SET symbol specifications

SET symbols can be used in model statements, from which assembler language

statements are generated, and in conditional assembly instructions. The three types

of SET symbols are: SETA, SETB, and SETC. A SET symbol must be a valid

variable symbol.

The rules for creating a SET symbol are:

v The first character must be an ampersand (&)

v The second character must be an alphabetic character

v The remaining characters must be 0 to 61 alphanumeric

v Do not set the first four characters to &SYS, which is used for system variable

symbols

Examples:

&ARITHMETICVALUE439

&BOOLEAN

&EASY_TO_READ

Local SET symbols need not be declared by explicit declarations. The assembler

considers any undeclared variable symbol found in the name field of a SETx

instruction as a local SET symbol, and implicitly declares it to have the type

specified by the SETx instruction. The instruction that declares a SET symbol

determines its scope and type.

The features of SET symbols and other types of variable symbols are compared in

Table 50.

Table 50. Features of SET symbols and other types of variable symbols

SETA, SETB, Symbolic

System Variable

Features

SETC symbols Parameters

Symbols

Can be used in:

Open code

Yes

&SYS_HLASM_PTF

&SYS_HLASM_RPM

&SYSASM

&SYSDATC

&SYSDATE

&SYSJOB

&SYSM_HSEV

&SYSM_SEV

&SYSOPT_CURR_OPTABLE

&SYSOPT_DBCS

&SYSOPT_OPTABLE

&SYSOPT_RENT

&SYSOPT_XOBJECT

&SYSPARM

&SYSSTEP

&SYSSTMT

&SYSTEM_ID

Macro definitions

Yes

&SYSTIME

&SYSVER

All

Chapter 9. How to write conditional assembly instructions

321

Table 50. Features of SET symbols and other types of variable symbols (continued)

SETA, SETB,

Symbolic

System Variable

Features

SETC symbols

Parameters

Symbols

Scope:

Local

Yes

&SYSADATA_DSN

&SYSADATA_MEMBER

&SYSADATA_VOLUME

&SYSCLOCK

&SYSECT

&SYSIN_DSN

&SYSIN_MEMBER

&SYSIN_VOLUME

&SYSLIB_DSN

&SYSLIB_MEMBER

&SYSLIB_VOLUME

&SYSLIN_DSN

&SYSLIN_MEMBER

&SYSLIN_VOLUME

&SYSLIST

&SYSLOC

&SYSMAC

&SYSNDX

&SYSNEST

&SYSPRINT_DSN

&SYSPRINT_MEMBER

&SYSPRINT_VOLUME

&SYSPUNCH_DSN

&SYSPUNCH_MEMBER

&SYSPUNCH_VOLUME

&SYSSEQF

&SYSTERM_DSN

&SYSTERM_MEMBER

&SYSTERM_VOLUME

Global

Yes

&SYSASM

&SYSDATC

&SYSDATE

&SYSJOB

&SYSM_HSEV

&SYSM_SEV

&SYSOPT_CURR_OPTABLE

&SYSOPT_DBCS

&SYSOPT_OPTABLE

&SYSOPT_RENT

&SYSOPT_XOBJECT

&SYSPARM

&SYSSTEP

&SYSSTMT

&SYSTEM_ID

&SYSTIME

&SYSVER

Yes¹

Values can be

No, read only

changed within

value²

scope of symbol

322

HLASM V1R6 Language Reference

Table 50. Features of SET symbols and other types of variable symbols (continued)

SETA, SETB, Symbolic

System Variable

Features

SETC symbols Parameters

Symbols

Notes:

1. The value assigned to a SET symbol can be changed by using the SETA, SETAF, SETB,

SETC, or SETCF instruction within the declared or implied scope of the SET symbol.

2. A symbolic parameter and the system variable symbols (except for &SYSSTMT,

&SYSM_HSEV, and &SYSM_SEV) are assigned values that remain fixed throughout their

scope. Wherever a SET symbol appears in a statement, the assembler replaces the

symbol's current value with the value assigned to it.

SET symbols can be used in the name, operation, and operand fields of macro

instructions. The value thus passed through the name field symbolic parameter

into a macro definition is considered as a character string and is generated as such.

If the COMPAT(SYSLIST) assembler option is specified, the value passed through

an operand field symbolic into a macro definition is also considered a character

string and is generated as such. However, if the COMPAT(SYSLIST) assembler

option is not specified, SET symbols can be used to pass sublists into a macro

definition.

Subscripted SET symbol specification

Here is the format of a subscripted SET symbol:

►► &symbol(subscript)

►◄

&symbol

Is a variable symbol.

subscript

Is an arithmetic expression with a value greater than or equal to 1.

Example:

&ARRAY(20)

The subscript can be any arithmetic expression allowed in the operand field of a

SETA instruction (see “Arithmetic (SETA) expressions” on page 359).

The subscript refers to one of the many positions in an array of values identified

by the SET symbol.

A subscripted SET symbol can be used anywhere an unsubscripted SET symbol is

allowed. However, subscripted SET symbols must be declared as subscripted by a

previous local or global declaration instruction, or implicitly as a local subscripted

SET symbol in a SETx instruction of the desired type.

