ACTR arithmetic_expression

►◄

sequence_symbol

Is a sequence symbol.

arithmetic_expression

Is an arithmetic expression used to set or reset a conditional assembly branch

counter.

A conditional assembly branch counter has a local scope; its value is decremented

by AGO and successful AIF instructions, and reassigned only by ACTR instructions

that appear within the same scope. Thus, the nesting of macros has no effect on the

setting of branch counters in other scopes. The assembler assigns a branch counter

for open code and for each macro definition. In the absence of an ACTR

instruction, a default value of 4096 is assigned.

Branch counter operations

Within the scope of a branch counter, the following occurs:

1. Each time an AGO or AIF branch is executed, the assembler checks the branch

counter for zero or a negative value.

2. If the count is not zero or negative, it is decremented by one.

3. If the count is zero or negative, the assembler takes one of two actions:

a. If it is processing instructions in open code, the assembler processes the

remainder of the instructions in the source module as comments. Errors

discovered in these instructions during previous passes are flagged.

b. If it is processing instructions inside a macro definition, the assembler

terminates the expansion of that macro definition and processes the next

sequential instruction after the calling macro instruction. If the macro

definition is called by an outer macro instruction, the assembler processes

the next sequential prototype instruction after the call; that is, it continues

processing at the next outer level of nested macros.

The assembler halves the ACTR counter value when it encounters serious syntax

errors in conditional assembly instructions.

ANOP instruction

You can specify a sequence symbol in the name field of an ANOP instruction, and

use the symbol as a label for branching purposes.

The ANOP instruction carries out no operation itself, but you can use it to allow

conditional assembly to resume assembly or conditional generation at an

instruction that does not have a sequence symbol in its name field. For example, if

you wanted to branch to a SETA, SETB, or SETC assignment instruction, which

requires a variable symbol in the name field, you can insert a labeled ANOP

instruction immediately before the assignment instruction. By branching to the

ANOP instruction with an AIF or AGO instruction, you are, in effect, branching to

the assignment instruction.

Chapter 9. How to write conditional assembly instructions

401

►► sequence_symbol ANOP

►◄

sequence_symbol

Is a sequence symbol.

No operation is carried out by an ANOP instruction. Instead, if a branch is taken

to the ANOP instruction, the assembler processes the next sequential instruction.

Example:

MACRO

&NAME

MOVE

&T,&F

LCLC

&TYPE

AIF

(T’&T EQ ’F’).FTYPE

Statement 1

&TYPE

SETC

’E’

Statement 2

.FTYPE

ANOP

Statement 3

&NAME

ST&TYPE

2,SAVEAREA

Statement 4

L&TYPE

2,&F

ST&TYPE

2,&T

L&TYPE

2,SAVEAREA

MEND

Statement 1 determines if the type attribute of the first macro instruction operand

is the letter F. If the type attribute is not the letter F, Statement 2 is the next

statement processed by the assembler. If the type attribute is the letter F, Statement

4 should be processed next. However, because there is a variable symbol (&NAME) in

the name field of Statement 4, the required sequence symbol (.FTYPE) cannot be

placed in the name field. Therefore, an ANOP instruction (Statement 3) must be

placed before Statement 4.

Then, if the type attribute of the first operand is the letter F, the next statement

processed by the assembler is the statement named by sequence symbol .FTYPE.

The value of &TYPE retains its initial null character value because the SETC

instruction is not processed. Because .FTYPE names an ANOP instruction, the next

statement processed by the assembler is Statement 4, the statement following the

ANOP instruction.

402

HLASM V1R6 Language Reference

Chapter 10. MHELP instruction

The MHELP instruction controls a set of trace and dump facilities. MHELP

statements can occur anywhere in open code or in macro definitions. MHELP

options remain in effect until superseded by another MHELP statement.

MHELP options

Options are selected by an absolute expression in the MHELP operand field.

►►

MHELP options

►◄

sequence_symbol

Is a sequence symbol.

options

Is the sum of the binary or decimal options. Here is a description of these

options:

MHELP B'1' or MHELP 1, Macro Call Trace:

This option provides a one-line trace listing for each macro call, giving the

name of the called macro, its nested depth, and its &SYSNDX value. The

trace is provided only upon entry into the macro. No trace is provided if

error conditions prevent entry into the macro.

