DB2 Server for VSE & VM Application Programming (Version 7 Release 5)

EXEC SQL DECLARE QUERY CURSOR FOR

SELECT PROJNO, ACTNO, ACSTAFF

FROM PROJ_ACT X

WHERE ACENDATE > ’2000-01-01’

AND ACSTAFF <

(SELECT AVG(ACSTAFF)

FROM PROJ_ACT

WHERE ACTNO = X.ACTNO)

EXEC SQL OPEN QUERY

EXEC SQL FETCH QUERY INTO :PN, :AN., :AS

EXEC SQL CLOSE QUERY

The X table in this query is slightly different. Conceptually, whenever there are

other conditions besides the one containing the subquery, they are applied to the

correlation table first. The X table that is derived from the PROJ_ACT table is:

PROJNO ACTNO ACSTAFF ACSTDATE ACENDATE

------ ------ ------- ---------- ----------

AD3111

1.25 1999-04-15 2000-01-15

MA2112

1.50 1999-02-15 2000-02-01

MA2113

2.00 1999-04-01 2000-12-15

MA2113

1.50 1999-09-01 2000-02-01

OP1010

130

4.00 1999-01-01 2000-02-01

Only rows with an ACENDATE greater than '2000-01-01' are included

in this "correlation table".

The values 70, 80, and 130 are used for X.ACTNO. Similarly, if you include a

GROUP BY clause in the outer-level query, that grouping is applied to the

conceptual correlation table first. Thus, if you use a correlated subquery in a

HAVING clause, it is evaluated once per group of the conceptual table (as defined

by the outer-level query’s GROUP BY clause). When you use a correlated subquery

in a HAVING clause, the correlated column-reference in the subquery must be a

property of each group (that is, must be either the group-identifying column or

another column used with a column function).

The use of a column function with a correlated reference in a subquery is called a

correlated function. The argument of a correlated function must be exactly one

correlated column (for example, X.ACSTAFF), not an expression. A correlated

function may specify the DISTINCT option; for example: COUNT(DISTINCT

X.ACTNO). If so, the DISTINCT counts as the single permitted DISTINCT

specification for the outer-level query-block (remember that each query-block may

use DISTINCT only once). For information on query-block, refer to the DB2 Server

for VSE & VM Database Administration manual.

Illustrating a Correlated Subquery

When would you want to use a correlated subquery? The use of a column function

is sometimes a clue. Consider this problem:

List the employees whose level of education is higher than the average for their

department.

First you must determine the select-list items. The problem says to “List the

employees”. This implies that the query should return something to identify the

Chapter 3. Coding the Body of a Program

employees. LASTNAME from the EMPLOYEE table should be sufficient. The

problem also discusses the level of education (EDLEVEL) and the employees’

departments (WORKDEPT). While the problem does not explicitly ask for these

columns, including them in the select-list will help illustrate the solution. A part of

the query can now be constructed:

SELECT LASTNAME, WORKDEPT, EDLEVEL

FROM EMPLOYEE

Next, a search condition (WHERE clause) is needed. The problem statement says,

“...whose level of education is higher than the average for that employee’s

department”. This means that for every employee in the table, the average

education level for that employee’s department must be computed. This statement

fits the description of a correlated subquery. Some property (average level of

education of the current employee’s department) is being computed for each row.

A correlation_name is needed on the EMPLOYEE table:

SELECT LASTNAME, WORKDEPT, EDLEVEL

FROM EMPLOYEE Y

The subquery needed is simple; it computes the average level of education for each

department:

SELECT AVG(EDLEVEL)

This clause tells the database

FROM EMPLOYEE

manager to compute the subquery

WHERE WORKDEPT = Y.WORKDEPT

once for each employee in the

outer- level query table.

The complete SQL statement is:

SELECT LASTNAME, WORKDEPT, EDLEVEL

FROM EMPLOYEE Y

WHERE EDLEVEL >

(SELECT AVG(EDLEVEL)

FROM EMPLOYEE

WHERE WORKDEPT = Y.WORKDEPT)

This will produce the following:

LASTNAME

WORKDEPT EDLEVEL

--------------- -------- -------

HAAS

A00

KWAN

C01

PULASKI

D21

HENDERSON

E11

LUCCHESI

A00

PIANKA

D11

SCOUTTEN

D11

JONES

D11

LUTZ

D11

MARINO

D21

JOHNSON

D21

SCHNEIDER

E11

MEHTA

E21

GOUNOT

E21

Application Programming

Suppose that instead of listing the employee’s department number, you list the

department name. A glance at the sample tables will tell you that the information

you need (DEPTNAME) is in a separate table (DEPARTMENT). The outer-level

query that defines a correlation variable can also be a join query.

When you use joins in an outer-level query, list the tables to be joined in the

FROM clause, and place the correlation_name next to one of these table names.

To modify the query to list the department’s name instead of the number, replace

WORKDEPT by DEPTNAME in the select-list. The FROM clause must now also

include the DEPARTMENT table, and the WHERE clause must express the

appropriate join condition.

This is the modified query:

SELECT LASTNAME, DEPTNAME, EDLEVEL

FROM EMPLOYEE Y, DEPARTMENT

WHERE Y.WORKDEPT = DEPARTMENT.DEPTNO

AND EDLEVEL >

(SELECT AVG(EDLEVEL)

FROM EMPLOYEE

WHERE WORKDEPT = Y.WORKDEPT)

This will produce the following:

LASTNAME

DEPTNAME

EDLEVEL

--------------- ------------------------------------ -------

HAAS

SPIFFY COMPUTER SERVICE DIV.

LUCCHESI

SPIFFY COMPUTER SERVICE DIV.

KWAN

INFORMATION CENTER

PIANKA

MANUFACTURING SYSTEMS

SCOUTTEN

MANUFACTURING SYSTEMS

JONES

MANUFACTURING SYSTEMS

LUTZ

MANUFACTURING SYSTEMS

PULASKI

ADMINISTRATION SYSTEMS

MARINO

ADMINISTRATION SYSTEMS

JOHNSON

ADMINISTRATION SYSTEMS

HENDERSON

OPERATIONS

SCHNEIDER

OPERATIONS

MEHTA

SOFTWARE SUPPORT

GOUNOT

SOFTWARE SUPPORT

The above examples show that the correlation_name used in a subquery must be

defined in the FROM clause of some query that contains the correlated subquery.

However, this containment may involve several levels of nesting. Suppose that

some departments have only a few employees and therefore their average

education level may be misleading. You might decide that in order for the average

level of education to be a meaningful number to compare an employee against,

there must be at least five employees in a department. The new statement of the

problem is:

List the employees whose level of education is higher than the average for that

employee’s department. Only consider departments with at least five employees.

Chapter 3. Coding the Body of a Program

The problem implies another subquery because, for each employee in the

outer-level query, the total number of employees in that persons department must

be counted:

SELECT COUNT(*)

FROM EMPLOYEE

WHERE WORKDEPT = Y.WORKDEPT

Only if the count is greater than or equal to 5 is an average to be computed:

SELECT AVG(EDLEVEL)

FROM EMPLOYEE

WHERE WORKDEPT = Y.WORKDEPT

AND 5 <=

(SELECT COUNT(*)

FROM EMPLOYEE

WHERE WORKDEPT = Y.WORKDEPT)

Finally, only those employees whose level of education is greater than the average

for that department are included:

SELECT LASTNAME, DEPTNAME, EDLEVEL

FROM EMPLOYEE Y, DEPARTMENT

WHERE Y.WORKDEPT = DEPARTMENT.DEPTNO

AND EDLEVEL >

(SELECT AVG(EDLEVEL)

FROM EMPLOYEE

WHERE WORKDEPT = Y.WORKDEPT

AND 5 <=

(SELECT COUNT(*)

FROM EMPLOYEE

WHERE WORKDEPT = Y.WORKDEPT));

This will produce the following:

LASTNAME

DEPTNAME

EDLEVEL

--------------- ------------------------------------ -------

PIANKA

MANUFACTURING SYSTEMS

SCOUTTEN

MANUFACTURING SYSTEMS

JONES

MANUFACTURING SYSTEMS

LUTZ

MANUFACTURING SYSTEMS

PULASKI

ADMINISTRATION SYSTEMS

MARINO

ADMINISTRATION SYSTEMS

JOHNSON

ADMINISTRATION SYSTEMS

HENDERSON

OPERATIONS

SCHNEIDER

OPERATIONS

Note: The above query is different from the previous correlated subqueries in that

the first subquery may return no values. Suppose that a department with

three employees is being evaluated.

Working from bottom to top, the following occurs:

Application Programming

SELECT LASTNAME, DEPTNAME, EDLEVEL

FROM EMPLOYEE Y, DEPARTMENT

WHERE Y . WORKDEPT = DEPARTMENT . DEPTNO

NULL

Predicate is unknown

AND EDLEVEL >

(SELECT

AVG(EDLEVEL)

FROM EMPLOYEE

WHERE WORKDEPT = Y.WORKDEPT

AND 5 <=

Predicate is false

(SELECT

COUNT(*)

FROM EMPLOYEE

WHERE WORKDEPT =

' A00 '

))

The inner-most subquery evaluates to 3. Thus, the expression “AND 5 <= 3” is

false. Because that expression is false, no rows satisfy the search condition of the

next subquery, and a null value is returned to the outer-most query. This causes

the predicate “EDLEVEL > subquery)” to evaluate to the unknown truth value.

The join condition “Y.WORKDEPT = DEPARTMENT.DEPTNO”, however, is

always true:

WHERE Y.WORKDEPT = DEPARTMENT.DEPTNO AND EDLEVEL > (subquery)

"TRUE"

AND

"UNKNOWN"

The following figure is the “AND” truth table for search conditions; “TRUE AND

UNKNOWN” causes the search condition in the query to be “UNKNOWN,” as

indicated above.

Chapter 3. Coding the Body of a Program

AND

No rows satisfy the search condition, so no employee is listed for department A00;

exactly the result wanted in this case.

Using a Subquery to Test for the Existence of a Row

You can use a subquery to test for the existence of a row satisfying some condition.

In this case, the subquery is linked to the outer-level query by the predicate

EXISTS or NOT EXISTS. (Refer to the DB2 Server for VSE & VM SQL Reference

manual for the syntax of the EXISTS predicate.)

When you link a subquery to an outer query by an EXISTS predicate, the subquery

does not return a value. Rather, the EXISTS predicate is true if the answer set of

the subquery contains one or more rows, and false if it contains no rows.

The EXISTS predicate is often used with correlated subqueries. The example below

lists the departments that currently have no entries in the PROJECT table:

DECLARE C1 CURSOR FOR

SELECT DEPTNO, DEPTNAME

FROM

DEPARTMENT X

WHERE

NOT EXISTS

(SELECT *

FROM PROJECT

WHERE DEPTNO = X.DEPTNO)

ORDER BY DEPTNO

You may connect the EXISTS and NOT EXISTS predicates to other predicates by

using AND and OR in the WHERE clause of the outer-level query.

Table Designation Rule for Correlated Subqueries

Unqualified correlated references are allowed. For example, assume that table EMP

has a column named SALARY and that table DEPT has a column named BUDGET,

but no column named SALARY.

SELECT * FROM EMP

WHERE EXISTS (SELECT * FROM DEPT

WHERE BUDGET < SALARY)

In this example, the system checks the innermost FROM clause for a SALARY

column. Not finding one, it then checks the next innermost FROM clause (which in

Application Programming

this case is the outer FROM clause). It is only necessary to use a qualified

correlated reference when you want the system to ignore a column with the same

name in the innermost tables.

To assist you in these situations, a warning message SQLCODE +12 (SQLSTATE

'01545') is issued whenever an SQL statement is executed that contains an

unqualified correlated reference in a subquery.

Combining Queries into a Single Query: UNION

The UNION operator enables you to combine two or more outer-level queries into

a single query. Each of the queries connected by UNION is executed to produce an

answer set; these answer sets are then combined, and duplicate rows are

eliminated from the result.

When ALL is used with UNION (that is, UNION ALL), duplicate rows are not

eliminated when two or more outer-level queries are combined into a single query.

If you are using the ORDER BY clause, you must write it after the last query in the

UNION. The system applies the ordering to the combined answer set before it

delivers the results to your program using the usual cursor mechanism.

It is possible (though unusual) to write a query using the UNION operator that

does not return results with a cursor. In this instance, only one row must be

retrieved from the tables, and an INTO clause must be placed only in the first

query.