The dimension (the maximum value of the subscript) of a subscripted SET symbol

is not determined by the explicit or implicit declaration of the symbol. The

dimension specified can be exceeded in later SETx instructions. Note, however, that

increasing the dimension of a subscripted SET symbol also increases the storage

required. For example, referencing only &ARRAY(1000000) still causes the

Chapter 9. How to write conditional assembly instructions

323

preceding 999999 elements to be allocated. You can determine the maximum

subscript using the N' attribute (see “Number attribute (N')” on page 336).

The subscript can be a subscripted SET symbol.

Created SET symbols

The assembler can create SET symbols during conditional assembly processing

from other variable symbols and character strings. A SET symbol thus created has

the form &(e), where e represents one or more of these:

v Variable symbols, optionally subscripted

v Strings of alphanumeric characters

v Other created SET symbols

After substitution and concatenation, e must consist of a string of up to 62

alphanumeric characters, the first of which is alphabetic. The assembler considers

the preceding ampersand and this string as the name of a SET variable. If this

created SET symbol has the same name as an existing SET symbol, they are treated

as identical. If this created SET symbol does not have the name of any existing SET

symbol, the usual rules for assigning type and scope apply.

You can use created SET symbols wherever ordinary SET symbols are permitted,

including declarations. A created SET symbol must not match the name of a

system variable symbol, nor the name of a symbolic parameter in a macro

prototype statement. You can also nest created SET symbols in other created SET

symbols.

Consider the following example:

&ABC(1) SETC

’MKT’,’27’,’$5’

Let &(e) equal &(&ABC(&I)QUA&I).

&I &ABC(&I) Created SET Symbol Comment

MKT

&MKTQUA1

Valid

&27QUA2

Invalid: character after ’&’ not alphabetic

&$5QUA3

Valid

&QUA4

Valid

The name of a created SET symbol cannot match the name of a system variable

symbol or of a symbolic parameter in a macro definition.

The created SET symbol can be thought of as a form of indirect addressing. With

nested created SET symbols, you can perform this kind of indirect addressing to

any level.

In another sense, created SET symbols offer an associative storage facility. For

example, a symbol table of numeric attributes can be referred to by an expression

of the form &(&SYM)(&I) to yield the Ith attribute of the symbol name in &SYM. As

this example indicates, created SET symbols can be declared and used as arrays of

dimensioned variables.

Created SET symbols also enable you to achieve some of the effect of

multiple-dimensioned arrays by creating a separate name for each element of the

array. For example, a 3-dimensional array of the form &X(&I,&J,&K) might be

addressed as &(X&I.$&J.$&K), where &I, &J, and &K typically have numeric values.

Thus, &X(2,3,4) is represented by &X2$3

$4. The $ separators guarantee that

&X(2,33,55) and &X(23,35,5) are unique:

324

HLASM V1R6 Language Reference

&X(2,33,55) becomes &X2

$33$55

&X(23,35,5) becomes &X23$35

Data attributes

The data, such as instructions, constants, and areas, that you define in a source

module, can be described by its:

v Type, which distinguishes a property of a named object or macro argument, for

example, fixed-point constants from floating-point constants, or machine

instructions from macro instructions

v Length, which gives the number of bytes occupied by the object code of the

named data

v Scaling, which shows the number of positions occupied by the fractional portion

of named fixed-point, floating-point, and decimal constants in their object code

form

v Integer, which shows the number of positions occupied by the integer portion of

named fixed-point and decimal constants in their object code form

v Count, which gives the number of characters that are required to represent the

named data, such as a macro instruction operand, as a character string

v Number, which gives the number of sublist entries in a macro instruction

operand

v Defined, which determines whether a symbol has been defined prior to the point

where the attribute reference is coded

v Operation Code, which shows if an operation code, such as a macro definition

or machine instruction, is defined prior to the point where the attribute reference

is coded

These characteristics are called the attributes of the symbols naming the data. The

assembler assigns attribute values to the ordinary symbols and variable symbols

that represent the data.

Specifying attributes in conditional assembly instructions allows you to control

conditional assembly logic, which, in turn, can control the sequence and contents

of the statements generated from model statements. The specific purpose for which

you use an attribute depends on the kind of attribute being considered. Here are

the attributes and their main uses:

Table 51. Data attributes

Attribute

Purpose

Main Uses

Type

Gives a letter that identifies type of

v In tests to distinguish

data represented

between different data

types

v For value substitution

v In macros to discover

missing operands

Length

Gives number of bytes that data

v For substitution into length

occupies in storage

fields

v For computation of storage

requirements

Scaling

Refers to the position of the decimal

v For testing and regulating

point in fixed-point, floating-point, and

the position of decimal

decimal constants

points

v For substitution into a

scale modifier

Chapter 9. How to write conditional assembly instructions

325

Table 51. Data attributes (continued)

Attribute

Purpose

Main Uses

Integer

Is a function of the length and scale

v To keep track of significant

attributes of decimal, fixed-point, and

digits (integers)

floating-point constants

Count

Gives the number of characters

v For scanning and

required to represent data

decomposing character

strings

v As indexes in substring

notation

Number¹

Gives the number of sublist entries in a

v For scanning sublists

macro instruction operand sublist, or

v As a counter to test for end

the maximum subscript of a

of sublist

dimensioned SET symbol to which a

v For testing array limits

value has been assigned.