MHELP B'10' or MHELP 2, Macro Branch Trace:

This option provides a one-line trace-listing for each AGO and AIF

conditional assembly branch within a macro. It gives the model statement

numbers of the “branched from” and the “branched to” statements, and

the name of the macro in which the branch occurs. This trace option is

suppressed for library macros.

MHELP B'100' or MHELP 4, Macro AIF Dump:

This option dumps undimensioned SET symbol values from the macro

dictionary immediately before each AIF statement that is encountered.

MHELP B'1000' or MHELP 8, Macro Exit Dump:

This option dumps undimensioned SET symbols from the macro dictionary

and records from the AINSERT buffer whenever an MEND or MEXIT

statement is encountered.

MHELP B'10000' or MHELP 16, Macro Entry Dump:

This option dumps parameter values from the macro dictionary

immediately after a macro call is processed.

MHELP B'100000' or MHELP 32, Global Suppression:

This option suppresses global SET symbols in two preceding options,

MHELP 4 and MHELP 8.

MHELP B'1000000' or MHELP 64, Macro Hex Dump:

This option, when used with the Macro AIF dump, the Macro Exit dump,

or the Macro Entry dump, dumps the parameter and SETC symbol values

403

in EBCDIC and hexadecimal formats. Only positional and keyword

parameters are dumped in hexadecimal; system parameters are dumped in

EBCDIC. The full value of SETC variables or parameters is dumped in

hexadecimal.

MHELP B'10000000' or MHELP 128, MHELP Suppression:

This option suppresses all currently active MHELP options.

MHELP Control on &SYSNDX:

The maximum value of the &SYSNDX system variable can be controlled by

the MHELP instruction. The limit is set by specifying a number in the

operand of the MHELP instruction that is not one of the MHELP codes

defined above, and is in the following number ranges:

256 to 65535

v Most numbers in the range 65792 to 9999999. Refer to “MHELP operand

mapping” for details.

When the &SYSNDX limit is reached, message ASMA013S ACTR counter

exceeded is issued, and the assembler in effect ignores all further macro

calls.

MHELP operand mapping

The MHELP operand field is mapped into a fullword. The predefined MHELP

codes correspond to the fourth byte of this fullword, while the &SYSNDX limit is

controlled by setting any bit in the third byte to 1. If all bits in the third byte are 0,

then the &SYSNDX limit is not set.

The bit settings for bytes 3 and 4 are shown in Table 62.

Table 62. &SYSNDX Control Bits

Byte

Description

Byte 3 - &SYSNDX control

Bit 0 = 1. Value=32768. Limit &SYSNDX to

32768.

Bit 1 = 1. Value=16384. Limit &SYSNDX to

16384.

..1

Bit 2 = 1. Value=8192. Limit &SYSNDX to 8192.

...1

Bit 3 = 1. Value=4096. Limit &SYSNDX to 4096.

.... 1...

Bit 4 = 1. Value=2048. Limit &SYSNDX to 2048.

.... .1..

Bit 5 = 1. Value=1024. Limit &SYSNDX to 1024.

.... ..1.

Bit 6 = 1. Value=512. Limit &SYSNDX to 512.

.... ...1

Bit 7 = 1. Value=256. Limit &SYSNDX to 256.

404

HLASM V1R6 Language Reference

Table 62. &SYSNDX Control Bits (continued)

Byte

Description

Byte 4

Bit 0 = 1. Value=128. MHELP Suppression.

Bit 1 = 1. Value=64. Macro Hex Dump.

..1

Bit 2 = 1. Value=32. Global Suppression.

...1

Bit 3 = 1. Value=16. Macro Entry Dump.

.... 1...

Bit 4 = 1. Value=8. Macro Exit Dump.

.... .1..

Bit 5 = 1. Value=4. Macro AIF Dump.

.... ..1.

Bit 6 = 1. Value=2. Macro Branch Trace.

.... ...1

Bit 7 = 1. Value=1. Macro Call Trace.

Note: You can use any combination of bit settings in any byte of the MHELP

fullword to set the limit, provided at least one bit in byte 3 is set. This explains

why not all values 65792 - 9999999 can be used to set the limit. For example, the

number 131123 does not set the &SYSNDX limit because none of the bits in byte 3

are set to 1.