The UNION operator is useful when you want to merge lists of values derived

from two or more tables and eliminate any duplicates from the final result.

UNION ALL will give better performance, however, because no internal sort is

done. This sort is done with the UNION operator to facilitate the elimination of

duplicates.

When both UNION and UNION ALL are used in the same query, processing is

from left-to-right. If the last union operation is UNION, the duplicates will be

eliminated from the final results; if it is UNION ALL, the duplicates will not be

eliminated. However, the left-to-right priority can be altered by the use of

parenthesis. A parenthesized subselect is evaluated first, followed, from

left-to-right, by the other components of the statement. For example, the results of

the following two queries, where A, B, and C are subselects, could be quite

different:

A UNION (B UNION ALL C)

(A UNION B) UNION ALL C

In the following example, the query returns all projects for which the estimated

mean number of employees is greater than 0.50, and it returns all the projects

where the proportion of employee time spent on the project is greater than 0.50:

Chapter 3. Coding the Body of a Program

SELECT PROJNO,’MEAN’

FROM PROJ_ACT

WHERE ACSTAFF > .50

UNION

SELECT PROJNO,’PROPORTION’

FROM EMP_ACT

WHERE EMPTIME > .50

The database manager combines the results of both queries, eliminates the

duplicates, and returns the final result in ascending order.

Note: The ascending order is a direct result of the internal sort, which is

performed to facilitate the elimination of duplicates.

PROJNO

EXPRESSION

------

------------

AD3110

MEAN

AD3110

PROPORTION

AD3111

MEAN

AD3111

PROPORTION

AD3112

MEAN

AD3112

PROPORTION

AD3113

MEAN

AD3113

PROPORTION

IF1000

MEAN

IF1000

PROPORTION

IF2000

MEAN

IF2000

PROPORTION

MA2100

MEAN

MA2100

PROPORTION

MA2110

MEAN

MA2110

PROPORTION

MA2111

MEAN

MA2111

PROPORTION

MA2112

MEAN

MA2112

PROPORTION

MA2113

MEAN

MA2113

PROPORTION

OP1010

MEAN

OP1010

PROPORTION

OP2000

MEAN

OP2010

MEAN

OP2010

PROPORTION

OP2011

MEAN

OP2011

PROPORTION

OP2012

MEAN

OP2012

PROPORTION

PL2100

MEAN

PL2100

PROPORTION

To connect queries by the UNION operator, you must ensure that they obey the

following rules:

v All corresponding items in the select-lists of the queries in the union must be

compatible.

v An ORDER BY clause, if used, must be placed after the last query in the union.

The order-list must contain only integers, not column names. In the example

query above, ORDER BY 1 is acceptable, but ORDER BY PROJNO is not.

Application Programming

v None of the queries in a union may select long strings.

v A union may not be specified inside a subquery.

v A union may not be used in the definition of a view.

v VARCHAR and VARGRAPHIC values that differ only by trailing blanks are

considered equal. One of the values will be eliminated as a duplicate value

unless UNION ALL is selected.

Unions between columns that have the same data type and the same length

produce a column with that type and length. If they are not of the same type and

length but they are union-compatible, the resulting column-type is a combination

of the two original columns.

The results of a UNION between two union-compatible items is summarized

below. The first row and first column of the table represent the data-type of the

first and second columns of the UNION join.

String Columns

CHAR

VARCHAR

GRAPHIC

VARGRAPHIC

CHAR

VARCHAR

ERROR

VARCHAR

ERROR

GRAPHIC

ERROR

GRAPHIC

VARGRAPHIC

ERROR

VARGRAPHIC

The length attribute of the resulting column will be the greater of the length

attributes of the original columns.

The UNION operators between columns that have the same character subtype and

CCSID produce a column with that subtype and CCSID. If they do not have the

same subtype and CCSID, the resulting subtype and CCSID are determined

following specific rules. For a detailed discussion of these rules, refer to the DB2

Server for VSE & VM SQL Reference manual.

Numeric Columns

SMALLINT

INTEGER

DECIMAL

SINGLE

DOUBLE

PRECISION

SMALLINT

INTEGER

DECIMAL

DOUBLE

PRECISION

INTEGER

DECIMAL

DOUBLE

PRECISION

DECIMAL

DOUBLE

PRECISION

SINGLE

DOUBLE

SINGLE

DOUBLE

PRECISION

DOUBLE

PRECISION

When both of the original columns are DECIMAL data-types, special rules apply

for determining the scale and precision of the resulting column.

Chapter 3. Coding the Body of a Program

Where s is the scale of the first column of the UNION join, s’ is the scale of the

second column, p is the precision of the first column, and p’ is the precision of the

second, the resulting column’s precision is:

MIN( 31,MAX( s , s’ ) + MAX( p-s , p’-s’ ) )

The scale of the resulting column is the maximum scale of the original columns of

the UNION join, MAX( s, s’).

When a UNION is performed on a DECIMAL and either an INTEGER or

SMALLINT column, the resulting column’s scale and precision can be calculated

with the previous formulas. However, remember to substitute 11 and 0 for the

precision and scale of an INTEGER column, and 5 and 0 for a SMALLINT column.

Datetime/Timestamp Columns

DATE

TIME

TIMESTAMP

DATE

ERROR

TIME

ERROR

TIME

ERROR

TIMESTAMP

ERROR

TIMESTAMP

Note: CHAR, VARCHAR, GRAPHIC, and VARGRAPHIC are not

union-compatible with DATE, TIME, or TIMESTAMP.

SQL Comments within Static SQL Statements

You can use a comment as a separator within static SQL statements written in the

various host languages. This comment is referred to as an SQL comment (as

opposed to host language comments), and is identified by two consecutive

hyphens (--) on the same line, not separated by a space and not part of a literal, a

string of DBCS characters, a quoted identifier, or an embedded host language

comment. In COBOL, the two hyphens must be preceded by a blank. The comment

ends at the end of the line.

Here is the sample query from the previous discussion on UNION, documented

with a few SQL comments:

SELECT PROJNO,’MEAN’

FROM PROJ_ACT -- PROJECT ACTIVITY TABLE

WHERE ACSTAFF > .50

-- FIRST QUERY IS FOR ESTIMATED MEAN NUMBER OF EMPLOYEES

UNION

-- SECOND QUERY IS FOR PROPORTION OF EMPLOYEE TIME

SELECT PROJNO,’PROPORTION’

FROM EMP_ACT -- EMPLOYEE ACTIVITY TABLE

WHERE EMPTIME > .50

The DB2 Server for VSE & VM SQL Reference manual for the detailed syntax rules

on the use of SQL comments within application programs.

Using Stored Procedures

A stored procedure is a user-written application program that is compiled and

stored at the server. When the database manager is running in multiple user mode,

local applications or remote DRDA applications can invoke the stored procedure.

Since the SQL statements issued by a stored procedure are local to the server, they

Application Programming

do not incur the high network costs of distributed statements. Instead, a single

network send and receive operation is used to invoke a series of SQL statements

contained in the stored procedure.

Figure 21 and Figure 22 illustrate how the use of stored procedures reduces

network traffic by decreasing the number of commands that flow between the

application requester and the application server.

Application Server

Application Requester

┌──────────────────────────┐

┌───────────────────────┐

│

│ EXEC SQL CREATE

├──────────► │ Process statement and

│

│ TABLE ...

│◄───────────┤ return SQLCA

│

│ EXEC SQL INSERT ...

├──────────► │ Process statement and

│

│◄───────────┤ return SQLCA

│

│ EXEC SQL COMMIT

├──────────► │ Process statement and

│

│ WORK ...

│◄───────────┤ return SQLCA

│

└───────────────────────┘

│

└──────────────────────────┘

Figure 21. Without Stored Procedures

Application Server

Stored Procedure Server

┌───────────────────────┐

┌────────────────────────┐

Application Requester

│

┌───────────────────┐

│

│ EXEC SQL CALL ... ├────►│Send request to stored ├───►│Invoke stored procedure │

│

│procedure server

│

│application

│

│Process statement and

│◄───┤EXEC SQL INSERT ...

│

│return SQLCA

├───►│

│

│Process statement and

│◄───┤EXEC SQL UPDATE ...

│

│return SQLCA

├───►│

│

│ Process results

│◄────┤Return results to

│◄───┤Stored procedure

│

│application requester

│

│completes and returns

│

│results

│

│ EXEC SQL COMMIT

├────►│Process statement and

│

│ WORK ...

│◄────┤return SQLCA

│

└───────────────────┘

│

└───────────────────────┘

└────────────────────────┘

Figure 22. With Stored Procedures

For information on the stored procedure environment, including stored procedure

servers, refer to the DB2 Server for VSE & VM Database Administration manual.

There are several other benefits that can be gained through the use of stored

procedures, including:

v In many applications, the integrity of the host variables used in SQL statements

is critical to the business function provided by the application. For example, a

Chapter 3. Coding the Body of a Program

debit/credit application might need to guarantee that the host variable values do

not change between debit and credit operations. In these applications, the

application designer would like to guarantee that sophisticated users cannot

employ online debugging tools to manipulate the content of SQL statements or

host variables used by the SQL application. By using stored procedures, the

application designer can encapsulate the application’s SQL statements into a

single message to the server, which moves the sensitive processing beyond the

reach of even the most sophisticated workstation user.

v Stored procedures can be used to hide the details of the database design from

client applications. In addition to simplifying the writing of client applications,

this means that if the database design is changed, only the stored procedure

needs to be modified. The more client applications that use the stored procedure,

the greater the benefit.

v Stored procedures can be used to hide sensitive data from application programs.

v Business logic can be encapsulated at the server, rather than being included in

numerous application programs.

v It is easier to maintain an environment in which applications are kept at the

server rather than spread across a number of requesters.

Writing Stored Procedures

Stored procedure that are to be used on a DB2 Server for VSE & VM database can

be written in PL/I, COBOL, C, or Assembler. Stored procedures are very much like

regular application programs, with the following exceptions:

v They must be LE compliant

v They cannot contain the following SQL statements: CONNECT, COMMIT,

ROLLBACK, or CALL

Note: Stored procedures must be written as MAIN programs; they cannot be SUB

programs.

The following is an example of a simple stored procedure. It contains one SQL

statement that SELECTs the salary of a given employee from the

SQLDBA.EMPLOYEE table. The employee number is provided as input, and the

salary and the SQLCODE for the SELECT statement are returned.

Application Programming

IDENTIFICATION DIVISION.

PROGRAM-ID. SAMP1.

ENVIRONMENT DIVISION.

INPUT-OUTPUT SECTION.

FILE-CONTROL.

DATA DIVISION.

FILE SECTION.

WORKING-STORAGE SECTION.

EXEC SQL BEGIN DECLARE SECTION END-EXEC.

CHAR6HV

PIC X(6).

SALHV

PIC S9(7)V9(2) COMPUTATIONAL-3.

EXEC SQL END DECLARE SECTION END-EXEC.

EXEC SQL INCLUDE SQLCA END-EXEC.

LINKAGE SECTION.

CHAR6

PIC X(6).

SALARY

PIC S9(7)V9(2) COMPUTATIONAL-3.

SQLCD

PIC S9(9) COMP.

PROCEDURE DIVISION USING CHAR6 SALARY SQLCD.

* TURN OFF SQL EXCEPTION PROCESSING *

EXEC SQL WHENEVER SQLWARNING CONTINUE END-EXEC.

EXEC SQL WHENEVER SQLERROR CONTINUE END-EXEC.

EXEC SQL WHENEVER NOT FOUND CONTINUE END-EXEC.

MOVE CHAR6 TO CHAR6HV.

EXEC SQL

SELECT SALARY INTO :SALHV FROM SQLDBA.EMPLOYEE

WHERE EMPNO = :CHAR6HV

END-EXEC.

MOVE SALHV TO SALARY.

MOVE SQLCODE TO SQLCD.

STOP RUN.

The following is an example of a CALL statement that could be used to invoke the

procedure shown above:

CALL SAMP_PROC (’000250’, :SALARY, :SQLCD)

The SQL CALL statement is discussed in more detail in “Calling Stored

Procedures” on page 96.

Returning Information from the SQLCA

Information about the execution of SQL statements within a stored procedure is

not returned to the application that invoked the stored procedure. If SQLCODE,

SQLSTATE, or any other information from the SQLCA is required by the calling

application, that information must be included in the parameter list of the stored

procedure and the parameters must be set explicitly in the stored procedure. This

is because there are many situations in which a negative SQLCODE does not

necessarily indicate a problem (such as dropping a table that does not exist). The

person who writes the stored procedure application must determine what

SQLCODEs should be returned to the caller.

