SPECIFICATIONS
602
Fuel tank volume
The fuel tank's refillable volume is shown in the
table below.
All models
Liter (approx.)
54
US gallons (approx.)
14.2
Related information
•
•
Air conditioning specifications
The climate system in the vehicle uses a freon-
free R134a refrigerant. For information regarding
the refrigerant, refer to the decal located on the
inside of the hood.
The prescribed grades and volumes for fluids and
lubricants in the air conditioning system are
shown in the tables below.
A/C Decal
Decal for R134a
Refrigerant
Vehicles with R134a refrigerant
Weight
Prescribed grade
540 g (1.19 lbs)
R134a
WARNING
The air conditioning system contains the
refrigerant R134a under pressure. Service
and repairs to the system should only be done
by an authorized workshop.
Compressor oil
Volume
Prescribed grade
130 ml (4.40 fl. oz.)
VC100yf
Evaporator
The A/C system evaporator must never be
repaired or replaced with a previously used
evaporator. The new evaporator must be certi-
fied and labeled in accordance with SAE
J2842.
Related information
•