Defined

Shows whether the symbol referenced

v To avoid defining a symbol

has been defined prior to the attribute

again if the symbol

reference

referenced has been

previously defined

Operation Code

Shows whether a given operation code

v To avoid assembling a

has been defined prior to the attribute

macro or instruction if it

reference

does not exist.

Notes:

1. The number attribute of &SYSLIST(n) and &SYSLIST(n,m) is described in “&SYSLIST

System Variable Symbol” on page 276.

Attribute reference

►► attribute_notation' ordinary_symbol

►◄

variable_symbol

literal

character_string

attribute_notation'

Is the attribute whose value you want, followed by a apostrophe. Valid

attribute letters are “D”, “O”, “N”, “S”, “K”, “I”, “L”, and “T”.

ordinary_symbol

Is an ordinary symbol that represents the data that possesses the attribute. An

ordinary symbol cannot be specified with the operation code attribute.

variable_symbol

Is a variable symbol that represents the data that possesses the attribute.

literal

Is a literal that represents the data that possesses the attribute. A literal cannot

be specified with the operation code attribute or count attribute.

character_string

Is a character string that represents the operation code in the operation code

attribute.

Examples:

326

HLASM V1R6 Language Reference

T’SYMBOL

L’&VAR

K’&PARAM

O’MVC

S’=P’975.32’

The assembler substitutes the value of the attribute for the attribute reference.

Reference to the count (K'), defined (D'), number (N'), operation code (O'), and

type (T') attributes can be used only in conditional assembly instructions or within

macro definitions. The length (L'), integer (I'), and scale (S') attribute references can

be in conditional assembly instructions, machine instructions, assembler

instructions, and the operands of macro instructions.

Attributes of symbols and expressions

Table 52 shows attribute references (in the columns) and types of symbols (in the

rows). Each intersection shows whether (“Yes”) or not (“No”) you can validly

apply the attribute reference to that symbol type, or (for SET symbols) to the value

of the symbol.

Table 52. Attributes and related symbols

Operation

Symbols

Type

Length

Scale

Integer

Count

Number

Defined

Code

Specified

In open code:

Ordinary

Yes

symbols

System variable

Yes

symbols with

global scope

Literals in

Yes

macro

instruction

operands

In macro

definitions:

Ordinary

Yes

symbols

Symbolic

Yes

parameters

System variable

symbols:

&SYSLIST

Yes

All others

Yes

Literals in

Yes

macro instruction

operands

Chapter 9. How to write conditional assembly instructions

327

The values of attribute references can be used in ordinary and conditional

assembly expressions, as shown in Table 53.

Table 53. Using attribute values

Operation

Symbols

Type

Length

Scale

Integer

Count Number Defined Code

Specified

In open code:

SETB¹, SETA,

SETA,

SETB¹,

SET symbols

SETC

SETB²

SETC

In ordinary

Yes

assembly:

In macro

SETB¹, SETA,

SETA,

SETB¹,

definitions:

SETC

SETB²

SETC

SET symbols

Notes:

Only in character relations.

Only in arithmetic relations.

The value of an attribute for an ordinary symbol specified in an attribute reference

comes from the item named by the symbol. The symbol must appear in the name

field of an assembler or machine instruction, or in the operand field of an EXTRN

or WXTRN instruction.

The value of an attribute reference to an expression is the value of that attribute

reference to its leftmost term.

Notes:

1. You cannot refer to the names of instructions generated by conditional

assembly substitution or macro generation until the instruction is generated.

2. If you use a symbol qualifier to qualify an ordinary symbol in an attribute

reference, the qualifier is ignored.

The value of an attribute for a variable symbol specified in an attribute reference

comes from the value substituted for the variable symbol as follows:

SET Symbols and System Variable Symbols

For SET symbols and all system variable symbols other than &SYSLIST, the

attribute values come from the current value of these symbols.

Symbolic Parameters and &SYSLIST

For symbolic parameters and the system variable symbol, &SYSLIST, the

values of the count and number attributes come from the operands of

macro instructions. The name field entry of the call is an “operand”, and is

referenced as &SYSLIST(0). The values of the type, length, scale, and

integer attributes, however, come from the values represented by the macro

instruction operands, as follows:

1. If the operand is a sublist, the entire sublist and each entry of the

sublist can possess attributes. The whole sublist has the same attributes

as those of the first suboperand in the sublist (except for the count

attribute, which can be different, and the number attribute which is

relevant only for the whole sublist).

328

HLASM V1R6 Language Reference

2. If the first character or characters of the operand (or sublist entry)

constitute an ordinary symbol, and this symbol is followed by either an

arithmetic operator (+, -, *, or /), a left parenthesis, a comma, or a

space, then the value of the attributes for the operand are the same as

for the ordinary symbol.

3. If the operand (or sublist entry) is a character string other than a sublist

or the character string described in the previous point, the type

attribute is undefined (U) and the length, scale, and integer attributes

are invalid.

Because the count (K'), number (N'), and defined (D') attribute references

are allowed only in conditional assembly instructions, their values are

available only during conditional assembly processing. They are not

available at ordinary assembly time.