Chapter 3. Coding the Body of a Program

See “Writing Stored Procedures” on page 94 for an example of a stored procedure

that returns an SQLCODE.

Language Environment^® (LE) Considerations

As mentioned previously, stored procedures must be LE-compliant. IBM Language

Environment for MVS and VM and the IBM Language Environment for VSE/ESA

establish a common run-time environment for different programming languages. It

combines essential run-time services, such as condition handling and storage

management. All of these services are available through a set of interfaces that are

consistent across programming languages. With LE, you can use one run-time

environment for your applications, regardless of the application’s programming

languages or system resource requirements.

Language Environment is the prerequisite run-time environment for applications

generated with the following IBM compiler products:

v IBM C for VM/ESA

v IBM SAA AD/Cycle C/370

v IBM COBOL for MVS and VM

v IBM SAA AD/Cycle COBOL/370

v IBM PL/I for MVS and VM

v IBM SAA AD/Cycle PL/I MVS and VM

v IBM C for VSE/ESA

v IBM COBOL for VSE/ESA

v IBM PL/I for VSE/ESA

Stored procedures can be written in assembly language as long as the assembly

language program uses the required macros to operate as an IBM Language

Environment application program.

For complete details, see the Language Environment documentation.

Preparing to Run a Stored Procedure

For DB2 Server for VM, once the stored procedure has been written, it must be

preprocessed, compiled, and linked like any application program, and the load

module must be put on a disk that can be accessed by the stored procedure server

that will run the stored procedure. For DB2 Server for VSE, once the stored

procedure has been written, it must be preprocessed, compiled, and linked like any

application program, and the phase must be put in a library that is in the stored

procedure server’s search path. In addition, the CREATE PROCEDURE statement

must be used to define the stored procedure to the database manager. See the DB2

Server for VSE & VM SQL Reference manual for information on the CREATE

PROCEDURE statement.

Calling Stored Procedures

Once a stored procedure has been created and the CREATE PROCEDURE

statement has been used to define it, it can be invoked. The SQL CALL statement

is used in an application program to invoke a stored procedure. The syntax of the

CALL statement is shown in Figure 23 on page 97.

Application Programming

►► CALL

procedure-name

►◄

host-variable

(

)

▼

host-variable

constant

NULL

USING DESCRIPTOR descriptor-name

Figure 23. Syntax of SQL CALL statement

For a complete description of the CALL statement, see the DB2 Server for VSE &

VM SQL Reference manual.

As indicated in Figure 23, the procedure name can be a host variable or a constant,

and parameters can be provided in a parameter list or in a descriptor (SQLDA). A

simple example of a CALL statement might look like this:

EXEC SQL CALL PROC1 (’000250’, :lastname, :salary, :sqlcd)

The CALL statement shown above assumes that none of the input parameters can

have null values. If you need to allow for null values, use indicator variables with

the host variables, as follows:

EXEC SQL CALL PROC1 (:empno :empnoi,

:lastname :lnamei,

:salary :salaryi,

:sqlcd :sqlcdi)

If you do not know the parameter structure of the procedure, or if you prefer to

use one structure rather than several host variables, you would use the following

form of the CALL statement:

EXEC SQL CALL PROC1 USING DESCRIPTOR :sqlda

where sqlda is the name of an SQLDA. The parameter information must be put in

the SQLDA before the CALL is issued.

The final example provides maximum flexibility:

EXEC SQL CALL :procname USING DESCRIPTOR :sqlda

where sqlda is the name of an SQLDA. The parameter information must be put in

the SQLDA before the CALL is issued.

Authorization

Authorization for stored procedures is done on a package level. That is, the issuer

of the CALL statement must be authorized to run the package associated with the

stored procedure. See Chapter 10, “Assigning Authority and Privileges,” on page

269 for more information on authorization.

AUTHIDs

On the CREATE PROCEDURE statement, you can specify an AUTHID. If you do,

then only a user with that AUTHID can run the stored procedure. The AUTHID

corresponds to the SQL ID of a connected user. This facility is useful for testing

modifications to a stored procedure. It allows the database administrator to create

a private copy of the stored procedure, modify and test it, without affecting the

Chapter 3. Coding the Body of a Program

copy of the stored procedure that is publicly accessible. Once the stored procedure

is fully tested, it can replace the existing, publicly accessible stored procedure.

Stored Procedure Parameters

The parameters for a stored procedure are defined on the CREATE PROCEDURE

statement. The CREATE PROCEDURE statement makes an entry in

SYSTEM.SYSPARMS for each parameter. The entry in SYSTEM.SYSPARMS

indicates the datatype, size, and purpose (input, output, or both) of the parameter.

The stored procedure must have a declaration for each parameter that is passed to

it. The declaration of each parameter must be compatible with the datatype and

size specified for it in SYSTEM.SYSPARMS. Table 11 shows the compatible

definitions for parameters in C, COBOL, PL/I, and Assembler.

Table 11. Definitions of Stored Procedure Parameters

SYSPARMS

COBOL

PL/I

Assembler

CHAR(n)

char

PIC X(n)

CHAR(n)

CLn

varname[n+1]

CHAR(1)

char

PIC X(1)

CHAR(1)

CL1

VARCHAR(n)

char

01 parm

CHAR(n)

H,CLn

varname[n+1]

49 parml

VARYING

PIC S9(4) COMP

49 parmd

PIC X(n)

SMALLINT

short

PIC S9(4) COMP

BIN FIXED(15)

INTEGER

long

PIC S9(9) COMP

BIN FIXED(31)

DECIMAL(x,y)

DECIMAL[(p,[s])]

PIC S9(x-y)V9(y) COMP-3

DEC FIXED(x,y)

PLn[’decimal

or DEC[(p,[s])]

constant’] or

P’decimal

constant’

REAL

float

COMP-1

BIN FLOAT(21)

FLOAT

double

COMP-2

BIN FLOAT(53)

GRAPHIC(n)

not supported

PIC G(n) DISPLAY-1 or PIC N(n)

GRAPHIC(n)

not supported

VARGRAPHIC(n)

not supported

01 parm

GRAPHIC(n)

not supported

49 parml

VARYING

PIC S9(4) COMP

49 parmd

PIC G(n)

USAGE IS DISPLAY-1

49 parmd PIC N(n)

Each of the high-level language definitions for stored procedure parameters

support only a single instance (scalar value) of the parameter. There is no support

for structure, array, or vector parameters. In some applications, it may be necessary

to return a table of results, where the table represents multiple occurrences of one

or more of the parameters passed to the stored procedure. Since this support is not

provided by the SQL CALL statement, one of the following techniques may be

used by the application to provide the required capability:

v If the data to be returned is in a table in the database, the calling program can

fetch the rows directly using SQL. Since a DRDA requester can intermix SELECT

and CALL statements in a unit of work, the DRDA block fetch protocol can be

used to retrieve the required data efficiently.

Application Programming

v Tabular data can be converted to string format and returned as a character string

parameter to the calling program. The calling program and the stored procedure

can establish a convention for interpreting the content of the character string. For

example, the SQL CALL statement can pass a 1920 byte character string

parameter to a stored procedure, allowing the stored procedure to return a 24 by

80 screen image to the calling program.

Datatype Compatibility

The datatype of a parameter provided on the CALL does not have to be identical

to the datatype expected by the stored procedure, but it must be compatible. That

is, if the stored procedure expects a CHAR(4) parameter, the caller can provide a

character or varchar value with a length of 4 or less. Similarly, if the procedure

expects an integer, most numeric datatypes (decimal, smallint, float) are acceptable,

as long as the number is not too large to be represented by an integer. In general,

datatypes that are considered compatible in other SQL statements are also

considered compatible in an SQL CALL. That is, if the value being provided on the

SQL CALL could be inserted into a column that has the same datatype as the

stored procedure parameter, then it is valid for the SQL CALL statement.

For more information on datatype compatibility, see the DB2 Server for VSE & VM

SQL Reference manual.

Conventions for Passing Stored Procedure Parameters

When an SQL CALL statement is issued, DB2 Server for VSE & VM builds a

parameter list for the stored procedure, containing the parameters provided on the

SQL CALL statement. When the initial parameter list is built, the parameters

contain the values established on entry to the SQL CALL statement. Eventually, the

database manager will run the stored procedure and return values for the

parameters to the calling program. If a stored procedure fails to set one or more of

the output parameters, the database manager will not detect this fact. Instead, it

will return the output parameter(s) to the calling program, with the value(s)

established on entry to the SQL CALL statement.

In order for the stored procedure to receive parameters correctly, the stored

procedure must be coded to accept the parameter list supplied by the database

manager. DB2 Server for VSE & VM supports two parameter list conventions. The

parameter list convention is determined by the value of the PARAMETERSTYLE

column in the SYSTEM.SYSROUTINES catalog table, which can be GENERAL or

GENERAL WITH NULLS.

The GENERAL Linkage Convention

If the GENERAL linkage convention is used:

v Input parameters cannot be NULL.

v NULLs can be passed for output parameters only.

v The stored procedure cannot return NULLs for output parameters.

v A parameter must be defined in the stored procedure for each parameter passed

in the SQL CALL statement.

For performance reasons, the calling application may choose to pass null indicators

with the output parameters on the SQL CALL statement. If the null indicator

associated with an output parameter is negative on entry to the SQL CALL

statement, the application requester transmits only the null indicator to the server.

This can be beneficial when dealing with large output parameters, since the entire

output parameter is not transmitted to the server. Upon successful completion of

Chapter 3. Coding the Body of a Program

the SQL CALL statement, none of the null indicators associated with the output

parameters will be null, since the stored procedure is restricted to non-null

parameter values.

When the GENERAL parameter list format is used, register 1 points to a list of

addresses, which in turn point to the individual parameters. Figure 24 describes

the GENERAL parameter list convention.

Reg 1

Addr of parm 1

Parm 1 data

Addr of parm 2

Parm 2 data

Addr of parm 3

Parm 3 data

Addr of parm n

Parm n data

Figure 24. GENERAL parameter list

The GENERAL WITH NULLS Linkage Convention

This is the default. If the GENERAL WITH NULLS linkage convention is used:

v Input parameters can be NULL. This is achieved through the use of indicator

variables, or by specifying the keyword NULL.

v The stored procedure can return NULLs for output parameters, by using

indicator variables.

v A parameter must be defined in the stored procedure for each parameter passed

in the SQL CALL statement. An array of indicator variables, with one indicator

variable for each parameter, must also be defined in the stored procedure.

The indicator variables are passed to the stored procedure as a single parameter -

an array of SMALLINT variables with an element for each indicator variable.

Figure 25 on page 101 describes the GENERAL WITH NULLS parameter list

convention.

100

Application Programming

Reg 1

Addr of parm 1

Parm 1 data

Addr of parm 2

Parm 2 data

Addr of parm 3

Parm 3 data

Addr of parm n

Parm n data

Addr of Indicator

vector

Indicator 1

Indicator 2

Indicator 3

Indicator n

Figure 25. GENERAL WITH NULLS parameter list

The stored procedure must determine which input parameters are null by

examining the array of indicator variables. The stored procedure must also assign

values to the indicator variables when returning the output parameters to the

calling program.

The array of indicator variables is not defined in the PARMLIST column of

SYSTEM.SYSROUTINES, and is not specified as a parameter in the SQL CALL

statement. In the SQL CALL statement in the client program, the indicator

variables are coded after each parameter, for example:

EXEC SQL CALL PROCX (:parm1:indicator1, :parm2:indicator2)

EXEC SQL CALL PROCX (:parm1 INDICATOR :indicator1, :parm2 INDICATOR :indicator2)

In order to support the linkage conventions described above, the high level

language application must be coded to support the required parameter list

convention.

Coding Examples

For examples of how to code stored procedures to receive and return parameters in

C, COBOL, PL/I, or Assembler, refer to the appendix for that language.

Special Considerations for C

The PLIST(OS) run-time option must be supplied.

Special Considerations for PL/I

The NOEXECOPS procedure option must be supplied.

Result Sets

In addition to returning parameters, a stored procedure can return query data,

known as result sets. A result set is defined by declaring a cursor with the WITH

RETURN clause, opening the cursor within the stored procedure, and leaving it

open when the procedure returns. The resulting rows of data that can be fetched

constitute a result set.

