(s) to protect OCIO-ITS information assets from loss without CCB

approval in an emergency only.

(c). If this authority is exercised, the administrator shall report it as an incident and follow

Chapter 10: Incident Identification, Declaration, Reporting, and Handling Security

Policy or it replacement.

(9). Incident Reporting and Response

In the event that a security vulnerability or breach, malicious activity, successful attack, or

violation of this policy has been discovered or suspected, an incident shall be reported in

accordance with Chapter 10: Incident Identification, Declaration, Reporting, and Handling

Security Policy or its replacement.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 73

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-Two: Security Architecture Framework Management Security Policy

22. CHAPTER TWENTY-TWO: SECURITY ARCHITECTURE

FRAMEWORK MANAGEMENT SECURITY POLICY

General Policy Statement

This policy establishes requirements for the USDA Office of the Chief Information Officer

(OCIO), Information Technology Services (ITS) to evaluate their Information System Security

(ISS) architecture framework to ensure adequate protection of all OCIO-ITS information

resources. The OCIO-ITS will conduct an initial review to develop a security model of their

information systems assets. The review will include a systematic approach of identifying and

allocating all information systems assets to a security architecture baseline. The baseline will

include assigning assets with their functional responsibilities (end user systems, relay systems,

etc), identifying how these assets are used to meet OCIO-ITS business needs and requirements, in

the form of security domains (Internal, External, Public Access, Remote Access), and finally

identifying the general security control requirements for each asset.

Policy Detail

(a).

The OCIO-ITS will develop a Security Architecture Framework (SAF) baseline and security

model within their respective IT structure in alignment with Cyber Security’s Guidance

Regarding Developing a Security Architecture Framework, CS-035, or its replacement, for

additional information and guidelines. The steps in this process include:

1. Identifying/storing information pertaining to local IT assets: The SAF process shall be

used by the OCIO-ITS to identify how each IT asset contributes to the security

architecture framework.

2. Identifying how assets link to a generic security model: The Service Center Agencies

supported by the OCIO-ITS shall determine how their assets link to a Basic Element

category and assign it to a generic security model.

3. Identifying security domains: After identifying the assets and assigning them to their

basic elements within the security model, the OCIO-ITS must develop security domains.

A security domain consists of a set of users, the data for a system, and a security policy

that governs the use of the domain.

4. Identifying security control requirements: Once OCIO-ITS assets have been categorized

into basic elements in the security model and security domains have been created,

security controls will be assigned based upon the level of security required for each

domain level and element.

5. Identifying security products to support security controls and security domains:

Only those products approved by the USDA OCIO in the Security Product Database will

be used for meeting security requirements unless otherwise agreed upon with the OCIO-

ITS.

6. Periodic Review of Security Architecture Framework: The OCIO-ITS will periodically

evaluate their ISS architecture to ensure that changes are made accordingly to the SAF

baseline to reflect changes in business and systems requirements.

7. Process Scope: This process can be used by the OCIO-ITS for small and large IT

architectures. The key is capturing all IT assets within the OCIO-ITS architecture.

(2).

Submission and review of the SAF shall follow the guidance in Cyber Security’s Guidance

Regarding Developing a Security Architecture Framework, CS-035, or its replacement.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 74

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-Three: Security Awareness, Training, and Education Security Policy

23. CHAPTER TWENTY-THREE: SECURITY AWARENESS, TRAINING,

and EDUCATION SECURITY POLICY

General Policy Statement

(1). This policy establishes requirements for the Security Awareness, Training, and Education

program for information resources supporting the USDA Office of the Chief Information

Officer (OCIO), Information Technology Services (ITS).

(2). Federal requirements justifying the OCIO-ITS Security Awareness, Training, and Education

program are as follows:

(a). OPM Regulation 5 CFR 930, Employees Responsible for the Management of Use of

Federal Computer Systems.

(b). National Institute of Standards and Technology (NIST) Special Publication 800-16,

OCIO-ITS Security Training Requirements: A Role-and Performance-Based Model,

dated April 1998.

(c). Executive Order 13103, Computer Software Piracy, dated September 30, 1998.

(d). NIST Special Publication 800-18, Guide for Developing Security Plans for Information

Technology Systems, December 1998.

(e). Office of Management and Budget (OMB) Circular No. A-130, Appendix III, dated

February 8, 1996, Security of Federal Automated Information Resources.

(f). Computer Security Act of 1987.

(g). Presidential Decision Directive 63 (PDD63), May 22, 1998.

(h). OPM Regulation Title 5, Volume2, Parts 930.301-305

Policy Detail

(1).

The OCIO-ITS will develop, organize, implement, and maintain an IT systems security

awareness training program to ensure the security of OCIO-ITS information resources and to

establish requirements for formal training to be conducted at least annually.

(2).

NIST Special Publication 800-16 is the source for guidance and direction in the design of the

computer security awareness training program in the OCIO-ITS.

(3).

All OCIO-ITS employees, contractors, subcontractors, grantees and co-operators involved in

the management, use, design, development, maintenance or operation of an application or

automated information system shall be made aware of their security responsibilities based on

their need-to-know and trained to fulfill them.

(4).

Training content shall assure that all groups specified above are versed in the rules and

requirements pertaining to security of the respective Federal IT systems, which they access,

operate, or manage.

(5).

Computer security awareness refresher training is required at least annually or whenever

there is a significant change in IT direction, major system modifications, changes/upgrades

in software utilized, or change of duties for continued access to OCIO-ITS information

systems.

(6).

The OCIO-ITS will retain records documenting initial or annual computer security

awareness training.

(7).

Training must include software piracy prevention and appropriate software use training in

compliance with Executive Order 13103, “Computer Software Piracy.”

(8).

The OCIO-ITS will distribute security alerts and advisories, as needed, through appropriate

media to remind all groups of security practices or to inform them of new security issues.

(9).

New OCIO-ITS and Service Center Agency (SCA) employees and Government contractors

shall receive Security Awareness Training within 30 days of being hired.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 75

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-Four: Security Plan Management Security Policy

24. CHAPTER TWENTY-FOUR: SECURITY PLAN MANAGEMENT

SECURITY POLICY

General Policy Statement

(1).

Federal Requirements

The Computer Security Act of 1987 and OMB A-130, Appendix III, requires security plans

for all USDA Office of the Chief Information Officer (OCIO), Information Technology

Services (ITS) information technology systems. Each plan shall reflect accurate and

comprehensive details required by NIST 800-18, Guide for Developing Security Plans for IT

Systems. The generic term “systems” covers all General Support Systems (GSS) and Major

Applications (MA).

(2).

Security Plans

(a).

The OCIO-ITS shall develop and maintain individual security plans for all general

support systems and major applications, and an Overall Program Security Plan. These

three types of plans shall be prepared using the instructions and templates as defined in

the following:

1. Security Plan Development, section b., (1).

2. General Support System (GSS) Security Plan Templates for Hardcopy Submission

(refer to CS-021, 2003 Annual Security Plans for Information Technology Systems

or its replacement for template)

3. Major Application (MA) Security Plan Templates for Hardcopy Submission (refer

to CS-021, 2003 Annual Security Plans for Information Technology Systems or its

replacement for template)

4. General Support System (GSS) Security Plan Templates for Electronic Submission

(refer to CS-021, 2003 Annual Security Plans for Information Technology Systems

or its replacement for template)

5. Major Application (MA) Security Plan Templates for Electronic Submission (refer

to CS-021, 2003 Annual Security Plans for Information Technology Systems or its

replacement for template)

6. Modification of these templates closely parallels NIST 800-18 but also contains

information required by Federal Information Security Management Act (FISMA),

and the Office of Inspector General audits.

(b).

The OCIO-ITS and Agency Information Systems Security Program Managers

(ISSPMs) shall work with their respective system owners and developers to prepare and

update security plans for all general support systems and/or major applications on a

periodic basis or when a GSS or MA is implemented or significantly changed.

(c).

The OCIO-ITS ISSPM shall prepare a security plan for the Overall Security Program as

outlined in Security Plan Development (Section b), and the Overall Program Security

Plan Template.

(d).

The OCIO-ITS ISSPMs will submit all completed annual security plans to the OCIO-

ITS CIO’s office and shall submit a cover letter with all plans attesting to the

completeness and accuracy of these security plans.

(e).

All OCIO-ITS shall submit security plans will be updated every three years or upon a

major change.

Policy Detail

(1). Security Plan Development

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 76

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-Four: Security Plan Management Security Policy

(a). Security plans shall reflect input from individuals with responsibilities concerning the

system and/or application including functional end users, system owners, the system

administrator, and the system security manager.

(b). For those contractors and/or partners operating an OCIO-ITS sponsored information

system, the respective ISSPM will ensure that the necessary contract language is

included in procurement requests to specify compliance with the security plan in the

development, maintenance, and operation of all information systems and/or

applications.

(c). Any security plan developed by a contractor or outside entity shall always be reviewed

by the sponsoring ISSPM and the application or system owners.

(2).

Determining General Support Systems and Major Applications

(a). All applications and systems shall be covered by system security plans if they are

categorized as a major application or general support system. All other applications

shall be accounted for in the Service Center Agencies’ Overall Security Plan.

(b). Applications that are categorized as non-major will require a statement regarding

security and require software certification before inclusion in the enterprise system.

(c). A system is identified by constructing logical boundaries around a set of processes,

communications, storage, and related resources. The elements within these boundaries

constitute a single system requiring a security plan. Each element of the system shall:

1. Be under the same direct management control

2. Have the same function or mission objective

3. Have essentially the same operating characteristics and security needs

4. Reside in the same general operating environment

5. A group of portable PCs provided to employees who require mobile computing

capability for their jobs

6. A system with multiple identical configurations that are installed in locations with

the same IT environmental and physical safeguards.

(d). All components of a system need not be physically connected, for example:

1. A group of stand alone personal computers (PCs) in an office

2. A group of PCs placed in an employees’ homes under defined telecommunications

program rules

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 77

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-Five: Server Management Security Policy

25. CHAPTER TWENTY-FIVE: SERVER MANAGEMENT SECURITY

POLICY

General Policy Statement

This policy establishes requirements for authorization and access to USDA Office of the Chief

Information Officer (OCIO), Information Technology Services (ITS) server resources through the

use of individual credentials. Group credentials are not permitted for access to any server. For

the purpose of this policy, system level resources such as Domain Name Server (DNS) or

Dynamic Host Configuration Protocol (DHCP) do not apply. The intent is to eliminate

anonymous access to resources and establish a foundation for auditing. Additionally, OCIO-ITS

servers containing sensitive information shall meet USDA C2-like Level of Trust.

Policy Detail

(1).

Server Configuration

(a).

Configuration standards and management procedures shall be used to control usability,

efficiency, and security of the overall server environment and shall be kept in a Trusted

Facility Manual (TFM). These standards and other procedures shall be strictly followed

when designing, implementing or managing server configurations. Written approval

from the Change Control Board (CCB) is required prior to any deviation from these

standards.

(b).

All security-related service packs, patches, and hot-fixes shall be tested and applied to

all servers in a timely manner in accordance with Chapter 16: Patch Management

Security Policy or its replacement.

(c).

All servers shall comply with the encryption of sensitive data in accordance with

Chapter 11: Information Classification Security Policy or its replacement.

(d).

All servers shall be physically secured in accordance with Chapter 17: Physical Access

Security Policy or its replacement.

(e).

All servers shall be protected by antivirus software in accordance with Chapter 27:

Virus Protection Security Policy or its replacement.

(f).

All servers will display a warning banner in accordance with Chapter 14: Network

Access Security Policy or its replacement.

(g).

All servers shall be backed up in a manner that allows for a complete server recovery,

including operating system, applications, data and system state, on a daily basis.

Archives of server backups shall be kept for a period of at least six weeks.

(h).

All back-up media shall be kept in a secured manner consistent with Chapter 17:

Physical Access Security Policy, or its replacement, and be protected by controlled

access.

(i).

A selected portion of backup media shall be kept in an alternate physical location

secured in a manner consistent with Chapter 17: Physical Access Security Policy, or its

replacement, and be protected by controlled access.

(j).

System owners shall be responsible for the documentation, validity, and availability of

information regarding their full operations outside of the backup archive.

(2).

Server Specification Settings

(a). Maximum password age shall be no more than 90 days.

(b). Maximum password length shall be set to 14 and the minimum length shall be set to 9.

(c). Lock out duration is set to 0 (zero) to enable lockout forever, or until unlocked by an

authorized administrator.

(d). Lock out procedures shall be initiated after three failed attempts to login.

(e). Password complexity shall be implemented on all servers.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 78

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-Five: Server Management Security Policy

(f). Null login credentials shall be disabled on all servers.

(g). All server configurations shall be set to prevent administrators from performing the

following actions:

1. Debugging programs

2. Using logon as a service

(3).

Server Management Access

(a). Access to server consoles and operating systems shall be limited to system

administrator personnel only. For security purposes, no exceptions to this rule shall be

allowed. All server administrator accounts shall comply with the password

requirements set by Chapter 3: Authorization and Access Control Security Policy or its

replacement.

(b). All non-essential user, group, and service accounts must be removed immediately.

(c). All non-essential services must be removed immediately.

(d). The administrator account is the original administrative account of the server and/or

domain. This account shall be renamed and used on a limited basis. Only select system

administrator personnel are to have knowledge of this account’s credentials.

(e). Administrators are not permitted to have access to more than one administrator account.

(f). Administrators are not permitted to share their account information with anyone,

including the help desk and management.

(g). Any service account used by a service to access system resources is not to be used for

any other purpose. Only system administrator personnel are permitted to have

knowledge of service account credentials.

(h). All system administrators shall receive the appropriate level of training to perform their

duties in a competent manner.

(4).

Server Classification

(a). Each server hosting a mission critical application or service in a production

environment shall be identified as a production server. All production servers must be

logically separated and isolated from test and development environments.

(b). Each server shall be clearly identified as to the classification of information stored or

used by the server. These classifications shall follow information classification

processes in accordance with Chapter 11: Information Classification Security Policy or

its replacement.

(c). Servers shall be managed and administered in accordance to their identified type and

classification.

(5).

Server Information Access

Access to server information is restricted to a system administrator and Information Systems

Security Program Managers (ISSPM) or persons with written permission from the ISSPM.

In the event that server access is created for security audit purposes, it shall be with read-

only privileges.

(6).

Server Logs

(a). All servers shall maintain security audit logs that include (at a minimum) the UserID,

date, time, and action performed.

(b). All servers shall log security auditing events showing successful and unsuccessful

events, including inappropriate access events.

(c). All log files and events shall be managed in a manner that maintains their integrity and

authenticity, and will be stored or archived for a minimum of six (6) months.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 79

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-Five: Server Management Security Policy

(d). Request for access to server logs shall comply with the server information statement in

this document.

(e). Access to security auditing logs shall be limited to system administrators and ISSPM

personnel.

(f). Event logs should be reviewed by system administrators on a daily basis and reviewed

randomly or on an as-needed basis by ISSPM personnel.

(7).

Server Implementation

All new servers shall meet defined standards and configuration requirements as outlined in

the appropriate configuration management document. A request for implementation of new

or revised configuration servers shall be submitted to the CCB. Only after obtaining CCB

approval shall system administrators proceed with the server implementation. Any changes

from the original design plan approved by CCB shall need to be resubmitted via a Request

for Change (RFC). Servers being added to the environment shall require additional approval

by the CCB.

(8).

Server Change Requests

Change requests for any changes to the enterprise server system components, configuration

or active directory design shall be submitted in writing via an RFC to the CCB for review.

All change requests shall include the reason and timeframe for the request as well as all

risks, threats, and known issues associated with this change. Only after CCB approval shall

system administrators proceed with the server changes.

(9).

Server Services

Servers shall only host services for which they were designed and approved to host. Any

additional services must be approved by the CCB. For the purpose of this policy, the term

‘services’ refers to specific services that a server was designed to host such as a web site, file

and print, DNS, DHCP, Telnet, or FTP. All services not required for system functionality

are to be disabled.

(10). Implied Authority

(a). All system administrators have the implied authority and responsibility to take action(s)

to protect OCIO-ITS information assets from loss without CCB approval in an

emergency to include modifying or changing server operating systems, hardware,

configurations, or accounts. This authority is only justified if a direct threat or attack

has been discovered and prompt action is required to reduce the risk and/or loss.

(b). The OCIO-ITS ISSPM has the implied authority and responsibility to direct and

authorize action(s) to protect OCIO-ITS information assets from loss without CCB

approval in an emergency only. This authority is only justified if a direct threat or

attack has been discovered and prompt action is required to reduce the risk and/or loss.

(c). If this authority is exercised, the administrator shall report it as an incident and follow

Chapter 10: Incident Identification, Declaration, Reporting, and Handling Security

Policy or it replacement.