Examples:

MHELP 256

Limit &SYSNDX to 256

MHELP 1

Trace macro calls

MHELP 65536

No effect. No bits in bytes 3,4

MHELP 65792

Limit &SYSNDX to 65792

See Figure 53 on page 406 for more examples.

Combining options

More than one MHELP option, including the limit for &SYSNDX, can be specified

at the same time by combining the option codes in one MHELP operand. For

example, call and branch traces can be invoked by:

MHELP B’11’

MHELP 2+1

MHELP 3

Substitution by variable symbols can also be used.

Chapter 10. MHELP instruction

405

┌────────────────────────┬───────────────────────────────────┬───────────────────────────────────┐

│ MHELP Instruction

│

MHELP Operand

│

MHELP Effect

│

├────────────────────────┼──────────┬────────────────────────┤

│

│ Decimal

│

Hexadecimal

│

├──────┬─────────┬───────┤

│

│ &SYSNDX │ MHELP │

│

├────────────────────────┼──────────┼──────┼─────────┼───────┼───────────────────────────────────┤

│ MHELP 4869

│

4869 │ 0000 │

│

│ Macro call trace and AIF dump;

│

│ &SYSNDX limited to 4869

│

│ MHELP 65536

│

65536 │ 0001 │

│

│ No effect

│

│ MHELP 16777232

│ 16777232 │ 0010 │

│

│ Macro entry dump

│

│ MHELP 28678

│

28678 │ 0000 │

│

│ Macro branch trace and AIF dump;

│

│ &SYSNDX limited to 28678

│

│ MHELP 256+1

│

257 │ 0000 │

│

│ Macro call trace;

│

│ &SYSNDX limited to 257

│

│ MHELP B’11’

│

3 │ 0000 │

│

│ Macro call trace, and

│

│ macro branch trace

│

└────────────────────────┴──────────┴──────┴─────────┴───────┴───────────────────────────────────┘

Figure 53. MHELP control on &SYSNDX

406

HLASM V1R6 Language Reference

Appendix A. Assembler instructions

Table 63 summarizes the basic formats of assembler instructions, and Table 64 on

page 410 summarizes assembler statements.

Table 63. Assembler instructions

Operation

Entry

Name Entry

Operand Entry

ACONTROL⁵

A sequence symbol or space

One or more operands, separated by

commas

ACTR

A sequence symbol or space

An arithmetic SETA expression

ADATA⁵

A sequence symbol or space

One-to-four decimal, self-defining terms,

and one character string, separated by

commas.

AEJECT²

A sequence symbol or space

Taken as a remark

AGO

A sequence symbol or space

A sequence symbol

AIF

A sequence symbol or space

A logical expression enclosed in

parentheses, immediately followed by a

sequence symbol

AINSERT⁵

A sequence symbol or space

A character string, followed by FRONT

or BACK

AMODE

Any symbol or space

24, 31, 64, ANY, or ANY31

ALIAS⁵

A symbol

A character string or a hexadecimal

string

ANOP

A sequence symbol or space

Taken as a remark

AREAD²

Any SETC symbol

NOPRINT, NOSTMT, CLOCKB,

CLOCKD, or spaces

ASPACE

A sequence symbol or space

An absolute expression

CATTR (z/OS

A valid program object external

One or more attributes

and CMS)

class name

CCW⁴

Any symbol or space

Four operands, separated by commas

CCW0⁴

Any symbol or space

Four operands, separated by commas

CCW1⁴

Any symbol or space

Four operands, separated by commas

CEJECT⁵

A sequence symbol or space

An absolute expression or space

CNOP⁴

Any symbol or space

Two absolute expressions, separated by

a comma

COM

Any symbol or space

Taken as a remark

COPY⁵

A sequence symbol or space

An ordinary symbol, or, for open code

statements, a variable symbol

CSECT

Any symbol or space

Taken as a remark

CXD⁴

Any symbol or space

Taken as a remark

DC⁴

Any symbol or space

One or more operands, separated by

commas

DROP

A sequence symbol or space

One or more absolute expressions and

symbols, separated by commas, or space

407

Table 63. Assembler instructions (continued)