Chapter 3. Coding the Body of a Program

101

Notes:

For a procedure to return result sets, the RESULT_SETS column in the

SYSTEM.SYSROUTINES entry for that procedure must contain a non-zero

value.

The DB2 Server for VSE & VM requester does not have the capability to

process result sets for procedures invoked over SQLDS protocol. DB2 Server

for VSE & VM returns result sets only to DRDA clients.

If any FETCHes are issued within the stored procedure, the result set rows

returned to the client start with the row after the last row that was fetched

within the stored procedure. That is, if the stored procedure issues three

FETCHes, the result set returned to the client starts with the fourth row.

The stored procedure must not use blocking. This is because if blocking is on,

the application server returns a full block of rows when a FETCH is issued,

leaving the cursor positioned on the row after the last row of the block. If the

stored procedure does not FETCH all of the rows in the block, the rows that

have already been returned to the stored procedure will not be returned to the

application requester.

The name of the stored procedure’s cursor is returned to the client along with

the result set. The client application obtains the cursor name and an

application-oriented description of the result set through extensions to the

SQL DESCRIBE statement. Because of this, the cursor names within the stored

procedures should be meaningful to a DRDA client application.

The SELECT statement associated with the cursor can reference tables,

synonyms, and views.

The database manager does not return result sets for cursors that are closed

before the stored procedure terminates. The application programmer must

issue an SQL CLOSE for each cursor that is not supposed to be returned to

the DRDA client.

Result sets are returned to the DRDA client in the order in which the cursors

were opened by the stored procedure.

When a stored procedure returns result sets, a warning SQLCODE is returned

on the CALL statement. The SQL warning tells the application program that

result sets are present.

10.

Assume the RESULTSETS column in system catalog table SYSROUTINES has

the value "x" and the DRDA client supports up to "y" result sets. The database

manager returns the lesser of "x" and "y" result sets to the client (call it "z").

If a stored procedure attempts to return more than "z" result sets, the SQL

CALL statement completes with SQLCODE +464 and SQLSTATE 01609 and

the database manager returns the first "z" result sets.

If the stored procedure returns 1 to "z" result sets, the SQL CALL statement

completes with SQLCODE +466 and SQLSTATE 01610 and the database

manager returns all the result sets.

Coding Client Programs to Process Results Sets

A client application program can receive and process result sets over DRDA from a

stored procedure by using the following SQL Extensions:

v The RESULT SET LOCATOR SQL data type, which allows a host variable to be

used as a unique identifier for a query result set returned by the stored

procedure. This is only supported in client applications written in Assembler, C,

COBOL, or PL/I.

v The SQL ASSOCIATE LOCATORS statement, which associates result set locator

variables with each result set returned by the stored procedure.

102

Application Programming

v The SQL ALLOCATE CURSOR statement, which defines a cursor and associates

it with a result set locator variable. This cursor is then used to fetch the rows in

the result set.

v The SQL DESCRIBE PROCEDURE statement, which allows the client application

retrieve information about the result sets returned by the stored procedure.

>The SQL DESCRIBE CURSOR statement, which allows the client application to

receive information belonging to the particular result set associated with the

cursor that will be used to fetch the rows in the result set.

A client application programmer should consider the following when calling a

stored procedure that may return result sets:

v The client application can determine how many result sets are returned by using

the DESCRIBE PROCEDURE statement, and determine the contents of each

result set by using the DESCRIBE CURSOR statement.

v By knowing the number and contents of the result sets that a stored procedure

returns, an application program can be simplified. However, if code is written

for the more general case, in which the number and contents of result sets can

vary, major modifications to the client program are avoided if the stored

procedure changes.

v The DB2 Server for VSE & VM requester has read-only access to stored

procedure result sets. The DRDA limited block fetch protocol is used to transmit

the result set to the client, even when the stored procedure’s cursor is

updateable. This means that on UPDATE WHERE CURRENT OF or a DELETE

WHERE CURRENT of statement cannot be issued against a result set. If one of

these commands is issued against a result set, SQLCODE -520 is returned with

SQLSTATE 42828.

For information on how to process result sets on clients other than DB2 Server for

VSE & VM Requester, refer to the following manuals:

1. IBM DB2 Universal Database Call Level Interface Guide and Reference

2. DB2 for OS/390 Application Programming and SQL Guide.

Result Set Processing

If the number of result sets and the characteristics of each result set are know, the

following steps need to be performed in order to access each result set:

v Declare as many result-set locator variables as the number of result sets returned

by the stored procedure.

v Invoke the stored procedure using the SQL CALL statement.

v Issue the ASSOCIATE LOCATORS statement once.

v Issue one ALLOCATE CURSOR statement for each result set returned by the

stored procedure.

Figure 26 on page 104 shows the relationship among the new SQL statements and

the new data type.

Chapter 3. Coding the Body of a Program

103

CLIENT

STORED PROCEDURE

OPEN RESULT SET 1

RESULT SET LOCATOR1

ALLOCATE

FETCH CURSOR1

CURSOR1

OPEN RESULT SET 2

RESULT SET LOCATOR2

ALLOCATE

ASSOCIATE

FETCH CURSOR2

CURSOR2

LOCATORS

OPEN RESULT SET 3

RESULT SET LOCATOR3

ALLOCATE

FETCH CURSOR3

CURSOR3

Figure 26. Relationship Among the New SQL Statements and the New Data Type

After the SQL CALL statement is executed, the ASSOCIATE LOCATORS statement

is issued. The ASSOCIATE LOCATORS statement associates the result sets

returned by the stored procedure with the result-set locator variables declared

previously and specified in the ASSOCIATE LOCATORS statement (see (1) in

Figure 26). For each result set returned, the ALLOCATE CURSOR statement is

issued to assign a local cursor name to the result set locator variable (see (2) in

Figure 26). Then, the rows of each result set can be processed by using the FETCH

statement specifying the local cursor name (see (3) in Figure 26).

Note that the order of the association of result sets and result set locator variables

is the order that the stored procedure used in opening the cursor; the first open

cursor issued by the stored procedure is associated with the first result set locator

variable, the second open cursor issued by the stored procedure is associated with

the second result set locator variable, and so on. Also, note that only cursors that

were opened with the option WITH RETURN, and remain open after the

procedure terminates, are returned.

Multiple result sets can be processed in parallel. For example, the first row of the

first result set is processed, the first row of the second result set is processed, then

the second row of the first result set is processed.

After the client program issues an SQL CALL statement, the DESCRIBE

PROCEDURE statement can be used to obtain information about the result sets

returned by the stored procedure. The DESCRIBE PROCEDURE statement should

be used when the number of result sets the stored procedure returned is unknown.

The DESCRIBE PROCEDURE returns the number of result sets returned from the

stored procedure and places information about the results sets in SQLDA.

Likewise, after the client program issued an SQL CALL statement, the DESCRIBE

CURSOR statement can be used to obtain information about a specific result set

returned by the stored procedure. The DESCRIBE CURSOR statement should be

used when the column names and data types of a particular result set are

unknown. After execution of the DESCRIBE CURSOR statement, the SQLDA

contains the information belonging to each column in the result set.

104

Application Programming

Note: When the server is DB2 Server for VSE & VM, private protocol is not

supported. These new statements are only supported for distributed

applications. If any of these statements is executed over private protocol, the

user will receive SQLCODE -947.

Using the DESCRIBE PROCEDURE SQL Statement

After the client program issues an SQL CALL statement, the DESCRIBE

PROCEDURE statement can be used to obtain information about the result sets

returned by the stored procedure. Figure 27 shows the DESCRIBE PROCEDURE

statement.

CLIENT

STORED

PROCEDURE

OPEN CURSOR1

SQLDA

SQLD = 2

SQLNAME = CURSOR1

SQLVAR1

SQLIND = -1

SQLDATA = LOCATOR1

DESCRIBE

OPEN CURSOR2

SQLNAME = CURSOR2

PROCEDURE

SQLVAR2

SQLIND = -1

SQLDATA = LOCATOR2

Figure 27. DESCRIBE PROCEDURE Statement

The DESCRIBE PROCEDURE statement should be used when the number of result

sets returned by the stored procedure is unknown. The DESCRIBE PROCEDURE

returns the number of result sets returned from the stored procedure and places

information about the result sets in an SQLDA, which must be made large enough

to hold the maximum number of result sets that the stored procedure may return.

To use the SQLDATA field from the DESCRIBE PROCEDURE statement, a result

set locator variable needs to be set up. A subscript variable is not valid in an

ALLOCATE CURSOR statement. For instance, the following is required to use the

SQLDATA variable for a COBOL program:

* Redefine the SQLDATA pointer as PIC S9(9) comp.

Chapter 3. Coding the Body of a Program

105

03 SQLDATA POINTER.

03 SQLDATANUM REDEFINES SQLDATA S9(9) COMP.

* Declare a result set locator variable to move the SQLDATA

* POINTER field too, to be used in the ALLOCATE CURSOR statement.

* You need to redefine this variable as PIC S9(9) comp.

01 LOCPTR SQL TYPE IS

RESULT-SET-LOCATOR VARYING.

01 LOCNUM REDEFINES LOCPTR S9(9) COMP.

* After the DESCRIBE PROCEDURE statement you can

* move the SQLDATANUM variable to the LOCNUM variable

MOVE SQLDATANUM(INDEX) TO LOCNUM.

* You can now allocate the cursor for the result set.

EXEC SQL ALLOCATE CURSOR1 CURSOR FOR RESULT SET

:LOCPTR

END-EXEC.

An alternative to using the SQLDATA field as shown above is to use the

ASSOCIATE LOCATORS statement to assign values to locator variables.

Using the DESCRIBE CURSOR SQL Statement

Once the application program issues an SQL CALL statement, the DESCRIBE

CURSOR statement can be used to obtain information about a specific result set

returned by the stored procedure. Figure 28 on page 107 shows the DESCRIBE

CURSOR statement.

106

Application Programming

SQLDA

RESULT SET 1

COL1

COL2

COL3

SQLD = 3

SQLTYPE = CHARACTER

SQLVAR1

SQLLEN = 5

SQLNAME = COL1

SQLTYPE = CHARACTER

DESCRIBE

SQLVAR2

SQLLEN = 15

CURSOR

SQLNAME = COL2

SQLTYPE = INTEGER

SQLVAR3

SQLLEN = 4

SQLNAME = COL3

SQLVAR 1

Figure 28. DESCRIBE PROCEDURE Statement

The DESCRIBE CURSOR statement should be used when the column names and

data types of a particular result set are unknown. After execution of the DESCRIBE

CURSOR statement, the contents of the SQLDA are similar to the execution of a

SELECT statement:

v The first 5 bytes of the SQLDAID are set to ’SQLRS’.

v SQLD contains the number of columns for this result set.

v Each SQLVAR entry gives information about a column.

In an SQLVAR entry:

v The SQLTYPE field contains the data type of the column.

v The SQLLEN field contains the length attribute of the column.

v The SQLNAME field contains the name of the column.

v The cursor name in the statement must have been previously allocated through

the ALLOCATE CURSOR statement.

Coding Summary to Process Result Sets

The following summarizes the steps to code a client application to process result

sets:

1. Declare a result set locator variable for each result set that is returned. If the

number of result sets is unknown, declare enough locator variables for the

maximum number of result sets that might be returned.

2. Call the stored procedure and check the SQL return code for a +466. A 466

SQLCODE indicates that the stored procedure returned one or more result sets.

Chapter 3. Coding the Body of a Program

107

Determine how many result sets the stored procedure is returning if this is

unknown. Use the SQL statement DESCRIBE PROCEDURE to determine the

number of result sets returned and the corresponding cursor names. DESCRIBE

PROCEDURE places information about the result sets in the SQLDA.

Associate result set locators to result sets.

Allocate cursors for fetching rows from the result sets.

Determine the contents of the result sets if unknown. Use the SQL statement

DESCRIBE CURSOR to determine the format of a result set and put this

information in an SQLDA. For each result set, an SQLDA big enough to hold

descriptions of all columns in the result set is needed. If the DESCRIBE

PROCEDURE statement is not used, host variables of the correct datatype and

size must be provided to receive the result sets.

Fetch rows from the result sets into host variables by using the cursors you

allocate with the ALLOCATE CURSOR statements. If the DESCRIBE CURSOR

statement is executed before the FETCH, the following steps should be

performed before fetching any rows:

v Allocate storage for host variables and indicator variables. Use the content of

the SQLDA from the DESCRIBE CURSOR statement to determine how much

storage you need for each host variable.

v Put the address of the storage for each host variable in the appropriate

SQLDATA field of the SQLDA.

v Put the address of the storage for each indicator variable in the appropriate

SQLIND field in the SQLDA.