(11). Incident Reporting and Response

In the event of a security vulnerability or breach, malicious activity, successful attack, or

violation of this policy has been discovered or suspected, an incident shall be reported in

accordance with Chapter 10: Incident Identification, Declaration, Reporting, and Handling

Security Policy or its replacement.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 80

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-Six: Systems Development Life Cycle Security Policy

26. CHAPTER TWENTY-SIX: SYSTEMS DEVELOPMENT LIFE CYCLE

SECURITY POLICY

General Policy Statement

(a).

This policy establishes requirements for the USDA Office of the Chief Information Officer

(OCIO), Information Technology Services (ITS) to successfully implement security

protocols and procedures into the Systems Development Life Cycle (SDLC) to ensure that a

system is developed in accordance with the stated requirements, works effectively, is cost

effective, is secure, and is maintainable. The inclusion of security controls and measures

early in the SDLC will result in less expensive and more effective security than adding it

after a system is operational.

(b).

The OCIO-ITS will implement baseline security controls during the developmental life cycle

of all IT systems. The security controls selected for each baseline must be implemented at

the recommended level of robustness in order to achieve the estimated threat coverage. In

cases where security baselines do not provide sufficient coverage against certain types of

threats, additional security controls must be provided upon discovery. National Institute of

Standards and Technology (NIST) Special Publication (SP) 800-53, Recommended Security

Controls for Federal Information Systems, provides additional information on appropriate

security controls for each type of baseline.

(c).

OCIO-ITS information systems security controls shall be integrated into the SDLC from

system inception. System owners will identify and contact the Information Systems Security

Program Manager (ISSPM) when the system is in the Initiation Phase of the SDLC.

(d).

Legacy systems which do not have an existing SDLC plan, or equivalent, shall develop an

SDLC Plan relative to the current phase of the system if it is not fully operational or

identified for additional security controls. Corresponding documentation shall clearly

reference its equivalence to SDLC information.

(e).

OCIO-ITS system security requirements documentation as identified in the SDLC shall be

placed under configuration management control from the inception of the system and will be

included as part of the total set of system documentation that evolves over the lifecycle.

(f).

All SDLC plans and SDLC related documents shall be kept current.

Policy Detail

The SDLC is separated into five phases during which information system products are developed.

These phases include the Initiation Phase, the Development/Acquisition Phase, the

Implementation Phase, the Operations/Maintenance Phase, and the Disposition Phase.

(1). Initiation Phase

This is the first phase in the SDLC. The following shall be included in this phase:

(a). Preparation of the Interconnectivity Security Agreement (ISA)

The OCIO-ITS shall initiate an ISA during this phase of the SDLC. An ISA is part of

the overall Certification and Accreditation process and must be completed for each new

system that will be connected to an existing legacy system, unless those systems are

under the same management.

(b). Preliminary Risk Assessment

The OCIO-ITS shall conduct an assessment in examination of the basic security needs

of the proposed system. A preliminary risk assessment shall define the threat

environment in which the system will operate. This assessment should (1) result in a

brief initial description of the basic security needs of the system, (2) define the threat

environment in which the product or system will operate, and (3) define a potential set

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 81

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-Six: Systems Development Life Cycle Security Policy

of countermeasures. This risk-based approach to information security is defined in

NIST SP 800-30, Risk Management Guide for Information Technology Systems.

(c). Security Categorization

The OCIO-ITS shall define and establish a level (i.e., low, moderate, or high) of

potential impact(s) to prevent a potential breach of security. FIPS Publication 199,

Standards for Security Categorization of Federal Information and Information Systems,

shall be used in conjunction with available vulnerability and threat information in

assessing all potential risk to an organization through operation of the proposed

information system.

(d). Privacy Impact Assessment

The OCIO-ITS is required to initiate a Privacy Impact Assessment (PIA) in this phase

as part of the ongoing security effort. Refer to Chapter 19: Privacy Impact Assessment

Security Policy, or its replacement, for additional information on this subject.

(2).

Development Phase

This is the second phase in the SDLC. The following shall be included in this phase:

(a).

Risk Assessment

The OCIO-ITS is required to perform a Security Risk Assessment during this phase to

identify protection requirements for the system through a formal risk assessment

process. The selection of appropriate types of safeguards or countermeasures must take

into consideration the results of the security assurance requirements analysis as defined

in the previous phase.

(b).

Security Functional Requirements Analysis

The OCIO-ITS is required to perform an analysis of requirements that include the

following components: (1) system security environment, and (2) security functional

requirements. This process shall include an analysis of laws and regulations such as the

Privacy Act, FISMA, OMB circulars, Agency enabling acts, NIST Special Publications

and FIPS, and other legislation and federal regulations, which define baseline security

requirements.

(c).

Security Assurance Requirements Analysis

The OCIO-ITS is required to conduct an analysis of requirements that address the

developmental activities required and assurance evidence needed to produce the desired

level of confidence that the information security will work correctly and effectively. A

balance must exist between the benefits to mission performance from system security

and the risks associated with operation of the system without security.

(d).

Cost Considerations and Reporting

The OCIO-ITS is required to determine what percentage of the development cost can be

attributed to information security over the life cycle of the system. Security controls

should be included at the beginning of the SDLC as it is the most cost effective

approach for two reasons: (1) it is usually more difficult to add functionality into a

system after it has been built; and (2) it is frequently less expensive to include the

preventive measures to deal with the cost of a security incident.

(e).

Security Planning

The OCIO-ITS is required to ensure that agreed upon security controls, planned or in

place, are fully documented in a system security plan. Refer to Chapter 24: Security

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 82

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-Six: Systems Development Life Cycle Security Policy

Plan Management Security Policy, or its replacement, for additional information on this

subject.

(f). Security Control Development

Security controls described in the respective security plans shall be designed,

developed, and implemented in this phase. Refer to Chapter 24: Security Plan

Management Security Policy, or its replacement, for additional information on this

subject.

(g). Developmental Security Test and Evaluation

The OCIO-ITS is required to ensure that security controls developed for a new

information system are working properly and are effective as evidence by the

developer’s test materials and test results.

(3).

Implementation Phase

This is the third phase of the SDLC. The following shall be included in this phase:

(a). Security Control Integration

The OCIO-ITS is required to make certain that security controls are integrated at the

operational site where the information system is to be deployed into production.

Security control settings and switches will be enabled in accordance with manufacturer

instructions and available security implementation guidance such as the Trusted Facility

Manual (TFM) for the system.

(b). Security Certification

The OCIO-ITS is required to ensure that security controls are effectively implemented

through established verification techniques and procedures within the system

certification process. Refer to Chapter 5: Certification and Accreditation Security

Policy, or its replacement, and in accordance with NIST SP 800-37: Guide for the

Security Certification and Accreditation of Federal Information Systems, May 2004.

(c). Security Accreditation

The OCIO-ITS is required to ensure that the necessary security authorization of an

information system to process, store, or transmit information is obtained. OMB

Circular A-130 requires the security authorization of an information system to process,

store, or transmit information. Refer to Chapter 5: Certification and Accreditation

Security Policy, or its replacement, and in accordance with NIST SP 800-37: Guide for

the Security Certification and Accreditation of Federal Information Systems, May 2004.

(4).

Operations and Maintenance Phase

This phase is the fourth phase of the SDLC. The following shall be included in this phase:

(a). Configuration Management and Control

The OCIO-ITS is required to ensure adequate consideration of potential security

impacts due to specific changes to an information system or its surrounding

environment. Depending upon the extent of change to an operational system, additional

Certification and Accreditation (C&A) measures may be required. Significant changes

include operating system version and major applications that could impact the current

operation.

(b). Continuous Monitoring

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 83

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-Six: Systems Development Life Cycle Security Policy

The OCIO-ITS is required to make certain that controls continue to be effective in their

application through periodic testing and evaluation.

(5). Disposition Phase

Disposition is the final phase in the SDLC. The following shall be included in this phase:

(a). Media Sanitization

The OCIO-ITS is required to make certain that all data is deleted, erased, and/or written

over as necessary to protect information system hardware. Refer to Chapter 13: Media

Sanitation and Disposal Security Policy, or its replacement, for additional information

on this subject.

(b). Hardware and Software Disposition

The OCIO-ITS is required to ensure that all hardware and software is disposed of in

accordance with Chapter 13: Media Sanitation and Disposal Security Policy or its

replacement.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 84

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-Seven: Virus Protection Security Policy

27. CHAPTER TWENTY-SEVEN: VIRUS PROTECTION SECURITY

POLICY

General Policy Statement

(1). This policy establishes the guidelines for the management and protection of software used

within the USDA Office of the Chief Information Officer (OCIO), Information Technology

Services (ITS). Instructions for installing and configuring the virus protection software on

workstations and laptops shall be made available online at

http://www.sci.usda.gov/cce/guides.html.

(2). Virus definitions and updates shall be tested and certified prior to deployment.

(3). All users are responsible for reporting suspected viruses to designated IT support staff

immediately.

Policy Detail

(1).

Virus Protected Systems

(a). Virus-checking software must be installed and maintained to include the latest virus

signature file applied on all servers, workstations, laptops, and personal electronic

devices regardless of operating system, whether connected to the OCIO-ITS networks

or not. This includes contractor-owned and/or contractor-operated systems, standalone

computers and personal electronic devices, and computers of the OCIO-ITS and

business partners connected to networks. Virus-checking software must meet the

requirements outlined in this policy and in CCE Trusted Facilities Manuals (TFM) or

standards.

(b). E-mail servers must have an antivirus package installed and running with the latest

virus signatures applied. E-mail servers shall have a content filtering package or

additional device capable of blocking specified attachments, installed, and be running.

(2).

Virus Software Configurations and Scanning Policy

(a). All non-Government machine-readable produced computer media (for example, floppy

diskettes, zip cartridges, CD-ROMs, tapes, etc.) and downloaded files must be scanned

for viruses and other malicious software before initial use. This pertains to all OCIO-

ITS equipment operated by employees, contractors, and partners.

(b). Remote access users are required to bring in their Government-issued computer laptops

and Portable Electronic Devices (PED) to their designated Service Center Agency work

facility (minimum of once each month) so that OCIO-ITS approved virus scans can be

run and/or antivirus software updates be installed on this equipment. However, this

frequency may change in the event of a virus outbreak.

(c). When feasible, standardized virus software configurations shall be used on non-

enterprise systems.

(d). Antivirus software shall be configured to scan all files and macros (not just program

executables) for viruses. This does not apply to swap files.

(e). Antivirus software shall be configured for both on-access and scheduled scanning.

(f). Antivirus software shall be configured so that all inbound and outbound files are

scanned along with the boot sector and floppy drive (during shutdown).

(g). Antivirus software shall be configured to scan e-mail attachments prior to sending or

opening.

(h). Antivirus software shall be configured so that ActiveX and Java components in Web

pages and HTML-based e-mail messages are scanned.

(i). End users shall not have the ability to disable the antivirus software on their computer.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 85

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-Seven: Virus Protection Security Policy

(j). All e-mail stored, inbound or outbound, with or without attachments, must be scanned

for viruses regardless of the destination address.

(k). E-mail scanning must include all attachments and macros. Attachments and macros

that cannot be scanned must be deleted and replaced with a message detailing the action

taken. Outgoing e-mail must be scanned at the network server to which the client is

connected. If a virus is detected on outgoing e-mail, the server must run a virus scan

immediately on the originating client.

(l). Antivirus software shall be configured so that all activity of the antivirus software is

logged. Ensure the logs are included in the daily backups. Logs must be maintained

until no longer needed.

(m). The date of the virus definitions shall be monitored to ensure the automatic update is

functioning properly.

(n). The directory that contains the “setup.exe” for the antivirus software shall be secured so

that end users cannot delete, rename, or write files to this directory, and/or inhibit any

file tampering.

(o). Antivirus software shall be configured to block e-mail that it is unable to scan.

(p). Antivirus updates shall be loaded at the time system instruction is received.

(q). Antivirus software shall be configured to automatically pull and apply the latest virus

definition updates from a central repository site daily.

(r). All non-Government-owned laptops shall have an OCIO-ITS approved/current version

of antivirus software installed prior to connecting to any OCIO-ITS network or

computer source.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 86

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-Eight: Vulnerability Scan Security Policy

28. CHAPTER TWENTY-EIGHT: VULNERABILITY SCAN SECURITY

POLICY

General Policy Statement

(1). This policy establishes the guidelines for the protection of USDA Office of the Chief

Information Officer (OCIO), Information Technology Services (ITS) information systems.

Vulnerability scans are required to be conducted on a monthly basis for all operational

networks, systems, and servers, inclusive of routers and switches, that the OCIO-ITS are

responsible for managing.

(2). OCIO-ITS is the configuration authority for all vulnerability scans performed and requires

that all scanning configurations established by the Service Center Agencies are required to

be uniform in approach.

(3). Each Information Systems Security Program Manager (ISSPM) is responsible for scanning

all regional-based hardware, regardless of who owns the equipment.

(a). East Region: Natural Resources Conservation Service, ISSPM

(b). Central Region: Farm Service Agency, ISSPM

(c). West Region: Rural Development, ISSPM

Policy Detail

(1).

New Equipment/Equipment Upgrade

(a). Informational scans may be requested by the ISSPM and Change Control Board (CCB)

prior to implementation of new or modified/upgraded equipment into the production

environment. Scan results shall be provided to the ISSPM and CCB.

(b). Scans will be conducted prior to new system installations and when any major

modifications/upgrades are implemented on current operational systems regarding their

connectivity, application functionality, and general security configurations. Service

Center Agencies and staff shall only scan networks or servers for which they are

responsible.

(c). A series of scans shall be performed during the developmental cycle such as baseline

server (if new hardware) with full applications loaded, then pre-pilot and pre-

production. The systems administrator should contact the closest regional Field Office

to coordinate the scanning request. Only pre-pilot and pre-production scans are

required for configuration management approval prior to further action.

(d). New systems and equipment or major modifications to existing systems/equipment

must be scanned in their development and/or test environment prior to deployment into

a production environment. System representatives must contact the ISSPM and CCB to

initiate a scan 10 working days prior to scheduling a special or pre-production scan.

The system/equipment will not be deployed until vulnerabilities identified have been

adequately addressed or a waiver has been approved. Equipment not scanned prior to

production will be removed immediately from the network.

(2).

Routine Scans

(a). The ISSPM shall coordinate all scans performed at the Agency level and provide the

OCIO Office of Cyber Security with the names and contact information for a primary

and secondary contact person relative to performing scans.

(b). Scan results from production sources shall be forwarded to the responsible ISSPM and

CCB for corrective action depending upon hardware ownership. It is the responsibility

of the applicable ISSPM and/or the CCB to ensure that all vulnerabilities are addressed

within the appropriate timeframes or when waivers are requested.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 87

Number 3602-001

FOR OFFICIAL USE ONLY

Chapter Twenty-Eight: Vulnerability Scan Security Policy

(c).

All scans should be completed no later than the 15th calendar day of each month, unless

they are considered a special scan, i.e., following major modifications/upgrades.

ISSPMs must notify the Department and all relative Service Center Agencies prior to

performing a scan.

(d).

Scan results will be provided to the responsible system owners/administrators so that

identified vulnerabilities can be addressed. High and medium risk vulnerabilities

require a formal response from the appropriate system representatives.

(e).

Responsible parties will reply back to the respective Agency ISSPM within seven

calendar days after receiving the scan results for a medium risk vulnerability, and

within one workday for a high-risk vulnerability. An action plan must be included for

vulnerabilities not mitigated within the required timeframes. The originating ISSPM

must receive the results no later than the 23^rdcalendar day of each month.

(f).

Computer network staff shall address vulnerabilities in the order of their associated risk

as a means to mitigate the most serious vulnerabilities immediately (High

→Medium→Low). All vulnerabilities on OCIO-ITS networks, systems, and servers

identified as ‘high’ and ‘medium’ must be formally addressed in a timely fashion. A

reasonable effort shall be made to address and correct vulnerabilities rated “low.”

(g).

Scan responses provided to the Agency ISSPM and CCB for all high and medium

vulnerabilities should fall into one of five categories:

Vulnerability has been corrected.

The response shall indicate what corrective action has been taken and the date of

correction. The system owner/administrator must sign the response to certify that

these actions have been taken. The ISSPM and CCB must initiate a rescan to

ensure that corrective actions mitigated the vulnerability.

Vulnerability is a false-positive.

System owners/administrators must explain why they believe an identified

vulnerability is a false-positive. Once the system owner/administrator has provided

the ISSPM and CCB an explanation and the ISSPM and CCB have concurred, the

system representatives will no longer have to address the vulnerability on

subsequent monthly reports.

Corrective action is planned, but has not been completed.

The response must include an explanation outlining steps planned and the

timeframe for expected completion.

Vulnerability cannot be mitigated for business reasons.

The responsible system owner/administrator shall provide strong justification for

vulnerabilities for which there is not a plan to correct. The ISSPM will request a

waiver from the OCIO for vulnerabilities that cannot be mitigated for business

reasons.