Operation

Entry

Name Entry

Operand Entry

DS⁴

Any symbol or space

One or more operands, separated by

commas

DSECT

A symbol or space

Taken as a remark

DXD⁵

A symbol

One or more operands, separated by

commas

EJECT⁵

A sequence symbol or space

Taken as a remark

END

A sequence symbol or space

A relocatable expression or space

ENTRY⁵

A sequence symbol or space

One or more relocatable symbols,

separated by commas

EQU⁴

A variable symbol or an ordinary

One to five operands, separated by

symbol

commas

EXITCTL⁵

A sequence symbol or space

A character-string operand followed by

one to four decimal self-defining terms,

separated by commas

EXTRN⁵

A sequence symbol or space

One or more relocatable symbols,

separated by commas

GBLA

A sequence symbol or space

One or more variable symbols that are

to be used as SET symbols, separated by

commas¹

GBLB

A sequence symbol or space

One or more variable symbols that are

to be used as SET symbols, separated by

commas¹

GBLC

A sequence symbol or space

One or more variable symbols that are

to be used as SET symbols, separated by

commas¹

ICTL

Space

One to three decimal self-defining terms,

separated by commas

ISEQ⁵

A sequence symbol or space

Two decimal self-defining terms,

separated by a comma, or space

LCLA

A sequence symbol or space

One or more variable symbols that are

to be used as SET symbols, separated by

commas¹

LCLB

A sequence symbol or space

One or more variable symbols that are

to be used as SET symbols, separated by

commas¹

LCLC

A sequence symbol or space

One or more variable symbols separated

by commas¹

LOCTR

A variable or ordinary symbol

Space

LTORG

Any symbol or space

Taken as a remark

2,5

MACRO

Space

Taken as a remark

MEND^2,5

A sequence symbol or space

Taken as a remark

MEXIT^2,5

A sequence symbol or space

Taken as a remark

MHELP

A sequence symbol or space

Absolute expression, binary, or decimal

options

408

HLASM V1R6 Language Reference

Table 63. Assembler instructions (continued)

Operation

Entry

Name Entry

Operand Entry

MNOTE

A sequence symbol or space

A severity code, followed by a comma,

followed by a character string enclosed

in apostrophes. Double-byte characters

are permitted if the DBCS assembler

option is specified.

OPSYN

An ordinary symbol

A machine instruction mnemonic

or an operation code defined by

a previous macro definition or

OPSYN instruction

An operation code mnemonic

Space

ORG

A sequence symbol or space

A relocatable expression or space

POP⁵

A sequence symbol or space

One or more operands, separated by

commas

PRINT⁵

A sequence symbol or space

One or more operands, separated by

commas

PUNCH⁵

A sequence symbol or space

A 1-to-80-character string enclosed in

apostrophes. Double-byte characters are

permitted if the DBCS assembler option

is specified.

PUSH⁵

A sequence symbol or space

One or more operands, separated by

commas

REPRO⁵

A sequence symbol or space

Taken as a remark

RMODE

Any symbol or space

24, 31, 64, or ANY

RSECT

Any symbol or space

Taken as a remark

SETA

A SETA symbol

An arithmetic expression

SETAF

A SETA symbol

An external function module, and the

arithmetic expressions it requires,

separated by commas

SETB

A SETB symbol

A 0 or a 1, or a logical expression

enclosed in parentheses

SETC

A SETC symbol

A type attribute, a character expression,

a substring notation, or a concatenation

of character expressions and substring

notations. Double-byte characters are

permitted if the DBCS assembler option

is specified.

SETCF

A SETC symbol

An external function module, and the

character expressions it requires,

separated by commas

SPACE⁵

A sequence symbol or space

An absolute expression

START

Any symbol or space

An absolute expression or space

TITLE^3,5

A 1-to-8-character string, a

A 1-to-100-character string enclosed in

variable symbol, a combination of

apostrophes. Double-byte characters are

character string or variable

permitted if the DBCS assembler option

symbol, a sequence symbol, or

is specified.

space

Appendix A. Assembler instructions

409

Table 63. Assembler instructions (continued)