Fetching rows from a result set is the same as fetching rows from a table.

Close all allocated cursors when finished processing the result sets.

The following sections are examples of C language code that accomplish each of

the steps discussed above.

Processing a Known Number of Result Sets: The following example of C

language code shows how to receive result sets when the number of result sets

returned is known. Coding for other languages is similar.

/*************************************************************/

/* Declare result set locators. For this example,

/* assume you know that two result sets will be returned.

/* Also, assume that you know the format of each result set. */

/*************************************************************/

EXEC SQL BEGIN DECLARE SECTION;

static volatile SQL TYPE IS RESULT_SET_LOCATOR *loc1, *loc2;

EXEC SQL END DECLARE SECTION;

/*************************************************************/

/* Call stored procedure P1.

/* Check for SQLCODE +466, which indicates that result sets

/* were returned.

/*************************************************************/

EXEC SQL CALL P1(:parm1, :parm2, ...);

if(SQLCODE==+466)

{

/*************************************************************/

/* Establish a link between each result set and its

/*************************************************************/

/* Associate a cursor with each result set.

/*************************************************************/

108

Application Programming

EXEC SQL ALLOCATE C1 CURSOR FOR RESULT SET :loc1;

EXEC SQL ALLOCATE C2 CURSOR FOR RESULT SET :loc2;

/*************************************************************/

/* Fetch the result set rows into host variables.

/*************************************************************/

while(SQLCODE==0)

{

EXEC SQL FETCH C1 INTO :order_no, :cust_no;

}

while(SQLCODE==0)

{

EXEC SQL FETCH C2 :order_no, :item_no, :quantity;

}

/*************************************************************/

/* All result sets have been processed, close allocated

/* cursor.

/*************************************************************/

EXEC SQL CLOSE C1;

EXEC SQL CLOSE C2;

}

Processing a Unknown Number of Result Sets: The following example of C

language code shows how to receive result sets when the number of result sets

returned, or what is in each result set, is unknown.

/*************************************************************/

/* Declare result set locators. For this example,

/* assume that no more than three result sets will be

/* returned, so declare three locators. Also, assume

/* that you do not know the format of the result sets.

/*************************************************************/

EXEC SQL BEGIN DECLARE SECTION;

static volatile SQL TYPE IS RESULT_SET_LOCATOR *loc1, *loc2, *loc3;

EXEC SQL END DECLARE SECTION;

/*************************************************************/

/* Call stored procedure P2.

/* Check for SQLCODE +466, which indicates that result sets

/* were returned.

/*************************************************************/

EXEC SQL CALL P2(:parm1, :parm2, ...);

if(SQLCODE==+466)

{

/*************************************************************/

{

/*************************************************************/

/* Determine how many result sets P2 returned, using the

/* statement DESCRIBE PROCEDURE.

:proc_da is an SQLDA

/* with enough storage to accommodate up to three SQLVAR

/* entries.

/*************************************************************/

EXEC SQL DESCRIBE PROCEDURE P2 INTO :proc_da;

/*************************************************************/

/* Now that you know how many result sets were returned,

/* establish a link between each result set and its

/* locator using the ASSOCIATE LOCATORS. For this example,

Chapter 3. Coding the Body of a Program

109

/* we assume that three result sets are returned.

/*************************************************************/

EXEC SQL ASSOCIATE LOCATORS (:loc1, :loc2, :loc3) WITH PROCEDURE

P2;

/*************************************************************/

/* Associate a cursor with each result set.

/*************************************************************/

EXEC SQL ALLOCATE C1 CURSOR FOR RESULT SET :loc1;

EXEC SQL ALLOCATE C2 CURSOR FOR RESULT SET :loc2;

EXEC SQL ALLOCATE C3 CURSOR FOR RESULT SET :loc3;

/*************************************************************/

/* Use the statement DESCRIBE CURSOR to determine the

/* format of each result set.

/*************************************************************/

EXEC SQL DESCRIBE CURSOR C1 INTO :res_da1;

EXEC SQL DESCRIBE CURSOR C2 INTO :res_da2;

EXEC SQL DESCRIBE CURSOR C3 INTO :res_da3;

/*************************************************************/

/* Assign values to the SQLDATA and SQLIND fields of the

/* SQLDAs that you used in the DESCRIBE CURSOR statements.

/* These values are the addresses of the host variables and

/* indicator variables into which DB2 will put result set

/* rows.

/*************************************************************/

/* Fetch the result set rows into the storage areas

/* that the SQLDAs point to.

/*************************************************************/

while(SQLCODE==0)

{

EXEC SQL FETCH C1 USING :res_da1;

}

while(SQLCODE==0)

{

EXEC SQL FETCH C2 USING :res_da2;

}

while(SQLCODE==0)

{

EXEC SQL FETCH C3 USING :res_da3;

}

/*************************************************************/

/* All result sets have been processed, close allocated

/* cursor.

/*************************************************************/

EXEC SQL CLOSE C1;

EXEC SQL CLOSE C2;

EXEC SQL CLOSE C3;

}

110

Application Programming

Chapter 4. Preprocessing and Running a DB2 Server for VM

Program

Defining the Steps to Execute the Program . . .

112

Selecting the Isolation Level to Lock Data

134

Comparing Single User Mode to Multiple User

Using the Blocking Option to Process Rows

Mode

112

in Groups

139

Using 31-Bit Addressing

112

Using the INCLUDE Statement

141

Initializing the User Machine

113

Including External Source Files

141

Using VM Implicit Connect

113

Including Secondary Input

141

Preprocessing the Program

114

Compiling the Program

142

Using the SQLPREP EXEC Procedure

114

Link-Editing and Loading the Program

142

Executing the SQLPREP EXEC in Single User

Link-Editing the Program with DB2 Server for

Mode

114

VM TEXT Files

143

Executing the SQLPREP EXEC in Multiple

Using the Resource Adapter Stub Routine

143

User Mode

115

Using Other TEXT Files

143

DB2 Server for VM Program Preparation

Including the TEXT File in the Link-Editing . .

143

Parameters

115

Using the CMS LOAD Command

143

Parameters for SQLPREP EXEC for Single

Using the CMS TXTLIB Command

144

and Multiple User Modes

118

Creating a Load Module Using the CMS

Parameters for SQLPREP EXEC for Single

GENMOD Command

144

User Mode Only

130

Running the Program

144

Parameters for SQLPREP EXEC in Multiple

Using a Consistency Token

144

User Mode Only

131

Loading the Package and Rebinding

145

Preprocessing and bindfile

131

Using Multiple User Mode

145

Preprocessing with an Unlike Application Server

132

Using Single User Mode

146

Using the Preprocessor Option File

132

Specifying User Parameters in Single User Mode

147

Using the Flagger at Preprocessor Time

133

Distributing Packages across Like and Unlike

Improving Performance Using Preprocessing

Systems

147

Parameters

134

Binding to Create Package

148

111

Defining the Steps to Execute the Program

This section discusses the factors involved in preparing a DB2 Server for VM

application program for operation. The major steps are:

1. Preprocessing

2. Compiling

3. Link-editing and loading

4. Running.

If preprocessing is performed with ″BIND″ and ″NOPACKAGE″ preprocessing

parameters, then additional Binding step is must before Running step to execute

the program successfully.

Note: Program preparation for FORTRAN language is not suported using Binding

step.

You also have to consider a few points before creating a DB2 Server for VM

package. They are:

v Running in single or multiple user mode

v Initializing your machine

v Using VM implicit connect.

Comparing Single User Mode to Multiple User Mode

One important factor that affects how application programs are preprocessed and

executed is whether the database manager is running in single or multiple user

mode.

Running a Program in Single User Mode

In single user mode, the system and your application programs run in a single

virtual machine. The application or preprocessor starts the database machine,

processes the SQL statements, and returns control to CMS. The application server

must be restarted for every invocation of an application program or preprocessor.

The database machine may have more than one application server defined for it,

but only a single application server can be active at any time.

Running a Program in Multiple User Mode

In multiple user mode, one or more applications concurrently access the same

application server. The system runs in one virtual machine while one or more DB2

Server for VM application programs or preprocessors operate in other virtual

machines. More than one application can access the same application server at the

same time, and an application program can access more than one application

server. Use the CONNECT statement to switch application servers from within an

application. This facility is called switching application servers (see “Switching

Application Servers” on page 302).

Using

31-Bit Addressing

The addressing mode of the application server is established when the application

server is started. The addressing mode of the application server is determined by

the information stored in the addressing mode (AMODE) field of the SQLDBN file

associated with the application server.

112

Application Programming

The addressing mode of the application requester is always 31-bit addressing.

Single user mode applications are invoked in the addressing mode of the

application server. If your single user mode application or user exit requires 24-bit

addressing and the addressing mode of the application server is 31-bit, you will

need to change the operating mode or the addressing mode of the application

server.

If the addressing mode of the application server does not match the addressing

mode of the single user mode application, errors may result.

Refer to the DB2 Server for VM System Administration manual for information on

single user mode, user exits, and how to determine and change the addressing

mode. To determine your dependencies on 24-bit addressing, see the VM/ESA:

CMS Application Migration Guide manual.

Initializing the User Machine

To preprocess or run a DB2 Server for VM application program in multiple user

mode, you must associate your user ID with the application server that you want

your program to access. To do this, specify the application server in the SQLINIT

EXEC.

You need only do this once, as long as you continue to operate on the same

application server or are using the CONNECT statement to switch application

servers. Even if you log off and log back on to your virtual machine, you retain

your association with the application server that was established by the SQLINIT

EXEC (the association is recorded on your A-disk).

If you want to switch to a different application server and cannot use the

CONNECT statement to do so, you must end your application program and

invoke the SQLINIT EXEC again, specifying the new application server.

For information on the SQLINIT EXEC, refer to the DB2 Server for VSE & VM

Database Administration manual.

Using VM Implicit Connect

In the VM environment, an explicit CONNECT statement is not required. Instead,

the database manager accepts the password verification of the VM virtual machine

and uses the VM user ID as the DB2 Server for VM user ID. This support is called

“implicit connect.” Implicit connect is possible if either the special user ID

ALLUSERS or the individual users have been granted CONNECT authority.

For example, assume the following GRANT statement:

GRANT CONNECT TO A, B, C, ALLUSERS

After this statement, any VM user may be implicitly connected to the system.

However, if the following statement is used, only users A, B, C can be implicitly

connected to the system:

REVOKE CONNECT FROM ALLUSERS

Thus, the special user ID “ALLUSERS” can be used to selectively turn the implicit

connect capability on or off for the total user set, while individual users can retain

implicit connect authority.

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

113

If no explicit CONNECT is performed, an implicit connect occurs when the

database manager receives a request to execute the first executable SQL statement.

If the implicit connect is processed successfully, the statement is executed. As a

result, the SQLCA contains information on the status of the execution of that

statement. Information regarding warning conditions encountered while the

connection was processed is lost. If the connection fails, the SQLCA contains

information on the status of the connection.

Preprocessing the Program

Preprocessing does two things:

v It changes the SQL source code so that it can be processed during host language

compiling

v It converts the SQL statements into a package, and binds the package to the

database.

The preprocessor replaces all the SQL statements in the program with host

language code that invokes the new package. The new version of the program also

contains the SQL statements in comment form. The package contains information

to carry out the SQL requests made by the program. The database manager follows

the best access path to the data for each SQL statement in the program, using

available indexes and data statistics of which the system keeps track.

When the program is run, the new code calls the system to handle each SQL

statement. It also links the program to the application server and translates

messages and statements between the two.

Using the SQLPREP EXEC Procedure

The SQLPREP EXEC is used in both single and multiple user mode to preprocess

application programs.

The preprocessors supplied with the database manager have the following

program names:

ASM

Assembler Preprocessor

C Preprocessor

COBOL

COBOL Preprocessor

Fortran

Fortran Preprocessor

PLI

PL/I Preprocessor

The preprocessor takes source program input from SYSIN, and produces a

modified source program, a source listing, and a package in the database. The

modified source program output is sent to SYSPUNCH, and the source listing to

SYSPRINT. Using the SQLPREP EXEC, you can direct SYSIN, SYSPUNCH, and

SYSPRINT to various virtual devices and CMS files.

The syntax diagram on page “DB2 Server for VM Program Preparation

Parameters” on page 115 lists all the parameters for the SQLPREP EXEC. An

explanation of each parameter follows the figure.