Vulnerability cannot be mitigated for vendor reasons.

The system owner/administrator shall provide information on what is needed from

the vendor to correct the vulnerability and the timeframe. If no fix is available or

will not be available for one month or longer, then the owner/administrator should

work with the ISSPM to find a workable alternative to mitigate the vulnerability.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 88

Number 3602-001

FOR OFFICIAL USE ONLY

Appendices

APPENDICES

Appendix A: Acronyms

ACRONYM

DEFINITION

ACL

Access Control List

Active Directory

ADPO

Application Development Program Office

AIM

AOL Instant Messenger

C&A

Certification and Accreditation

Command and Control

CCB

Change Control Board

CCE

Common Computing Environment (enterprise system)

CCTV

Closed Circuit Television

CHAP

Challenge-Handshake Authentication Protocol

CIO

Chief Information Officer

CIRT

Computer Incident Response Team

Configuration Management

Certifying Officer

COTR

Contracting Officers Technical Representative

COTS

Commercial-Off-The-Shelf (Software)

CPIC

Capital Planning and Investment Control

Cyber Security (USDA)

Certification Team

DAA

Designated Accrediting Authority

DAM

Deputy Administrators for Management

DES

Data Encryption Standard

DHCP

Dynamic Host Configuration Protocol

DIG

Director of Infrastructure Governance

DIO

Director of Infrastructure Operations

DMZ

De-Militarized Zone

DNS

Domain Name Server

DoS

Denial of Service

DRAM

Dynamic Random Access Memory

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 89

Number 3602-001

FOR OFFICIAL USE ONLY

ACRONYM

DEFINITION

EPROM

Erasable Programmable ROM

FIPS

Federal Information Processing Standards

FISMA

Federal Information Security Management Act

FMFIA

Federal Managers Financial Integrity Act

FOIA

Freedom of Information Act

FOUO

For Official Use Only

FPS

Federal Protective Service

FSA

Farm Service Agency

FSC

Field Service Center

FTP

File Transfer Protocol

FTPS

Secure File Transfer Protocol

GISRA

Government Information Security Reform Act

GMSP

Group Manager of Security Policy

GOTS

Government-Off-The-Shelf (Software)

GPEA

Government Paperwork Elimination Act

GPRA

Government Performance and Results Act

GSA

General Services Agency

GSS

General Support System

HTTP

HyperText Transmission Protocol

HTTPS

HyperText Transmission Protocol, Secure

I-TIPS

Information Technology Investment Portfolio System

IDS Administrator

IAP

Internet Access Provider

IDS

Intrusion Detection System

IHP

Incident Handling Program

IHT

Incident Handling Team

IMAP

Internet Message Access Protocol

IMAPS

Internet Message Access Protocol, Secure

IO Lab

Interoperability Lab

IRC

Internet Relay Chat

ISA

Interconnectivity Security Agreement

ISP

Internet Service Provider

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 90

Number 3602-001

FOR OFFICIAL USE ONLY

ACRONYM

DEFINITION

ISS

Information System Security

ISSPM

Information Systems Security Program Manager

Information Technology

ITS

Information Technology Services

ITWG

Information Technology Working Group

LAN

Local Area Network

Major Application

MAC

Media Access Control

Malware

Malicious Software

MP3

MPEG Audio Layer 3

NetBIOS

Network Basic Input/Output System

NFS

Network File System

NIACAP

National Information Assurance Certification & Accreditation Process

NIST

National Institute of Standards and Technology

National information Technology Center - Systems Network Control

NITC- SNCC

Center

NRCS

Natural Resources Conservation Services

NSA

National Security Agency

NTP

Network Time Protocol

OCIO

Office of the Chief Information Officer

OEP

Occupant Emergency Plan

OIG

Office of Inspector General

OMB

Office of Management and Budget

OPM

Office of Personnel Management

Personal Computer

PDA

Personal Digital Assistant

PDD

Presidential Decision Directive

PDSD

Personnel and Document Security Division

PED

Portable Electronic Device

PGP

Pretty Good Privacy

PIA

Privacy Impact Assessment

PKI

Public Key Infrastructure

Public Law

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 91

Number 3602-001

FOR OFFICIAL USE ONLY

ACRONYM

DEFINITION

Program Manager

POP3

Post Office Protocol, version 3

POP3S

Post Office Protocol, version 3, Secure

PROM

Programmable ROM

Risk Assessment

RCF

Remote Call Forwarding

Rural Development

RIP

Routing Information Protocol

RFC

Request for Change

RLOGIN

Remote Login

ROM

Read Only Memory

RPC

Remote Procedure Call

Relay System

S/MIME

Secure/Multipurpose Internet Mail Extension

SAF

Security Architecture Framework

SBU

Sensitive But Unclassified

SCA

Service Center Agency

SCIF

Secure Compartmented Information Facility

SCMI

Service Center Modernization Initiative

SDLC

Systems Development Life Cycle

Standard Form

SIDO

Security Incident Duty Officer

Strategic Manager

SMTP

Simple Mail Transfer Protocol

SNMP

Simple Network Management Protocol

SOW

Statement of Work

Security Plan

SSP

System Security Plan

SRAM

Static Random Access Memory

SSH

Secure Shell

SSI

Sensitive Security Information

SSID

Service Set ID

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 92

Number 3602-001

FOR OFFICIAL USE ONLY

Appendix B: Definitions

TERM

DEFINITION

The ability to log on to an information resource through the use of an

identifier, such as a UserID, to associate a person/user with a set of

Access

access authorizations and privileges on a particular information system

(i.e., an account). Generally, an individual must have an account and/or

a password in order to use a system.

The security service that ensures LAN resources are being utilized in an

Access Control

authorized manner.

The formal declaration by the Designated Accrediting Authority (DAA)

that the system is approved to operate using a prescribed set of

Accreditation

safeguards and should be strongly based on the risks identified during

certification.

Active Directory

The directory service for Microsoft Windows 2000 Domain Controllers.

Security commensurate with the risk and magnitude of the harm

resulting from the loss, misuse, or unauthorized access to, or

modification of, information. This includes assuring that systems and

Adequate Security

applications used by the Agency operate effectively and provides

appropriate confidentiality, integrity, and availability, using cost-

effective management, personnel, operational, and technical controls.

A contraction of the words alphabetic and numeric, which indicates a

Alphanumeric

combination of any letters, numbers, and special characters.

A place away from the traditional worksite that has been approved for

Alternative Worksite

the performance of officially assigned duties. It may be an employee’s

home, a Telework Center, or other approved worksite.

Application

A program or system that permits a user to process certain types of data.

Centralized office within the Application Development division of

OCIO-ITS which is established for each IT project and it’s associated

SDLC processing. The mission of the Program Office is to ensure that

Application Development

the appropriate administrative, physical, and technical safeguards are

Program Office (ADPO)

incorporated into all applications, whether new or modified existing

programs. Additionally, it is responsible for generating a strategic plan

for each application or system.

Information system resources that support an OCIO-ITS organizational

Asset

mission. This includes, but is not limited to, property, software, data,

public image, and intellectual property.

An audit trail is a series of records of computer events, about an

operating system, application or user activities. An information

Audit Trail

resource may have several audit trails, each devoted to a particular type

of activity.

Verifying the identity of a user, process, or device, often as a

Authentication

prerequisite to allowing access to resources in an information system.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 94

Number 3602-001

FOR OFFICIAL USE ONLY

TERM

DEFINITION

The property of being genuine and able to be verified and be trusted;

Authenticity

assurance of the validity of a transmission, message, or originator

within an information system.

The act of empowering and individual with the ability to perform a

specific action with regards to an information system. This action or

Authorization

actions may include the ability to access and/or modify system

software, hardware, networks, etc.

An AIS is any assembly of electronic equipment, hardware, software,

Automated Information

and firmware configured to collect, create, communicate, disseminate,

System

process, store, and control data or information.

That aspect of security that deals with the timely delivery of

Availability

information and services to the user.

Basic Input/Output System

A set of instructions stored in Erasable Programmable Read-Only

(BIOS)

Memory (EPROM) chip on the computer system.

This method of authentication using fingerprint scan, voice recognition,

retina scan, or signature recognition. This may be used as an alternative

Biometric Authentication

to dynamic passwords or smart cards only if it can be proved to provide

a level of reliability.

To start the computer by loading the computer’s operating system into

Boot

the computer's main memory.

Any illegal penetration or unauthorized access to an information

Breach

resource.

Capital Planning and

A systematic approach to selecting, managing, and evaluating

Investment Control

information technology investments.

(CPIC)

The comprehensive assessment of technical and non-technical security

features and other safeguards associated with the use and environment

Certification

of a system to establish whether the system meets a set of specified

security requirements.

A formal evaluation and approval process with regard to technical and

non-technical security controls of an Information Technology (IT)

Certification and

system that establishes the extent to which a particular design and

Accreditation (C&A)

implementation meets a set of specified security requirements based on

an assessment of management, operational, and technical controls

within the IT system.

The Certifying Officer assumes the role of an independent technical

liaison for all stakeholders involved in the Certification and

Accreditation process and is an objective third party, independent of the

Certifying Officer (CO)

system developers. The Certifying Officer provides a comprehensive

evaluation of the system, including technical and non-technical controls,

to determine if the system is configured with the proper security

controls in place.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 95

Number 3602-001

FOR OFFICIAL USE ONLY

TERM

DEFINITION

Clear Text

Unencrypted information or data.

Software acquired by Government contract through a commercial

Commercial-Off-The-Shelf

vendor. This software is a standard product, not developed by a vendor

(COTS)

for a particular Government project.

The Common Computing Environment was established as an enterprise

Common Computing

system to provide a single, common computing environment for the

Environment (CCE)

Farm Service Agency (FSA), Natural Resources Conservation Service

(NRCS), and Rural Development (RD) agencies of USDA.

The unauthorized disclosure, modification, substitution, or use of

Compromise

sensitive information (includes plaintext cryptographic keys and other

critical security components).

The physical space that houses any equipment or interconnected system

or subsystems of equipment that is used in the automatic acquisition,

Computer Room

storage, manipulation, management, movement, control, display,

switching, interchange, transmission or reception of data or information.

A violation or imminent threat of violation of computer security

Computer Security

policies, acceptable use policies, standard security practices, or an

Incident

exploited system weakness or vulnerability.

Files provided by manufacturers of computer virus detection software to

Computer Virus Definition

identify all known current viruses. As new computer viruses are

Files

identified, virus definition files are updated and released by vendors to

eliminate, prevent, or destroy computer viruses.

Preserving authorized restrictions on information access and disclosure,

Confidentiality

including means for protecting personal privacy and proprietary

information.

A family of security controls on the management class dealing with the

Configuration

control of changes made to hardware, software, firmware,

Management

documentation, test, test fixtures, and test documentation throughout the

lifecycle of an information system.

A plan that describes the management controls involved in all changes

and updates made to a system that affects security. The plan includes

Configuration

all documentation supporting these changes and updates. This plan is

Management Plan

maintained throughout the Certification and Accreditation process and

updated according to system development lifecycle (SDLC) activities.

An action plan for ensuring Information Technology processing

continuity despite catastrophic events. Contingency Plans cover three

types of actions: 1) Emergency procedures for initially responding to

Contingency Plan

disruptions at primary locations; 2) Backup procedures for conducting

operations at alternate locations, when necessary; 3) Recovery

procedures for restoring normal operations back at the primary IT

facility.

Non-Government employee under contract and who use OCIO-ITS

Contractors

information systems or computer resources.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 96

Number 3602-001

FOR OFFICIAL USE ONLY

TERM

DEFINITION

Any action, device, procedure, technique or measure that reduces a

Countermeasure

system’s vulnerability to a threat.

An intruder who breaks into an information resource or network using a

Cracker

variety of unauthorized access methods, exploiting resources either

maliciously or for personal gain.

Credentials

Identification consists of a unique UserID and password for each user.

Critical information is that information which is used to support

Critical Information

customer service functions and other ongoing business requirements.

The science and practice that embodies principles, means and methods

Cryptography

for the transformation of information to hide its content, prevent its

undetected modification, and prevent its unauthorized use.

The unauthorized accidental or deliberate modification, destruction or

Damage

removal of information or data from an information resource.

Data Encryption Standard

A DES key consist of 64 binary digits of which 567 are randomly

(DES)

generated and used directly by the algorithm per FIPS Publication 46-3

The state that exists when computerized data or information is the same

Data Integrity

as that in the source documents or code and has not been exposed to

accidental or malicious alteration or destruction.

A cryptographic key, which is used to transform data (i.e., encrypt,

Data Key

decrypt, authenticate).

The process of transforming encrypted data into plain or readable

Decryption

information.

Decryption takes encrypted information and makes it comprehensible

Decryption Software

again.

A De-Militarized Zone is logically and physically restricted space that

De-Militarized Zone

may contain sensitive equipment such as firewalls, Intrusion Detection

(DMZ)

Systems (IDS), or network nodes.

The intentional degradation or blocking of computer or network

Denial of Service (DoS)

resources. Action(s) which prevent any part of a computer system or

network from functioning in accordance with its intended purpose.

Designated Accrediting

The DAA determines accreditation based on security risks of the

Authority (DAA)

system, business case, and budget.

A peripheral device that connects computers to each other for sending

Dial-in Modem

communications via the telephone lines.

A plan that identifies recovery procedures in the event of natural or

man-made disasters or catastrophes affecting the availability of the

Disaster Recovery Plan

system. This plan is tested annually to ensure the continued

effectiveness and adequacy of the plan.

The process of transforming readable information into cipher text

Encryption

through a sophisticated mathematical conversion process.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 97

Number 3602-001

FOR OFFICIAL USE ONLY

TERM

DEFINITION

A computer program that allows data to be encrypted during

transmission (useful for transmitting data across unsecured

Encryption Software

communications links) or in storage of the data (i.e., saving to a PDA,

computer hard disk, floppy disk, or CD).

There are a wide variety of different encryption products available. The

National Institute of Standards and Technology maintains a list of

Encryption Standards

cryptographic modules that have been validated against Federal

Information Processing Standard (FIPS) 140-2.

The process of transforming encrypted data into plain or readable

Exposure

information.

This term includes, but is not limited to, personal and mainframe

computers (networked or stand-alone), software; systems, networks,

Facility

network ports for access, email servers, intranet web servers, and

gateways used to access external networks such as the Internet and

World Wide Web.

A combination of hardware and software that controls network traffic

using stateful inspection of all traffic and monitors and controls sessions

Firewall

between internal and external users and internal networks, computers,

and resources.

A method of communication that incrementally can go from the speed

Frame Relay

of an ISDN to the speed of a T1 line.

The Freedom of Information Act, enacted in 1966, provides that any

person has a right, enforceable in court, of access to Federal Agency

Freedom of Information

records, except to the extent that such records are protected from

Act (FOIA)

disclosure by one of nine exemptions or by one of three special law

enforcement record exclusions.

Interconnected information resources under the same direct

management control that shares common functionality. It normally

includes hardware, software, information, data, applications,

General Support Systems

communications, facilities, and people, and provides support for a

(GSS)

variety of users and/or applications. Individual applications support

different mission-related functions. Users may be from the same or

different organizations.

An individual who attempts to unauthorized access information systems

Hacker

and network resources primarily to create havoc, produce disruptions,

and/or bring the system down altogether.

To damage, injure, or impair information systems using electronic

Harm

methods.

Potential for exceptionally serious impact on an Agency or program

High-risk

mission or the overall efficiency of the service.

The use of an identifier, such as a UserID, to allow an information

Identification

system to associate a person/user with a set of access authorizations and

privileges on a particular information system.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 98

Number 3602-001

FOR OFFICIAL USE ONLY

TERM

DEFINITION

Requires individual users to be held accountable for their actions after

Individual Accountability

being notified of the rules of behavior in the use of the system and the

penalties associated with the violation of those rules.

Analysis is performed during the initial life cycle phases to determine

Impact Analysis

the overall effect of proposed changes on existing security controls.

Any adverse event, real or suspected, involving the security of OCIO-

ITS information resources is to be considered a security incident. Any

Incident

violation of law, regulation or security policy, real or suspected, is to be

considered a security incident.

Policies, procedures and practices used to report, contain, investigate

Incident Handling and

and preserve evidence and respond to security incidents. Used

Response

synonymously with incident response.

Any OCIO-ITS Information Technology Resource consisting of

Information Resources

personnel, equipment, funds, and information technology.

The protection of data and information systems from unauthorized

Information Security

access, use, disclosure, disruption, modification, or destruction in order

to provide confidentiality, integrity, and availability.

The formal process of identifying each system in terms of its

Information Sensitivity

confidentiality, integrity, and availability.

A discrete set of information resources organized for the collection,

Information System

processing, maintenance, use, sharing, dissemination, or disposition of

information.