Operation

Entry

Name Entry

Operand Entry

USING

A symbol or space

Either a single absolute or relocatable

expression or a pair of absolute or

relocatable expressions enclosed in

parentheses and followed by 1 to 16

absolute expressions, separated by

commas, or followed by a relocatable

expression

WXTRN⁵

A sequence symbol or space

One or more relocatable symbols,

separated by commas

XATTR⁵

An external symbol

One or more operands, separated by

(z/OS and

commas

CMS)

Notes:

1. SET symbols can be defined as subscripted SET symbols.

2. Can only be used as part of a macro definition.

3. See “TITLE instruction” on page 219 for a description of the name entry.

4. These instructions start a private section.

5. These instructions can be specified before the first executable control section.

Table 64. Assembler statements

Instruction Entry

Name Entry

Operand Entry

ModelStatements^{1 and 2}

An ordinary symbol, variable

Any combination of characters

symbol, sequence symbol, or a

(including variable symbols)

combination of variable

symbols and other characters

that is equivalent to a symbol,

or space

Prototype Statement³

A symbolic parameter or space

Zero or more operands that

are symbolic parameters

(separated by commas), and

zero or more operands

(separated by commas) of the

form symbolic parameter,

equal sign, optional standard

value

Macro Instruction

An ordinary symbol, a variable

Zero or more positional

Statement³

symbol, or a combination of

operands (separated by

variable symbols and other

commas), and zero or more

characters that is equivalent to

keyword operands (separated

a symbol, any character string,

by commas) of the form

a sequence symbol⁴ or space

keyword, equal sign, value⁵

Assembler Language

An ordinary symbol, a variable

Any combination of characters

Statement¹²

symbol, a sequence symbol, or

(including variable symbols)

a combination of variable

symbols and other characters

that is equivalent to a symbol,

or space

410

HLASM V1R6 Language Reference

Table 64. Assembler statements (continued)

Instruction Entry

Name Entry

Operand Entry

Notes:

1. Variable symbols can be used to generate assembler language mnemonic operation codes

(listed in Chapter 5, “Assembler instruction statements,” on page 99), except COPY,

ICTL, ISEQ, and REPRO. Variable symbols cannot be used in the name and operand

entries of COPY, ICTL, and ISEQ instructions, except for the COPY instruction in open

code, where a variable symbol is allowed for the operand entry.

2. No substitution is done for variables in the line following a REPRO statement.

3. Can only be used as part of a macro definition.

4. When the name field of a macro instruction contains a sequence symbol, the sequence

symbol is not passed as a name field parameter. It only has meaning as a possible

branch target for conditional assembly.

5. Variable symbols appearing in a macro instruction are replaced by their values before the

macro instruction is processed.

Appendix A. Assembler instructions

411

Appendix B. Summary of constants

Table 65 and Table 66 on page 414 summarize the types of assembler constants.

Table 65. Summary of constants (part 1 of 2)

Implicit

Length

Modifier

Constant

Type

(Bytes)

Alignment

Range

Specified By

Address

Fullword

.1 to 4¹

Any expression

Doubleword Address

Doubleword

.1 to 8¹

Any expression

Binary

As needed

Byte

.1 to 256

Binary digits

Character

As needed

Byte

.1 to 256²

Characters

ASCII Character

As needed

Byte

.1 to 256²

Characters

Unicode Character

As needed

Byte

2 to 256³

Characters

Floating Point Hex

Doubleword

.1 to 8

Decimal digits

Floating Point Hex

Doubleword

.12 to 8

Decimal digits

Floating Point Binary

Doubleword

.12 to 8

Decimal digits

Floating Point Decimal

Doubleword

Decimal digits

Floating Point Hex

Fullword

.1 to 8

Decimal digits

Floating Point Hex

Fullword

.12 to 8

Decimal digits

Floating Point Binary

Fullword

.9 to 8

Decimal digits

Floating Point Decimal

Fullword

Decimal digits

Fixed Point

Fullword

.1 to 8

Decimal digits

Doubleword Fixed

Doubleword

.1 to 8

Decimal digits

Point

Graphic (DBCS)