Executing the SQLPREP EXEC in Single User Mode

In single user mode, the SQLPREP EXEC is executed on the database machine.

(The DBname parameter indicates that you are in single user mode, and identifies

114

Application Programming

the application server that you want to access.) The SQLPREP EXEC then issues an

SQLSTART and passes the DBname parameter. If the preprocessor encounters no

errors (warnings are permissible), a package is created or replaced on the specified

application server.

Executing the SQLPREP EXEC in Multiple User Mode

Use the SQLPREP EXEC in multiple user mode to preprocess an application

program on one or more application servers. Use the SQLINIT EXEC to establish

the default application server. If you want to preprocess your application program

on other application servers, use the DBList or DBFile parameter to specify the

other application servers on which you want to preprocess your application. Either

of these parameters temporarily overrides the application server specified by the

SQLINIT EXEC.

For each application server specified, the SQLPREP EXEC:

1. Establishes a link to the application server

2. Preprocesses the application program against the application server

3. Displays summary messages showing the results for this preprocessing step.

A package is created for each application server on which the program was

successfully preprocessed. If an error is encountered during preprocessing on one

of these application servers, and the ERROR parameter was not specified, a

package is not created for that application server. See page 122 for a discussion of

the ERROR option.

When the SQLPREP EXEC is used for more than one application server, only one

copy of the modified source program output is retained (the PUNCH parameter),

but all the source listings (the PRINT parameter) are appended to produce a single

source listing. The NOPUNCH and NOPRINT parameters may be used to

suppress modified source program output and source listings, respectively.

DB2 Server for VM Program Preparation Parameters

The following are parameters for all DB2 Server for VM preprocessors unless

otherwise noted.

►► SQLPREP

ASM

PrepParm

►

COBol

FORTran

PLI

► ( PREPname=

package_id

►

collection_id.

►

,PrepFile=

(

fileparms

)

prepparms

►

)

►

,USERid= authorization_name/password

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

115

►

sysIN

(

fileparms

)

sysPRint

(

fileparms

)

Reader

Printer

Terminal

►

sysPUnch

(

fileparms

)

sysBInd

(

fileparms

)

Punch

(1)

(2)

►

multiple-user-mode-parms

►◄

(2)

single-user-mode-parms

Notes:

Optional for multiple-user-mode.

Valid for DB2 Server for VM only.

fileparms:

filename

filetype

filemode

prepparms:

,APOST

,NOBIND

,SBLocK

►

(1)

,BIND

,BLocK

,CCSIDGraphic

(integer)

,Quote

,NOBLocK

►

,CCSIDMixed

(integer)

,CCSIDSbcs

(integer)

,NOCHECK

(1)

►

,CHARSUB

(

Sbcs

)

,CHECK

(1)

,COBRC

Mixed

,ERROR

,COB2

Bit

,CTOKEN

(NO)

,NOEXIST

►

,CTOKEN

(

)

,DATE

(

EUR

)

,EXIST

YES

ISO

JIS

LOCAL

USA

,EXPLAIN

(NO)

►

,EXPLAIN

(

)

(2)

(3)

YES

,NOFOR

,DYNALC

116

Application Programming

Notes:

COBOL only (DB2 Server for VM only).

Implied if STDSQL(89) is specified for DB2 Server for VM.

COBOL, PL/I, C, and Assember only.

prepparms (continued):

,NOGRaphic

,ISOLation

(RR)

,KEEP

►

(1)

,ISOLation

(

)

,REVOKE

,GRaphic

(2)

USER

,LineCount

(60)

►

,LABEL

(label_text)

,LineCount

(integer)

,PACKAGE

,PERiod

►

(2)

,NOPACKAGE

(2)

,OWner

(authorization_name

)

,COMma

,PRint

,PUnch

►

,NOPRint

,NOPUnch

(2)

,QUALifier

(collection_id

)

,RELease

(COMMIT)

,REPLACE

,SEQuence

►

,RELease

(

COMMIT

)

,NEW

(3)

(2)

,NOSEQuence

DEALLOCATE

,SQLApost

►

(2)

(4)

(5)

,SQLQuote

,NOSQLCA

,STDSQL

(NO)

►

,SQLFLAG

(

SAA

)

,STDSQL

(

)

(6)

(COMPLETE)

►

,TIME

(

EUR

)

ISO

JIS

LOCAL

USA

Notes:

COBOL and PL/I only (DB2 Server for VM only).

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

117

Only meaningful for a non-DB2 Server for VM or -DB2

Server for VSE

application server.

C only.

COBOL only.

Implied if STDSQL(89) is specified.

86 is a synonym for 89.

multiple-user-mode-parms:

DBFile

(

fileparms

)

DBList

(

▼

server_name

)

single-user-mode-parms:

Dbname

(server_name)

►

dcssID

(dcss_id)

►

LOGmode

(

)

PARMID

(filename)

Parameters for SQLPREP EXEC for Single and Multiple User

Modes

The parameters for the SQLPREP EXEC that apply to both single and multiple user

mode are described below. When choosing names within any of these parameters,

avoid whatever line-end-delimiter character (normally #) is being used in your

installation.

ASM

COBol

FORTran

PLI

This parameter identifies to the EXEC the preprocessor to be executed. This

parameter is required, and must be specified first. The order in which you specify

the other keywords is not important.

PREPname=package_id

PREPname=collection_id.package-id

The collection_id.package_id is the name by which the database manager

identifies the package. The collection_id portion is optional, and fully qualifies

the package_id and any unqualified objects referenced within the package.

If collection_id is not specified, it defaults to the user’s authorization ID at the

application requester site. In the database manager, however, an object’s

collection_id must be the same as the user’s authorization ID at the application

server site. If the collection_id does not match the application server

authorization ID, a preprocessing error results. This restriction does not apply

if the application server authorization ID has DBA authority.

118

Application Programming

The authorization ID at the application requester and application server sites is

the authorization_name specified on the USERid parameter. If the USERid

parameter is not specified, the authorization ID is the VM logon ID at the

application requester site. In some situations, the VM logon ID is converted

before it is received at the application server site. If the authorization ID is the

VM logon ID, the conversion can cause the authorization IDs at each site to

differ.

To avoid a situation in which the collection_id does not match the application

server authorization ID, explicitly state the collection_id equal to the application

server authorization ID.

For information on how to determine the authorization ID at the application

server site, refer to the DB2 Server for VM System Administration and the

Distributed Relational Database Connectivity Guide manuals.

USERid=authorization_name/password

The authorization_name is the name by which the application server identifies

the owner of a package. The password should agree with the one established

for this authorization_name by a DB2 Server for VM GRANT CONNECT

statement. This information is used when executing a CONNECT statement to

gain access to the application server, which determines whether proper

authorization exists for the static SQL statements in the program.

If the USERid option is not specified, refer to the DB2 Server for VM System

Administration manual, Chapter 6, Maintaining Database Security, for more

information about how to resolve the userid and password.

PrepFile=(filename)

PrepFile=(filename filetype)

PrepFile=(filename filetype filemode)

The PrepFile parameter identifies the file name (and optionally the file type

and file mode) of the CMS (or SFS) file containing the list of preprocessor

parameters. If filetype is not specified, PREPPP is used as the default. If filemode

is not specified, A is used as the default and the first file found with the

default file name and file type are used. For a detailed discussion of the

options file, see “Using the Preprocessor Option File” on page 132.

The following parameters can be specified in the PrepFile or on the command

line.

PrepParm

These parameters specify the preprocessor options.

APOST

Quote (COBOL preprocessor only)

You must include the Quote preprocessor parameter whenever you use the

Quote parameter in the COBOL compiler. Quote causes the preprocessor to

use double quotation marks (") as constant delimiters in the VALUE

clauses of the declarations it generates. If you do not specify this

parameter, the COBOL preprocessor defaults to APOST, and generates

single quotation mark (') delimiters for its internal source declarations.

The use of a single or double quotation marks in SQL statements is not

affected by this parameter. APOST/Quote is stored in the bind file header

if BIND is specified and a bind file is successfully created after

preprocessing.

NOBIND

BIND

When the NOBIND parameter is specified, the preprocessor does not create

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

119

a bindfile; NOBIND is the default. When the BIND parameter is specified,

the preprocessor creates a bindfile. One bindfile per program is created

irrespective of number of target databases. The bindfile will not be created

if NOCHECK is in effect and there was an error found during SQL

statement validation. BIND is ignored if CHECK is specified. For a more

detailed discussion of the bind file, see “Preprocessing and bindfile” on

page 131 and “Binding to Create Package” on page 148.

Note: The Fortran preprocessor ignores the BIND parameter, if specified.

NOBLocK

BLocK

SBLocK

IBLocK

When the BLocK parameter is specified under private protocol , all eligible

query cursors return results in groups of rows, and all eligible insert

cursors process inserts in groups of rows. When BLocK parameter is

specified under DRDA, all eligible PUT statements are grouped together

for processing.

When the IBLocK parameter is specified under DRDA, all eligible

homogenous Insert statements are grouped together for processing.

Homogenous insert statements are defined as a set of insert statements

that:

v Access the same DB2 table

v Access the same set of columns in that table, in the same order

There must be an ’SQL COMMIT’ statement after a set of homogenous

insert statements. This causes the buffer to be sent, processed by the DB2

UDB server and the response is received and parsed by the application

requester.

The IBLocK parameter does not work under private protocol.

This improves the performance of programs running in multiple user

mode, where many rows are inserted or retrieved. For a discussion of

eligible cursors, see “Using the Blocking Option to Process Rows in

Groups” on page 139.

When NOBLocK is specified, rows are not grouped.

BLock/NOBLock is stored in the bind file header, if BIND is specified and

a bind file is successfully created after preprocessing. If you want to

change the BLocK option, you must recompile (or reassemble), and relink

your program after preprocessing it. You must also use SQLBIND or

rebuild the package if BIND is specified. Preprocessing alone does not

change the BLocK setting. You must also use SQLBIND to rebuild the

package if BIND is specified.

SBLocK is primarily for use with application servers that support the FOR

FETCH ONLY clause on the DECLARE CURSOR statement. When SBLock

is specified, all eligible cursors return results in group of rows. This is the

default.

Following is a comparison of the BLocK and SBLocK options as they apply

to the DB2 Server for VM preprocessors:

120

Application Programming

v If there are COMMIT, ROLLBACK, or dynamically defined statements in

a program, then:

- With BLocK, all eligible cursors are blocked (that is, the data on

which the cursor operates is transferred in groups of rows).

- With SBLocK, the FOR FETCH ONLY clause of the DECLARE

CURSOR statement can be used to select the cursors that are to be

blocked. Cursors without this clause are not blocked.

v If there are no COMMIT, ROLLBACK, or dynamically defined

statements in a program, the effects of BLocK and SBLocK are the same:

all eligible cursors are blocked.

Note: Only the DB2 Server for VM preprocessors turn off SBLocK blocking

because of the presence of COMMIT and ROLLBACK statements. In

non-DB2 Server for VM preprocessors, only the presence of

dynamically defined statements has this effect.

If you want to change the BLocK option, you must recompile (or

reassemble) and relink your program after preprocessing it. Preprocessing

alone does not change the BLocK setting.

The blocking of FETCH statements is supported both with the DRDA

protocol and SQLDS protocol. The blocking of PUTs is supported both

with DRDA and SQLDS protocols. The blocking of INSERT statements is

supported only with DRDA protocol and not with SQLDS. See “Using the

Blocking Option to Process Rows in Groups” on page 139 for guidelines on

deciding the programs for which to specify blocking.

CCSIDGraphic (integer)

This parameter specifies the default CCSID attribute to be used for graphic

columns created in the package, if an explicit CCSID is not specified on the

CREATE or ALTER statements in the package. If this parameter is not

specified, the target application server uses the system default. This option

is stored in the bind file header if BIND is specified and a bind file is

successfully created after preprocessing.

CCSIDMixed (integer)

This parameter specifies the default CCSID attribute to be used for

character columns created with the mixed subtype in the package, if an

explicit CCSID is not specified on the CREATE or ALTER statements in the

package. If this parameter is not specified, the target application server

uses the system default. This option is stored in the bind file header if

BIND is specified and a bind file is successfully created after

preprocessing.

CCSIDSbcs (integer)

This parameter specifies the default CCSID attribute to be used for

character columns created with the SBCS subtype in the package, if an

explicit CCSID is not specified on the CREATE or ALTER statements in the

package. If this parameter is not specified, the target application server

uses the system default. This option is stored in the bind file header if

BIND is specified and a bind file is successfully created after

preprocessing.