The primary role of the ISSPM is to provide security engineering and

Information Systems

security architecture support to the OCIO-ITS. This is performed in

Security Program

formal establishment of realizable security solutions that is consistently

Manager (ISSPM)

applied within OCIO-ITS in compliance with the application

development community.

Any equipment or interconnected system or subsystem of equipment

that is used in the automatic acquisition, storage, manipulation,

management, movement, control, display, switching, interchange,

Information Technology

transmission, or reception of data or information. The term information

(IT)

technology includes computers, ancillary equipment, software,

firmware and similar procedures, services (including support services),

and related resources.

An area of special-use space in OCIO-ITS locations that houses web

Information Technology

farms, computer or telecommunications equipment/devices and the

Restricted Space

general space surrounding those areas.

Office of the Chief

USDA IT component that specializes in providing information

Information Officer

technology support to the Service Center Agencies including Large

(OCIO), Information

Offices, Field Offices, and their partners.

Technology Services (ITS)

Integrity

Guarding against improper information modification or destruction, and

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 99

Number 3602-001

FOR OFFICIAL USE ONLY

TERM

DEFINITION

includes ensuring information non-repudiation and authenticity.

A set of networks and machines that use the TCP/IP protocol suite

Internet

connected through gateways, and share a common name and address

spaces.

The Lab’s primary focus is the testing and approval/disapproval of

legacy and COTS software and hardware products on the CCE

Interoperability Lab (IO

platform. Other functions are system and security configuration

LAB)

management of PC and server rollouts, software repackaging, SNA

gateway configuration, and virus protection administration throughout

the CCE Enterprise Domain.

Intruder

An intruder is a person who is the perpetrator of a security incident.

Intrusion is an unauthorized, inappropriate or illegal activity by insiders

Intrusion

or outsiders that can be considered a penetration or breach of an IT

resource.

Intrusion Detection Systems can include the following four types: 1)

Anomaly Detection - this type picks out traffic, protocols, or packets

Intrusion Detection System

that appear out of the ordinary, 2) Misuse Detection - these identify

(IDS)

threats based on signatures and are similar to antivirus programs, 3)

Passive Systems - these identify and log security compromises, and 4)

Reactive Systems - these block apparent malicious activity.

Represents a broad scope of activities designed to sustain and recover

critical IT services following an emergency. IT contingency planning

fits into a much broader emergency preparedness environment that

includes organizational and business process continuity and recovery

IT Contingency Planning

planning. Ultimately an organization would use a suite of plans to

properly prepare response, recovery, and continuity activities for

disruptions affecting the organization’s IT systems, business processes,

and the facility.

An expenditure of money and/or resources for IT and IT-related

products or services involving managerial, technical, or organizational

IT Investment

risks for which there are expected benefits to the organization’s

performance.

The net mission impact considering 1) the probability that a particular

threat-source will exercise (accidentally trigger or intentionally exploit)

IT Related Risk

a particular information system vulnerability and 2) the resulting impact

if this should occur.

Computer rooms used for housing Web Farms, DMZ equipment,

IT Restricted Space

mission critical systems, systems containing sensitive information and

critical infrastructure resources.

Defining boundaries around a set of processes, communications,

IT System

storage, and related resources (an architecture) identifies a system.

A room that contains equipment used to support Local Area Networks

LAN Room

(LAN). Most LANs connect workstations and personal computers that

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 100

Number 3602-001

FOR OFFICIAL USE ONLY

TERM

DEFINITION

span a relatively small area such as a single building or complex.

The impact an incident has on an organization. Impact includes: loss of

data; the cost to a OCIO-ITS Agency or mission area, negative

Level of Consequence

consequences to the organization (i.e., damage to reputation); and the

magnitude of damage that must be corrected.

An expression of the criticality/sensitivity of an information system in

Levels of Concern

the areas of confidentiality, integrity, availability, and exposure as

expressed qualitatively as high, moderate, or low.

Local Area Network

A LAN connects workstations and personal computers that span a

(LAN)

relatively small area, such as a single building or complex.

A command procedure stored on the laptop with a set of commands for

logging into another computer or computer network.

Potential for limited impact on an Agency or program mission or

Low Risk

efficiency of the service.

An application that requires special attention to security due to the risk

and magnitude of the harm resulting from the loss, misuse, or

unauthorized access to or modification of the information in the

application. A breach in a major application might comprise many

Major Application (MA)

individual application programs and hardware, software, and

telecommunications components. Major applications can be either a

major software application or a combination of hardware/software

where the only purpose of the system is to support a specific mission-

related function.

Medium Access Control

At the lowest level, computers communicate with each other using this

(MAC) Address

hardware address.

An operation system and its resource components that are required for

Mission Critical

an OCIO-ITS site to successfully function

Misuse

Unauthorized use of any OCIO-ITS Asset by any individual.

Potential for moderate to serious impact on an OCIO-ITS or program

Moderate-Risk

mission or efficiency of the service.

A part of the U.S. Department of Commerce, formerly called the

National Institute of

National Bureau of Standards, NIST promotes and maintains

Standards and Technology

measurement standards. It also has active programs for encouraging

(NIST)

and assisting industry and science to develop and use these standards.

Information that has been determined pursuant to Executive Order

National Security

12958 or any predecessor order, or by the Atomic Energy Act of 1954,

Information

as amended, to require protection against unauthorized disclosure and is

marked to indicate its classified status.

Those positions involving activities of the Government that are

concerned with the protection of the nation from foreign aggression or

National Security Position

espionage, including development of defense plans or policies,

intelligence or counterintelligence activities, and related activities

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 101

Number 3602-001

FOR OFFICIAL USE ONLY

TERM

DEFINITION

concerned with the preservation of the military strength of the United

States; positions that require regular use of, or access to, classified

information.

Any information system (including any telecommunications system)

used or operated by the OCIO-ITS or by a contractor of the OCIO-ITS,

or other organization on behalf of the OCIO-ITS - 1) the function,

operation, or use of which: involves intelligence activities; involves

cryptologic activities related to national security; involves command

and control of military forces; involves equipment that is an integral

part of a weapon or weapons system; or is critical to the direct

National Security System

fulfillment of military or intelligence missions, excluding a system that

is to be used for routine administrative and business applications, for

format, payroll, finance, logistics, and personnel management

applications; or, 2) is protected at all times by procedures established

for information that have been specifically authorized under criteria

established by an Executive Order or an Act of Congress to be kept

classified in the interest of national defense or foreign policy.

The necessity for access to, knowledge of, or possession of classified or

other sensitive information in order to carry out officially sanctioned

duties. Responsibility for determining whether a person’s duties require

possession or access to this information rests upon the individual having

Need-to-Know

current possession (or ownership) of the information involved, and not

on the prospective recipient. This principle is applicable whether the

prospective recipient is an individual, a contractor, another Federal

Agency or a foreign Government. (Source: USDA DM 3440-1).

A group of computers and associated peripheral devices connected by a

Network

communications channel capable of sharing files and other resources

among several users.

Network-based systems examine the individual packets flowing through

a network. Unlike firewalls, which typically look primarily at IP

Network-Based IDS

addresses and ports, network-based intrusion detection systems are able

to understand all the different flags and options that can exist with a

network packet.

Assurance that the sender of information is provided with proof of

delivery and the recipient is provided with proof of the sender’s

Non-Repudiation

identity, so neither can later legitimately deny having processed, stored,

or transmitted the information.

Potential for limited damage to the national security (Damage to

Non-Sensitive

national security defines National Defense Confidential information).

The OEP provides the response procedures for occupants of a facility in

the event of a situation posing a potential threat to the health and safety

Occupant Emergency Plan

of personnel, the environment, or property. Such events would include

(OEP)

a fire, hurricane, criminal attack or medical emergency. General

Services Administration (GSA) owned facilities maintain plans based

on the GSA OEP template.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 102

Number 3602-001

FOR OFFICIAL USE ONLY

TERM

DEFINITION

Office of Chief

The USDA's OCIO supervises and coordinates the design, acquisition,

Information Officer

maintenance, use, and disposition of information and information

(OCIO)

technology (IT) by the OCIO-ITS.

The mission of the Office of Inspector General is to investigate

Office of Inspector

allegations of crime against the department’s programs, and to promote

General (OIG)

the economy and efficiency of it operations, with the object of helping

to protect its programs and to ensure integrity.

Security methods that focus on mechanisms that primarily are

Operational Controls

implemented and executed by people as opposed to systems.

A unique, secret, string of alphanumeric characters selected by each

user that is associated with a particular UserID. The password’s

Password

primary function is to protect the UserID from unauthorized use. A

non-display mode is used when the password is entered to prevent

disclosure to others.

A small mobile hand-held device that provides computing and

Personal Digital Assistant

information storage and retrieval capabilities. PDA devices offer

(PDA)

applications such as office productivity, database applications, address

books, schedulers, and to-do lists.

Physical security refers to the protection of building sites and equipment

(and all information and software contained therein) from theft,

Physical Security

vandalism, natural disaster, manmade catastrophes and accidental

damage.

Any electronic device that is capable of receiving, storing, or

Portable Electronic Device

transmitting information using any format (i.e., radio, infrared, network

(PED)

or similar connections) without permanent connections to Federal

networks.

The location where an employee would work absent a Telework

Primary Worksite

arrangement. Also known as a traditional worksite or official duty

station.

Any item, collection, or grouping of information about an individual

that is maintained by an Agency, including, but not limited to, his

education, financial transactions, medical history, and criminal or

Privacy Information

employment history and that contains his name, or the identifying

number, symbol, or other identifying particular assigned to the

individual, such as a finger or voice print or a photograph.

Data which is accessible to all identified and authenticated public users

Public Data

of OCIO-ITS information resources, i.e., customers that use or store

information on OCIO-ITS data resources.

The ability to access OCIO-ITS information and systems from a remote

Remote Access

location, across an external telecommunications service.

A combination of: 1) the likelihood that a particular vulnerability in an

Risk

information system will be either intentionally or unintentionally

exploited by a particular threat resulting in a loss of confidentiality,

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 103

Number 3602-001

FOR OFFICIAL USE ONLY

TERM

DEFINITION

integrity, or availability; and 2) the potential impact or magnitude of

harm that a loss of confidentiality, integrity, or availability will have on

operations (including mission, functions, image, or reputation), assets,

or individuals (including privacy) should the exploitation occur.

A process that includes defining and valuing the assets, defining the

threats to those assets, determining the system’s vulnerabilities, and

Risk Assessment

recommending reasonable safeguards to reduce risks to acceptable

levels.

The ongoing process of identifying, controlling, and mitigating risks to

OCIO-ITS operations (including mission, functions, image, or

reputation), assets, or individuals resulting from the operation of an

Risk Management

information system or multiple information systems. It includes: risk

assessment, cost benefit analysis, and the selection, implementation,

testing and evaluation of security controls.

Rules that have been established and implemented concerning the use

of, security in, and acceptable level of risk for the system. Rules will

clearly delineate responsibilities and expected behavior of all

individuals with access to the system. Rules should cover such matters

Rules of Behavior

as work at home, dial-in access, connection to the internet, use of

copyrighted works, unofficial use of Federal Government equipment,

the assignment and limitation of system privileges, and individual

accountability.

Safeguards

Synonymous with security controls and countermeasures.

A screen engaged by an operating system to prevent screen burns or

Screen Saver

discoloring. Screen savers can be configured to start after a specific

period of time and to also be password protected.

Secure Compartmented

A facility where Sensitive Compartmented Information (SCI) may be

Information Facility

stored, used, discussed, and/or processed is called a Sensitive

(SCIF)

Compartmented Information Facility or SCIF.

The official management decision to authorize operation of an

information system. This authorization, given by a senior OCIO-ITS

official, is applicable to a particular environment of operation, and

Security Accreditation

explicitly accepts the level of risk to operations (including mission,

functions, image, or reputation), assets, or individuals, remaining after

the implementation of an agreed upon set of security controls.

A formal analysis conducted by the Agency Information Systems

Security Program Manager in conjunction with the business owner or

Security Analysis

developer, for the purpose of determining the importance of

information, assessing risks, formulating mitigation strategies, and other

measures needed to safeguard the IT investment.

The automatic logging of successful and unsuccessful access events

Security Audit Logs

including login/logoff, resource access, execution of security

commands, and changes to security tables.

Security Certification

A comprehensive evaluation of the management, operational, and

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 104

Number 3602-001

FOR OFFICIAL USE ONLY

TERM

DEFINITION

technical security controls in an information system. This evaluation,

made in support of the security accreditation process, determines the

effectiveness of these security controls in a particular environment of

operation and the remaining vulnerabilities in the information system

after the implementation of such controls.

The management, operational, and technical controls (safeguards or

countermeasures) prescribed for an information system which, taken

Security Controls

together, satisfy the specified security requirements and adequately

protect the confidentiality, integrity, and availability of the system and

its information.

The Security Plan documents all security-related activities. In the pre-

operation phases of the SDLC, the Security Plan needs to list actions to

ensure that the system is developed in a reasonably secure environment

and that it contains sufficient and appropriate security features. It

defines the security requirements and provides the systematic

Security Plan

management plans to meet those requirements. During the system’s

operation phase, the Security Plan becomes the document for

responding to new vulnerabilities and threats as well as serving as the

primary basis for management reports. It must be updated as least

annually, but may be updated more often prior to the system’s

operational phase.

A document outlining acceptable and unacceptable requirement and

Security Policy

practices directed and with the intent to provide IT security.

Information that is not as critical as Classified Information, the need to

Sensitive But Unclassified

protect this data has been recognized by the administration, law and the

(SBU)

Institute of Standards and Technology .

Information for which unauthorized access to, or the loss or misuse of,

which would adversely affect the national interest or the conduct of

Federal programs, or the privacy to which individuals are entitled under

5 U.S.C. Section 552a (the Privacy Act), but that has not been

specifically authorized under criteria established by an Executive Order

or an Act of Congress to be kept classified in the interest of national

Sensitive Security

defense or foreign policy. Systems that are not national security

Information (SSI)

systems, but contain sensitive information, are to be protected in

accordance with the requirements of the Computer Security Act of 1987

(P.L.

100-235). Some specific categories of sensitive information are

protected by statute, regulation or contract, (i.e., privacy information,

proprietary information, export control information, pre-publication

academic information).

A class of modules that provide automated detection and response to

threats. These modules are installed at strategic locations throughout

Sensors/Taps

the enterprise network and include network sensors, server sensors and

operating system sensors.

A computer or device on a network that manages and hosts network

Server

resources.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 105

Number 3602-001

FOR OFFICIAL USE ONLY

TERM

DEFINITION

These Agencies, which include FSA, NRCS, and RD, are currently

Service Center Agency

operating in partnership to accomplish a USDA modernization initiative

(SCA)

that establishes a common information technology infrastructure.

Handheld smart cards with embedded microprocessor chips containing

authentication data and verified by a corresponding card reader (i.e.,

PCMCIA slot in a notebook computer) may be used for remote user

authentication, only if used with a secondary (two factor) authentication

Smart Cards

mechanism. Acceptable secondary authentication mechanisms include:

remembered PIN code or Biometric (i.e., signature verification,

fingerprint reader) authentication. PIN codes must not be stored in

close proximity to the smart card and must not be marked on the token.

Simultaneous direct access to a non-USDA network (such as the

Split Tunneling

Internet or a home network) from a remote device while connected into

the OCIO-ITS network via a VPN tunnel.

The OCIO-ITS organization that requested that the third party have

Sponsoring Organization

access into the OCIO-ITS network.

A major subdivision or component of an information system consisting

Subsystem

of hardware, software, or firmware that performs a specific function.

A collection of hardware, software, major application, operating system,

System

and firmware integrated together to perform one or more functions.

The process for creating and implementing information technology-

based system software and hardware inclusive of application code,

System Development

middleware, operating systems, networks, firewalls, routers, switches,

personal computers, servers, mainframe computers, etc., within the

OCIO-ITS.

A contingency planning guide for Information Technology systems. It

is the scope of activities associated with a system, encompassing the

system’s initiation, development and acquisition, implementation,

operation and maintenance, and ultimately its disposal that instigates

System Development Life

another system initiation. The phases through which software evolves

Cycle (SDLC)

from an idea to implementation include the Initiation Phase,

Development Phase, Certification and Accreditation Phase,

Implementation Phase, Operation and Maintenance Phase, and the

Disposal Phase. These phases may vary depending on the complexity

of the system being developed.

The primary liaison for a designated information system within the IT

community. This person is responsible for all information technology-

System Owner

related activities including security. Additionally, this official

represents the interests of the user community throughout the life cycle

of the information system.

A set of requirements that are used to delegate how system security will

be managed. This plan includes system identification, management

Security Plan (SP)

controls, operational controls, and technical controls. The Security Plan

outlines responsibilities for all system users and describes the rules of

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 106

Number 3602-001

FOR OFFICIAL USE ONLY

TERM

DEFINITION

behavior for those users.