The system variable symbol &SYSLIST, with a valid subscript, can be used

in an attribute reference to refer to a macro instruction operand, and, in

turn, to an ordinary symbol. Thus, any of the attribute values for macro

instruction operands and ordinary symbols in the following subsections

can also be substituted for an attribute reference containing &SYSLIST (see

“&SYSLIST System Variable Symbol” on page 276).

Type attribute (T')

The type attribute has a value of a single alphabetic character that shows the type

of data represented by:

v An ordinary symbol

v A macro instruction operand

v A SET symbol

v A literal

v A system variable symbol

The type attribute can change during an assembly. The lookahead search might

assign one attribute, whereas the symbol table at the end of the assembly might

display another.

The type attribute reference can be used in the operand field of a SETC instruction

or as one of the values used for comparison in the operand field of a SETB or AIF

instruction.

The type attribute can also be specified outside conditional assembly instructions.

Then, the type attribute value is not used for conditional assembly processing, but

is used as a value at assembly time.

The following letters are used for the type attribute of data represented by

ordinary symbols and outer macro instruction operands that are symbols that

name DC or DS statements.

A-, J-type address constant, implied length, aligned (also CXD instruction

label)

Binary constant

Character constant

Long floating-point constant, implicit length, aligned

Short floating-point constant, implicit length, aligned

Fullword fixed-point constant, implicit length, aligned

Fixed-point constant, explicit length

Halfword fixed-point constant, implicit length, aligned

Floating-point constant, explicit length

Chapter 9. How to write conditional assembly instructions

329

Extended floating-point constant, implicit length, aligned

Packed decimal constant

Q-type address constant, implicit length, aligned

A-, S-, Q-, J-, R-, V-, or Y-type address constant, explicit length

S-type address constant, implicit length, aligned

R-, V-type address constant, implicit length, aligned

Hexadecimal constant

Y-type address constant, implicit length, aligned

Zoned decimal constant

Graphic (G) constant

When a literal is specified as the name field on a macro call instruction, and if the

literal has previously been used in a machine instruction, the type attribute of the

literal is the same as for data represented by ordinary symbols or outer macro

instructions operands.

The following letters are used for the type attribute of data represented by

ordinary symbols (and outer macro instruction operands that are symbols) that

name statements other than DC or DS statements, or that appear in the operand

field of an EXTRN or WXTRN statement:

Machine instruction

Control section name

The name field on a macro instruction, when the name field is:

v A valid symbol not previously defined

v A valid literal not previously defined

Identified as an external symbol by EXTRN instruction

CCW, CCW0, or CCW1 instruction

Identified as an external symbol by WXTRN instruction

The following letter is used for the type attribute of data represented by inner and

outer macro instruction operands only:

O Omitted operand (has a value of a null character string). Such an operand

need not be a null string: a macro operand such as (,,) has a null first

suboperand.

The following attribute is used for the type attribute of the value of variable

symbols:

N The value is numeric

The following letter is used for symbols or macro instruction operands that cannot

be assigned any of the above letters:

Undefined, unknown, or unassigned

The common use of the U type attribute is to describe a valid symbol that

has not been assigned any of the type attribute values described above. If

the assembler is not able to determine what the named symbol represents,

it also assigns the U type attribute. Thus, the U type attribute can mean

undefined, or unknown, or unassigned at the time of the reference. Consider

the following macro definition:

Name

Operation

Operand

macro

MAC1 &op1,&op2

setc T’&op1

setc T’&op2

DC C’&A’

DC containing type attribute for op1

DC C’&B’

DC containing type attribute for op2

mend

330

HLASM V1R6 Language Reference

When the macro MAC1 is called in Figure 43, neither of the operands has

previously been defined, however GOOD_SYMBOL is a valid symbol name,

whereas ?BAD_SYMBOL? is not a valid symbol name. The type attribute for

both operands is U, meaning GOOD_SYMBOL is undefined, and ?BAD_SYMBOL?

is unknown.

When the macro MAC1 is called in Figure 44, GOOD_SYMBOL is a valid symbol

000000

00000 00004

8 a csect

mac1 GOOD_SYMBOL,?BAD_SYMBOL?

000000 E4

10+

DC C’U’

DC containing type attribute for op1

000001 E4

11+

DC C’U’

DC containing type attribute for op2

end

Figure 43. Undefined and unknown type attributes

name, and has been defined in the DC instruction at statement 12.

?BAD_SYMBOL? is a not valid symbol name, and the assembler issues an

error message at statement 13. The type attribute for GOOD_SYMBOL is C,

meaning that the symbol represents a character constant. The type attribute

for ?BAD_SYMBOL? is U, meaning that the type is unknown.

000000

00000 00006

8 a csect

mac1 GOOD_SYMBOL,?BAD_SYMBOL?