CHARSUB (Sbcs)

CHARSUB (Mixed)

CHARSUB (Bit)

This parameter specifies the character subtype attribute to be used for

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

121

character columns created in the package, if an explicit subtype or CCSID

is not specified. If you do not specify this parameter, the target application

server uses the system default. This option is stored in the bind file header

if BIND is specified and a bind file is successfully created after

preprocessing.

NOCHECK

CHECK

ERROR

If you specify the NOCHECK parameter, the preprocessor executes

normally; that is, it validates all SQL statements when performing package

functions. If NOPACKAGE is specified, package functions are not

performed and so NOCHECK is ignored in this case. NOCHECK will be

stored in the BIND file header if BIND is specified and a bind file is

successfully created after preprocessing; NOCHECK is the default.

If you specify the CHECK parameter, the preprocessor checks all SQL

statements for validity and generates error messages if necessary, but does

not generate a package or bind file. PACKAGE and BIND are ignored if

CHECK is specified.

If you specify ERROR, the preprocessor executes normally except that most

statement-parsing errors are tolerated. When one of these errors is

detected, the preprocessor generates an error message in the output listing

and the modified source code in commented form, and continues

processing. The program can be compiled and executed, but the erroneous

statement cannot be executed. If NOPACKAGE is specified, package

functions are not performed and so ERROR is ignored in this case. ERROR

will be stored in the bind file header if BIND is specified and a bind file is

successfully created after preprocessing. You should use the ERROR option

when you are also generating a bind file and intend to bind it against a

remote application server, where at least one statement in the program is

specific to an unlike application server.

COB2 (COBOL preprocessor only)

This parameter enables you to use certain COBOL II functions that are

supported by the COBOL II Release 3 compiler and later. Refer to “Using

the COB2 Parameter (DB2 Server for VM)” on page 360 for a list of those

functions.

COBRC (COBOL preprocessor only)

If this parameter is specified, the preprocessor will generate the statement

'MOVE ZEROS TO RETURN-CODE' after it generates a call to ARIPRDI.

For more information, see “Using the COBRC Parameter” on page 361

CTOKEN (NO)

CTOKEN (YES)

This parameter causes the preprocessor to store a consistency token in the

modified source code and the package. At run time, consistency tokens in

the program’s load module and package must match before the application

server executes the package. CTOKEN(NO) is the default. If CTOKEN(YES)

is specified, the consistency token generated by the preprocessor will be an

8-byte 390 Time-of-Day (TOD) clock value. If CTOKEN(NO) is specified,

the consistency token will be 8 blanks. For a more detailed discussion of

consistency tokens, see “Using a Consistency Token” on page 144. This

option is stored in the bind file header if BIND is specified and a bind file

is successfully created after preprocessing.

DATE (EUR)

122

Application Programming

DATE (ISO)

DATE (JIS)

DATE (LOCAL)

DATE (USA)

If this parameter is specified, the output date format chosen overrides the

default format specified at installation time; otherwise, all dates will be

returned in the default format specified at installation time. (See the DB2

Server for VSE & VM SQL Reference manual for a description of these

formats.) This option is stored in the bind file header if BIND is specified

and a bind file is successfully created after preprocessing.

NOEXIST

EXIST

If the EXIST parameter is specified, the preprocessor executes normally;

that is, it generates modified source code and performs package functions.

An error will be generated if objects (such as tables) referenced in

statements in the program do not exist or if proper authorization does not

exist.

If the NOEXIST parameter is specified, object and authorization existence

is not required, and if not found, a warning will be issued. NOEXIST is the

default. NOEXIST/EXIST is stored in the bind file header if BIND is

specified and a bind file is successfully created after preprocessing.

EXPLAIN(NO)

EXPLAIN(YES)

This parameter specifies whether explanatory information for all

explainable SQL statements in a package should be produced.

EXPLAIN(NO) is the default.

If EXPLAIN(YES) is specified, each explainable SQL statement in the

program is explained during preprocessing. If you specify EXPLAIN(YES),

an EXPLAIN ALL is executed. The complete set of explanation tables must,

therefore, be available. If they are not available, you receive an SQLCODE

-649

(SQLSTATE = 42704) and preprocessing is not successful. To interpret

the explanation tables, refer to the DB2 Server for VSE & VM Performance

Tuning Handbook manual. This option is stored in the bind file header if

BIND is specified and a bind file is successfully created after

preprocessing.

NOFOR

This parameter enables you to omit the FOR UPDATE OF clause in the

static cursor query statement, and execute positioned updates to any

column in the result table for which you have UPDATE authority. It is

referred to in this manual as NOFOR support.

Note: This option is also implied if the STDSQL (89) or STDSQL (86)

parameter is specified.

DYNALC

This parameter enables you to preprocess an application program

containing FETCH statements for a cursor that is allocated by a dynamic

ALLOCATE CURSOR statement.

Note: This option is only accepted by the COBOL, PL/I, C, and Assembler

preprocessors.

NOGRaphic

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

123

GRaphic (COBOL and PL/I preprocessors only)

The GRaphic parameter indicates to the preprocessor whether graphic

constants can be used in SQL statements and whether DBCS string format

should be validated. NOGRaphic is the default.

If GRaphic is specified, the preprocessor accepts SQL statements containing

graphic constants, and checks that all strings of DBCS characters are

correctly formatted.

If NOGRaphic is specified, the preprocessor does not allow graphic

constants in SQL statements, and does not verify the format of strings of

DBCS characters.

Note: If the DBCS parameter of the SQLINIT EXEC is specified as YES, the

graphic option is not used and preprocessing occurs as though

GRaphic had been specified. Refer to “Initializing the User Machine”

on page 113 for a discussion of the SQLINIT EXEC.

ISOLation (RR)

ISOLation (CS)

ISOLation (RS)

ISOLation (UR)

ISOLation (USER)

This parameter lets you specify one of the following isolation levels at

which your program runs:

v Specify RR (repeatable read) to have the database manager hold a lock

on all data read by the program in the current logical unit of work. This

is the default.

v Specify CS (cursor stability) to have the database manager hold a lock

only on the row or page of data pointed to by a cursor.

v Specify UR (uncommitted read) to have the database manager allow

applications to read data without locking, including uncommitted

changes made by other applications.

v RS (read stability) is not supported by application servers. For a

description of RS, see the IBM SQL Reference manual.

v Specify USER to have the application program control its isolation level.

You cannot specify the USER option when you are using DRDA protocol

(if you do, it is ignored and the isolation level defaults to CS).

See “Selecting the Isolation Level to Lock Data” on page 134 for guidelines

on choosing the isolation level for your program. This option is stored in

the bind file header if BIND is specified and a bind file is successfully

created after preprocessing.

Note: If you want to change the ISOLation option, you must recompile (or

reassemble) and relink your program after preprocessing it.

Preprocessing alone does not change the ISOLation setting. You

must also use Binder to rebuild the package if BIND is specified.

Preprocessing alone does not change the ISOLation setting.

KEEP

REVOKE

These parameters are applicable if the program has previously been

preprocessed, and the owner has granted the RUN privilege on the

resulting package to some other users. Specify the KEEP parameter to have

these grants of the RUN privilege remain in effect when the preprocessor

produces the new package. Specify the REVOKE parameter to remove all

124

Application Programming

existing grants of the RUN privilege. (These grants will also be removed if

the owner of the program is not entitled to grant all the privileges

embodied in the program.)

KEEP is the default. KEEP/REVOKE is stored in the bind file header if

BIND is specified and a bind file is successfully created after

preprocessing.

LABEL (label_text)

This parameter specifies a label for the package. Label_text can be up to 30

characters in length; the default is spaces. This option is stored in the bind

file header if BIND is specified and a bind file is successfully created after

preprocessing.

LineCount (integer)

The parameter determines how many lines per page are to be printed in

the output listing. The value integer specifies the number of lines per page.

The valid range for this value is 10 to 32 767. If no value is specified, or if

there is an error in the specification of the LineCount parameter, then the

default value of 60 is used.

OWner (authorization_name)

This parameter specifies the authorization_name of the owner of the package

being created. The OWner parameter is to be used when you are

preprocessing against a non-DB2 Server for VM application server.

However, if you specify this parameter when preprocessing against an

application server, the authorization_name must be the same as the

application server authorization ID. If this parameter is not specified, the

application server selects the default.

See the section on PREPname on page 118 for a discussion on application

server and application requester authorization IDs.

PACKAGE

NOPACKAGE

If you specify the PACKAGE parameter, the preprocessor performs

package functions and creates a package against a local database.

PACKAGE is ignored if CHECK is specified; PACKAGE is the default. If

you specify the NOPACKAGE parameter, the preprocessor does not

perform package functions and will not create a package. If you specify

NOCHECK as well as NOPACKAGE, NOCHECK is ignored. If you specify

ERROR as well as NOPACKAGE, ERROR is ignored.

PERiod

COMma

This parameter specifies the character that delimits decimals in SQL

statements. PERiod is the default.

For an application server, the only acceptable decimal delimiter is a period.

NOPRint

The PRint parameter specifies that the entire preprocessor modified source

listing output is produced. The NOPRint parameter specifies that the

preprocessor listing output is suppressed, except for the summary

messages that are normally printed at the end. PRint is the default.

PUnch

NOPUnch

The PUnch parameter specifies that the preprocessor modified source

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

125

output is produced. The NOPUnch parameter specifies that the

preprocessor modified source output is suppressed.

QUALifier (collection_id)

This parameter specifies the default collection_id to be used within the

package to resolve unqualified object names in static SQL statements.

The QUALifier parameter is meant to be used when preprocessing against

a non-DB2 Server for VM application server. If you specify this parameter

when preprocessing against an application server, the collection_id must be

the same as the application server authorization ID. If you do not specify

this parameter, the default is selected by the application server.

RELease (COMMIT)

RELease (DEALLOCATE)

This parameter specifies when the application server releases the package

execution resources and any associated locks.

For an application server, the only acceptable action is

RELEASE(COMMIT), which releases resources at the end of a logical unit

of work.

REPLACE

NEW

This parameter specifies whether the package being created is new or

whether it will replace an existing package that has the same name. If

REPLACE is specified and no previous package exists with the same name,

no error or warning is issued, and the package is created. REPLACE is the

default. If NEW is specified, an error will occur if the package already

exists with the same name. REPLACE/NEW is stored in the bind file

header if BIND is specified and a bind file is successfully created after

preprocessing.

Note: If NEW is specified along with KEEP or REVOKE, an error will

occur.

SEQuence

NOSEQuence (C preprocessor only)

If SEQuence is specified, the preprocessor searches only columns 1 through

72 of the source file. When NOSEQuence is specified, the preprocessor

assumes there are no sequence numbers in the input file and it accepts

input from columns 1 to 80. SEQuence is the default.

Note: In the latter case, you must use the NOSEQ and MARGINS (1,80) C

compiler options when compiling the modified source.

SQLApost

SQLQuote (COBOL preprocessor only)

This parameter specifies the character that delimits strings (quoted literals)

in SQL statements. SQLApost and SQLQuote are optional parameters.

SQLApost is the default.

For an application server, the only acceptable string delimiter is a single

quotation mark.

NOSQLCA

This parameter allows you to declare an SQLCODE without declaring all

of the SQLCA structure. It is referred to as NOSQLCA support in this

manual.

126

Application Programming

If you request NOSQLCA support, it is your responsibility to make sure

that there are no explicit declarations of the SQLCA in your application

program. For more information on using SQLCODE without the SQLCA,

refer to “Using the Automatic Error-Handling Facilities” on page 197.

Note: This option is also implied if the STDSQL(89) or STDSQL (86)

parameter is specified.

SQLFLAG (SAA)

SQLFLAG (89)

SQLFLAG (89(COMPLETE))

This parameter invokes Flagger, a function that flags those static SQL

statements that do not conform to the SQL-89 standard or IBM’s Systems

Application Architecture* (SAA*) standard on an SQL dialect. If you

specify SAA, it provides syntax checking against the SAA Database Level 1

standard. If you specify 89, it will provide syntax checking against the

SQL-89 standard. If you specify 89(COMPLETE), it will provide both

syntax and semantics checking against the SQL-89 standard. Note that you

cannot check both SAA and SQL-89 in the same preprocessor run.

See “Using the Flagger at Preprocessor Time” on page 133 for more details

on this facility, including an explanation of the SQL-89 standard.