Hardware and software controls used to provide automated protection to

Technical Controls

the system or applications. Technical controls operate within the

technical system and applications.

A customized arrangement that allows an employee to work away from

the traditional worksite or official duty station in either 1) his/her home,

2) a Telework center, such as those established by the General Services

Administration (GSA) or, 3) a virtual or mobile office setting. The

Telework

work site is not to be considered a barrier to an employee’s ability to

perform such obligations as official travel, attending face-to-face

meetings and communication with colleagues and customers. Telework

addresses the location of the work site as opposed to the work schedule.

A written agreement completed and signed by an employee and

Telework Agreement

appropriate official(s), that outlines the terms and conditions of the

Telework arrangement.

An employee who, with the approval of his/her supervisor, works full,

part-time at locations, or work sites other than the primary worksite.

Telework Participant

This does not include employees who only work remotely while in

official travel status.

Any circumstance or event with the potential to intentionally or

Threat

unintentionally exploit a specific vulnerability in an information system

resulting in a loss of confidentiality, integrity, or availability.

Triple DES

A key that consist of three DES keys, also referred to as a key bundle.

A Trojan horse is a command procedure containing hidden code that,

Trojan Horse

when invoked, performs some unwanted function. A virus can infect a

legitimate program and transform it into a Trojan horse.

A document listing required security standards and settings, including

implemented setting and standards. The TFM cautions about the

Trusted Facilities Manual

functions and privileges that should be controlled when running a

(TFM)

secure facility and procedures for examining and maintaining audit

trails including the audit trail record structure.

In networking, a gateway is a combination of hardware and software

that links two different types of networks. A secure gateway or firewall

Trusted Network Gateway

blocks or filters access between two networks, often between an internal

trusted network and an external un-trusted (public) network such as the

Internet.

All Federal Employees, Contractors, and volunteers, Permanent or

User

Temporary, which access OCIO-ITS information resources and network

resources.

The authorization code used to identify OCIO-ITS users who are

UserID

entitled to access OCIO-ITS computer resources.

The process of evaluating software at the end of the software

Validation

development process to ensure compliance with software requirements.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 107

Number 3602-001

FOR OFFICIAL USE ONLY

TERM

DEFINITION

The process used by an independent certification agent to confirm or

Verification

establish by testing, evaluation, examination, investigation or competent

evidence.

A technology by which authorized individuals (such as remote

employees) can gain secure access to an organization’s intranet via the

Internet. VPN technology provides secure data transmission across

Virtual Private Network

public network infrastructures. VPNs employ cryptographic techniques

(VPN)

to protect information as it passes from one network to the next or from

one location to the next. Data that is inside the VPN tunnel, the

encapsulation of one protocol packet inside another, is encrypted and

isolated from other network traffic.

A program that searches out other programs and infects them by

embedding a copy of itself within the other programs. When the other

Virus

programs are executed, the embedded virus is executed, thus spreading

the infection.

A condition or weakness in security procedures, technical, management

Vulnerability

or physical controls that could be exploited by a threat.

A test of the network’s or system’s vulnerability to known exploits and

Vulnerability Scan

attack methods, by either passive (non-intrusive) or active (intrusive)

scanning of network points of access.

A formal approval to not comply with a security policy or exemption

Waiver

from a security policy.

A web farm is an integrated collection of firewalls, switches, servers,

back-up libraries and other components that are precisely focused to

Web Farm

develop and maintain a secure, scalable and redundant web delivery

infrastructure.

Any digital communication protocol or process that does not require a

Wireless Access

physical connection media. This includes but not limited to all 802.11

a/b/g or infer-red access devices or point-to-point devices.

A transport mechanism that supports communication between mobile,

Wireless Technology

portable, or fixed facilities using the electromagnetic spectrum without

a physical connection.

A self-replicating program that is self-contained and does not require a

host program. It is designed to propagate through a network rather than

Worm

just a single computer. A worm exploits flaws in operating systems or

inadequate system configurations. Release of a worm usually results in

brief, but spectacular, outbreaks that can shut down entire networks.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 108

Number 3602-001

FOR OFFICIAL USE ONLY

Appendix C: OCIO-ITS Security Waiver Form

OCIO-ITS Security Waiver Form

Requests for exceptions to these waiver requirements will include a persuasive and cogent justification.

The waiver package will include the following:

An explanation of exception requested.

• Identify which policy and item(s) the exception covers and provide information detailing the

exemption requested. Explain why the policy cannot be implemented.

Business case necessitating the service.

• How will the lack of this exemption impact program delivery?

Is sensitive (SBU) information involved?

• Details explaining how the confidentiality, integrity and availability of the sensitive information

will be preserved.

• Since this exemption may increase the vulnerabilities to the system/application, how will the

information be safeguarded?

Technical details of the proposed alternative approach.

• Explain the technical solution. Include diagrams that show the current condition and what the

proposed alternative approach will look like (before and after). If this is provided electronically,

use Visio or a similar type of software.

Associated security costs for the Agency requested solution funded by the proposing Agency (Include

a copy of any IT Moratorium Waiver Request and associated hardware and software costs not

covered in waiver)

• How much is this going to cost? How does this compare to the cost of implementing the policy?

Risk analysis of the proposed alternative approach.

• Since this exemption may increase the vulnerabilities to the system/application, a risk assessment

needs to accompany this request. What are some of the current exploits of these vulnerabilities

identified in risk analysis and how are these addressed by the proposed solution?

Assurances that any alternatives implemented will not adversely affect the costs, security,

maintenance or operations of existing solutions implemented by other Departmental entities.

• Who else is potentially at risk and are they aware of the risk?

A schedule and tasks to be undertaken to become compliant.

• When do you plan to become compliant with OCIO-ITS policy? Provide an action plan and

appropriate milestones. Typically the plan should run no more than a year. Waivers for longer

than 12 months will be re-evaluated periodically.

NOTE: Any alternatives implemented will be subject to periodic reviews and must be adjusted, as

necessary, to conform to the USDA Enterprise Architecture and Security standards. Waiver packages

will be forwarded to the ITS Information Systems Security Program Manager (ISSPM) in accordance

with normal procedures. These packages will be forwarded to OCIO Cyber Security for review and

further action. Additionally, all waiver packages are subject to review by the OIG and other audit bodies.

OCIO-ITS Security Policy Manual - FINAL - Version 1.0

Page 109

Number 3602-001

FOR OFFICIAL USE ONLY

DEPARTMENT OF THE NAVY

Headquarters United States Marine Corps

Washington, D.C. 20380-1775

13 October 2010

FOREWORD

Marine Corps Warfighting Publication (MCWP) 4-11.9, Ammunition Logistics, provides

guidance for commanders, staffs, logisticians, ammunition and aviation ordnance

officers, supply officers, and ammunition and aviation ordnance Marines. This

publication discusses the Marine Corps ammunition and aviation ordnance communities’

organization and support structure, the general responsibilities of ammunition and

aviation ordnance personnel, the systems used in support of ammunition logistics,

planning considerations, safety issues, training, and the regulatory environment in which

Marine Corps ammunition logistic operations are planned and executed. Various

elements of Navy supporting establishments with ammunition responsibilities that have

not been addressed in other USMC Service doctrine are introduced in the MCWP 4-11.9.

This publication’s purpose is to extend the concepts established by Marine Corps

Doctrinal Publication 4, Logistics; MCWP 4-1, Logistics Operations; MCWP 4-11, Tac-

tical Level Logistics; MCWP 4-11.7, MAGTF Supply Operations; MCWP 3-21.2,

Aviation Logistics; and Field Manual 4-30.1, Munitions Support in the Theater of

Operations, as they apply to ammunition operations for the operating forces. This

publication describes Marine Corps ammunition and aviation ordnance logistic operations

in both garrison and expeditionary environments. Applicable tactics, techniques and

procedures from other Service manuals have been incorporated. The overall intent is to

provide a single-source, informative reference for Marine Corps ammunition logistics.

In order to reach the widest possible audience, this publication will address ammunition

as a general use commodity, only distinguishing between subclass V(W) ground

ammunition and subclass V(A) aviation ordnance where it is absolutely necessary. In

general, wherever the terms ammunition, munitions, or ordnance appears in this

document it should be construed as both ground ammunition and aviation ordnance,

unless one term or the other is specifically applicable to the subject.

FOR OFFICIAL USE ONLY

AMMUNITION LOGISTICS

TABLE OF CONTENTS

Chapter 1: Overview

Strategic, Operational, and Tactical Logistics

1-1

Strategic Logistics

1-1

Operational Logistics

1-2

Tactical Logistics

1-2

DOD Munitions Requirements Process

1-2

Implementation of the Munitions Requirements Process

1-3

Roles and Responsibilities

1-3

Chief of Naval Operations Responsibilities

1-3

Navy Organizational Responsibilities

1-3

Deputy Commandant for Installations and Logistics

1-3

Deputy Commandant for Aviation

1-4

Commanding General, Marine Corps

Combat Development Command

1-4

Commanding General, Training and Education Command

1-4

Commander, Marine Corps Systems Command

1-4

Deputy Chief of Naval Operations for

Fleet Readiness and Logistics

1-4

The Naval Operational Logistics Support Center

1-4

Service Requirements Determination

1-4

War Reserve Munitions Requirement

1-6

Training and Testing Requirement

1-6

Universal Need Statement

1-6

Class V(A) Requirements Determination

1-6

Resourcing

1-7

Class V Acquisition

1-7

Acquisition of Marine Corps Ground Ammunition

1-7

Acquisition of Navy Munitions

1-7

Quality Evaluation

1-7

Care of Supplies in Storage

1-8

Class V(W) Maintenance

1-8

Disposal

1-9

The Marine Corps Combat Logistics Organization

1-9

Marine Logistics Group

1-9

Marine Aviation Logistics Squadron

1-10

Chapter 2: General Class V Management

Logistic Operational Architecture

2-1

Request Management

2-1

Order Management

2-1

FOR OFFICIAL USE ONLY

_____________________________________________________________________________________________________

MCWP 4-11.9

Capacity Management

2-1

Production Management

2-1

Execution

2-2

Ordnance Information System

2-2

The Marine Corps and Ordnance Information System

2-2

Marine Corps Class V Inventory Management Systems

2-2

Navy Class V Inventory Management Systems

2-2

Future Capabilities

2-2

Munition Inventory and Transaction Reporting

2-3

Asset Visibility and Accountability

2-3

Malfunction Reporting

2-3

Supply Discrepancy Report

2-3

Missing, Lost, Stolen, or Recovered

2-3

Automatic Identification Technologies

2-4

Chapter 3: Operational Ammunition Requirements Determination

Ground Ammunition

3-1

Aviation Ordnance

3-1

Modeling/Deliberate Planning for Major

Operations and Campaigns

3-1

Execution of a Deliberate Plan

3-2

Crisis Action/Contingency Planning

and Immediate Requirements Determination

3-2

Transition of Class V(W) Combat Planning Factors

3-2

Operational Requirements in a Joint Environment

3-2

Expressing Capabilities and Requirements for Class V(W)

3-3

Combat Load

3-3

Day of Ammunition

3-3

Combat Load Versus Day(s) of Ammunition

3-4

Chapter 4: Class V Movement Planning

Planning for Class V Combat Logistic Support

4-1

Special Consideration During Movement Planning

4-2

The Global Command and Control System

4-2

Joint Operation Planning and Execution System

4-2

The Global Combat Support System-Joint

4-2

Joint Force Requirements Generator II

4-2

Logistics Automated Information

Systems and Aviation Logistics

4-3

Class V Sourcing

4-3

War Reserve Positioning

4-3

Class V(W) Sourcing

4-3

Class V(A) Sourcing

4-4

Transportation Planning

4-4

FOR OFFICIAL USE ONLY

Ammunition Logistics^{____________________________________________________________________________________________} v

Time-Phased Force and Deployment Data

4-4

Validation

4-6

Reports

4-6

Flow Initiation Class V(W)

4-6

Planned Class V Sustainment Flow Notification

4-7

Chapter 5: Movement, Mobility, and Deployment of Class V Materiel

Transportation Funding

5-1

Transportation and Asset Tracking

5-1

Organizations Supporting Movement of Class V

5-2

United States Transportation Command

5-2

Air Mobility Command

5-2

Military Sealift Command

5-2

Prepositioning Ships

5-2

Sealift Ships

5-2

Military Surface Deployment and Distribution Command

5-2

Joint Munitions Command

5-3

Joint Munitions Transportation Coordinating Activity

5-3

Naval Operational Logistics Support Center

5-3

Modes of Shipment

5-3

Airlift

5-4

Strategic Airlift

5-4

Channel Lift

5-4

Ship Movement

5-4

Surface Movement

5-4

Strategic Ammunition Ports

5-4

Military Ocean Terminal, Sunny Point

5-4

Military Ocean Terminal, Concord

5-4

Navy Munitions Command, Detachment Indian Island

5-4

Additional Ammunitions Ports (Nonstrategic)

5-5

Navy Munitions Command, Detachment Charleston

5-5

Navy Munitions Command, Detachment Earle

5-5

Blount Island Terminal, Jacksonville

5-5

Chapter 6: Ammunition/Aviation Ordnance Operations

Reception and Staging

6-1

Naval Expeditionary Logistics Support Force

6-1

Navy Cargo Handling Battalion

6-1

Naval Ordnance Reporting and Handling Battalion

6-1

Port and Terminal Operations

6-1

Operational Safety Concerns

6-2

Onward Movement and Integration

6-2

Movement

6-2

Combat Logistic Support During Amphibious Operations

6-3

FOR OFFICIAL USE ONLY

_____________________________________________________________________________________________________

MCWP 4-11.9

Storage

6-3

Aviation Ground Support

6-5

Aviation Logistic Support

6-6

Forward Arming and Refueling Points

6-6

Security

6-6

Distribution

6-7

Distribution Methods

6-8

Distribution Method Considerations

6-8

The Munitions Report

6-8

Sustainment and Resupply

6-8

Class V Resupply

6-8

Theater-Level Class V General Support

6-9

Class V(A) Sustainment

6-9

Sustainment Planning

6-9

Supply Rates

6-9

Class V External Support

6-9

Common Item Support

6-9

Cross-Service Support

6-11

Common Item Support Versus Cross-Leveling

6-11

Class V(A) and Common Item Support

6-11

Chapter 7: Retrograde Operations

General Retrograde Planning

7-1

Operational Safety

7-2

Condition of Munitions

7-2

Functional Considerations

7-2

Retrograde Operations

7-3

Visibility and Accountability

7-3

Segregation and Inspection

7-3

Packaging and Packing Materials

7-4

Unserviceable Munitions

7-4

Other Considerations

7-4

Safety

7-4

Destruction of Ammunition

7-4

Routine Destruction

7-4

Emergency Destruction

7-5

Ammunition Maintenance

7-5

Physical Security

7-6

Transportation and Storage

7-6

Ammunition Supply Points

7-7

Retrograde Turn In

7-7

Chapter 8: Class V for the Marine Expeditionary Unit

The MEU as Part of an Expeditionary Strike Group

8-1

Landing Force Supplies

8-1

Combat Load

8-1

FOR OFFICIAL USE ONLY

CHAPTER 1

OVERVIEW

Class V ammunition is a complex commodity in

end item, it is funded and procured through a

terms of research and development, acquisition,

complex cycle of processes managed at the Ser-

life cycle management, and, eventually, disposal.

vice headquarters level.

The Department of Defense (DOD) spends bil-

lions of dollars annually to develop and acquire

new munitions and to replenish stocks expended

STRATEGIC, OPERATIONAL,

in training and operational use. Therefore, the

AND TACTICAL LOGISTICS

business of ammunition, supply Class V, is a com-

plex and highly interrelated venture composed of

Strategic, operational, and tactical logistics are

planning, requirements determination, resourcing,

the supporting triad that enables commanders to

acquisition, storage, maintenance, quality eval-

execute modern expeditionary warfare. Opera-

uation, multimodal transportation, movement and

tional logistics is the bridge between organic

retrograde planning and execution, explosives

capabilities that serve tactical requirements and

safety, disposal, and, most importantly, sustain-

strategic or national capabilities. Tactical logis-

ment of the operating forces whether in garrison

tics includes organic unit capabilities and the

or deployed.

combat service support that is necessary to sup-

port military operations. Combat service support

Ground ammunition and aviation ordnance are

is executed in the form of general and direct sup-

two of the most complex commodities used by

port obligations.

the operating forces to sustain combat, contin-

gency, and training operations. Although funda-

Strategic Logistics

mentally a supply commodity, Class V materiel

Strategic logistic capabilities are generated based

has a number of management attributes that do

on guidance from the President and/or Secretary

not apply to general supplies and requires

of Defense, the Joint Chiefs of Staff, and logistic

specialized storage, handling, transportation, and

requirements that are identified by the operating

inventory control methods.

forces. Upon receipt of an execution, the Service

Like fuel or food, ammunition is a consumable

components will execute Class V sourcing to

item; however, ammunition is often character-

meet the combatant commanders (CCDRs)/joint

ized by variable rates of consumption. Thus, it

force commanders (JFCs) requirements and move

the materiel into theater and areas of operations.

must be replenished from time to time, to ensure

sufficient stocks are available on short notice in

Therefore, the Service component commander

the event of a contingency. In addition, unlike

must rely on force-held stocks for initial accom-

most consumables, Class V materiels cannot be

panying supplies. The commander is then

procured on the open market. Like principal end

dependent on the respective Navy or Marine

items such as tanks or the expeditionary fighting

Corps inventory control point (ICP) to provide

vehicle, Class V materiel is characterized by

the balance of identified requirements. The

long lead times for production; in most cases,

Defense Logistics Agency is a significant agent

upwards of several years. Also like a principal

in supplying deployed forces with many of the

FOR OFFICIAL USE ONLY

1-2 ^{____________________________________________________________________________________________________}MCWP 4-11.9

commodities and parts that are required. However,

Tactical Logistics

Defense Logistics Agency has no Class V

responsibilities or capabilities.