As needed

Byte

2 to 256³

DBCS characters

Fixed Point

Halfword

.1 to 8

Decimal digits

Length

Fullword

1 to 4

Class name or external DSECT name⁴

Floating Point Hex

Doubleword

.1 to 16

Decimal digits

Floating Point Hex

Doubleword

.12 to 16

Decimal digits

Floating Point Binary

Doubleword

.16 to 16

Decimal digits

Floating Point Decimal

Doubleword

Decimal digits

Floating Point Hex

Quadword

.1 to 16

Decimal digits

Decimal

As needed

Byte

.1 to 16

Decimal digits

Offset

Symbol naming a DXD, DSECT, or

Fullword

1 to 4

part

QY⁴

Halfword

3 only

Address

R⁴

Fullword

3, 4

Symbol

Address

One absolute or relocatable expression,

Halfword

2 only

or two absolute expressions: exp(exp)

Halfword

3 only

Address

Fullword

3, 4

Relocatable symbol

Hexadecimal

As needed

Byte

.1 to 256²

Hex digits

413

Table 65. Summary of constants (part 1 of 2) (continued)

Implicit

Length

Modifier

Constant

Type

(Bytes)

Alignment Range

Specified By

Address

Halfword

.1 to 2¹

Any expression

Decimal

As needed Byte

.1 to 16

Decimal digits

Notes:

1. Bit length specification permitted with absolute expressions only; relocatable A-type constants, 2, 3, or 4 bytes

only; relocatable Y-type constants, 2 bytes only.

2. In a DS assembler instruction, C-and-X type constants can have length specification to 65535.

3. The length modifier must be a multiple of 2, and can be up to 65534 in a DS assembler instruction.

4. GOFF only.

Table 66. Summary of constants (part 2 of 2)

No. of

Constants

Range for

Constant

Type

per Operand

Exponents

Scale

Truncation or Padding Side

Address

Multiple

Left

Binary

Multiple

Left

Character

One

Right

ASCII Character

One

Right

Unicode Character

One

Right

Floating Point Hex

Multiple

-85 to +75

0 to 13

Right¹

Floating Point Hex

Multiple

-2³¹ to 2³¹-1

0 to 13

Right¹

Floating Point Binary

Multiple

-2³¹ to 2³¹-1

N/A

Right¹

Floating Point Decimal

Multiple

-2³¹ to 2³¹-1

N/A

Floating Point Hex

Multiple

-85 to +75

0 to 5

Right¹

Floating Point Hex

Multiple

-2³¹ to 2³¹-1

0 to 5

Right¹

Floating Point Binary

Multiple

-2³¹ to 2³¹-1

N/A

Right¹

Floating Point Decimal

Multiple

-2³¹ to 2³¹-1

N/A

Fixed Point

Multiple

-85 to +75

-187 to +346

Left¹

Graphic (DBCS)

One

Right

Fixed Point

Multiple

-85 to +15

-187 to +346

Left¹

Length

Multiple

Left¹

Floating Point Hex

Multiple

-85 to +75

0 to 27

Right¹

Floating Point Hex

Multiple

-2³¹ to 2³¹-1

0 to 27

Right¹

Floating Point Binary

Multiple

-2³¹ to 2³¹-1

N/A

Right¹

Floating Point Decimal

Multiple

-2³¹ to 2³¹-1

N/A

Floating Point Hex

Multiple

-2³¹ to 2³¹-1

0 to 28

Right¹

Decimal

Multiple

Left

Offset

Multiple

Left

Address

Multiple

Left

Address

Multiple

Address

Multiple

Left

414

HLASM V1R6 Language Reference

Appendix C. Macro and conditional assembly language

summary

This appendix summarizes the macro and conditional assembly language described

in Part 3 of this publication. Table 67 indicates which macro and conditional

assembly language elements can be used in the name and operand entries of each

statement. Table 69 on page 419 summarizes the expressions that can be used in

macro instruction statements. Table 71 on page 420 summarizes the attributes that

can be used in each expression. Table 72 on page 421 summarizes the variable

symbols that can be used in each expression. Table 73 on page 422 summarizes the

system variable symbols that can be used in each expression.