STDSQL (NO)

STDSQL (89)

STDSQL refers to the SQL Standard that has been implemented in the

user’s application program. If NO is specified or the STDSQL parameter is

not used, the preprocessor uses DB2 Server for VM standards. If 89 is

specified, functions specific to ANS SQL standard 89 are also provided by

the preprocessor. STDSQL(NO) is the default. These functions consist of

the following support:

v NOSQLCA

v NOFOR

Note: STDSQL(86) is a synonym for STDSQL(89).

TIME (EUR)

TIME (ISO)

TIME (JIS)

TIME (LOCAL)

TIME (USA)

If this parameter is specified, the output time format chosen overrides the

default format specified during installation. If it is not specified, all times

will be returned in the default format that was specified during

installation. (See the DB2 Server for VSE & VM SQL Reference manual for a

description of these formats.) This option is stored in the bind file header if

BIND is specified and a bind file is successfully created after

preprocessing.

sysBInd

This parameter identifies the name of the bindfile that will be created after

successful completion of preprocessing with ″BIND″ parameter.

sysBInd (filename)

sysBInd (filename filetype)

sysBInd (filename filetype filemode)

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

127

This optional parameter identifies the filename (fn), and optionally the

filetype (ft) and filemode (fm), of the CMS bindfile. The filetype

specification defaults to ″BINDFILE″ and filemode defaults to A.

If this form of the sysBInd parameter is supplied, the following CMS

FILEDEF command is issued for the bindfile:

FILEDEF SYSBIND DISK fn ft fm . . .

(RECFM FB LRECL 80 BLOCK 800)

If this parameter is omitted, filename of the sysin parameter is used as fn,

while ft and fm default to ″BINDFILE″ and A respectively.

sysIN

Two choices exist:

sysIN( filename)

sysIN( filename filetype )

sysIN( filename filetype filemode )

This optional parameter identifies the filename (fn), and optionally the

filetype (ft) and filemode (fm), of the CMS file containing the

preprocessor source input. The filetype specification defaults to the

following:

ASM

ASMSQL

CSQL

COBOL

COBSQL

Fortran

FORTSQL

PL/I

PLISQL

The file mode specification will default to A.

The following CMS FILEDEF command is issued for the preprocessor

source input file:

FILEDEF SYSIN DISK fn ft fm (RECFM FB LRECL 80 BLOCK 800)

sysIN( Reader )

This specification of the sysIN optional parameter identifies that the

preprocessor source input file is a virtual reader file. The following

CMS FILEDEF command is issued for the preprocessor source input

file:

FILEDEF SYSIN READER (RECFM F LRECL 80)

Note: If the sysIN parameter is not specified, you must enter a CMS

FILEDEF command for the preprocessor source input

(ddname=SYSIN) before issuing the SQLPREP EXEC.

sysPRint

Five choices exist:

1. sysPRint( filename)

sysPRint( filename filetype )

sysPRint( filename filetype filemode )

This optional parameter identifies the filename (fn) and optionally the

filetype (ft) and filemode (fm) of the CMS file containing the preprocessor

source output listing. The filetype specification defaults to LISTPREP,

and the filemode specification to A.

128

Application Programming

If this form of the sysPRint parameter is supplied, the following CMS

FILEDEF command is issued for the preprocessor source output listing

file:

FILEDEF SYSPRINT DISK fn ft fm . . .

(RECFM FBA LRECL 121 BLOCK 1210 DISP MOD)

sysPRint( Printer )

This specification of the sysPRint optional parameter identifies that the

preprocessor source output listing file is directed to a virtual printer

file. If sysPRint(Printer) is specified, the following CMS FILEDEF

command is issued for the preprocessor source output listing file:

FILEDEF SYSPRINT PRINTER (RECFM FA LRECL 121)

sysPRint( Terminal )

This specification of the sysPRint optional parameter identifies that the

preprocessor source output listing file is directed to the console

terminal. If sysPRint(Terminal) is specified, the following CMS

FILEDEF command is issued for the preprocessor source output listing

file:

FILEDEF SYSPRINT TERM (RECFM FA LRECL 121)

If the sysPRint parameter is not specified and the preprocessor source

input file was assigned to the virtual reader, then the preprocessor

source output listing file is assigned to the virtual printer by the CMS

FILEDEF command described in item 2 above.

If the sysPRint parameter is not specified and the preprocessor source

input file was assigned to a CMS file, then the following default CMS

FILEDEF command is issued for the preprocessor source output listing

file:

FILEDEF SYSPRINT DISK fn LISTPREP A . . .

(RECFM FBA LRECL 121 BLOCK 1210 DISP MOD)

In this example, fn is the file name specification used for the

preprocessor SYSIN file, and file mode is defaulted to A.

Note: If sysPRint and sysIN information is not specified, then the user

must issue a CMS FILEDEF command for the preprocessor source

output listing file (ddname=SYSPRINT) before issuing the SQLPREP

EXEC.

sysPUnch

Four choices exist:

1. sysPUnch( filename)

sysPUnch( filename filetype )

sysPUnch( filename filetype filemode )

This optional parameter identifies the filename (fn) and optionally the

filetype (ft) and filemode (fm) of the CMS file containing the preprocessor

modified source output. The file type specification will default to a

value based on the preprocessor invoked as follows:

ASM

ASSEMBLE

COBOL

Fortran

PL/I

PLIOPT

The file mode specification will default to A.

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

129

If this form of the sysPUnch parameter is supplied, the following CMS

FILEDEF command is issued for the preprocessor modified source

output file:

FILEDEF SYSPUNCH DISK fn ft fm . . .

(RECFM FB LRECL 80 BLOCK 800)

2. sysPUnch( Punch )

This specification of the sysPUnch optional parameter identifies that the

preprocessor modified source output file is directed to a virtual punch

file. If sysPUnch(Punch) is specified, the following CMS FILEDEF

command is issued for the preprocessor modified source output file:

FILEDEF SYSPUNCH PUNCH (RECFM F LRECL 80)

3. If the sysPUnch parameter is not specified and the preprocessor source

input file was assigned to the virtual reader, then the preprocessor

modified source output file is assigned to the virtual punch with the

CMS FILEDEF command described above in item 2 above.

4. If the sysPUnch parameter is not specified and the preprocessor source

input file is assigned to a CMS file, then the following default CMS

FILEDEF command is issued for the preprocessor modified source

output file:

FILEDEF SYSPUNCH DISK fn ft A . . .

(RECFM FB LRECL 80 BLOCK 800)

In this example, fn is the file name specification used for the

preprocessor source input file, and file mode is defaulted to A. ft is the

default file type as determined by the previously mentioned method.

Note: If sysPUnch and sysIN information is not specified, then the user

must issue a CMS FILEDEF command for the preprocessor modified

source output file (ddname=SYSPUNCH) before issuing the

SQLPREP EXEC.

Parameters for SQLPREP EXEC for Single User Mode Only

The parameters for the SQLPREP EXEC that apply only to single user mode are:

DBname(dbname)

This mandatory parameter identifies the name of the application server to be

accessed by the SQL statements in the preprocessor source input file.

This parameter is used as the DBname parameter for the SQLSTART EXEC that

is executed when the database manager is started in single user mode. The

system initialization parameters SYSMODE=S and PROGNAME=progname

(where progname varies according to which preprocessor is being invoked)

will also be supplied in the PARM parameter of the SQLSTART EXEC.

dcssID(dcssid)

This parameter identifies the method by which all DB2 Server for VM modules

will be loaded for execution. If this parameter is specified, it will be used as

the dcssID parameter for the SQLSTART EXEC. If this parameter is omitted,

the dcssID parameter will not be passed to the SQLSTART EXEC.

Refer to the DB2 Server for VM System Administration manual for more

information.

LOGmode (Y)

LOGmode (A)

LOGmode (N)

LOGmode (L)

This parameter identifies the value to be used for the DB2 Server for VM

130

Application Programming

initialization LOGmode parameter when the database manager is started in

single user mode. If this parameter is omitted, the LOGmode parameter will

not be supplied as an initialization parameter to the SQLSTART EXEC.

Refer to the DB2 Server for VM System Administration manual for more

information.

PARMID (filename)

This parameter identifies the file name of a CMS file that contains DB2 Server

for VM initialization parameters. If this parameter is omitted, the PARMID

parameter will not be passed as a parameter to the SQLSTART EXEC.

Refer to the DB2 Server for VM System Administration manual for more

information.

Parameters for SQLPREP EXEC in Multiple User Mode Only

The parameters for the SQLPREP EXEC that apply only to multiple user mode are:

DBFile (filename)

DBFile (filename filetype)

DBFile (filename filetype filemode)

This optional parameter specifies the file name, the file type, and optionally the

file mode of a CMS file containing a list of application servers on which the

program will be preprocessed. If filetype is not specified, PREPDB will be used

as the default file type. If filemode is not specified, the first file with the given

filename and filetype will be used.

The rules governing the format of the CMS file are as follows:

v Each record has only one application server name.

v The first word in each record is the application server name.

v Comments can be added to the right of the application server name,

separated from the application server name by a blank. will be treated as a

comment.

v An empty record or a record with an ″*″ in the first position will be treated

as a comment.

DBList (server_name)

This optional parameter specifies a list of application servers on which the

program will be preprocessed.

Note that this parameter and the DBFile parameter are mutually exclusive.

Preprocessing and bindfile

When a program is preprocessed successfully with ″BIND″ preprocessing

parameter, preprocessor creates a bindfile that contains preprocessing parameters

and modified SQL statements. Preprocessor does not necessarily connect to an

application server for the creation of the bindfile. Preprocessor creates one file per

program that is preprocessed. The bindfile created in preprocessing step is served

as input to the binding process to create the package in any local or remote

application server.

The overall effect of parameters that decide creation of package and bindfile in

combination with few other prep parameters has been summarized below. Some of

the parameters, though not mutually exclusive, can override the effect of other

parameters. The table below mentions various combination of some parameters

that are allowed, but their composite effects are different.

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

131

Connection

with

database

Parameter1

Parameter2

Parameter3

Parameter4

Overall Effect

Action

required

BIND

PACKAGE

CHECK

ERROR

CHECK

Only syntax checking

BIND

NOPACKAGE

CHECK

ERROR

CHECK +

Only syntax checking

NOPACKAGE

NOBIND

PACKAGE

CHECK

ERROR

CHECK + NOBIND

Only syntax checking

NOBIND

NOPACKAGE

CHECK

ERROR

NOBIND +

Only syntax checking

NOPACKAGE +

CHECK

BIND

PACKAGE

NOCHECK

ERROR

ALL

Creates Bindfile &

YES

Package with error

tolerence

BIND

NOPACKAGE

NOCHECK

ERROR

BIND

Creates Bindfile

NOBIND

PACKAGE

NOCHECK

ERROR

ALL

Creates Package with

YES

error tolerence

NOBIND

NOPACKAGE

NOCHECK

ERROR

NOBIND +

None

NOPACKAGE

Preprocessing with an Unlike Application Server

The SQLPREP EXEC accepts only those parameters and options which are listed in

this manual. Some of those options are only meaningful to one or more of the

other IBM relational database server or servers. The SQLPREP EXEC does not filter

out options that are not applicable to an application server before sending them to

that application server.

Equivalent parameters and options for IBM relational database products are given

in the IBM SQL Reference manual. For example, the VALIDATE(BIND) parameter in

the DB2 product for z/OS and the EXIST parameter for the DB2 Server for VM

product are equivalent preprocessing parameters.

When the DB2 Server for VM system acts as an application server and receives an

unsupported preprocessing parameter value, it returns an error message to the

application requester.

Using the Preprocessor Option File

Instead of specifying all the preprocessing parameters (found in PrepParm) in the

SQLPREP EXEC you can use an options file. Maintaining a set of standard options

files has several advantages: they can save you time; they can ensure consistent use

of preprocessing parameters; and the number of parameters that you can use is not

limited by the number of positions on the command line.

You can use a preprocessor options file by including the PrepFile parameter when

you issue the PREP command. The file itself can contain only one preprocessor

parameter per line. If more are found an error message is returned. Blank lines are

ignored, and parameters may be in either upper or lower case. Comments may be

inserted into the options file by placing an asterisk (*) to the left of the comment.

Everything to the right of the asterisk is ignored. The file must be fixed blocked

and must have a record length of 80 bytes. Figure 29 on page 133 is an example of

a preprocessor option file.

132

Application Programming

DB2 Server for VSE & VM Application Programming (Version 7 Release 5) - page 3