Class V is delivered to tactical level combat sup-

port agencies during the integration phase of the

Operational Logistics

RSOI process. Tactical logistics includes organic

capabilities and the combat support activities that

Operational logistics connects the logistic efforts

are necessary to support military operations.

of the strategic level with those of the tactical

level. The reception, staging, onward movement,

and integration (RSOI) process is the operational

DOD MUNITIONS

level activity that brings strategically delivered

REQUIREMENTS PROCESS

ammunition through the ports and to the tactical

level combat logistic agencies. The RSOI

process involves identification of containers, the

Each Military Service is required to identify a

major subordinate command, and the cargo’s

total munitions requirement (TMR) to arm their

intended destination.

weapon systems and forces to perform their

assigned military mission. The steps and

Class V material will often be delivered to

procedures for doing so are depicted in figure 1-1

multiple locations, which is determined by

and are described in DOD Instruction (DODI)

Service component and the type of activity being

3000.4, DOD Munitions Requirements Process

supported. Great care must be taken when

(DOD MRP).

storing ammunition before the local storage sites

are prepared.

Combat Requirement

Total Munitions

War Reserve Munitions

Phased Threat

Requirement

Distribution

Training and Testing

Strategic Readiness

Requirement

Program

Requirement

Development

Current Operation/

Forward Presence

Projected

Requirement

Inventory

Figure 1-1. Munitions Requirements Process.

FOR OFFICIAL USE ONLY

Ammunition Logistics^{__________________________________________________________________________________________} 1-3

Chief of Naval Operations Responsibilities

IMPLEMENTATION OF THE

MUNITIONS REQUIREMENTS PROCESS

The CNO provides Service headquarters-level

munitions management support to the operating

Marine Corps Order (MCO) 8000.7, Marine

forces. In concert with the Marine Corps’ Deputy

Corps Capabilities-Based Munitions

Commandant (DC) for Aviation, they collectively:

Requirements (MCCBMR) Process for Ground

Coordinate with MARFOR, CINCs

[Navy

Ammunition (Class V[W]),provides a full

Commander in Chiefs] , and other major

explanation of the munitions requirements pro-

cess

(MRP) and the Marine Corps’

claimants to obtain accurate input to the

implementation of this process for Class V(W).

NNOR and to ensure training and testing

The Navy implements MRP through the

requirements (TTRs) are submitted.

nonnuclear ordnance requirement (NNOR) pro-

Provide ordnance logistic guidance and policy

cess described in the current editions of Office of

during the deliberate planning process.

the Chief of Naval Operations Instruction

Pass TTR inputs to the Naval Operational

(OPNAVINST) 8011.9A, Non-Nuclear

Logistics Support Center (NOLSC) and

Ordnance Requirements (NNOR) Process, and

resource sponsors for development of the CNO-

OPNAVINST 8010.12F, Naval Conventional

and CMC-approved noncombat expenditure

Ordnance Operational Logistics Policy.

allocation.

Approve and promulgate annual noncombat

expenditure allocation to the numbered fleet

ROLES AND RESPONSIBILITIES

commanders, MARFOR, and other major

claimants for further distribution to the naval

Responsibilities and capabilities for munitions

forces.

management overlap because no organization or

Resolve Class V(A) materiel shortfalls identified

level of support can function effectively without

during the deliberate planning process.

extensive coordination between supported and

supporting organizations. Responsibility for

Class V(W) ammunition within the Marine Corps

Navy Organizational Responsibilities

rests with multiple departments within Headquar-

ters, Marine Corps (HQMC), Marine Corps Com-

Since Class V(A) aviation ordnance material used

bat Development Command (MCCDC), Training

by the Marine Corps is procured and managed by

and Education Command (TECOM), Marine

the Navy, the CNO and CMC headquarters staffs

Corps Systems Command (MARCORSYSCOM),

jointly have specific responsibilities for overall

and the Marine Corps forces (MARFOR).

naval ordnance management.

Class V(A) aviation ordnance material used by

Deputy Commandant for

the Marine Corps is procured and managed by the

Installations and Logistics

Navy, Chief of Naval Operations (CNO) and

Commandant of the Marine Corps (CMC) head-

The DC for Installations and Logistics establishes

quarters staffs. Each staff has specific responsi-

logistic and materiel management policies for all

bilities that collectively manage naval ordnance.

Marine Corps-owned equipment and supplies.

Operational requirements are principally the

With few exceptions, these policies are applicable

domain of the operating forces and are discussed

to all classes of supply managed by the Marine

in detail in chapter 4. Details on Class V support

Corps, including Class V(W) ground ammunition.

under unified action can be found in appendix A.

FOR OFFICIAL USE ONLY

1-4 ^{____________________________________________________________________________________________________}MCWP 4-11.9

Deputy Commandant for Aviation

testing, and ammunition assets undergoing

maintenance or renovation.

The DC for Aviation assists the Deputy CNO for

Fleet Readiness and Logistics (N4) in esta-

Deputy Chief of Naval

blishing acquisition and fielding policies for

Operations for Fleet Readiness and Logistics

aviation ordnance materiel used by Marine avia-

Class V(A) logistic and materiel management

tion organizations.

policies for munitions used by Marine aviation

are separately prescribed by the Deputy Chief of

Commanding General, Marine

Naval Operations for Fleet Readiness and

Corps Combat Development Command

Logistics (N4) and implemented through the

The Commanding General (CG), MCCDC is

Commander, Naval Supply Systems Command

(NAVSUPSYSCOM).

responsible for establishing the Class V(W) TMR

and publishing planning factors for combat and

The Naval Operational

contingencies. The CG, MCCDC is also the DC

Logistics Support Center

for Combat Development and Integration.

The NOLSC will provide ICP-level management

Commanding General,

for naval ammunition, serving as the

Training and Education Command

NAVSUPSYSCOM operational and joint force to

the Navy component commanders and to the

The CG, TECOM determines training require-

unified commanders.

ments and provides Class V(W) materiel allow-

ances for all Marine Corps training requirements.

SERVICE

Commander, Marine

REQUIREMENTS DETERMINATION

Corps Systems Command

The Commander, MARCORSYSCOM is

Determination of Service-wide ammunition

responsible for research, development, and

requirements is a complex task, and it is the

acquisition of Marine Corps systems, equipment,

responsibility of a multitude of agencies identi-

and materiel. The Program Manager for Ammu-

fied in figure 1-2.

nition (PM Ammo) performs these functions for

the commander with respect to Class V(W). The

In the 1990s, following Operations Desert

PM Ammo is a unique organization within the

Shield/Desert Storm, it became apparent that a

Marine Corps and within DOD. The organization

more sophisticated process was required for

performs or manages all life cycle tasks

determining the Services’ ammunition require-

associated with Marine Corps ground ammu-

ments. This complex analysis provides a greater

nition. Among these responsibilities is providing

role for the CCDRs/JFCs and the Service com-

worldwide ICP services for the Marine Corps.

ponents of the operating forces, and one that

This includes ammunition stocks held as war

begins much earlier in the process. This process

reserve, stocks procured or held for training and

is the MRP. The product of the MRP is a TMR.

FOR OFFICIAL USE ONLY

Ammunition Logistics^{__________________________________________________________________________________________} 1-5

OSD (AT&L)

OSD (P)

DIA

COCOMs

POM MRP

Kickoff

Implementation

Threat Reports

Near-Year PTDs

Out-Year PTDs

Conference

Guidance

OCT

NOV

FEB

JUN

JUL

MARFORs

MCSC

TFSD

Testing

TPFDDs

TFSMS Data

Requirements

MARFORs

MCSC

TECOM

QUANTICS

MCCDC

30 Sep

OPLAN

Inventory/

Training

Run USMC

Analyze/ Review

Submit Signed

Validation

Requirements

WRMR Model

Output Results

TMR

Deliveries

PP&O

FMID/PP&O

JTCG/ME

OCT - DEC

Warfighting-

SME Input

JMEMS Data

Capabilities

Validation

Requirements

JUN - SEP

MCCDC

CJCS/Services

Run USMC

Analyze/ Review

Submit Signed

WRMR Model

Output Results

TMR

FEB

SEP

CJCS

Chairman of the Joint Chiefs of Staff

DIA

Defense Intelligence Agency

FMID

Fires and Maneuvers Integration Division

JMEMS

Joint Munitions Effectiveness Manuals

JTCG/ME

Joint Technical Coordination Group for Munitions

MCCDC

Marine Corps Combat Development Command

MCSC

Marine Corps Systems Command

OPLAN

Operational Plan

OSD(AT&L)

Operational Services Division (Acquisition Technology and Operational)

OSD(P)

Office of Secretary of Defense Policy

POM

Program Objective Memorandum

PP&O

Plans, Policy, and Operations

PTD

Phased Threat Distribution

SME

Subject Matter Expert

TFSD

Total Force Structure Division

TFSMS

Total Force Structure Management System

WRMR

War Reserve Munitions Requirement

Figure 1-2. Munitions Requirements for Program Objectice Memorandum Cycle.

FOR OFFICIAL USE ONLY

1-6 ^{____________________________________________________________________________________________________}MCWP 4-11.9

The TMR for each Service is the sum of the war

Defense Program requirement, and/or projected

reserve materiel requirement (WRMR) and the

life cycle of each munition. Surveillance, accep-

TTR. The following paragraphs discuss the further

tance testing, and production losses of munitions

subdivision of these two main requirements.

items are accounted for in this category.

War Reserve Munitions Requirement

Universal Need Statement

The three components of the WRMR are the

During operational execution, requirements are

combat requirement, the strategic readiness

updated as needed or conditions change through

requirement, and the current operations/forward

the UNP [universal need process] .

presence requirement.

The component commander may initiate the

universal need statement (UNS) process at any

Combat Requirement

time. Through the chain of command, the UNS is

The combat requirement represents the quantity

ultimately presented to the CG MCCDC. If the

of munitions that are required in order to equip a

CG MCCDC validates the requirement, it is

specified force structure to perform its assigned

forwarded to the Marine Requirements Oversight

military mission and to meet CCDR/JFC objec-

Council (MROC). The MROC is a panel of

tives, including munitions needed for overlapped

senior officers headed by the Assistant Comman-

threat allocations.

dant of the Marine Corps; its members consist of

the DCs of all departments.

Strategic Readiness Requirement

If approved by the MROC, the DC for Program

The strategic readiness consists of the quantity of

and Resources provides fiscal resources, or may

munitions needed to arm forces that are not com-

direct the realignment of existing funds origi-

mitted to support combat operations in the

nally allocated for another program. The develop-

assigned major operations and campaigns, as

ment or procurement of the requested item is the

well as those in the strategic reserve. This also

responsibility of MARCORSYSCOM, along with

includes any additional munitions requirements

the total life cycle management of the material

generated from treaties or statutory obligations

solution to the operational requirement.

to allies.

For example, during Operations Iraqi Freedom

and Enduring Freedom there were a number of

Current Operations/Forward

instances where validated requirements (via the

Presence Requirement

appropriate chain of command) were provided to

The current operations/forward presence require-

PM Ammo, MARCORSYSCOM for immediate

ment represents the sum of munitions that are

sourcing, procurement, and delivery. These UNS

required to arm forces, conduct current opera-

included shoulder-launched multipurpose assault

tions, and meet forward presence obligations in

weapon rocket (with novel explosive [thermo

accordance with DODI 3000.4.

baric]), 5.56mm nonmolybdenum coated 77 grain

projectile, the surface demining flare, and the

Training and Testing Requirement

light assault weapon (rocket).

The TTR is the munitions required in order to

Class V(A) Requirements Determination

train the Marine Corps and support its Service

programs ensuring that weapons and platforms

The Navy and Marine Corps aviation component

deliver the intended effectiveness. This can be

of the MRP is the NNOR process. The NNOR

stated as an annual requirement, a Future Years

identifies ordnance ship fill, combat expenditures,

FOR OFFICIAL USE ONLY

Ammunition Logistics^{__________________________________________________________________________________________} 1-7

maintenance pipeline and training, testing,

ammunition items that are used by the Marine

current operations, and forward presence require-

Corps are common to the Army and/or other

ments to accomplish Navy and Marine Corps’

Services. For common items, Marine Corps funds

missions and to execute the scenarios outlined in

are transferred to PEO Ammo located at Picatinny

DODI 3000.4. The output of the NNOR provides

Arsenal, NJ, because one Service is responsible

the Department of the Navy’s (DON’s) baseline

for providing the acquisition support infrastructure

input into the DOD Planning, Programming, and

for two or more user Services. All Service-unique

Budgeting System.

munitions are procured through Navy Program

Managers or directly by PM Ammo.

Acquisition of Navy Munitions

RESOURCING

The Navy has a complex munitions acquisition

The DC for Programs and Resources develops

infrastructure that is built around the PEOs for

and manages the Marine Corps’ budget process,

various weapons platforms and combatants that

makes high-level investment decisions, and allo-

are currently in the operating forces. For the pur-

cates the funds appropriated by the Congress to

poses of this publication, the primary interest is

meet the Marine Corps’ mission needs. The DC

on the Class V(A) aviation ordnance procured by

for Programs and Resources also works closely

the Naval Air Systems Command affiliated PEOs

with the Navy counterpart to ensure that the Navy

for use by naval aviation.

and Marine Corps programs and priorities are

aligned to serve a common naval logistic inte-

Quality Evaluation

gration strategy for the operating forces and the

supporting establishment.

Quality evaluation (QE) is a broad, general term

applied to a set of inspections, functional testing,

and laboratory analysis of representative munition

lot samples taken from the inventory for the sole

CLASS V ACQUISITION

purpose of assessing the proper state of the

inventory. Quantity, exposure to environmental

Acquisition (or procurement) of munitions is a

elements during storage, age, malfunction history,

complex process, and it is collaboratively

and manufacturing variables are considered when

executed by acquisition professionals, graduates

selecting samples. Random sampling of available

of the Defense Acquisition University, and com-

lots provides a statistically sound method and

modity subject matter experts. These acquisition

repeatable results in determining reliability and

professionals and subject matter experts are

probabilities of future performance at a given

located with the various Navy/Marine Corps pro-

confidence level. From these determinations,

gram executive offices (PEOs) and program

inventory management decisions such as global

managers, such as Naval Sea Systems Com-

positioning, reclassification, and maintenance

mand, Naval Air Systems Command,

options can be implemented.

MARCORSYSCOM, and the Army’s Program

Executive Office, Ammunition (PEO Ammo).

In addition, quality audits of vendors/suppliers

are conducted that include the following:

Acquisition of Marine

Reviewing vendor/supplier’s quality system

Corps Ground Ammunition

procedures.

Acquisition of Marine Corps ground ammunition

Conducting on-site auditing of vendors and/or

is managed and executed by the PM Ammo,

suppliers.

MARCORSYSCOM. Most Class V(W) ground

Auditing and reviewing of maintenance lines.

FOR OFFICIAL USE ONLY

1-8 ^{____________________________________________________________________________________________________}MCWP 4-11.9

Participating in pre- and post-contract award

the care and maintenance of those stocks rests

and facility reviews.

with the owning Service. There is a large

Reviewing contracts and solicitations.

quantity of ammunition that is held by the

Monitoring first article acceptance tests and lot

Services in order to meet wartime requirements,

and the special storage requirements associated

acceptance tests.

with ammunition for safety and security belongs

to the owning Service. A significant portion of

The Navy and Marine Corps both conduct exten-

Marine Corps-owned ammunition is stored in

sive stockpile QE and in-Service engineering

other-Service facilities, primarily Army, and to a

support activities on their respectively-owned

lesser extent, Navy tidewater activities, amphi-

stocks. The Marine Corps and the Navy conduct

bious shipping, and maritime prepositioning

functional testing and laboratory analysis of rep-

ships (MPS). A small percentage of Marine

resentative lot samples from the inventory.