000000 C3

10+

DC C’C’

DC containing type attribute for op1

000001 E4

11+

DC C’U’

DC containing type attribute for op2

000002 A9

12 GOOD_SYMBOL dc cl1’z’

000003 A9

13 ?BAD_SYMBOL? dc cl1’z’

** ASMA147E Symbol too long, or first character not a letter - ?BAD_SYMBOL?

end

Figure 44. Unknown type attribute for invalid symbol

The type attribute value U, meaning undefined, unknown, or unassigned, is

assigned to the following:

v Ordinary symbols used as labels:

- For the LTORG instruction

- For the EQU instruction without a third operand

- For DC and DS statements that contain variable symbols, for example,

U1 DC &X’1’

- That are defined more than once, even though only one instance of

the label is generated due to conditional assembly statements. A

lookahead scan for attributes of a symbol might encounter more than

one occurrence of a symbol, in which case the assembler cannot yet

tell which statements will be generated. In such cases, type attribute

U is assigned. At a later time, when the symbol has been generated,

its type attribute is changed to the correct value for the type of

statement it names.

v SETC variable symbols that have a value other than a null character

string or the name of an instruction that can be referred to be a type

attribute reference

v System variable symbols except:

- &SYSDATC, &SYSM_HSEV, &SYSM_SEV, &SYSNDX, &SYSNEST,

&SYSOPT_DBCS, &SYSOPT_RENT, &SYSOPT_XOBJECT, and

&SYSSTMT, which always have a type attribute value of N

Chapter 9. How to write conditional assembly instructions

331

- Some other character type system variable symbols can be assigned

the value of a null string, in which case they have a type attribute

value of O

v Macro instruction operands that specify a literal that is not a duplicate of

a literal used in a machine instruction

v Inner macro instruction operands that are ordinary symbols

Notes:

Ordinary symbols used in the name field of an EQU instruction have the type

attribute value U. However, the third operand of an EQU instruction can be

used explicitly to assign a type attribute value to the symbol in the name field.

The type attribute of a sublist is set to the same value as the type attribute of

the first element of the sublist.

High Level Assembler and earlier assemblers treat the type attribute differently:

Because High Level Assembler allows attribute references to statements

generated through substitution, certain cases in which a type attribute of U

(undefined, unknown, or unassigned) or M (macro name field) is given

under the DOS/VSE Assembler, might give a valid type attribute under High

Level Assembler. If the value of the SETC symbol is equal to the name of an

instruction that can be referred to by the type attribute, High Level

Assembler lets you use the type attribute with a SETC symbol.

Because High Level Assembler allows attribute references to literals, certain

cases in which a type attribute of U (undefined, unknown, or unassigned) is

given by Assembler F and Assembler H for a macro operand that specifies a

literal, might give a valid type attribute under High Level Assembler. If the

literal specified in the macro instruction operand is a duplicate of a literal

specified in open code, or previously generated by conditional assembly

processing or macro generation, High Level Assembler gives a type attribute

that shows the type of data specified in the literal. The COMPAT(LITTYPE)

option causes High Level Assembler to behave like Assembler H, always

giving a type attribute of U for the T' literal.

When a type attribute reference is made outside conditional assembly

instructions, its value is treated as a character self-defining term. For

example, if the symbol A is defined in this statement:

A(*)

then the symbol A has type attribute 'A' in conditional assembly instructions.

However, if this statement is followed by

A(T’A)

Generates X’000000C1’

the generated data is the same as if you had written

A(C’A’)

Generates X’000000C1’

Length attribute (L')

The length attribute has a numeric value equal to the number of bytes occupied by

the data that is named by the symbol specified in the attribute reference.

Evaluation of length attribute references for conditional assembly statements is

handled differently from references in ordinary assembly.

In conditional assembly statements, the operand of a length attribute reference

must be either an ordinary symbol whose length attribute is either known, or can

332

HLASM V1R6 Language Reference

be determined in lookahead mode (Figure 45); or it must be a variable symbol

whose value is that of an ordinary symbol satisfying the same rules.

In ordinary assembly statements, the operand of a length attribute reference can be

a character-valued conditional assembly expression whose value is that of an

ordinary symbol.

Here is an example to clarify this distinction:

SETC

’B’

C’A&B’

Valid in ordinary assembly

LAB

AL1(L’A&B)

Valid in ordinary assembly

SETA

L’A&B

Invalid in conditional assembly

&T1

SETB

(L’A&B EQ 2)

Invalid in conditional assembly

&T2

SETB

(2 EQ L’A&B)

Invalid in conditional assembly

The two SETB statements receive different diagnostic messages, because the errors

are detected during different parts of the assembler's analysis of the SETB

expressions.

In conditional assembly statements, the operand of a length attribute reference

must be an ordinary or variable symbol, and not a character expression.

The length attribute can also be specified outside conditional assembly instructions.

Then, the length attribute value is not available for conditional assembly

processing, but is used as a value at assembly time.

Figure 45 is an example showing the evaluation of the length attribute for an

assembler instruction in statement 1 and for a conditional assembly instruction in

statement 8.