Table 67. Macro language elements (part 1)

Variable Symbols

Global-scope SET Symbols²

Local SET Symbols²

Symbolic

Sequence

Statement

Parameter

SETA

SETB

SETC

SETA

SETB

SETC

Symbol

MACRO

Prototype

Name

Statement

Operand

GBLA

Operand¹¹

Operand

Operand¹¹

Name

GBLB

Operand¹¹

Operand

Operand¹¹

Name

GBLC

Operand¹¹

Operand

Operand¹¹

Name

LCLA

Operand¹¹

Operand

Operand¹¹

Name

LCLB

Operand¹¹

Operand

Operand¹¹

Name

LCLC

Operand¹¹

Operand

Name

Model

Name

Statement

Operation

Operand

SETA

Name¹²

Name

Name¹²

Name

Name¹²

Operand³

Operand

Operand⁴

Operand¹⁰

Operand

Operand⁴

Operand¹⁰

SETAF

Name¹²

Name

Name¹²

Name¹⁰,¹²

Name

Name¹²

Name¹⁰,¹²

Operand³,¹³

Operand¹³

Operand⁴,¹³

Operand¹³

Operand⁴,¹³

Operand¹³

SETB

Name¹²

Name

Name¹²

Name

Name¹²

Operand⁷

Operand

Operand⁷

Operand

Operand⁷

SETC

Name¹²

Name

Name¹²

Name

Operand

Operand⁸

Operand⁹

Operand

Operand⁸

Operand⁹

Operand

SETCF

Name¹²

Name

Name¹²

Name

Operand¹³

Operand⁸,¹³

Operand⁹,¹³

Operand¹³

Operand⁸,¹³

Operand⁹,¹³

Operand¹³

ACTR

Operand³

Operand

Operand⁴

Operand³

Operand

Operand⁴

Operand³

Name

AEJECT

AGO

Name

Operand

AIF

Operand⁷

Operand

Operand⁷

Operand

Operand⁷

Name

Operand

Name

ANOP

AREAD

Name¹²

Name

Name¹²

Name

ASPACE

Operand³

Operand

Operand⁴

Operand³

Operand

Operand⁴

Operand³

Name

417

Table 67. Macro language elements (part 1) (continued)

Variable Symbols

Global-scope SET Symbols²

Local SET Symbols²

Symbolic

Sequence

Statement

Parameter

SETA

SETB

SETC

SETA

SETB

SETC

Symbol

Name

MEXIT

MNOTE

Operand

Name

MEND

Name

Outer

Name

Macro

Operand

Name

Inner

Name

Macro

Operand

Notes:

1. Variable symbols in macro instructions are replaced by their values before processing.

2. Depending upon their values, system variable symbols with global scope can be used in the same way as global SET symbols, and

system variable symbols with local scope can be used in the same way as local SET symbols.

3. Only if value is self-defining term.

4. Converted to arithmetic 0 or 1.

5. Only in character relations.

6. Only in arithmetic relations.

7. Only in arithmetic or character relations.

8. Converted to an unsigned number.

9. Converted to character 0 or 1.

10. Only if one to ten decimal digits, not greater than 2147483647.

11. Only in created SET symbols if value of parenthesized expression is an alphabetic character followed by 0 to 61 alphanumeric

characters.

12. Only in created SET symbols (as described above) and in subscripts (see SETA statement).

13. The first operand of a SETAF or SETCF instruction must be a character (SETC) expression containing or evaluating to an eight byte

module name.

Table 68. Macro language elements (part 2)

Attributes

Type

Operation

Statement

Length

Scale

Integer

Count

Number

Defined

Code

MACRO

Prototype

Statement

GBLA

GBLB

GBLC

LCLA

LCLB

LCLC

Model

Statement

SETA

Operand

SETAF

Operand¹³

SETB

Operand⁵

Operand⁶

Operand⁵

SETC

Operand

SETCF

Operand¹³

ACTR

Operand

AEJECT

AGO

AIF

Operand⁵

Operand⁶

Operand

ANOP

AREAD

ASPACE

Operand

418

HLASM V1R6 Language Reference

Table 68. Macro language elements (part 2) (continued)

Attributes

Type

Operation

Statement

Length

Scale

Integer

Count

Number

Defined

Code

MEXIT

MNOTE

MEND

Outer

Macro

Notes:

1. Variable symbols in macro instructions are replaced by their values before processing.

2. Depending upon their values, system variable symbols with global scope can be used in the same way as global SET symbols, and

system variable symbols with local scope can be used in the same way as local SET symbols.