Corps-owned ammunition is also held in host

The Services conduct an extensive quality assu-

nation (HN) facilities as geoprepositioned

rance and stockpile monitoring effort for most

stocks, with the HN providing care of supplies

Class V assets. Quality is ensured through

in storage.

assessments and audits of manufacturers, as well

The Navy is responsible for the care and main-

as surveillance and maintenance programs. The

tenance of those stocks held in Navy storage

Marine Corps generally contracts for the requisite

facilities, including Class V(A) aviation ord-

engineering and technical support from a variety

nance. Like the Marine Corps, a portion of the

of Army and Navy technical and engineering

Navy’s large inventory is stored in other-Service

support agencies to accomplish this task. For the

facilities, primarily the Army. However, unlike

Navy, much of this support is organic.

the Marine Corps, a substantial portion of the

Oversight for QE and in-Service engineering

Navy’s preferred weapons inventory is embarked

activities on Navy ammunition is the respon-

in the Navy’s combatant vessels as ship’s allow-

sibility of the Deputy CNO (Fleet Readiness and

ance; on combat logistics force (CLF) shipping as

Logistics) (N4). The CNO is responsible for

replenishment stocks; or is stored at tidewater

assessing the maintenance and QE programs to

weapons stations, on amphibious shipping, and

ensure optimization of resources and compliance

on MPS. A small percentage of Navy-owned

with OPNAVINST 4850.1, Conventional

ammunition is also held in HN facilities as

Ordnance Assessment and Maintenance Re-

geoprepositioned stocks (principally, Class V(A)

quirements Policy.

aviation ordnance), with the HN providing care

of supplies in storage.

CARE OF SUPPLIES IN STORAGE

Class V(W) Maintenance

The care of supplies in a storage program, as part

The assistant program managers at PM Ammo,

of the DOD Stock Readiness Program, is

with in-Service engineering and technical sup-

intended to maintain stored Navy and Marine

port personnel, determine if a maintenance effort

Corps material in ready-for-issue condition and to

is more cost effective than new procurement.

prevent deterioration and additional damage of

Once a maintenance project is planned and

unserviceable material.

scheduled, a complex process is begun to obtain

replacement components, select a maintenance

As is the case with all Service-owned stocks held

site, position assets, and conduct a quality audit

within Service-owned facilities, responsibility for

FOR OFFICIAL USE ONLY

Ammunition Logistics^{__________________________________________________________________________________________} 1-9

of the maintenance line. The maintenance

regarding the disposition of Class V(A), to

program gives PM Ammo an option to meet

include item specific DDAs for naval ammu-

stockpile inventory objectives at a lower cost than

nition can be found in OPNAVINST 8026.2,

new procurement.

Navy Munitions Disposition Policy.

Disposal

THE MARINE CORPS

From time to time, munitions must also be

COMBAT LOGISTICS ORGANIZATION

removed from the inventory for a variety of rea-

sons. In some cases, it has become obsolete or the

Operational experience, coupled with lessons

weapon system that it served is no longer in the

learned and technological advancements prompted

active inventory. In other cases, the ammunition

the reorganization and realignment of the combat

item may have become unserviceable due to age

support infrastructure to more efficiently and

or other environmental factors and may not be

effectively support the operating forces and

economically repairable. Most frequently, the

ammunition has been rendered unusable due to

supporting establishment.

rough handling in the field, loss of lot identity, or

Combat service support centers around the

damage that occurred in transit to or from train-

Marine logistics group (MLG). The MLG is the

ing exercises or operational events.

MARFOR, Marine expeditionary force (MEF),

and Marine air-ground task force (MAGTF) com-

Class V(W) Disposal Authority

bat support/logistic support agent.

The PM Ammo manages the disposal of muni-

tions that are no longer useful and has esta-

Marine Logistics Group

blished a designated disposition authority (DDA)

for making determinations on such munitions.

The MLG, shown in figure 1-3, on page 1-11, is a

The functions of the DDA and the rules under

combat and logistic support organization that

which PM Ammo operates are discussed in

includes units, oriented to both the garrison and

appendix B.

deployed environments, executing specified gen-

eral and direct support missions.

Class V(A) Disposal Authority

The MLG provides logistic support for the MEF.

Commander, NAVSUPSYSCOM is assigned

The MLG performs those functions that exceed

authority for the worldwide management of

the organic capabilities of the supported units.

demilitarization, recycling, declassification, and

The MLG commander, normally a brigadier

disposal of excess, obsolete, unserviceable, and

general, serves as the principal logistic advisor to

waste military and foreign Class V(A) generated

the MEF commander.

at Navy and Marine Corps activities. The only

exception is with large strategic rocket motors.

The MLG consists of the MLG headquarters, a

Commander, NAVSUPSYSCOM designated the

general support combat logistics regiment, a

NOLSC to perform these functions for Navy-

direct support combat logistics regiment, and

owned Class V materiel. Accordingly, the DDA

several separate reporting battalions. In general,

for Navy-owned assets (including Class V(A)

these battalions include a headquarters and

assets of interest to the Marine Corps) is located

service battalion, three general support combat

within the NOLSC. Further detailed information

logistics battalions, a deployable MLG Forward

FOR OFFICIAL USE ONLY

1-10 ^{___________________________________________________________________________________________________}MCWP 4-11.9

with a headquarters element and limited core

Class V support and structured to facilitate task

support capabilities to facilitate the arrival of the

organization in support of the entire MEF or any

main body of the MLG, and a separate combat

combination of smaller MAGTFs.

logistics company.

Marine Aviation Logistics Squadron

Based on the mission, the commander task orga-

nizes the MLG’s general support regiment into

The Marine aviation logistics squadron (MALS) is

combat service support organizations of varying

the Marine Corps’ tactical aviation logistic organi-

sizes. The general support regiment also provides

zation. The MALS provides direct Class V(A)

core maintenance, transportation support, deliber-

support to aircraft squadrons and is responsible

ate engineering, and health services support.

for providing intermediate ordnance/armament

support and is organized under the Marine air-

The direct support regiment is organized into

craft group of the Marine aircraft wing. In a

separate combat logistics battalions in direct

deployed environment, MALS ordnance is typi-

support of assigned infantry or artillery battalions.

cally referred to as aviation combat element (ACE)

ordnance and it may deploy as a unit or a small

The ammunition company of the MLG provides

detachment as a part of the MAGTF. This MALS

Class V supply support to the MEF-sized

ordnance detachment maintains and operates the

MAGTF. The company possesses organic capa-

ammunition supply point (ASP), or theater stor-

bilities to transport its administrative and com-

age area (TSA), normally a function of the sup-

mand and control functions. The company is

porting station.

organized to plan, coordinate, and supervise

FOR OFFICIAL USE ONLY

CHAPTER 2

GENERAL CLASS V MANAGEMENT

The term wholesale is usually applied to an

Capacity management.

activity that controls and manages both material

Production management.

assets and storage facilities, and is usually not a

Execution.

direct supplier to the end user. In the ammunition

context, wholesale is applied to management

Request Management

activities undertaken by the Navy or Marine Corps

Class V ICPs.

Request management is the process performed by

the supported unit, and includes the planning and

Ammunition storage facilities are managed and

preparation for future training or contingency

operated by local commanders. The Service ICP

events. When the supported unit’s ammunition

does not own or control the storage facilities

requirements have been determined, it leads to

where a majority of the conventional ammunition

the creation of a demand that initiates a requisition

that they manage is stored. The ICP must rely on

that the logistic and supply systems must satisfy.

other Services, organizations, and activities to

execute the retail inventory management actions,

Order Management

including processing issues, receipt documents,

and preparation for shipment.

Order management is generally the same for

Class V(W) and V(A). The ASP, which is the

Retail level ammunition management functions

supporting unit, will receive the demand and

include responsibilities for both the supported

begin the process of obligating assets, planning

and the supporting units. These responsibilities

human and equipment resources, and performing

include maintaining asset visibility and account-

all the administrative work that is required in

ability, providing physical security, and reporting

order to issue the ammunition assets to the

of expenditures and other transactional activity.

supported unit.

These functions are performed in the context of

the logistic operational architecture.

Capacity Management

Capacity management for Class V is the responsi-

bility of the supporting establishment such as the

LOGISTIC OPERATIONAL ARCHITECTURE

ASP, the field ammunition supply point (FASP),

or the forward arming and refueling point (FARP).

The logistic operational architecture is a transfor-

Capacity management involves ensuring that the

mational approach to organizational change for

quantities of Class V that are on hand at any

meeting the logistic support demands of the

given storage area not exceed the physical capac-

operating forces and supporting establishment. The

ity or violate the explosives safety regulations for

logistic operational architecture breaks the

the materiel being stored.

functional actions down into five broad cate-

gories that are directly applicable to all Class V

Production Management

management activities:

Production management is an event-driven

Request management.

activity of the supporting unit and ensures that all

Order management.

required personnel, equipment, tools, and

FOR OFFICIAL USE ONLY

2-2 ^{____________________________________________________________________________________________________}MCWP 4-11.9

materials are available to satisfy the supported

throughout the DON. Users are able to perform a

unit’s demand on their required delivery date in a

wide variety of local management functions using

timely manner.

only the local Web browser on a desktop computer

and a set of specialized ordnance information

Execution

management applications. Transactional and stock

status information is uploaded as batch processes.

Execution is a joint responsibility of the sup-

porting storage activity and the supported unit, it

The Marine Corps and

involves both the administrative actions and the

Ordnance Information System

physical transfer of Class V assets. Execution

also includes observance of the requirements for

The Marine Corps uses an unclassified version of

physical security of arms, ammunition, and

the Navy’s OIS; a commodity-based system sup-

explosives and the assignment of qualified per-

porting naval logistic integration. This transition

sonnel to perform those duties.

merges the wholesale ammunition management

functions of the Navy and Marine Corps, as well

Supporting unit responsibilities for execution

as the Coast Guard, into a single, coherent, inte-

include the processing of issues; transaction

grated system and set of processes.

reporting; processing and implementation of

notices of ammunition reclassification to retail

Marine Corps Class V

stocks; ammunition information notices; and

Inventory Management Systems

other activities that facilitate ammunition support

and administration, operations, and accounting at

The Marine Corps version of OIS supports both

wholesale management functions executed by the

the retail level.

PM Ammo and the retail-level ammunition man-

agement functions executed by supporting ASPs,

ORDNANCE INFORMATION SYSTEM

both in garrison and when deployed.

Navy Class V Inventory

Near real time data entry and update is provided

Management Systems

by the Web-enabled Ordnance Information

System (OIS). The OIS provides the capabilities

The Navy version of OIS supports both wholesale

to exercise wholesale—and retail—level ammu-

management functions executed by the NOLSC

nition inventory management functions. At

and the retail-level ammunition management

appropriate management levels, several OIS-

functions executed by supporting shore activi-

based applications are available to authorized and

ties, air stations, and ships afloat.

accredited users on secured networks:

Future Capabilities

Ordnance visibility.

Naval forces operational readiness assessment

Future releases of the OIS should enable the

Ordnance assessment portfolio.

ground ammunition and aviation ordnance

Global Naval Ordnance Positioning Plan.

communities to become full participants in the

Global Combat Support System-Joint (GCSS-J)

The OIS provides ordnance information support to

family of systems and the future integrated

naval leadership and the user community

digital environment.

FOR OFFICIAL USE ONLY

Ammunition Logistics^{__________________________________________________________________________________________} 2-3

with Class V notify the appropriate agencies in

MUNITION INVENTORY AND

order to implement “cause and effect” analysis.

TRANSACTION REPORTING

Class V(W) malfunction/deficiency reports are

required when supported units experience a mal-

The OIS will be utilized to account for and

function. These reports are submitted in accor-

manage Class V stocks. Standard accounting

dance with the current edition of MCO 8025.1D,

practices/forms will apply. In addition to the in-

Class V(W) Malfunction and Defect Reporting.

theater munitions reporting procedures, Class V

transactions will be reported to the appropriate

Class V(A) malfunction/deficiency reports are

ICP as follows:

required when supported units experience a mal-

function. These reports are submitted as conven-

Class V(A) transactions are reported to

tional ordnance deficiency reports or explosives

NOLSC via an ammunition transaction report

event reports in accordance with the current edi-

generated from the Retail Ordnance Logistics

tion of OPNAVINST 5102.1D, Navy & Marine

Management System. When the OIS is fully

Corps Mishap and Safety Investigation, Report-

deployed, the requirement for ammunition

ing, and Record Keeping Manual.

transaction report will be eliminated.

Class V(W) transactions are reported to PM

Supply Discrepancy Report

Ammo via a transaction item report generated

from the Retail Ordnance Logistics Manage-

Supply discrepancies result when the quantity

ment System. When the OIS is fully deployed,

identified on shipping and transportation docu-

the requirement for an internal transaction item

ments, or on ammunition packaging, differs from

report will be eliminated, but it will still be

what is actually received. When this occurs, a

required for transactions external to the Marine

supply discrepancy report is required per the

Corps.

current edition of Naval Supply Systems Com-

mand (NAVSUP) Publication P-724, Conven-

Asset Visibility and Accountability

tional Ordnance Stockpile Management Policies

and Procedures.

Once ammunition is issued to supported units, a

process must be in place to establish and maintain

Missing, Lost, Stolen, or Recovered

asset visibility and accountability. Reporting

requirements exist to account for assets held by

The loss of ammunition items due to inadequate

supported units; expenditures of serialized

accountability, negligence, or theft may result in

ammunition; and to report missing, lost, stolen, or

significant monetary loss, safety, and security

recovered ammunition items. Personnel assigned

problems. Such losses may potentially impact

ammunition duties are responsible for following

unit readiness and adversely affect homeland

procedures established in local standing operating

security efforts. The missing, lost, stolen, or

procedures (SOPs). These principles also apply

recovered reporting system was designed to

when conducting munitions reports (MUREPs)

enable the Marine Corps to centrally track mate-

for the CCDR/JFC, as discussed in chapter 6.

rial losses and to identify trends and areas where

security enhancements may be required. The cur-

Malfunction Reporting

rent MCO 4340.1A, Reporting of Missing, Lost,

Knowledge of Class V performance is critical in

Stolen, or Recovered (MLSR) Government Prop-

maintaining a robust, flexible, and safe stockpile.

erty, contains details for reporting missing, lost,

It is imperative that units experiencing problems

stolen, or recovered ammunition.

FOR OFFICIAL USE ONLY

2-4 ^{____________________________________________________________________________________________________}MCWP 4-11.9

Automatic Identification Technologies

multiple formats in use in commercial

applications, but the format used for military

Automatic identification technologies are combi-

shipments is PDF-417. The two-dimensional

nations of reader equipment, software, tools, and

format label contains a significantly larger amount

procedures that are inserted into logistic manage-

of information than linear barcode labels.

ment processes. These technologies may be

Additionally, since the data is stored redundantly,

applied in a variety of end uses, including receipt

the label can sustain a substantial amount of

and inventory, point-of-issue transaction tracking,

damage and still be read by a barcode reader.

transportation tracking, and asset management.

Radio Frequency Identification

The two most common methods in use for Class V

management functions are barcoded labels and

The use of RFID as a technology to automate the

radio frequency identification (RFID) tags.

collection of data that is used for tracking ship-

ments and materiel until delivered to a storage

Barcoding

point or the supported unit is just beginning to

mature. The RFID technology requires a tag

Barcoding is a mature technology used extensively

where the transported items are stored, a tag

by DOD and commercial industry for tracking

reader device for interrogating or creating the

material in transit and in storage. Barcodes used

tags, and a communications method to move the

by DOD are either linear or data matrix.

collected data to a system where the information

The linear barcode is considered to be a legacy

can be used or evaluated. Unlike the one-

barcode. This barcode format is known as 3-of-9,

dimensional and two-dimensional labels, RFID

and it is sometimes shortened to Code 39. The

tags can be reformatted and reused several times.

linear, one-dimensional barcode is a series of

Receiving and transportation processes must

vertical lines of varying thickness with spaces of

ensure that all tags are “captured” and read, or the

variable duration that can be read by a scanning

benefits of the tag are lost.

device. The barcode may also display a human-

readable string beneath the coding to make ready

Other Technologies

identification possible without a scanner. Used

Other technologies/techniques that will be

for two decades, the one-dimensional label has

incorporated in ammunition logistic processes in

significant limitations in that it contains only

the near future include the electronic product

limited information and may be unreadable if

code tag (class 2) (as a successor to the current

damaged or faded.

RFID tag media) and the use of unique

The data matrix barcode is a modern barcode

identification numbers for costly ammunition

format, also known as data matrix, two-

items, as well as ammunition items that may meet

dimensional barcode symbology. There are

other defined criteria.