000000

E740

1 CSYM DC

CL(L’ZLOOKAHEAD)’X’ Length resolved later

2 &LEN SETA

L’CSYM

** ASMA042E

Length

attribute of symbol is unavailable; default=1

C’&LEN ’ REAL LENGTH NOT AVAILABLE

000002 F140

C’1 ’

REAL LENGTH NOT AVAILABLE

4 &TYP SETC T’CSYM

C’&TYP ’ TYPE IS KNOWN

000004 C340

C’C ’

TYPE IS KNOWN

6 &DEF SETA D’CSYM

C’&DEF ’ SYMBOL IS DEFINED

000006 F140

C’1 ’

SYMBOL IS DEFINED

8 &LEN SETA L’zlookahead Length resolved immediately

9 CSYM2 DC

CL(&len)’X’

000008 E740

+CSYM2 DC

CL(2)’X’

10 &LEN SETA L’CSYM2

C’&LEN ’ REAL LENGTH NOW AVAILABLE

00000A F240

C’2 ’

REAL LENGTH NOW AVAILABLE

00000C 0001

12 ZLOOKAHEAD DC

H’1’

END

Figure 45. Evaluation of length attribute references

In statement 2 the length of CSYM has not been established because the definition of

CSYM in statement 1 is not complete. The reference to the length attribute results in

a length of 1 and error message ASMA042E. However, statement 5 shows that the

type attribute is assigned, and statement 7 shows that the defined attribute is

Chapter 9. How to write conditional assembly instructions

333

assigned. In comparison, the length attribute for symbol CSYM2 is available

immediately, as it was retrieved indirectly using the conditional assembly

instruction in statement 8.

During conditional assembly, an ordinary symbol used in the name field of an

EQU instruction has a length attribute value that depends on the order of the

symbol's definition and the reference to its length attribute.

v If the first operand of the EQU instruction is a self-defining term, the length

attribute value is 1.

v If the first operand of the EQU instruction is a symbol whose value and length

attribute are defined, the length attribute value is that of the symbol in the first

operand.

v If the first operand of the EQU instruction is a defined symbol and the EQU

instruction specifies a length value in the second operand, the length attribute

value is that of the second operand.

At assembly time, the symbol has the same length attribute value as the first term

of the expression in the first operand of the EQU instruction. However, the second

operand of an EQU instruction can be used to assign a length attribute value to the

symbol in the name field. This second operand cannot be a forward reference to

another EQU instruction.

Notes:

1. The length attribute reference, when used in conditional assembly processing,

can be specified only in arithmetic expressions.

2. When used in conditional assembly processing, a length attribute reference to a

symbol with the type attribute value of M, N, O, T, U, or $ is flagged. The

length attribute for the symbol has the default value of 1.

Scale attribute (S')

The scale attribute can be used only when referring to fixed-point, floating-point,

or decimal constants. The following table shows the numeric value assigned to the

scale attribute:

Constant

Types

Type of DC or DS

Value of Scale

Allowed

Attribute Assigned

Fixed-Point

H and F

Equal to the value of the scale modifier

(-187 through +346)

Floating Point

D, E, and L

Equal to the value of the scale modifier(0

through 14 — D, E)(0 through 28 — L)

Decimal

P and Z

Equal to the number of decimal digits

specified to the right of the decimal

point(0 through 31 — P)(0 through 16 —

The scale attribute can also be specified outside conditional assembly instructions.

Then, the scale attribute value is not used for conditional assembly processing, but

is used as a value at assembly time.

Notes:

1. The scale attribute reference can be used only in arithmetic expressions.

334

HLASM V1R6 Language Reference

2. When no scale attribute value can be determined, the reference is flagged and

the scale attribute is 1.

3. If the value of the SETC symbol is equal to the name of an instruction that can

validly define the scale attribute, the assembler lets you use the scale attribute

with a SETC symbol.

4. Binary floating-point constants return an attribute of 0.

5. Decimal floating-point constants return an attribute of 0.

6. The scale attribute reference can only be used in arithmetic expressions in

conditional assembly instructions, and in absolute and relocatable expressions

in assembler and machine instructions.

Integer attribute (I')

The integer attribute has a numeric value that depends on the length and scale

attribute values of the data being referred to by the attribute reference. The

formulas relating the integer attribute to the length and scale attributes are given

in Table 54.

The integer attribute can also be specified outside conditional assembly

instructions. Then, the integer attribute value is not used for conditional assembly

processing, but is used as a value at assembly time.

Notes:

1. The integer attribute reference can be used only in arithmetic expressions.

2. When no integer attribute value can be determined, the reference is flagged and

the integer attribute is 1.

3. If the value of the SETC symbol is equal to the name of an instruction that can

validly define the integer attribute, the assembler lets you use the integer

attribute with a SETC symbol.

4. Binary floating-point constants return an attribute of 0.

5. Decimal floating-point constants return an attribute of 0.

6. The integer attribute reference can only be used in arithmetic expressions in

conditional assembly instructions, and in absolute and relocatable expressions

in assembler and machine instructions.