3. Only if value is self-defining term.

4. Converted to arithmetic 0 or 1.

5. Only in character relations.

6. Only in arithmetic relations.

7. Only in arithmetic or character relations.

8. Converted to an unsigned number.

9. Converted to character 0 or 1.

10. Only if one to ten decimal digits, not greater than 2147483647.

11. Only in created SET symbols if value of parenthesized expression is an alphabetic character followed by 0 to 61 alphanumeric

characters.

12. Only in created SET symbols (as described above) and in subscripts (see SETA statement).

13. The first operand of a SETAF or SETCF instruction must be a character (SETC) expression containing or evaluating to an eight byte

module name.

Table 69. Conditional assembly expressions

Arithmetic

Character

Logical

Expression

Expressions

Self-defining

Any combination of characters

A 0 or a 1 Absolute,

Can

terms Absolute,

(including double-byte

predefined ordinary

contain

predefined ordinary

characters, if the DBCS

symbols SETB

symbols Length, scale,

assembler option is specified)

symbols Arithmetic

integer, count, defined,

enclosed in apostrophes Any

relations Character

and number

variable symbol enclosed in

relations Arithmetic

attributes SETA and

apostrophes A concatenation of

value

SETB symbols SETC

variable symbols and other

symbols whose values

characters enclosed in

are a self-defining

apostrophes Built-in

term Symbolic

Functions A type or operation

parameters if the

code attribute

corresponding operand

reference Substrings

is a self-defining

term Built-in

Functions &SYSDATC

&SYSLIST(n) if the

corresponding operand

is a self-defining

term &SYSLIST (n,m) if

the corresponding

operand is a

self-defining

term &SYSOPT_DBCS,

&SYSOPT_RENT, and

&SYSOPT_XOBJECT

&SYSM_HSEV and

&SYSM_SEV

&SYSNDX, &SYSNEST,

and &SYSSTMT

Operations

+, - (unary and binary),

Concatenation, with a period (.),

AND, OR, NOT,

*, and /; Parentheses

or by juxtaposition; substrings

XOR Parentheses

permitted

Range of values

-2³¹ to +2³¹-1

0 through 4064 characters

0 (false) or 1 (true)

Appendix C. Macro and conditional assembly language summary

419

Table 69. Conditional assembly expressions (continued)

Arithmetic

Character

Logical

Expression

Expressions

Used in

SETA

SETC operands Character

SETB operands AIF

operands Arithmetic

relations Created SET symbols

operands Created SET

relations Created SET

symbols

symbols Subscripted

SET symbols &SYSLIST

subscripts Substring

notation Sublist notation

Built-in functions fall into the following categories:

Table 70. Built-in functions

Value Type

Functions

Arithmetic

AND, B2A, C2A, D2A, DCLEN, FIND, INDEX, NOT, OR, SLA, SLL,

SRA, SRL, X2A, XOR

Logical

AND, AND NOT, ISBIN, ISDEC, ISHEX, ISSYM, NOT, OR, OR

NOT, XOR, XOR NOT

Character

A2B, A2C, A2D, A2X, B2C, B2D, B2X, BYTE, C2B, C2D, C2X, D2B,

D2C, D2X, DCVAL, DEQUOTE, DOUBLE, LOWER, SIGNED,

UPPER, X2B, X2C, X2D

Table 71. Attributes

Can be used only if

Attribute

Notation

Can be used with:

Type Attribute is:

Can be used in:

Type

Ordinary symbols

Any value

SETC expressions

defined in open code;

symbolic parameters

Character relations

inside macro

definitions;

&SYSLIST(n),

&SYSLIST(n,m) inside

macro definitions;

SET symbols; all

system variable

symbols

Length

Ordinary symbols

Any value except M, N, O,

SETA and ordinary

defined in open code;

T, U

arithmetic

symbolic parameters

expressions

inside macro

definitions;

&SYSLIST(n), and

&SYSLIST(n,m) inside

macro definitions

Scale

Ordinary symbols

H,F,G,D,E,L,K,P, and Z

SETA and ordinary

defined in open code;

arithmetic

symbolic parameters

expressions

inside macro

definitions;

&SYSLIST(n), and

&SYSLIST(n,m) inside

macro definitions

420

HLASM V1R6 Language Reference

High Level Assembler for z/OS & z/VM & z/VSE. Language Reference (Version 1 Release 6) - page 22