FOR OFFICIAL USE ONLY

CHAPTER 3

OPERATIONAL AMMUNITION

REQUIREMENTS DETERMINATION

Class V operational requirements can be described

AVIATION ORDNANCE

as the quantity of munitions required to equip a

specified force structure to accomplish its

assigned missions. This quantity of munitions is

The NNOR is the methodology used to calculate

conventional ordnance requirements for the

intended to support the CCDR/JFC commander’s

DON. The NNOR process is outlined in detail in

requirements to execute combat operations, as

OPNAVINST 8011.9A and uses a sophisticated

well as materiel required for the conduct of sub-

model to calculate DON threat-oriented and level

sequent security operations (during the transition

of effort ordnance requirements for Navy forces

from combat operations).

and Marine Corps aviation units. Model inputs

While the CG, MCCDC also has a role in the

regarding support and sustainment of the

operating forces are provided by the warfighters.

requirements determination process, the com-

Model outputs that support operational

mander is ultimately responsible for determining

requirements are reviewed and approved by the

that operational Class V requirements are suffi-

Nonnuclear Ordnance Planning Board, which

cient to execute the mission. Ammunition require-

provides top-level direction in the NNOR

ments are determined based on the mission,

process. Class V(A) sustainment methodologies

commander’s intent, assigned force levels, and

are predicated on theater and type, model, and/or

established planning factors.

series (T/M/S) of assigned aircraft for a given

operational plan. The NNOR provides the factors

for determining initial requirements and follow-

GROUND AMMUNITION

on sustainment. Sortie generation rates are a

primary determining factor in expressing the

The operating forces use combat planning fac-

remaining endurance of MAGTF aviation and its

tors (CPFs) that are generated by MCCDC and

ordnance support capability.

used to assist in Class V(W) combat/contin-

gency requirements planning. In general, ammu-

MODELING/DELIBERATE PLANNING FOR

nition requirements are determined by applying

MAJOR OPERATIONS AND CAMPAIGNS

force structure (table of organization and table of

equipment data), weapons mix, combat inten-

sity, and phase duration to the appropriate com-

In deliberate planning, operational requirements

bat planning factors.

will be developed by MCCDC, in active consul-

tation with the MARFOR, using an automated

Supportability of those requirements may be con-

computer modeling method. Aggregate require-

strained by available inventories. The process for

ments and individual combat planning factors are

programming and budgeting for ammunition

generated from this model. In order to attain

requirements is described in MCO 8000.7.

precise outputs, a high degree of accuracy and

FOR OFFICIAL USE ONLY

3-2 ^{____________________________________________________________________________________________________}MCWP 4-11.9

granularity is required in the model data inputs

For operations where predetermined combat plan-

time-phased force and deployment data (TPFDD);

ning requirements have not been established by

phases; posture statements; and theater specific

the WRMR model, refer to CPFs published on

logistical constraints such as, terrain-related,

the MCCDC Web page www.mccdc.usmc.mil/

open mountainous, or urban terrain that is

CDD/Ammo/mysite/default.htm. The Web page,

provided by the MARFOR.

in conjunction with the ammunition require-

ments generator, will act as the sole source docu-

ment for Class V(W) requirements determination.

EXECUTION OF A DELIBERATE PLAN

TRANSITION OF CLASS V(W)

In determining operational requirements for

COMBAT PLANNING FACTORS

Class V, a number of considerations must be

taken into account, bearing in mind the inherently

fluid environment in which combat operations

As a regional theater matures, the combat plan-

ning factors used for initial planning may no

take place. Requirements must be reviewed, mod-

longer support the operational requirements due

ified, and updated when conditions such as

to changes in tactics, techniques, and procedures

forces, force closure timeline, threat report, or

or the overall scope of the mission. As condi-

target apportionment change or branching plans

tions mature, planners must base their future sus-

are considered or executed. Given that the input-

tainment requirements on current combat

ted model data remains the same and only a force

expenditure data as long as a correlation exists

structure increase has occurred, additional opera-

with planned future operations. This evolving pro-

tional requirements should not be determined by

cess provides commanders with the maximum

applying CPFs to the increased force structure;

operational flexibility to prosecute near term cur-

rather the additional units should be armed with

rent and planned future operations. Although the

combat loads that support Marine Corps doc-

quantities for combat loads (CLs) (which provide

trine of arming the force. Additionally, the

the initial combat capability) may remain static,

increase of combat units/personnel may increase

emergent tactics, techniques, and procedures and

the Class V(W) logistical requirements, since

local tactical conditions will require adjustment

additional personnel normally increase physical

of planning rates to complement operational con-

dispersion. Similar considerations must be taken

siderations. Designation of expenditure-based

into account when analyzing any of the above ele-

planning factors for determining future ammuni-

ments. Planning requirements always require

tion requirements is a component function in a

revalidation prior to execution.

mature theater.

CRISIS ACTION/CONTINGENCY

OPERATIONAL REQUIREMENTS

PLANNING AND IMMEDIATE

IN A JOINT ENVIRONMENT

REQUIREMENTS DETERMINATION

In an era of increasingly joint operations and the

planned potential for implementation of common

Class V(A) crisis action/contingency planning

item support (CIS), new concepts and approaches

will be initially guided by the planned consump-

for sustainment of the forces are required. Plans

tion rates established in the NNOR for the T/M/S

must consider the efficiencies that are gained by

aircraft assigned and adjusted to reflect locally

having integrated ammunition support. Plans

available or readily accessible assets.

FOR OFFICIAL USE ONLY

Ammunition Logistics^{___________________________________________________________________________________________} 3-3

must be coordinated with the various Services

Combat Load

that are involved to ensure the adequacy of per-

In accordance with the MCO 8000.7, the CL is

sonnel, assets, storage requirements, materials

defined as the standard quantity and type of

handling equipment, accountability procedures,

munitions carried by weapons platforms/troops

and safety.

and/or its dedicated support vehicle. Using the

phrase CL implies that a weapons platform or an

individual has its full doctrinal load of ammuni-

EXPRESSING CAPABILITIES AND

tion, in terms of quantity and type. It is important

REQUIREMENTS FOR CLASS V(W)

to note that the CL provides various durations of

support depending on the weapon system when

In expressing logistical capabilities and require-

the CPFs are used as the divisor.

ments, it is important to understand that ammuni-

Day of Ammunition

tion requirements and capabilities are generally

expressed in terms of CL and day(s) of ammuni-

By design, the DOA corresponds to a composite

tion (DOA). These terms are exclusive to ground

daily quantity that represents an average daily

ammunition and are not interchangeable. Each

expenditure for total forces and weapons plat-

term of reference comes with its own set of

forms over the entire battlespace during a specific

advantages and liabilities.

period of time, typically measured in days. In

Pre-battle

Battle

Post-battle

Combat Logistic Support

Combat Arms

Duration of Activity

Figure 3-1. Logistic Demands Versus Duration and Intensity of Activity.

FOR OFFICIAL USE ONLY

3-4 ^{____________________________________________________________________________________________________}MCWP 4-11.9

terms of the MCCDC modeled CPF, a DOA is

capability, while the DOA is more definitive for a

the projected average quantity required to replen-

commander to assess his logistic endurance,

ish the previous days expenditure from the CL.

depending on current and future consumption.

This approach requires that the commander

The DOA provides a point in time measure of

understands the interrelation and fluidness of the

endurance and can fluctuate during different

terms, especially the DOA. In expressing endur-

phases of an operation based on intensity and

ance, the term DOA should be placed in a context

duration as depicted in figure 3-1. Assault phase

where the planned requirements may be arrayed

combat operations will consume assets at a higher

rate than stability operations.

against estimated future operational needs. The

MUREP and historical expenditures are valuable

Combat Load Versus Day(s) of Ammunition

tools for the continual validation and comparison

of the projected and actual expenditures as related

Under combat conditions, the CL should be

to the available inventory.

regarded as a tool for identifying initial combat

FOR OFFICIAL USE ONLY

CHAPTER 4

CLASS V MOVEMENT PLANNING

Movement planning is the art and science of

unit’s mission. If the mission is not correctly

selecting the forces and equipment that are to be

determined, follow-on planning in support of that

moved and marshaled to arrive at their respective

mission will also be flawed.

planned ports of embarkation (POE). Depending

The purpose of mission analysis is to review and

on the origin of the deploying force, it may be

analyze orders, guidance, and other information

either a strategic deployment from the continental

provided by higher headquarters and produce a

United States (CONUS) or an operational deploy-

mission statement. The inputs to the mission

ment from elsewhere within the theater. Move-

analysis step come from the higher headquarters

ment planning is done in conjunction with

deliberate or crisis action planning.

and the commander. During the mission analysis

process, intelligence preparation of the bat-

Any plan involving insertion of military forces

tlespace is a critical input for both the commander

into a conflict or contingency generally requires

and the logistician.

ammunition to initially arm and sustain that

force. Therefore, Class V planning requires a

The commander’s initial guidance will broadly

careful analysis of what ammunition would be

outline what is expected of the operational

required, timing of the required ammunition

planning team and the products that are produced

deliveries, and sourcing of the required

in the planning process. The most critical inputs

incremental shipments.

to the planning process are those contained within

the commander’s orientation, which is comprised

To facilitate ammunition requirements into

of his initial guidance and his commander’s

planning, logisticians participate in all steps of

battlespace area evaluation. The Class V planner

the Marine Corps Planning Process (MCPP)

must look at the infrastructure within the battle-

with representatives of the other warfighting

space and ask the following:

functions, staff sections, and subject matter

experts by participating in the operational

Where are the ports, airfields, and roads?

planning team. The operating forces provide input

What are the choke points in the amphibious

to the joint planning process using the process

objective area?

described in Marine Corps Warfighting Publi-

What are the limiting factors for RSOI of Class

cation (MCWP) 5-1, Marine Corps Planning

V materiel?

Process. The MCPP is designed for use at any

echelon of command to plan force organization

During this process, the Class V planner can

and employment, and it complements the joint

derive the major POE(s) and begin to determine

deliberate and crisis action planning procedures.

the anticipated throughput rates for these

locations. The commander will also provide the

first look at the friendly and enemy centers of

PLANNING FOR CLASS V

gravity. The logistician will look at these from a

COMBAT LOGISTIC SUPPORT

logistic perspective to analyze where the center of

gravity is for the operation. The commander will

Mission analysis is the first and, arguably, the

describe their intent and will outline what is

most important step in the MCPP for logisti-

viewed to be critical information requirements,

cians, and it is the step in the process where the

both in planning and in execution. Logistic-related

commander and planners will determine the

commander’s critical information requirements

FOR OFFICIAL USE ONLY

4-2 ^{____________________________________________________________________________________________________}MCWP 4-11.9

may be the capabilities of the port/airfield/bridges

family of systems that are necessary to plan,

within the area of operations or the depth of

deploy, sustain, and employ forces. The GCCS

sustainment available or desired. Necessarily, this

provides joint operation planning and execution

includes Class V materiel.

capabilities and facilitates the deployment and

redeployment of MARFOR and associated

The Class V planner should plan for main and

supplies and equipment, to include ammunition.

intermediate storage locations and the sequences

of actions that are best suited to supporting the

Joint Operation

maneuver forces. In addition, he should under-

Planning and Execution System

stand the probable timing of each action. These

are initial projections, which should be derived

The Joint Operation Planning and Execution Sys-

from the various courses of action as they evolve.

tem (JOPES) enables supported commanders,

Class V planners should be aware of critical

supporting commanders, and other members of

events and decision points to enable the logistic

the joint planning and execution community to

support to be in place prior to the critical event.

manage the deployment of forces and follow-on

Logistic critical events and decision points are

sustainment. See Chairman of the Joint Chiefs of

likely to occur 24 to 48 hours ahead of MAGTF

Staff Manual (CJCSM) 3122.02C, Joint Opera-

events and decision points that depend on the

tion Planning and Execution System (JOPES),

action and reaction continuum.

Volume III (Crisis Action Time-Phased Force

and Deployment Data Development and Deploy-

Special Consideration

ment Execution), for detailed information .

During Movement Planning

The Global Combat Support System-Joint

In planning Class V, special considerations have

to be given to proper timelines. Services must be

The GCSS-J provides universal access to infor-

careful to consider all aspects of planning

mation and interoperability of logistic information

timelines such as, at a minimum, official release

and other support functions through vertical and

of assets by Service headquarters, requisitioning,

horizontal fusion. The GCSS-J will share infor-

containerization, depot out loading, and shipping

mation with other command and control systems

in order to ensure that the assets do not arrive too

to contribute to the CCDR’s/JFC’s common

late to support the CCDR’s concept of operations.

operational picture. Ultimately, the GCSS-J will

Untimely or inaccurate planning can reduce depot

provide near real time command and control of the

responsiveness, tax commercial transportation

ammunition logistic pipeline from battlefield to

mechanisms, congest ports, and ultimately

sustaining base as a fused picture of combat

jeopardize mission accomplishment. Additionally,

support to the warfighter.

costs for ammunition movements can reach

exorbitant levels if it is not planned properly or if

Joint Force Requirements Generator II

execution does not closely follow planning. For

many reasons, planning must be carefully crafted

Planners use the Joint Force Requirements

and maintained in order to ensure that the

Generator II (JFRG II) (an automated tool) to

available resources are used and to ensure a

develop force structure, tailor force lists, compute

timely execution.

sustainment, estimate and plan lift requirements,

and generate the TPFDD. The JFRG II also acts

The Global Command and Control System

as a deployable JOPES enabling the planner to

communicate with JOPES in order to transmit or

The United States’ national command and control

receive TPFDD information. The forces and

system—the Global Command and Control

equipment entered in JFRG II are used to develop

System (GCCS)—consists of an interoperable

time-phased Class V(W) requirements. Plans may

FOR OFFICIAL USE ONLY

Ammunition Logistics^{__________________________________________________________________________________________} 4-3

be downloaded from JOPES to the JFRG II,

War Reserve Positioning

modified, and transmitted to other logistics

automated information systems (LOGAISs).

A significant portion of Marine Corps-owned

ammunition is held in Joint Munitions Com-

Logistics Automated Information

mand (JMC)-managed depot(s) and, to a lesser

Systems and Aviation Logistics

extent, Navy activities. The Navy also stores a

portion of its inventory in JMC-managed facilities.

The LOGAISs are utilized by Marine aircraft

The bulk of Class V(W) sustainment/WRMSI

wing/MALS aviation logistic planners and

will be sourced from these wholesale level depots.

embarkation representatives while developing

TPFDD in support of deliberate and crisis action

Unlike Marine Corps ground ammunition, a

planning. While designing force deployment,

substantial portion of Class V(A) used by Marine

planning, and execution plans, Marine aviation

aviation is embarked in amphibious and strike

logistic planners utilize data derived from the

force vessels as mission load allowance (MLA),

Support Equipment Resources Management

on CLF shipping as replenishment stocks, at

Information System and the Shipboard Uniform

naval weapons stations, and on MPS. A small

Automated Data Processing System databases in

percentage of Class V(A) aviation ordnance is

order to develop TPFDD in support of deliberate

also held in HN facilities as geoprepositioned

and crisis action planning.

stocks. The Army JMC is subordinate to the

Army Material Command and performs logistic

functions, as agreed upon with the single manager

CLASS V SOURCING

for conventional ammunition (SMCA). The JMC

is a field operating activity that supports the

Sourcing of Class V materiel (the function of

SMCA executor and the Military Services. As

identifying assets by Department of Defense

such, the JMC is responsible for providing

identification code [DODIC], location, quantity,

storage, physical security, basic housekeeping,

and mode of shipment for movement) to support

and depot offloading for the Military Services.

warfighting requirements differs between ground

The PEO Ammo is designated as the executor for

ammunition and aviation ordnance. While the

the SMCA.

mechanisms are generally the same, the sources

of supply are not.

Class V(W) Sourcing

The Marine Corps war reserve support is desig-

During crisis, conflict, or wartime, a crisis

nated as either war reserve material stocks force-

response cell (CRC) is activated at PM Ammo,

held (WRMSF) or war reserve materiel stocks in-

MARCORSYSCOM. Once requirements are

stores (WRMSI). The WRMSF assets are

determined and consolidated, the MARFOR/MEF

prepositioned or regionally controlled by ope-

will source the allocated WRMSF. Initial sourcing

rating forces such as landing force operational

shortfalls are based on validated requirements,

reserve material (LFORM), maritime preposi-

minus available WRMSF and other theater stocks,

tioning forces (MPFs), and HN/NATO [North

and forwarded to PM Ammo for sourcing from

Atlantic Treaty Organization] storage activities

WRMSI. Figure 4-1, on page 4-5, illustrates this

and other available Marine Corps theater stocks to

concept. Additional information on management

increase accessibility. The WRMSI stocks are held

and withdrawal of WRMSF and WRMSI stocks

at wholesale depots, which are managed by the

can be found in MCO P4400.39H, War Reserve

Service ICP.

Materiel Policy Manual.

FOR OFFICIAL USE ONLY

Military reference books and manuals (2009-2023, Volume 8) - page 33