Table 54. Relationship of integer to length and scale attributes

Formula Relating Integer to

Values of the Integer

Constant Type

Length and Scale Attributes

Examples

Attribute

Fixed-point(H and F)

I’ = 8*L’-S’-1

HALFCON DC HS6’-25.93’

I’ = 8*2-6-1

= 9

ONECON DC FS8’100.3E-2’

I’ = 8*4-8-1

= 23

when L’ ≤ 8

Floating-point

I’ = 2*(L’-1)-S’

SHORT

DC ES2’46.415’

I’ = 2*(4-1)-2

(D, E, and L)

= 4

LONG

DC DS5’-3.729’

I’ = 2*(8-1)-5

= 9

when L’ > 8

I’ = 2*(L’-1)-S’-2

EXTEND DC LS10’5.312’

I’ = 2*(16-1)-10-2

L-type only

= 18

Chapter 9. How to write conditional assembly instructions

335

Table 54. Relationship of integer to length and scale attributes (continued)

Formula Relating Integer to

Values of the Integer

Constant Type

Length and Scale Attributes

Examples

Attribute

Decimal¹

I’ = 2*L’-S’-1

PACK

DC P’+3.513’

I’ = 2*3-3-1

Packed (P)

= 2

I’ = L’-S’

ZONE

DC Z’3.513’

I’ = 4-3

= 1

Zoned (Z)

Note:

1. The value of the integer attribute is equal to the number of digits to the left of the assumed decimal point after

the constant is assembled, and the value of the scale attribute is equal to the number of digits to the right of the

assumed decimal point.

Count attribute (K')

The count attribute applies only to macro instruction operands, to SET symbols,

and to the system variable symbols. It has a numeric value equal to the number of

characters:

v That constitute the macro instruction operand, or

v That are required to represent as a character string the current value of the SET

symbol or the system variable symbol.

Notes:

1. The count attribute reference can be used only in arithmetic expressions.

2. The count attribute of an omitted macro instruction operand has a value of 0.

3. Doubled quotes ('') in quoted character strings count as one character. Doubled

ampersands (&&) in quoted character strings count as two characters. For more

information about character pairs see “Evaluation of character expressions” on

page 389.

4. These pairing rules mean that the length attribute of a character variable

substituted into a character constant might be different from the count attribute

of the substituted variable.

5. The count attribute differs from the Number (N') attribute, described below.

Number attribute (N')

The number attribute applies to the operands of macro instructions and

subscripted SET symbols.

When applied to a macro operand, the number attribute is a numeric value equal

to the number of sublist entries.

When applied to a subscripted SET symbol, the number attribute is equal to the

highest element to which a value has been assigned in a SETx instruction.

Consider the example in Figure 46 on page 337.

336

HLASM V1R6 Language Reference

macro

MAC1 &op1

lcla &SETSUB(100)

4 &SETSUB(5) seta 20,,,70

5 &B

seta N’&SETSUB

6 &C

seta N’&op1

DC C’Highest referenced element of SETSUB = &B’

DC C’Number of sublist entries in OP1 = &C’

mend

000000

00000 0004C

10 a

csect

MAC1 (1,(3),(4))

000000 C889878885A2A340

12+

DC C’Highest referenced element of SETSUB = 8’

000028 D5A4948285994096

13+

DC C’Number of sublist entries in OP1 = 3’

end

Figure 46. Number attribute reference

N’&op1 is equal to 3 because there are three subscripts in the macro operand in

statement 11: 1, (3), and (4).

N’&SETSUB is equal to 8 because &SETSUB(8), assigned the value 70 in statement 4, is

the highest referenced element of the &SETSUB array entries.

Notes:

1. The number attribute reference can be used only in arithmetic expressions.

2. N'&SYSLIST refers to the number of positional operands in a macro instruction,

and N'&SYSLIST(n) refers to the number of sublist entries in the n-th operand.

3. For positional macro parameters, either explicitly named or implicitly named as

&SYSLIST(n):

a. If the first character of an operand is a left parenthesis, count the number of

unquoted and unnested commas between it and the next matching right

parenthesis. That number plus one is the number attribute of the operand.

b. If there is no initial left parenthesis, the number attribute is one.

4. For all other system variable symbols, the number attribute value is always

one. This is also true for &SYSMAC. The range of the subscript for &SYSMAC

is 0 - &SYSNEST.

5. N' is always zero for unsubscripted set symbols. The number attribute (N'),

when used with a macro instruction operand, examines its list structure, not

the number of characters in the operand. (The number of characters is

determined by the count (K') attribute.)

Defined attribute (D')

The defined attribute shows whether the ordinary symbol or literal referenced has

been defined prior to the attribute reference. A symbol is defined if it has been

encountered in the operand field of an EXTRN or WXTRN statement, or in the

name field of any other statement except a TITLE statement or a macro instruction.

A literal is defined if it has been encountered in the operand field of a machine

instruction. The value of the defined attribute is an arithmetic value that can be

assigned to a SETA symbol, and is equal to 1 if the symbol has been defined, or 0

if the symbol has not been defined.

The defined attribute can reference:

v Ordinary symbols not constructed by substitution

v Macro instruction operands

Chapter 9. How to write conditional assembly instructions

337

v SETC symbols whose value is an ordinary symbol

v System variable symbols whose value is an ordinary symbol

v Literals

Here is an example of how you can use the defined attribute:

Name

Operation

Operand

AIF

(D’A).AROUND

1,4

.AROUND

ANOP

In this example, assuming there has been no previous definition of the symbol A,

the statement labeled A is assembled, since the conditional-assembly branch around

it is not taken. However, if by an AGO or AIF conditional-assembly branch the

same statement is processed again, the statement at A is not assembled:

Name

Operation

Operand

.UP

AIF

(D’A).AROUND

1,4

.AROUND

ANOP

AGO

.UP

You can save assembly time using the defined attribute which avoids lookahead

mode (see “Lookahead” on page 340 for more information). You can use the

defined attribute in your program to prevent the assembler from making this

time-consuming forward scan. This attribute reference can be used in the operand

field of a SETA instruction or as one of the values in the operand field of a SETB

or AIF instruction.

Notes:

1. D' applied to a SETA or SETB symbol, or to a system variable symbol, is an

error.

2. D' applied to a SETC symbol or symbolic parameter is valid only if the value of

the SETC symbol or symbolic parameter is a valid ordinary symbol or literal.

Operation code attribute (O')

The operation code attribute shows whether a given operation code has been

defined prior to the attribute reference. The operation code can be represented by a

character string or by a variable symbol containing a character string. The variable

must be set using a SETC assembler instruction prior to being referenced by the

operation code (O') attribute.

The operation code attribute has a value of a single alphabetic character that shows

the type of operation represented.

This attribute reference can be used in the operand field of the SETC instruction or

as one of the values used in the operand field of a SETB or AIF instruction.

The following letters are used for the value of the operation code attribute:

Assembler operation code

Extended mnemonic operation code

Macro definition

Machine operation code

Macro definition found in library

338

HLASM V1R6 Language Reference

Undefined, unknown, unassigned, or deleted operation code

Notes:

1. The operation code (O') attribute can only be used in a conditional assembly

statement.

2. The assembler does not enter lookahead mode to resolve the operation code

type, therefore only operation codes defined at the time the attribute is

referenced return an operation code type value other than U.

3. When the operation code is not an assembler instruction or a machine

instruction, and the operation code is not a previously defined macro, then all

libraries in the library data set definition list are searched. This might have an

adverse impact on the performance of the assembly, depending on the number

of libraries assigned in the assembly job and the number of times the operation

code attribute is used.

Examples:

Name

Operation

Operand

SETC

O’MVC

&A contains the letter O, because MVC is a machine operation code:

Name

Operation

Operand

SETC

’DROP’

SETC

O’&A

&B contains the letter A, because DROP is an assembler operation code.

The following example checks to see if the macro MAC1 is defined. If not, the

MAC1 macro instruction is bypassed. This prevents the assembly from failing

when the macro is not available.

Name

Operation

Operand

&CHECKIT SETC

O’MAC1

AIF

(’&CHECKIT’ EQ ’U’).NOMAC

MAC1

.NOMAC

ANOP

Redefined Operation Codes: If an operation code is redefined using the OPSYN

instruction then the value returned by a subsequent operation code attribute

reference represents the new operation code. If the operation code is deleted using

the OPSYN instruction then the value returned is U.

Sequence symbols

You can use a sequence symbol in the name field of a statement to branch to that

statement during conditional assembly processing, thus altering the sequence in

which the assembler processes your conditional assembly and macro instructions.

You can select the model statements from which the assembler generates assembler

language statements for processing at assembly time.

A sequence symbol consists of a period (.) followed by an alphabetic character,

followed by 0 to 61 alphanumeric characters.

Examples:

Chapter 9. How to write conditional assembly instructions

339

.BRANCHING_LABEL#1

Sequence symbols can be specified in the name field of assembler language

statements and model statements; however, sequence symbols must not be used as

name entries in the following assembler instructions:

ALIAS

EQU

OPSYN

SETC

AREAD

ICTL

SETA

SETAF

CATTR

LOCTR

SETB

SETCF

DXD

Also, sequence symbols cannot be used as name entries in macro prototype

instructions, or in any instruction that already contains an ordinary or a variable

symbol in the name field.

Sequence symbols can be specified in the operand field of an AIF or AGO

instruction to branch to a statement with the same sequence symbol as a label.

Scope: A sequence symbol has a local scope. Thus, if a sequence symbol is used in

an AIF or an AGO instruction, the sequence symbol must be defined as a

label in the same part of the program in which the AIF or AGO instruction

appears; that is, in the same macro definition or in open code.

Symbolic Parameters:

If a sequence symbol appears in the name field of a macro instruction, and

the corresponding prototype statement contains a symbolic parameter in

the name field, the sequence symbol does not replace the symbolic

parameter wherever it is used in the macro definition. The value of the

symbolic parameter is a null character string.

Example:

MACRO

&NAME

MOVE

&TO,&FROM

Statement 1

&NAME

2,SAVEAREA

Statement 2

2,&FROM

2,&TO

2,SAVEAREA

MEND

------------------------------------------------------------------

.SYM

MOVE

FIELDA,FIELDB

Statement 3

------------------------------------------------------------------

2,SAVEAREA

Statement 4

2,FIELDB

2,FIELDA

2,SAVEAREA

The symbolic parameter &NAME is used in the name field of the prototype

statement (Statement 1) and the first model statement (Statement 2). In the

macro instruction (Statement 3), a sequence symbol (.SYM) corresponds to

the symbolic parameter &NAME. &NAME is not replaced by .SYM and, therefore,

the generated statement (Statement 4) does not contain an entry in the

name field.

Lookahead

Symbol attributes are established in either definition mode or lookahead mode.

340

HLASM V1R6 Language Reference

High Level Assembler for z/OS & z/VM & z/VSE. Language Reference (Version 1 Release 6) - page 18
